Reply® DL Response Keypad
Model CRS10000
Users Manual
Purpose of the Keypad
The Reply® DL Model CRS10000 Keypad is a wireless portable device that makes it possible
for a number of people to participate interactively in a class situation or group meeting. The
product accomplishes this by sending keypad switch closure information from the keypad to a
base unit which employs a wireless transceiver to receive the keypad signal. These signals are
processed by the base unit and delivered to a host computer which allows the responses to be
stored, analyzed and if desired displayed on a video projector for feedback to the group
showing the results of their participation. As such, the product is very similar to another
Fleetwood product, the CRS1200. The Model CRS10000 adds to the Model CRS1200 by
incorporating an 800 MHz wireless microphone circuit that allows a participant at a remote
site to speak into the keypad and communicate with an instructor through a phone line
connection. This adds the dimension of allowing verbal interaction from a remote site with an
instructor.
Description of the Keypad
The Reply Model CRS10000 Keypad is housed in a plastic enclosure similar in appearance to
a calculator. It is powered by an internal 9 volt alkaline battery with no external wires or
electrical connections. The keypad uses a membrane switch panel for numeric entry and a 7
segment LED display for entry display to the user. The keypad uses a synthesized transceiver
compliant with FCC Part 15 Subpart B and C. An integrated microphone and talk request
button provide an audio function for use in multiple site applications. The wireless
microphone portion of the device is compliant with and approved under Part 74.
Using the Keypad
To use a Reply® DL Keypad, a corresponding channel Reply® DL base unit must be active
and under control of an application running on a local or remote host computer. This is
usually the responsibility a local facilitator in cooperation with host site staff in a distance
learning environment.
A program on a host site computer under control of the instructor or facilitator determines
when responses from the keypads are to be received and when control of the wireless
microphone in the keypads is required. Typically this program will deliver a number of
informational screens via satellite or other video transmission method on a video projection
system and then will present a question screen. The participants with keypads will then be
instructed to respond using the numeric keys on the keypad. A user holding a keypad responds
by pressing one of the keys and the corresponding number will indicate on the 7 segment LED

Fleetwood Group Inc. FCC ID: FBR-DL800B User Manual Page 2 of 4
File Name: DLMAN.DOC Date: 07/13/01
display. When interrogated by the base via the 216 MHz link, the keypad sends the key
information to the base in a 10 millisecond duration signal from the 345 MHz transmitter.
When the 216 MHz signal responds with an appropriate state of the acknowledge bit for the
keypad, the keypad turns back off and awaits the next key press. This sequence takes on the
average between one and two seconds. If the keypad LED winks and comes back on, the
signal was not received by the base and the keypad will retry the next time it is interrogated
(typically about 2.5 seconds). The keypad spends most of its time in a sleeping mode
conserving the battery and allowing for thousands of transmissions.
If a user wishes to talk to the instructor the user presses the “Talking Face” key on the keypad.
This transmits the microphone request to the base unit and via a data modem on the base to
the host to notify the instructor. When the instructor is ready to take the request, an activation
signal is sent out via the data modem to the remote site base unit which in turn commands the
keypad to activate the microphone.
In Case of Difficulty
The Reply® Model CRS10000 Keypads are built using the latest technology and high
reliability components. There are very few things the keypad user can do wrong to cause a
failure, but in the unlikely event responses are not being received by the base and passed on to
the personal computer, the next pages detail procedures that can help identify the source of the
problem:

Fleetwood Group Inc. FCC ID: FBR-DL800B User Manual Page 3 of 4
File Name: DLMAN.DOC Date: 07/13/01
CHART 1
Keypad Communication Checkout
Are some
keypads being
received?
Press a number on
a non-working
keypad
Does
its display light?
Replace bad
battery and retry or
keypad defective -
return to factory
No
Defective base or
PC software problem.
See Reply Base Manual
Does its
display flash at a
rapid rate?
Yes
Replace bad
battery and retry
keypad
Yes
Does its
display stay on solid
(never wink)?
No
Keypad defective
Return to factory
for service
Does display
wink at a regular rate
(between .5 and 2.5
seconds?
Yes
No
Keypad transmit
problem
Yes
Keypad receive
problem
Yes
No
No

Fleetwood Group Inc. FCC ID: FBR-DL800B User Manual Page 4 of 4
File Name: DLMAN.DOC Date: 07/13/01
CHART 2
Keypad Audio Checkout
Defective base or
PC software problem.
See Reply DL Manual
Did the
"Wait" LED light when
the "Talk" button was
pressed?
Keypad defective
Return to factory
for service
No
Did the
"Wait" LED transition
from blinking
to solid?
Yes
Did the
"Talk" LED come on
after the solid
"Wait"?
Yes
Did other
keypads transistion from
blinking to solid?
No
No
No
Was
acceptable keypad
audio received at
the DL host?
Yes
Satisfactory
Yes
Does the
audio work properly
on some keypads
No
No
