Flash FL-202 BEAM 5R User manual

USER MANUAL
Moving Head
FL-202 BEAM 5R
F1000363

Moving Head FL-202 BEAM 5R F1000363
www.flash-butrym.pl
1
Table of Contents
1Introduction......................................................................................................................................................2
2Safety information ...........................................................................................................................................2
3Product information ........................................................................................................................................3
3.1 Features .......................................................................................................................................................3
3.2 Specification................................................................................................................................................3
4Installation........................................................................................................................................................4
5Connections......................................................................................................................................................4
5.1 Connecting DMX signal.............................................................................................................................4
5.2 Voltage specification..................................................................................................................................5
5.3 Connecting power supply........................................................................................................................5
6Operation manual............................................................................................................................................6
6.1 DMX channel list........................................................................................................................................6
Spis treści
1Wprowadzenie...............................................................................................................................................12
2Zasady bezpieczeństwa ................................................................................................................................12
3Informacje o produkcie .................................................................................................................................13
3.1 Cechy .........................................................................................................................................................13
3.2 Specyfikacja...............................................................................................................................................13
4Instalacja .........................................................................................................................................................15
5Połączenia.......................................................................................................................................................15
5.1 Podłączenie sygnału DMX ......................................................................................................................15
5.2 Specyfikacja zasilania...............................................................................................................................15
5.3 Podłączanie zasilania...............................................................................................................................16
6Lista kanałów DMX.......................................................................................................................................17

www.flash-butrym.pl
2
1INTRODUCTION
Thank you for purchasing Moving Head FL-202 BEAM 5R. For safety reasons and to ensure the
trouble-free operation, carefully read the instructions.
2SAFETY INFORMATION
1. CAUTION ! Avoid looking directly into the light source (meant especially for epileptics)!
2. CAUTION ! Keep away from fire!
3. Before connecting the unit to the mains, make sure it is not damaged mechanically. If you
notice any signs of damage you should contact your dealer immediately. Do not connect the
device to the mains.
4. Do not use the device in high humidity conditions and at temperatures above 40° C
5. The device must be installed on stable structures
6. WARNNING! Minimum distance of inflammable materials from the surface: 12m.
7. To reduce the risk of electrical shock or fire, do not expose this unit to rain or moisture.
8. Do not spill water or other liquids into or on to your unit.
9. During long periods of non-use, disconnect the units main power.
10. It should be installed in a well-ventilated place, at a distance of 50cm or more with the walls.
At the same time, please check if the fan and ventilation holes are unobstructed.
11. Disconnect the power supply before installation.

Moving Head FL-202 BEAM 5R F1000363
www.flash-butrym.pl
3
The product has perfect performance and integrity packing. All users should be strictly comply with the
warning and operating instructions as stated. Or we aren't in charge of any result by misusing. Any damage
resulting by misuse is not within the company’s warranty.
WARNING! THE BULB IS HOT!
Please turn off or restart the device only after 20 minutes after turning off the lamp, once it is fully cooled
down. Frequent switching will reduce the life span of lamps and bulbs.
CAUTION! The head and yoke must be unlocked before operation! Check the pan/tilt locks!
3PRODUCT INFORMATION
3.1 Features
High quality 190W discharge lamp R5
Fast and precise movement
Electronic monitoring of the error message
Ultra compact design (15kg)
Adjusting the speed of PAN and TILT via DMX
PAN and TILT rotation resolution: 16bit
3 lenses
Two side handles for transportation
PAN and TILT lock for safe handling
Two handles for clamps
Designed for use indoors
Can be mounted in any position
3.2 Specification
Power consumption: 300W
Power supply voltage: 100 - 240V
Voltage frequency: 50/60Hz
Diode power: 1W
Lamp type: 5R
Display: Color LCD
Color: Color wheel - 14 colors + white
ZOOM: No
Beam angle (min): 1°
Beam angle (max): 1°
Dimming: Linear: 0 - 100%
FROST filter: Yes
FOCUS: Electronic
GOBO wheel: 17 patterns
PAN range: 540°
TILT range: 250°
Number of DMX channels: 16 / 17 / 20
DMX standard: DMX 512
Control interface: Wheel controller
Operating modes: Auto, DMX512, Sound, Master/Slave
Features: Resetting the lamp on and off using the DMX512 signal

