FläktGroup GMPM Instruction Manual

PUR (A, B, C, D)
SLIDE IN ROTOR CASSETTE
CENTRIFLOW 3D PLUG FAN WITH PERMANENT
MAGNET AND ASYNCHRONOUS MOTOR
CONTENT PAGE
1. Importent information........................................................................ 2
2. Saferty notes......................................................................................... 2
3. Technical description ........................................................................ 3
4. Transport .................................................................................................4
5. Mounting instructions........................................................................ 5
6. Commissioning .................................................................................... 6
7. Maingenance......................................................................................... 8
8. Faults..................................................................................................... 10
9. Spare parts ......................................................................................10
10. Distances ............................................................................................. 10
11. Air flow measurement..................................................................10
12. Disposal of the product................................................................10
13. Declaration of conformity.............................................................11
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice
CENTRIFLOW 3D PLUG FAN GMPM, GMEB
INSTALLATION AND MAINTENANCE

IMPORTANT INFORMATION, SAFETY NOTES
1. IMPORTANT INFORMATION
FläktGroup fans comply with the requirements for health and
safety of the EC Machinery Directive.
All fans leave the factory after being subjected to testing.
These instructions are intended for use by professional service
staff. The installation, commissioning and operation of the fans
must be carried out by professional staff who are familiar with
the safety regulations.
Tools and protective equipment necessary for preventing acci-
dents from occurring while installing and operating the fan must
be used/worn in accordance with the local safety regulations.
All personnel involved with the product must carefully study this
operating manual and diligently comply with all orders and in-
structions.
FläktGroup does not accept responsibility for any damage
that can be attributed to non-observance of these instructions.
The warranty issued by the manufacturer will be forfeited if any
changes to the product are made without the manufacturer’s
consent.
2. SAFETY NOTES
This symbol is designed to point out all safety and
danger related information regarding danger on the
operating personnel’s lives and health.
Centriflow 3D GMPM, GMEB - Installation and Maintenance
2
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

3. TECHNICAL DESCRIPTION
The fan is used to generate a desired air volume at a given
pressure rise that corresponds to the pressure losses in the duct
system to which the fan is connected, and internal losses inside
of the Air Handling Unit.
The plug fan is intended to be used inside of the Air Handling Unit.
3.1 DESIGN
TECHNICAL DESCRIPTION
3.2 OPERATING CONDITIONS
The standard operating temperature range of the fan is –20° C -
+40° C. The maximum permissible ambient temperature of the
motors is +40° C.
If they are operated in conditions where the ambient temperature
is higher, the rated output will as a rule have to be reduced. See
the instructions of the motor manufacturer.
The fans are designed to be used as parts of equip-
ment. They are not ready for use as a stand-alone
product and the standard version does not have
protection against body contact, the appropriate
protective measures are to be taken according to
EN 292/294.
Only operate the fan up to the maximum permissible speed given
in the information on the fan rating plate.
3.3 MOTORS
Both AC- and PM-motors can be used with GMPM and GMEB plug
fans.
AC-motors are IEC-standard IE2 or IE3 motors. The motors are
equipped with a thermistor and they are designed for a frequen-
cy converter use. Admissible environmental temperature: from
–15°C up to +40° C.
PM-motors are high efficiency IE4 permanent magnet motors.
They shall be used together with a frequency converter and can-
not be connected directly to the mains. Admissible environmental
temperature: from –15° C up to + 40° C.
3.4. FREQUENCY CONVERTERS
All fans used in an Air Handling Unit in the European Union area
shall be equipped with a speed controller in accordance with the
Regulation 1253/2014.
1. Front plate
2. Inlet cone
3. Impeller and hub
4. Motor
5. Base frame
6. Motor bracket
7. Front plate support (fan size 056 and bigger)
8. Vibration dampers (optional)
9. Built-on frequency converter (optional)
10. Frequency converter mounting plate (optional)
1
1
2
2
9
9
7
7
5
5
8
8
6
6
10
4
4
3
3
Sizes ≤071.
Sizes ≥080.
Centriflow 3D GMPM, GMEB - Installation and Maintenance
3
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

