Flanders Crank Lock HEPA Filter Housing C-3 User manual

C-3 and C-4
Crank Lock HEPA Filter Housing
Bulletin PB1604-0107
Important Features
• Choice of frame construction materials
• Stainless steel filter locking mechanism for
strength, durability and long-term integrity
• Access for up to four filters and prefilters wide
per door for quick filter changeout
• Double pin hinges enable the doors to make
level contact with the door gasket for a uni-
formly tight seal
General
C-3 and C-4 Side Access HEPA/ULPA Filter Housings
are designed for use with nominal 12 inch deep
HEPA/ULPA filters. They are factory-assembled
flanged units suitable for gel sealed or gasket sealed
HEPA filters. Both the prefilters and the primary
HEPA/ULPA filters are serviceable through the same
gasketed side access door.
Versatility
C-3 and C-4 housings may be used with Alpha 95 fil-
ters (95% DOP efficiency) and with Alpha Cell and
Alpha 2000 filters (99.97% and 99.99% DOP efficien-
cy). Standard housings accept nominal 12 inch deep
filters and 16” and 18” carbon adsorbers in a variety
of face sizes. They can be arranged from one filter
high and one filter wide to four filters high and eight fil-
ters wide. If large housings are not practical to rig into
place, smaller units may be stacked in the field.
Options
• Choce of frame construction materials
• Insulation
• Lifting lugs
• Transitions
• Static pressure ports
• DOP test ports
• High temperature modifications
• Weathercap
• Magnahelic gauges (mounted)
• PrefilterTrack
Construction
Housings are 24 inches deep in the direction of air
flow, (26 inches deep if it has a 4” prefilter section.)
and are constructed in your choce of frame materials.
Flanges are furnished for duct connections on the air
entering and air leaving sides. All joints are intermit-
tently welded and finished to remove all burrs and
sharp edges. The joints are then sealed with silicone
enabling the housing to withstand an internal pressure
of +/- 3.0 in. w.g.
The filter locking mechanism for the fluid gel seal-
model housing is a 300 Series stainless steel hand-
operated arm that moves the filter s gel-filled channel
on to the internal housing knife edge sealing flange.
The same mechanism also pulls the filter away from
the sealing flange when changing filters. The filter
locking mechanism for gasket seal-model housing is a
300 Series stainless steel and brass device. The
mechanism presses the gasketed filter against the
housing s sealing surface by means of a mechanical
bolt and thrust assembly that is manually operated
using a standard 3/4 inch socket or wrench.
Standard 2 inch or 4 inch prefilter tracks will accom-
modate pleated panel filters with efficiency ranges up
to 50% per the ASHRAE Standard 52.2 dust spot test
methods. Access doors have 0.5 in. thick closed cell
neoprene gaskets around the inside perimeter.
Double pin door hinges which pivot, allow the door to
make level contact with the gasket when closed.
Stainless steel wing nuts secure the doors.
Flanders Filters - Foremost in Air Filtration
Toll Free: 1-800-637-2803
®
FOREMOST IN AIR FILTRATION

Cfm Capacities and Dimensions
Using Standard Alpha 95 and Alpha Cell and High Capacity Alpha 2000 HEPA Filters
1. Height and Width code: the first numeral represents the number of 24 in. x 24 in. filters high and wide. See also
Model Number Development on page 3.
2. Standard housing depth is 23-1/4 inches with or without an optional prefilter track.
3. Housings greater than four wide must have filter removal from both sides.
4. Capacities shown are based on nominal 12 inch deep filters.
A flange in the housing mates into a
gel-filled channel on the filter. The
gel seal guarantees filter-to-frame
sealing and is recommended for
critical applications.
A spring-loaded filter clamping
mechanism is used to maintain seal-
ing pressure for gasketed filters. The
gasket seal is suitable for many
applications.
Gel Seal
Gasket Seal
Housing
Knife Edge
Sealing Flange
Gasket
Flanders Filters - Foremost in Air Filtration
Toll Free: 1-800-637-2803
Face Width Code
Height Velocity 1W 2W 3W 4W 5W 6W 7W 8W
Code (fpm) CFM Capacity
1H 500 1000 4000 6000 8000 10000 12000 14000 16000
275 1100 2200 3300 4400 5500 6600 7700 8800
375 1500 3000 4500 6000 7500 9000 10500 12000
500 2000 4000 6000 8000 10000 12000 14000 16000
2H 500 4000 8000 12000 16000 20000 24000 28000 32000
275 2000 4000 6000 8000 10000 12000 14000 1600
375 3000 6000 9000 12000 15000 18000 21000 24000
500 4000 8000 12000 16000 20000 24000 28000 32000
3H 500 6000 12000 18000 24000 30000 36000 42000 48000
275 3000 6000 9000 12000 15000 18000 21000 24000
375 4500 9000 13500 18000 22500 27000 31500 36000
500 6000 12000 18000 24000 30000 36000 42000 48000
4H 500 8000 16000 24000 32000 40000 48000 56000 64000
275 4000 8000 12000 16000 20000 24000 28000 32000
375 6000 12000 18000 24000 30000 36000 42000 48000
500 8000 16000 24000 32000 40000 48000 56000 64000
C-4C-3

