Flash F7300256 User manual

User Manual
Instrukcja Obsługi
F7300256
LED LOGO PROJECTOR 300W
IP65 ANIMATION EFFECT

User Manual •Instrukcja Obsługi
Please keep this User Manual for future
      
another user, be sure that they also receive
this instruction booklet.
Unpack and check carefully there is no
transportation damage before using the

Before operating, ensure that the voltage
and frequency of power supply match the

It’s important to ground the yellow/green
conductor to earth in order to avoid electric
shock.
Disconnect main power before servicing
and maintenance.


only, but always by taking its base.

IMPORTANT!

at the LOGO PROJECTOR, as intense illumination
can damaged the display.
Don’t operate it where the temperature is
higher than this.
In the event of serious operating problem,
     

carried out by unskilled people can lead to
damage or malfunction. Please contact the
nearest authorized technical assistance
center. Always use the same type spare
parts.
Do not connect the device to any dimmer
pack.
Do not touch any wire during operation
and there might be a hazard of electric
shock.
To prevent or reduce the risk of electrical
  
rain or moisture.

visibly damaged.
Do not look directly at the LED light spot

2. SAFETY INFORMATION
1. INTRODUCTION
    LED LOGO PROJECTOR 300W IP65 ANIMATION
EFFECT

WARNING!
Figure 2.

An operating temperature range is betwen: -10º - +35º
Attention! e device must be supplied with at least 20%
of power at all times.

LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256
       
holes on the bracket. Always ensure that
       
and slipping while operating. Always
ensure that the structure to which you are
attaching the unit is secure and is able to

5.1 Connecting DMX signal
     

4. INSTALLATION
5. CONNECTION
3. PRODUCT INFORMATION
weight. Also always use a safety cable that
can hold 12 times of the weight of the unit



of people and has no one pass by or under
it.
      



1
3
22
FEMALE
XLR
GROUND
DMX +
DMX -
MALE
XLR
3
1
CAUTION!     
DMX signal has to be terminated with a



DMX
Controller DMX 512 DMX 512
1
FEMALE
XLR
GROUND
DMX +
DMX -
MALE
XLR
2
3
4
5
1
2
3
45


Light source: 1pcs 300W LED
Signal: DMX 512













The connection is performed using

(included). The device must be
operated by qualified personnel.
5.2 Voltage specification
Input Voltage Total Power Frequency
110-240V 300W 50/60Hz
5.3 Connecting power supply
CAUTION! In the case of cable damage do not attempt to repair.

a person with appropriate permissions.
Make sure that the power grid supply
parameters are consistent with device
parameters and limitations are not

---- Run Mode
---- Scene Run
---- Scene Set
---- DMX Address
---- Channel Mode
---- DMX signal
---- Display
---- Linear Color
---- Load Default
---- DiS
---- MT
---- Power
---- Reset Cal.
---- Sensor Monitor
---- System Errors
---- DMX Monitor
---- Set
---- Manual
---- system
---- Chinese and English switch
---- Screen rotation
Main interface
5.4 Menu structure
User Manual •Instrukcja Obsługi
---- Dimmer
---- Strobe
---- Color
---- Gobo
---- Gobo Rotation
---- Effect Animation
---- Focus
---- Zoom
---- Reset

5.5 Manual control

enter the host state (do not receive DMX signal, send DMX signal to the bus to the slave).

setup menu.
Options Explain
1CH. Dimming 0-255 Press the ‚OK’ key to enter the edit state. At this time,
select the hundreds place and press the „Up” and
„Down” keys to change the channel value. Press the
„OK” button again to select the ten digits for editing.
Press again to exit edit state
.... 0-255
8CH. Zoom 0-255
9CH. Reset 0-255
5.6 Set up
Options Explain
Operating
mode
DMX Slave status: Receive DMX signal from
console or host
Auto 1 Master status: self-propelled and send DMX
signal to slave
Auto 2
Random
Sound
Program
Scene Run Auto, Colse, Scene 20, Scene
19... 1
Scene Set Scene Save, Scene Select (1-20) Scene Time, AutoRun (On/Off), Dimmer, Shutter, Color, Gobo, Roto Gobo RT, Gobo Anim, Focus,
Zoom
DMX Address 1-512
Channel Mode 9 CH
DMX Signall Keep/Clear
Display On/Off
Linear Color On/Off
Load Default On/Cancel
LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256

5.8 Channel table
User Manual •Instrukcja Obsługi
CH Value REMARKS
1 0-255 Dimmer
2 0-255 Strobe/Stop
3 0-255 Colour Wheel
0 White
5 White/Red
10 Red
20 Red/Green
25 Green
35 Green/Blue
40 Blue
50 Blue/Yellow
55 Yellow
65 Yellow/Pink
70 Pink
80 Pink/Cyan
90 Cyan/Magenta
95 Magenta
105 Magenta/Orange
110 Orange
120 Orange/White
125 White
128-191 Colours Anticlockwise fast>slow
192-255 Colours Clockwise fast>slow
4 0-255 Gobo Wheel
0-9 Open
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo 4
50-59 Gobo 5
60-69 Gobo 6
70-79 Gobo 7
80-89 Gobo 1 Shake slow>fast
90-99 Gobo 2 Shake slow>fast
100-109 Gobo 3 Shake slow>fast
110-119 Gobo 4 Shake slow>fast
120-129 Gobo 5 Shake slow>fast

LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256
130-139 Gobo 6 Shake slow>fast
140-149 Gobo 7 Shake slow>fast
150-199 Gobo Anticlockwise fast>slow
200-255 Gobo Clockwise fast>slow
5 0255 Roto Gobo
0-127 Indexed
128-192 Clockwise fast>slow
193-255 Anticlockwise slow>fast
6 0-255 Animation Effect
7 0-255 Focus
8 0-255 Zoom
9 255 Reset

OSTRZEŻENIE!
WAŻNE!


