FLAME SIX-IN-A-ROW brief description 10/2009

The FLAME “Six-In-A-Row” is a universal MIDI-sequencer / con-

troller which can be used as a stand-alone MIDI device but also

as a remote for PC/Mac via MIDI (not USB!). It can be put into

standard application or into MIDI remote mode booting with

START. Following updates or other software are loadable perma-

nently per USB (only with PC).

In boot sequence you can select the standard application (now

the MIDI-phrase-sequencer) or the MIDI remote function. After

power-on please push down the yellow key (right bottom) to

activate the select menu. Follow the display messages:

Push the left yellow button for the MIDI-phrase-sequencer or the

right yellow button for the MIDI-remote-unit. Now the selected

programm is loading. For the next power-on: The unit started

always automaticly with the last selected program.

In the SETUP PAGE you can set following parameters:

MIDI CLOCK - Intern/extern synchronization

SENDCLOCK - in external sync send of MIDI clock on/off

MIDI CHANNEL - Midi channels of the tracks (1..16)

SAVE USER DATA - save data without pattern data

SAVE PATTERN/ALL - save all data (pattern and user data)

In all menus there can be switched between TEMPO and selected

value by pushing the data entry knob.

The range of TEMPO is between 10..230 bpm.

CONNECTIONS

MORE INFORMATIONS, DOWNLOADS AND THE FULL MANUAL ON: http://flame.fortschritt-musik.de

The remote mode offers the possibility to communicate with a

PC/Mac via MIDI (not USB!). A relatively simple protocol is impli-

mented which is based on MIDI control change and on note com-

mands. This makes it possible to put the LEDs and the LCD display

individually. The key buttons and the endless control dial send

the according note / control change data. Up to 16 devices can be

run at the same time using different MIDI channels.

With the aid of MAX/MSP, PURE DATA, REAKTOR or with LOGIC

ENVIRONMENT you can programme your own applications.

Please download the entire MIDI documentation on the website:

http://flame.fortschritt-musik.de

MIDI-REMOTE-UNIT

The first standard application is a MIDI phrase sequencer. It ope-

rates independantely from PC/Mac as a single hardware tool. The

sequencer is planned as a performance tool.

It possesses 5 tracks: 2 MELODY tracks and 3 DRUM tracks.

Unlike to the step sequencer the sequences are generated-mani-

pulated-recorded here directly. At your disposal are precast

rhythm patterns (phrases, beat/pulse) which can be combined

arbitrarily. The generated pattern is at most 4 measures long but

the particular measure parts can be switched on/off independan-

tely from each other during the performance. That makes varia-

tions of the pattern cycle easily possible.

To each sequencer track can be assigned one own MIDI channel .

The pattern can be back upped in the internal EEPROM.

Synchronisation is possible per external MIDI clock. The sending

of MIDI clock at external synchronisation can be switched off.

MIDI-PHRASE-SEQUENCER

SETUP PAGE

SET TEMPO / VALUES

PLAY MENU (top row, don’t press SHIFT)

USB

RUN/LOAD

SWITCH

MIDI-IN

Start/Stop

don’t press Shift !

Measures of Pattern

1 2 3 4

SELECT PAGES (top row, press SHIFT)

Melody

Blinking key

for saving

1 Track Melody 1

2 Track Melody 2

3 Track Drum A

4 Track Drum B

5 Track Drum C

Melody

Drum

A B C

unused Setup

Page

press Shift !

Pages

MIDI-OUT

POWER SUPPLY

(12VDC/800mA)

POWER ON

SWITCH

MIDI - PHRASE - SEQUENCER

GETTING START

MELODY PAGES ( Melody tracks 1 + 2 )

DRUM PAGE ( Drum tracks A B C )

ADDITIONAL INFORMATIONS

SELECT MENUS

press hold down key SHIFT and menu key (menu yellow, selected green)

change value with the data entry knob

MUTE

HOLD

CHORD

ARPEGGIO

PHRASE

BEAT

CLEAR

CLEAR FUNCTIONS

1. Press key CLEAR for clear Steps on current position (16th quantized)

2. Press key CLEAR and key LOWER KEYNOTE for clear all Steps of Track

3. Press key CLEAR and key START/STOP for clear all tracks of pattern

CLEAR FUNCTIONS

1. Press key CLEAR of track for clear Steps on current position of track

2. Press key CLEAR and key ALTERNATE of track for clear all steps of track

3. Press key CLEAR of TRACK-C and key START/STOP for clear all tracks of pattern
