ENGINEERED SOLUTIONS FOR CLEAN AIR
Trion's Models M750 and M1100
commercial air cleaners have been especially
designed for large rooms or multi-room
facilities. They have the capacity to help
remove up to 99.97% of tobacco smoke, dust,
pollen, lint, bacteria and mold spores from
recirculated indoor air. Nuisance odor control
is also possible with an optional adsorption
module.
They are easy to install on a wall
or suspend from a ceiling and feature
variable speed control, non-electrostatic, high
efficiency micro-glass filters (optional HEPA
filter or 14 Ib. charcoal filter), a commercial
duty cabinet, and adjustable outlet grille.
The Model M750 and M1100 air cleaners
can be used in cocktail lounges, clubs,
bingo halls, meeting rooms, bowling centers,
computer rooms, conference rooms,
designated smoking areas, or wherever people
gather to work or relax.
MEDIA AIR CLEANING
DIRTY AIR PRE-FILTER MAIN-FILTER CLEAN AIR
MODEL M750 • M1100
HOW IT WORKS
Trion's Models M750 and M1100 uses a principle called Interception Filtration. Dirty, polluted air is drawn
through the pre-filter to remove larger dust particles. The second stage, micro-glass deep pocket media
filter strips submicron particles from the air stream by interception. The small diameter fibers in the filter
intercept and retain these small particles while the large surface area of the filter gives long life and low
pressure drop. The blower is designed specifically to handle the filtration system at rated CFM over the
useful life of the filter. The Trion units work independently of any HVAC system.
FEATURES / BENEFITS
• High Efficiency Filters - removal of sub-micron particles
• Recirculates Indoor Air - less expense to heat or cool air
• Front Access - no tools required to change filters
• 4-Way Adjustable Outlet Diffuser - ability to better control air pattern
MEDIA AIR CLEANERS

SPECIFICATIONS MODEL M750

SPECIFICATIONS MODEL M1100
BLOWER LONG
FILTER BAG
PRE-FILTER
BLOWER FINAL
ABSORBER
PRE-FILTERLONG
FILTER BAG
BLOWER ABSORBER
MODULE
PRE-FILTERHEPA
FILTER
BLOWER ABSORBER
MODULE
PRE-FILTERSHORT
FILTER BAG
BLOWER HEPA
FILTER
PRE-FILTERSHORT
FILTER BAG
BLOWER ABSORBER
MODULE
PRE-FILTER

SPECIFICATIONS
CABINET 18 gauge welded galvanized steel
FINISH Epoxy powder coat brown paint
AIR FLOW Horizontal - right to left or left to right
FILTER ACCESS End-load–no tools required
ACCESSORIES Filter change indicator gauge
MOUNTING HARDWARE
INCLUDED 4 eyebolts
Optional wall mounting brackets
MODEL M750 MODEL M1100
DIMENSIONS
INSTALLATION
WEIGHT
ELECTRICAL INSTALLATION
MOTOR
BLOWERS
POWER CONSUMPTION
INPUT POWER
CONTROLS
GENERAL
SOUND RATING
PRE-FILTER
MAIN FILTER
MAIN FILTER
OPTIONS
GAS / ODOR
ADSORBER MODULE
OPTION
FINAL ADSORBER
OPTION
STANDARD SPECIFICATIONS FOR EACH UNIT
30” L x 20” W x 14.5” H 43”L x 20” W x 14.5” H
Wall or Ceiling mount Wall or Ceiling mount
70 lbs., Shipping Wt. 111 lbs. 95 lbs., Shipping Wt. 125 lbs.
8’ power cord with 3 prong plug included 8’ power cord with 3 prong plug included
1/8 HP Thermally protected 1/2 HP Thermally protected
Direct drive squirrel cage forward curved Direct drive squirrel cage forward curved
3.8 Amps Max, 349 Watts Max 7.2 Amps Max, 778 Watts
120 VAC, 60 Hz, 1 Ph 120 VAC, 60 Hz, 1 Ph
U.L. recognized and listed components throughout U.L. recognized and listed components throughout
Variable speed control and indicator light Variable speed control and indicator light
Throw Distance: to 45 ft. Throw Distance: to 45 ft.
4-way adjustable air outlet louvers 4-way adjustable air outlet louvers
200 CFM to 750 CFM 600 CFM to 1025 CFM
41-62 dBA 43-64 dBA
1” thick polyester foam, washable 1” thick polyester foam, washable
95% Multi-pocket bag (ASHRAE 52.1) 95% Multi-pocket filter bag
95% HEPA (0.3 micron or larger) 95% efficiency filter bag and 95% HEPA
99.97% HEPA 95% filter bag and 99.97% HEPA
HEPA mounts on the clean air side of main filter
2” thick VEE bank 2” thick VEE bank module and filter bag
Dimensions: 11.75” H x 17.75” W x 11.75” D Dimensions: 11.75” H x 17.75” W x 11.75” D
Refillable Refillable
Capacity: 14 lbs. activated charcoal or Capacity: 14 lbs. activated charcoal or
21 lbs. activated alumina 21 lbs. activated alumina
Final adsorber with 4 lbs. activated charcoal Final adsorber with 4 lbs. activated charcoal
capacity or 6 lbs. of activated alumina capacity or 6 lbs. of activated alumina
Use on the clean air side of filter bag or HEPA
Corporate Office: 101 McNeill Road . Sanford, NC 27330
Phone: [phone] . Fax: [phone] . www.trioninc.com . email: [email protected]
Local Distributor
Form No. 02-0350 . © 2001, Trion, Inc. . 6/01