www.flash-butrym.pl
4
AC IN: powerCON
AC OUT: powerCON
DMX IN: XLR - 3 pin, XLR - 5 pin
DMX OUT: XLR - 3 pin, XLR - 5 pin
IP Rating: IP20
Housing made: ABS
Cooling: Active
Height [cm]: 51
Width [cm]: 40
Depth [cm]: 32
Weight [kg]: 15
Weight with packaging [kg]: 17
Set includes: Power cord, Power cord (LINK), Mounting bracket (2pcs), XLR cable
4INSTALLATION
After removing the packaging, check if the device was not damaged during transport. Before connecting to
the mains, make sure that the device is securely mounted. The manufacturer is not responsible for damage
caused by unstable mounting.
Ensure proper connection to the mains and proper grounding. Make sure that the electrical parameters are
consistent with device requirements. All activities, including connecting the device to the mains must be
performed by qualified personnel.
5CONNECTIONS
The device is equipped with the following interfaces:
1. DMX (in/out): XLR 5-pin, XLR 3-pin socket
2. Power (in/out): powerCON socket
5.1 Connecting DMX signal
The connection is performed using cable with XLR-female -> XLR-Male plugs.
CAUTION: At the last fixture, the DMX signal has to be terminated with a terminator. Solder a 120resistor
between signal (-) and signal (+) into a XLR plug and plug it in the DMX output of the last fixture.

Moving Head FL-202 BEAM 5R F1000363
www.flash-butrym.pl
5
5.2 Voltage specification
Input Voltage
Total Power
Frequency
100~245V
300W
50/60Hz
5.3 Connecting power supply
The connection is performed using power cable with PowerCon connector (included).
The device must be operated by qualified personnel. Make sure that the power grid supply parameters are
consistent with device parameters and limitations are not exceeded.
CAUTION! In the case of cable damage do not attempt to repair. Replacement or repair can be made only
on the manufacturer or by a person with appropriate permissions.

www.flash-butrym.pl
6
6OPERATION MANUAL
6.1 DMX channel list
16CH mode (Smal)
Channel
Function
Effect
CH 1
Color wheel
0: White
5: White + red
9: Red
13: Red + orange
18: Orange
22: Orange + aquamarine
26: Aquamarine
30: Aquamarine + light orange
35: Light orange
39: Light orange + cold white
43: Cold white
47: Cold white + lavender
52: Lavender
56: Lavender + light yellow
60: Light yellow
64: Light yellow + cyan
69: Cyan
73: Cyan + violet
77: Violet
82: Violet + yellow
86: Yellow
90: Yellow + CTO260
94: CTO260
99: CTO260 + CTO190
103: CTO190
107: CTO190 + CTB8000
111: CTB8000
116: CTB8000 + pink
120: Pink
124: Pink + white
128-145: White
146-255: Pattern clockwise rotation, slow-fast
CH 2
Strobe
0-9: Close
10-240: Strobe, slow-fast
241-255: Open
CH 3
Dimmer
0-255: 0-100%

Moving Head FL-202 BEAM 5R F1000363
www.flash-butrym.pl
7
CH 4
Gobo wheel
0-4: White (open)
5: Gobo 1
10: Gobo 2
15-15: Gobo 3
20-19: Gobo 4
25: Gobo 5
30: Gobo 6
35: Gobo 7
40: Gobo 8
45: Gobo 9
50: Gobo 10
55: Gobo 11
60: Gobo 12
65: Gobo 13
70: Gobo 14
75: Gobo 15
80: Gobo 16
85: Gobo 17
90-129: Gobo clockwise rotation, fast-slow
130-134: Stop
135-170: Gobo counterclockwise rotation, slow-fast
171: Gobo 1 shake, slow-fast
176: Gobo 2 shake, slow-fast
181: Gobo 3 shake, slow-fast
186: Gobo 4 shake, slow-fast
191: Gobo 5 shake, slow-fast
196: Gobo 6 shake, slow-fast
201: Gobo 7 shake, slow-fast
206: Gobo 8 shake, slow-fast
211: Gobo 9 shake, slow-fast
216: Gobo 10 shake, slow-fast
221: Gobo 11 shake, slow-fast
226: Gobo 12 shake, slow-fast
231: Gobo 13 shake, slow-fast
236: Gobo 14 shake, slow-fast
241: Gobo 15 shake, slow-fast
246: Gobo 16 shake, slow-fast
251: Gobo 17 shake, slow-fast
CH 5
Prism
0-127: Prism Off
128-255: Prism On
CH 6
Prism rotation
0-127: 0° - 420°
128-190: Clockwise rotation, fast-slow
191-192: Stop
193-255: Counterclockwise rotation, slow-fast
CH 7
Empty
0-255: No function
CH 8
Frost
0-127: Frost Off
128-255: Frost On
CH 9
Focus
0-255: Focus, far-close
CH 10
Pan
0-255: Pan rotation 0°-540°
CH 11
Pan fine
0-255: Pan rotation fine
CH 12
Tilt
0-255: Tilt rotation 0°-250°
CH 13
Tilt fine
0-255: Tilt rotation fine
CH 14
Empty
0-255: No function
CH 15
Reset
0-127: No function
128-255: Reset
CH 16
Lamp on / off
0-25: No function
26-100: Lamp off
101-255: Lamp on