TRANSPORT
4 TRANSPORT
4.1 TRANSPORT INSPECTION
Check the fan immediately after you receive it and make sure that
it has not been damaged during transport. If you discover any
damage, get in touch with the transportation company without
delay. Briefly rotate the fan impeller to see that it rotates easily.
Check the information on the fan rating plate.
Proper procedures must be followed when transporting the product!
Faulty conditions in transporting may result in serious damage on
the product
4.2 TRANSPORT SAFETY
The transport material is to be selected according to the packag-
ing and the weight of the product. Loading must be carried out
as instructed.
4.3 INTERMEDIATE STORAGE
If the fan is to be stored before or in between uses, the following
needs to be taken in account:
– Original packaging is to be used. If the storage conditions re-
quire it, additional protection may be added
– The storage environment must be dry, dust-free and not have
a high level of humidity (<70%)
– Storage temperature must be in between –25° C and +40° C
Before commissioning, the respective instructions must be
studied thoroughly.
4.4 LIFTING OF THE FAN
4.4.1 SIZES ≤071
The fan is to be lifted with three lifting chains/beams (one
attached to the front plate and two to the rear end of the fan).
There are three alternative places to attach the rear lifting hooks,
which are to be used depending on the fan combination.
Wherever possible, use holes on the motor bracket as shown in
the picture below.
In case of a built-on frequency converter, if there is no access to
the hole on the motor bracket behind the frequency converter
assembly bracket, one of the rear chains/beams could be
attached to the hole on the frequency converter assembly bracket
(up to fan size 045).
With bigger fans (or if there are no holes on the motor bracket)
holes on the base frame are to be used. In this case it must be
taken into account not to damage the frequency converter.
Transverse beam must be used if needed.
Beware of damaging the fan while lifting. Always adjust chains/
beams long enough not to get in touch with motor, frequency
converter or impeller.
Centriflow 3D GMPM, GMEB - Installation and Maintenance
4
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

TRANSPORT, MOUNTING INSTRUCTIONS
Beware of damaging the fan while lifting. Always adjust chains/
beams long enough not to get in touch with motor, frequency con-
verter or impeller.
4.4.2 SIZES ≥080
The fan is to be lifted with four lifting chains/beams, two attached
to the front plate supports and two to the motor bracket. Lifting
points are shown in the picture below.
5 MOUNTING INSTRUCTIONS
5.1 INSTALLATION OF THE FAN
The fan is to be installed to a base frame using anti-vibration
mountings. Alternatively the base could be mounted on anti-
vibration mountings.
The base must be level and stable. The fan must only be mounted
in a horizontal plane.
5.2 BUILT-ON FREQUENCY CONVERTER
If needed, the frequency converter can be removed to the other
side of the fan with the following instructions. Otherwise please
use the cable tie (delivered with the fan) to attach the motor cable
to the motor bracket and mounting plate, see point 5.2.4.
5.2.1 Loosen the upper bolts and remove lower fixing bolts (M6) of
the frequency converter mounting plate. You might need a
10 mm wrench with the upper front bolt.
Upper bolt
Lower bolt
Centriflow 3D GMPM, GMEB - Installation and Maintenance
5
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

5.3 FITTING THE ACCESSORIES
The fan should normally be connected to the air handling unit
by means of flexible connection or other type of a gasket to
eliminate vibration transfer from fan to the AHU casing.
Providing necessary grounding for the accessories is within the
constructor’s field of responsibility.
Inlet protective screen can be fitted directly to the front frame or
outside AHU to the inlet opening.
5.4. SAFETY REGULATIONS AND CE-MARKING
The GMPM and GMEB fan is CE-marked as a Partly Completed
Machinery and must not be put into service until the final machi-
nery into which it is to be incorporated has been declared in con-
formity with provisions of the Machinery Directive 2006/42/EC.
The fan is ErP compliant. Other compliant directives are shown in
the Declaration of Conformity.
5.5 ELECTRICAL CONNECTIONS
All electrical connections must be wired by authorised person-
nel only. The necessary electrical and safety precautions must be
taken into account. If the motor is operated across a frequency
converter, the connections must be made according to the in-
structions of the frequency converter manufacturer. The motor
must be grounded.
5.6 ADDITIONAL GROUNDING OF THE MOTOR AND
THE BUILT-ON FREQUENCY CONVERTER
The built-on frequency converter can be additionally grounded to
the air handling unit or base. Attach the grounding wire (not in-
cluded in the fan delivery) securely under the lower fixing bolt of
the frequency converter (marked with a grounding symbol) and to
the air handling unit or base.
MOUNTING INSTRUCTIONS
5.2.2 Slide off the mounting plate.
5.2.3 Put the removed upper bolts on their new places on the
other side of the motor bracket. Bolts shall be loose enough
to get the mounting plate slided to its place. After that at-
tach also the earlier removed lower bolts on the other side
and tighten all bolts.
5.2.4 Attach the cable tie to the motor bracket /mounting plate.
In case of fan size 080 frequency converter assembled with
mounting plate: Remove the frequency converter first to better ac-
cess the mounting plate fixing bolts. Loosen the upper bolts and
remove the lower bolts to detach the mounting plate. Reassemble
in reverse order.
Centriflow 3D GMPM, GMEB - Installation and Maintenance
6
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