Height Filters/ Width Code
Code Weight
1W 2W 3W 4W 5W 6W 7W 8W
1H Filters 1 2 3 4 5 6 7 8
Weight 105 190 270 380 460 540
2H Filters 2 4 6 8 10 12 14 16
Weight 200 305 460 610 765 920
3H Filters 3 6 9 12 15 18 21 24
Weight 255 405 590 810 995 1180
4H Filters 4 8 12 16 20 24 28 32
Weight 345 520 710 1040 1230 1420
Filter Usage and Housing Weight
Model Number Development
(1) Filters/Weight: Top number indicates the number of filters required to fill the unit. Bottom number indicates the
approximate weight in pounds of the housing EMPTY. Add 32 pounds for each HEPA/ULPA filter and 2 pounds per each
prefilter to determine approximate weight when loaded with filters.
Add 10% to calculate the approximate rigging weight of housings
C3G - 1H1W - GGF - GLV - D1
Filter type:
C3G - Gasket Seal
C4F - Fluid Seal
Housing Size:
Filters High x Wide
(See Chart)
Filter Size:
CCF - 12”x12”x11-1/2” HEPA Filter
2CCF -12”x12”x11-1/2” HEPA filter with a 2” prefilter
4CCF -12”x12”x11-1/2” HEPA filter with a 4” prefiler
CGF - 12”x24”x11-1/2” HEPA Filter
2CGF- 12”x24”x11-1/2” HEPA Filter with 2” prefilter
4CGF- 12”x24”x11-1/2” HEPA filter with a 4” prefilter
GCF- 24”x12”x11-1/2” HEPA filter
2GCF- 24”x12”x11-1/2” HEPA filter with 2” prefilter
4GCF- 24”x12”x11-1/2” HEPA filter with 4” prefilter
GGF- 24”x24”x11-1/2” HEPA filter
2GGF- 24”x24”x11-1/2” HEPA filter with 2” prefilter
4GGF- 24”x24”x11-1/2” HEPA filter with 4” prefilter
CC12- 12”x12”x11-1/2” carbon adsorber
CG12- 12”x24”x11-1/2” carbon adsorber
GC12- 24”x12”x11-1/2” carbon adsorber
GG12- 24”x24”x11-1/2” carbon adsorber
CG16- 12”x24”x16” carbon adsorber
GC16- 24”x12”x16” carbon adsorber
GG16- 24”x24”x16” carbon adsorber
GG18- 24”x24”x18” carbon adsorber.
Flanders Filters - Foremost in Air Filtration
Toll Free: 1-800-637-2803
Housing Material:
GLV: Galvanized steel
304: Type 304 S/S
304L: Type 304 L S/S
316: Type 316 S/S
316L: Type 316L S/S
ALZ - 14 gauge aluminized
(non-standard)
The filter size arrangements listed at left are the only standard
arrangements. 6” prefilters are available but non-standard.
Any prefilter with a carbon housing is available but not standard.
Multi-wide CC, CG and GC units are available but non-standard.
CC16, CC18, CG18 & GC18 units are not available.
Door Locations
D1- Filter access and housing on
one side only
D1A - Doors on both sides, but filter
access from one side only.
D2 - Doors on both sides and filter
access from both sides.

Guide Specifications
Notes:
1. Standard construction is 14 ga. galvanized steel housing and doors leak tight to +/- 3.0 in. w.g.
2. Maximum operating temperature for standard C-3 and C-4 Housings is 250°F. High temperature C-3 and C-4 Housings
are available for 400°F continuous and 500 °F intermittent duty.
1.0 HEPA/ULPA Filter Housings
1.1 Side access HEPA filter housings shall be C-3 and
C-4 as manufactured by Flanders.
1.2 Units shall be factory-assembled housings with
flanges for duct connections on the air entering
and air leaving sides.
1.3 Housings shall be suitable for operation at +/- 3.0
in. w.g. internal pressure.
2.0 Construction
2.1 Housings shall be made of galvanized or stainless
steel with 11 ga. corner posts. Joints shall be inter-
mittently welded and sealed with silicone.
2.2 Tracks for prefilters shall be fabricated from the
same material as the housing.
2.3 The filter locking mechanism for the gel seal
model shall be a 300 Series stainless steel
hand-operated arm that moves the filter so its gel-
filled channel mates with the internal housing knife
edge sealing flange. The same mechanism shall
also pull the filter away from the sealing flange
when changing filters.
2.4 The filter locking mechanism for the gasket seal
model housing shall be a 300 Series stainless
steel and brass device. The mechanism shall
press the gasketed filter against the housing’s
sealing surface by means of a mechanical bolt and
thrust assembly that is manually operated using a
standard 3/4 inch socket or wrench.
3.0 Features
3.1 Model numbers and capacities shall be as speci-
fied and/or shown on the drawings.
3.2 Provide options as specified.
Construction Details