www.flash-butrym.pl
8
17CH mode (Stan)
Channel
Function
Effect
CH 1
Color wheel
0: White
5: White + red
9: Red
13: Red + orange
18: Orange
22: Orange + aquamarine
26: Aquamarine
30: Aquamarine + light orange
35: Light orange
39: Light orange + cold white
43: Cold white
47: Cold white + lavender
52: Lavender
56: Lavender + light yellow
60: Light yellow
64: Light yellow + cyan
69: Cyan
73: Cyan + violet
77: Violet
82: Violet + yellow
86: Yellow
90: Yellow + CTO260
94: CTO260
99: CTO260 + CTO190
103: CTO190
107: CTO190 + CTB8000
111: CTB8000
116: CTB8000 + pink
120: Pink
124: Pink + white
128-145: White
146-255: Pattern clockwise rotation, slow-fast
CH 2
Strobe
0-9: Close
10-240: Strobe, slow-fast
241-255: Open
CH 3
Dimmer
0-255: 0-100%

Moving Head FL-202 BEAM 5R F1000363
www.flash-butrym.pl
9
CH 4
Gobo wheel
0-4: White (open)
5: Gobo 1
10: Gobo 2
15-15: Gobo 3
20-19: Gobo 4
25: Gobo 5
30: Gobo 6
35: Gobo 7
40: Gobo 8
45: Gobo 9
50: Gobo 10
55: Gobo 11
60: Gobo 12
65: Gobo 13
70: Gobo 14
75: Gobo 15
80: Gobo 16
85: Gobo 17
90-129: Gobo clockwise rotation, fast-slow
130-134: Stop
135-170: Gobo counterclockwise rotation, slow-fast
171: Gobo 1 shake, slow-fast
176: Gobo 2 shake, slow-fast
181: Gobo 3 shake, slow-fast
186: Gobo 4 shake, slow-fast
191: Gobo 5 shake, slow-fast
196: Gobo 6 shake, slow-fast
201: Gobo 7 shake, slow-fast
206: Gobo 8 shake, slow-fast
211: Gobo 9 shake, slow-fast
216: Gobo 10 shake, slow-fast
221: Gobo 11 shake, slow-fast
226: Gobo 12 shake, slow-fast
231: Gobo 13 shake, slow-fast
236: Gobo 14 shake, slow-fast
241: Gobo 15 shake, slow-fast
246: Gobo 16 shake, slow-fast
251: Gobo 17 shake, slow-fast
CH 5
Prism
0-127: Prism Off
128-255: Prism On
CH 6
Prism rotation
0-127: 0° - 420°
128-190: Clockwise rotation, fast-slow
191-192: Stop
193-255: Counterclockwise rotation, slow-fast
CH 7
Empty
0-255: No function
CH 8
Frost
0-127: Frost Off
128-255: Frost On
CH 9
Focus
0-255: Focus, far-close
CH 10
Pan
0-255: Pan rotation 0°-540°
CH 11
Pan fine
0-255: Pan rotation fine
CH 12
Tilt
0-255: Tilt rotation 0°-250°
CH 13
Tilt fine
0-255: Tilt rotation fine
CH 14
Empty
0-255: No function
CH 15
Reset
0-127: No function
128-255: Reset
CH 16
Lamp on / off
0-25: No function
26-100: Lamp off
101-255: Lamp on
CH 17
Pan / Tilt speed
0-5: Fastest
6-250: Fast-slow
251-255: Fastest