COMMISSIONING
6 COMMISSIONING
6.1 SAFETY CHECKING
• Rotate the shaft and check that the impeller can move freely.
• Make sure that there are no foreign objects in the fan or in the
ducting.
• Also check that there is no unusual noise in the fan.
• Check that the installation work has been carried out in
accordance with the relevant regulations.
• All necessary protective devices must be installed.
• The fan may only be commissioned after all proper proce-
dures have been followed and all necessary inspections have
been carried out.
6.2 TEST RUN
Briefly switch on the power supply to the motor to check whether
the fan impeller rotates in the correct direction. If the impeller is
rotating in the correct direction, the fan may be switched on.
Check that no abnormal mechanical sound and no surging occurs.
Centriflow 3D GMPM, GMEB - Installation and Maintenance
7
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

7. MAINTENANCE
7.1 WARRANTY
A precondition of the warranty is that regular maintenance has
been carried out. Defects under warranty must immediately be
notified to the manufacturer or the importer. The warranty does
not cover service work or indirect damages.
7.2 MAINTENANCE
7.2.1 BEFORE MAINTENANCE
Switch off the power supply to the fan at the safety switch and
wait until the impeller is fully stopped.
THERE IS A RISK OF ELECTRIC SHOCK ON PM-
MOTORS IF THE IMPELLER IS ROTATING.
ENSURE THAT THE IMPELLER IS SURELY STILL
BEFORE AND DURING THE MAINTENANCE WORK.
7.2.2 INSPECTION
The fan is to be inspected at least once a year.
7.2.3 CHECKING THE MOTOR BEARINGS
The motors are meant to be operated in dry or humid air at a
normal ambient temperature. The motor bearings have to be lu-
bricated in accordance with the instructions that accompany the
motor. Bearings are to be replaced in accordance with the motor
manufacturer’s instructions.
7.2.4 IMPELLER
The maximum permissible vibration level measured from the
motor bearing is 4.5mm/s RMS. The impeller can be cleaned by
using a vacuum cleaner, compressed air or by brushing. If the
impeller is coated with greasy dirt it can be washed with a deter-
gent or a solvent.
The cleaning is to be done at least once a year. Badly tarnished
impeller will result in lower efficiency of the fan and increases en-
ergy consumption.
MAINTENANCE
7.3 REPLACING THE MOTOR AND THE IMPELLER
The fan has to be disconnected and taken out from the unit be-
fore the motor can be replaced.
1. Dismantle the front plate supports (fan size 056 and bigger)
and the front plate and inlet cone (front plate and inlet cone
are permanently riveted to each other).
2. Release the impeller from the motor shaft by loosening the
clamp screw and removing the end bolt and washer.
Support
Support
Clamp screw End bolt
and washer
Centriflow 3D GMPM, GMEB - Installation and Maintenance
8
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

MAINTENANCE
3. If needed, use an extraction tool to pull the impeller off the
motor shaft. There is a groove in the impeller hub for the ex-
traction tool. With bigger sizes it is recommended to support
the impeller.
Size of the extraction tool needed depends on the impeller
size. Please follow the general instructions of the extraction
tool carefully.
4. Dismantle the old motor from the motor bracket.
5. Mount a new motor to the motor bracket, do not tighten the
fixing bolts.
6. Clean the motor shaft and the impeller hub hole. Use of lubri-
cation is recommended.
7. Mount the impeller on the motor shaft.
8. Mark the needed overlap to the inlet cone, see the below
illustration and table.
Fan size “Overlap [mm]”
025 4.5
028 5.0
031 5.6
035 6.3
040 7.1
045 8.0
050 9.0
056 10.0
063 11.2
071 12.6
080 14.2
090 16.0
9. Mount the front plate and inlet cone (permanently riveted to
each other).
10. Mount the front plate supports (fan size 056 and upwards).
11. Align the impeller and check that the gap between the impel-
ler and the inlet cone is as equal as possible around the im-
peller. Also check that the overlap is correct.
12. Tighten the motor fixing bolts, reassemble and tighten the end
bolt and washer, tighten the clamp screw.
Before installing and starting the fan, make sure that there is no
mechanical contact between the impeller and the inlet cone.
7.4 FINAL INSPECTION
Check that:
• The impeller is mounted for the correct direction of rotation.
• All screws and nuts have been tightened.
• No foreign objects have been left in the fan or in the ducting.
OVERLAP
Centriflow 3D GMPM, GMEB - Installation and Maintenance
9
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

