FKI GL MAXI Series Troubleshooting guide

User and service manual
Grill plate
GL MAXI-series
Version 2.1 –Marts 2021

2
1. Table of content
1. Table of content ..........................................................................2
2. Introduction................................................................................3
3. In general...................................................................................3
3.1. Manufacturer...........................................................................................................3
3.2. Name of the grill plate.............................................................................................3
3.3. Machine tag ............................................................................................................4
4. Overview and utilization ................................................................4
4.1. General description.................................................................................................4
4.2. Purpose of the contact grill and intended utilization................................................4
4.3. Technical specifications and consumption..............................................................4
5. Operation...................................................................................5
6. Installation .................................................................................5
6.1. Installation...............................................................................................................5
6.2. Connection..............................................................................................................5
7. Maintenance and repair.................................................................5
7.1. Cleaning..................................................................................................................5
7.2. Repair .....................................................................................................................6
7.2.1. Spare parts .........................................................................................................6
8. End of use..................................................................................7
8.1. Destruction..............................................................................................................7
9. Appendix ...................................................................................7
9.1. Signs, symbols and pictograms...............................................................................7
9.2. EU –Declaration of conformity ...............................................................................8
9.3. Wiring diagrams......................................................................................................9

3
2. Introduction
Original manual
This manual is a translation to FKI Fast Food Teknik original user’s manual for
grill plate type GL 6060 MAXI og GL 9060 MAXI.
Purpose
The purpose of this manual is to ensure proper installation, use, handling and
maintenance of the grill plate.
Accessibility
The instruction manual must be kept in a –to the staff –well known place
which is easy to access for electricians and personnel who maintain the contact
grill.
Knowledge
The employer (owner of the grill plate) is obligated to ensure that people who
operates, serve and maintain the contact grill, has read the instruction manual
or as minimum are familiar with the parts which are relevant to their job.
Furthermore, everybody who operate, serve and maintain the grill plate is obli-
gated to seek information in this manual.
3. In general
3.1. Manufacturer
The grill plate is manufactured by
Company: FKI Fast Food Teknik A/S
Address: Byghøjvej 5, Verninge
DK-5690 Tommerup
3.2. Name of the grill plate
The full name of the grill plate is GL xx60 MAXI, where xx stands for the size of
the grill plate.

4
3.3. Machine tag
The machine tag is placed on the rear.
4. Overview and utilization
4.1. General description
The grill plate is made entirely of stainless steel with rounded edges for easy cleaning. The
machine consists of a cabinet with increased all-welded steel plate, 2 or 3 heating zones
with thermostat control (50-300°C) and are provided with grease drawer for the collection
of excess frying fat.
4.2. Purpose of the contact grill and intended utilization
The grill plate is suited for cooking/frying of all products made for cooking on a frying pan.
4.3. Technical specifications and consumption
Overall dimensions
Type
With x depth x hight
Weight in
kg
GL 6060 MAXI
605 x 605 x 415 mm
55
GL 9060 MAXI
905 x 605 x 415 mm
75
Elektricity
Connection power: 3 x 400 V AC (Norway: 3 x 230V)
Connection frequency: 50/60 Hz
Consumption of current and power
Type
Current [Amp.]
Power [kW]
GL 6060 MAXI 400V
17,3
8,0
GL 6060 MAXI 400V
13,0
6,0
GL 6060 MAXI 230V
22,6
6,0
GL 9060 MAXI 400V
13,0
9,0
GL 9060 MAXI 230V
22,6
9,0

5
5. Operation
The grill plate is equipped with 2 or 3 heating zones controlled by using a ther-
mostat device. Each zone is switched on by turning the control knob and set
the desired temperature on the scale with the mark on the front.
During heating, and when the heating elements are active the yellow glow
lamp next to the temperature regulation will light up.
We recommend checking the temperature of the frying surface using a ther-
mometer, since the calibration of the thermostat may not exactly reflect the
scale on the knob.
The grill plate is shut off by turning the temperature knob to zero.
6. Installation
6.1. Installation
The grill plate is designed for installation on a table or desk. The frying pan is equipped
with adjustable legs/feet.
6.2. Connection
The connection cable shall be fitted with an appropriate 400V plug (not part of the delivery)
and connected to a wall switch
Connection without plug is only allowed after a safety switch.
A certified electrician shall make connection.
7. Maintenance and repair
7.1. Cleaning
The grill plate should be cleaned several times a day for excess drippings. The grill plate is
fitted with grease drain. Scrape excess fat to drain hole, where it flows into a collection
drawer. The drawer is emptied and cleaned as needed.
Once daily clean the cooking plate carefully on the working surface, and all exterior sur-
faces wiped off with a damp cloth.
Cleaning should be carried out when cooking plate is more than 50°C warm.

6
7.2. Repair
Authorized service personnel with knowledge of electrical appliances should always per-
form Repairs.
7.2.1. Spare parts
Pos
Part number
Pcs.
Description
1
82-03510
4
Leg adjustable
2
83-07507
2 (3)
Glow lamp Ø9 mm yellow400V
3
83-06577
2 (3)
Thermostat 50-300°C 3-pole
4
83-06587
2 (3)
Knob for thermostat 50-300°C
5
83-08756
1 (2)
Fat drawer
6a
83-08920
2 (3)
Heat element 3,0 kW 400V
6b
83-08921
2 (3)
Heat element 3,0 kW 230V (Norge)
6c
83-10362
2
Heat element 4,0 kW 400V
Number in parenthesis is for GL 9060 MAXI

7
8. End of use
8.1. Destruction
The grill plate is marked with the above recycling symbol (EC directive 2002/96/EC) and
must be disposed in accordance with your country’s order.
This means that when the product becomes obsolete, you should dispose it after the local
municipality’s rule, e.g. in unsorted waste stream
9. Appendix
9.1. Signs, symbols and pictograms
The contact grill is marked with the following symbols and pictograms:
Recycling symbol (see 8.1)

8
9.2. EU –Declaration of conformity

9
Wiring diagrams

10

11

12
