PrecisionCell HT
High Temperature Rigid Filters
Bulletin PB1003-1106
General
PrecisionCell HT filters are designed for high tem-
perature applications up to 900o F. They feature the
same rugged construction as the Gas Turbine
PrecisionCell. The HT version is manufactured of
specially selected components to meet high temper-
ature requirements.
They are ideal for paint drying ovens or any appli-
cation requiring high efficiency filtration at high tem-
peratures. PrecisionCell HT filters are offered in two
high temperature operating ranges; 750ºF and 900º
F and efficiency ranges of 65%, 85% and 95% per
ASHRAE Standard 52.1. Offered as a MERV 11-14
according to ASHRAE 52.2.
Construction
The enclosing frame is manufactured of aluminized
steel, which is designed to eliminate spalling of cor-
rosion inhibitors @ elevated temperatures.
The media pack is stabilized by a media pack
retaining bar and captured by faceguards upstream
and downstream. Grid strap bracing on the air
entering and leaving sides maintain the rigidity and
integrity of the PrecisionCell HT.
The media is designed for operation in high tem-
perature applications and manufactured from one
continuous sheet of wet-laid micro-fine fiberglass,
which provides the required tensile strength and
operating pressure drop for these stringent applica-
tions.
Physical Data
Frame: 24 ga. aluminized steel
Media: Dual layer microfine fiberglass
Separators: Hemmed-edge corrugated aluminum
Header Frame: 7/8” wide aluminized steel
Faceguards: Aluminized steel expanded
Cross Bracing: 1/2” “T” strap downstream and
horizontal strap upstream
Important Features
• Continuous duty up to 900ºF
• Aluminized steel construction
• 65%, 85%, 95% efficiencies
• Faceguards and grid straps
• MERV 11 to 14
Flanders Filters - Foremost in Air Filtration
Toll Free: 1-800-637-2803

Operating Nominal Size 500 fpm Media Weight
Efficiency Limit ºFH x W x D (inch) Rating Area Each
cfm pd (sq. ft.) (lbs)
750 24 x 24 x 12 2000 .45 140 26
60-65% 24 x 12 x 12 1000 69 21
900 24 x 24 x 12 2000 .50 175 28
24 x 12 x 12 1000 90 22
750 24 x 24 x 12 2000 .55 140 26
80-85% 24 x 12 x 12 1000 69 21
900 24 x 24 x 12 2000 .60 175 28
24 x 12 x 12 1000 90 22
750 24 x 24 x 12 2000 .65 140 26
90-95% 24 x 12 x 12 1000 69 21
900 24 x 24 x 12 2000 .70 175 28
24 x 12 x 12 1000 90 22
Notes:
1. PD represents clean pressure drop in inches w.g. The recommended final pressure drop is 2.5 inch w.g.
2. Operation down to zero velocity is satisfactory for all models.
3. Efficiencies are average and are based on ASHRAE Standard 52.1 and 52.2 dust spot test methods.
Performance values stated may be averages typical of the products listed. Contact factory for actual perform-
ance test reports on specific products.
4. Perfmormance values shown in this publication may be averages or estimates intended to generally represent
product styles. Always contact factory for latest actual test data on specific Flanders Precisionaire models.
1.0 General
1.1 High temperature rigid filters shall be
PrecisionCell HT separator type as manufactured
by Flanders.
1.2 Filter sizes and temperature ranges shall be as
scheduled on the drawings.
2.0 Filter Construction
2.1 Filters shall be constructed by pleating a contin-
uous sheet of wet-laid micro-fine glass media
into closely spaced pleats with hemmed-edge
corrugated aluminum separators.
2.2 The filter pack shall be sealed into a 24 ga.
aluminized steel frame with fire-retardant
sealant.
2.3 Expanded metal aluminized steel faceguards
shall be installed on the air entering and air leav-
ing sides.
2.4 A 1/2” “T” strap shall be installed on the down-
stream side and 1/2” horizontal strap on the air
entering side.
3.0 Performance
3.1 Initial and final resistance shall not exceed the
scheduled values.
3.2 Media area shall equal that of the scheduled
high temperature filter.
3.3 The manufacturer shall guarantee performance
as outlined in section 7.4 of ARI Standard 800.