8. FAULTS
If any faults occur during operation, they shall be repaired by
qualified maintenance personnel.
Some examples of incorrect use:
- foreign particles inside fan (AHU)
- corrosive media inside AHU
- too low or high temperatures
- too high vibrations
- incorrect maintenance
Possible problems generated:
- bearing damage
- corrosion damage
- vibration generated damage
- broken impeller
9. SPARE PARTS
The following spare parts are available: impeller, inlet cone (in-
cluding the front plate), motor and drive. Please contact Fläkt-
Group sales unit.
10. RECOMMENDED DISTANCE TO OTHER
COMPONENTS
To achieve the best possible operation of the fan inside of the Air
Handling Unit the following minimum distances shall be followed:
11. AIR FLOW MEASUREMENT DEVICE
The airflow sensor is used for measuring the airflow of the plug
fans. The method is based on differential pressure. The pressure
is measured at a specific point in the inlet cone and the reference
pressure is measured upstream of the inlet cone. The air flow
sensor is supplied factory mounted in the inlet cone. The air flow
is calculated as a function of the coefficient k and the differential
manometer reading Dp
m
from the equation:
q
v
= air flow m
3
/s
k = k-factor of each fan
Dp
m
= differential pressure reading (Pa)
FAULTS, SPARE PARTS, DISTANCES, AIR FLOW MEASUREMENT DEVICE, DISPOSAL
qv =
1
k
∆pm
x
GMEB-1-aaa
GMPM-1-aaa
k-factor
025 67.56
028 54.40
031 41.63
035 36.01
040 29.62
045 22.56
050 18.89
056 14.56
063 11.63
071 9.07
080 7.35
090 5.77
Size CØ D ELD R
025 110 275 190 290 138
028 123 307 212 324 154
031 137 342 258 361 171
035 154 386 290 406 193
040 174 436 327 458 218
045 196 491 370 518 246
050 220 549 415 581 275
056 244 610 463 648 305
063 273 683 520 728 342
071 308 769 586 820 385
080 348 870 659 923 435
090 392 980 733 1038 490
LD
C
B
R
E
A
ØD
12.DISPOSAL OF THE PRODUCT
Used product shall be disposed or recycled according to the local
laws and regulations.
Centriflow 3D GMPM, GMEB - Installation and Maintenance
10
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

13. DECLARATION OF CONFORMITY
EC Declaration of incorporation for Partly Completed machinery
Machinery Directive 2006/42/EC, Annex II, sub B
Manufacturer: Fläkt Woods Oy
Address: Kalevantie 39
FI-20520 Turku, Finland
Name and address of the person authorised to compile the relevant technical documentation:
Name: Heikki Stenberg Address: as above
The design of the Partly Completed Machinery:
GMEB/GMPM /GMEC with accessories
Induction AC-motor
Induction AC-motor with integrated VSD
Electronically commutated external rotor motor with integrated controller
Permanent magnet motor with controller
The following essential requirements of the Machinery Directive (2006/42/EC) are applied and fulfilled:
1.1.2, 1.1.3, 1.1.5, 1.5.1
The specific technical documentation in accordance with Appendix VII B has been written and is available.
The specific documentation will be transmitted to a reasoned request by national authorities.
And that this partly completed machinery is in conformity with the provisions of the following other EC-
Directives:
Low Voltage Directive 2014/35/EU
EMC-Directive 2014/30/EU
ErP Directive 2009/125/EC
And furthermore, declares that
the following (parts/clauses of) European harmonised standards have been
applied: EN ISO 12100-2010, EN ISO 13857:2008 and ISO EN 5801
This partly completed machinery must not be put into service until the final machinery into which it is to be
incorporated has been declared in conformity with provisions of the Machinery Directive 2006/42/EC, where
appropriate.
Turku, 20.4.2016 Heikki Stenberg
R&D Manager
Centriflow 3D GMPM, GMEB - Installation and Maintenance
11
FläktGroup DC_9853GB_20180425_R0 Specifications are subject to alteration without notice

FG_DC-9853GB_Centriflow 3D GMPM, GMEB_IN-MA_180425_R0 © Copyright 2018 FläktGroup
WWW.FLAKTGROUP.FI GMPM/GMEB 9853
» Learn more on www.flaktgroup.com
or contact one of our offices
A HISTORY OF INNOVATION
AND RELIABILITY
With more than a century of accumulated industry experience, FläktGroup is
in a unique position to deliver energy efficient components and solutions for
integrated performance, reliability and quality. With modern manufacturing
technologies, precise deliveries and technical support, FläktGroup is your
partner – fulfilling and surpassing industry standards and certifications.