Rysunek 2. 

User Manual •Instrukcja Obsługi
Zakres temperatur pracy wynosi od: -10º do +35º
Uwaga! Urządzenie musi być zawsze zasilane co najmniej
20% mocy.

2. ZASADY BEZPIECZENSTWA
3. INFORMACJE O PRODUKCIE
4. INSTALACJA
LED LOGO PROJECTOR 300W IP65 ANIMATION
EFFECT


przez wykwalifikowany personel, aby
  

    


    
    

   


     


     
  

    

    
w dobrze wentylowanym pomieszczeniu,
     

     
     



   
     
    

uszkodzenia spowodowane niestabilnym

    
      
   
     
    
   

    

1. WPROWADZENIE
: 1 szt. 300W LED
Sterowanie: DMX 512












LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256

DMX
Controller DMX 512 DMX 512
5.2 Specyfikacja zasilania
5.3 Podłączenie zasilania
Napięcie Zasilania Pobór Mocy Częstotliwość zasilania
110-240V 300W 50/60Hz
5.1 Podłączenie sygnału DMX
    
    

5. POLACZENIA






1
3
22
ŻEŃSKI
XLR
GROUND
DMX +
DMX -
MĘSKI
XLR
3
1
    




UWAGA! 


wykwalifikowany personel techniczny.
    
    
     
  

ŻEŃSKI
XLR
1
GROUND
DMX +
DMX -
MALE
XLR
2
3
4
5
1
2
3
45


User Manual •Instrukcja Obsługi

5.4 Struktura Menu
5.5 Obsługa




Options Explain
1CH. Dimming 0-255 Naciśnij przycisk „OK”, aby wejść w stan edycji. W tym
momencie należy wybrać klawiszami „Góra” i „Dół”
zmienić wartość kanału. Ponownie naciśnij przycisk
„OK”, . Naciśnij ponownie, aby wyjść ze stanu edycji.
.... 0-255
8CH. Zoom 0-255
9CH. Reset 0-255
LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256
---- Run Mode
---- Scene Run
---- Scene Set
---- DMX Address
---- Channel Mode
---- DMX signal
---- Display
---- Linear Color
---- Load Default
---- DiS
---- MT
---- Power
---- Reset Cal.
---- Sensor Monitor
---- System Errors
---- DMX Monitor
---- Set
---- Manual
---- system
---- Chinese and English switch
---- Screen rotation
Main interface
---- Dimmer
---- Strobe
---- Color
---- Gobo
---- Gobo Rotation
---- Effect Animation
---- Focus
---- Zoom
---- Reset

User Manual •Instrukcja Obsługi
5.8 Channel table
CH Wartość OPIS
1 0-255 Dimmer
2 0-255 Strobo/Stop
3 0-255 Tarcza Kolorów
0Biały
5Biały/Czerwony
10 Czerwony
20 Czerwony/Zielony
25 Zielony
35 Zielony/Niebieski
40 Niebieski
50 Niebieski/Żółty
55 Żółty
65 Żółty/Różowy
70 Różowy
80 Różowy/Cyjan
90 Cyjan/Magenta
95 Magenta
105 Magenta/Pomarańczowy
Opcje Opis
Operating
mode
DMX Slave status: Receive DMX signal from
console or host
Auto 1 Master status: self-propelled and send DMX
signal to slave
Auto 2
Random
Sound
Program
Scene Run Auto, Colse, Scene 20, Scene
19... 1
Scene Set Scene Save, Scene Select (1-20) Scene Time, AutoRun (On/Off), Dimmer, Shutter, Color, Gobo, Roto Gobo RT, Gobo Anim, Focus,
Zoom
DMX Address 1-512
Channel Mode 9 CH
DMX Signall Keep/Clear
Display On/Off
Linear Color On/Off
Load Default On/Cancel

LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256
110 Pomarańczowy
120 Pomarańczowy/Biały
125 Biały
128-191 Tarcza kolorów rotacja (lewo) szybko>wolno
192-255 Tarcza kolorów rotacja (prawo) szybko>wolno
4 0-255 Tarcza Gobo
0-9 Puste
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo 4
50-59 Gobo 5
60-69 Gobo 6
70-79 Gobo 7
80-89 Gobo 1 Shake wolno>szybko
90-99 Gobo 2 Shake wolno>szybko
100-109 Gobo 3 Shake wolno>szybko
110-119 Gobo 4 Shake wolno>szybko
120-129 Gobo 5 Shake wolno>szybko
130-139 Gobo 6 Shake wolno>szybko
140-149 Gobo 7 Shake wolno>szybko
150-199 Gobo Anticlockwise wolno>szybko
200-255 Gobo Clockwise wolno>szybko
5 0255 Roto Gobo
0-127 Indeksowane
128-192 Rotacja (lewo) wolno>szybko
193-255 Rotacja (prawo) wolno>szybko
6 0-255 Tarcza Efektu Animacji
7 0-255 Focus
8 0-255 Zoom
9 255 Reset

User Manual •Instrukcja Obsługi

LED LOGO PROJECTOR 300W IP65 ANIMATION EFFECT •Art No F7300256
