Installation and operating instructions
FB222 bike tracker
Introduction
In developing the products we offer, the manufacturers have acted with the utmost care and in
accordance with international standards.
Warranty
We offer a 12-month warranty on the products, which is valid from the date of purchase. Keep the
invoice or block you received at the time of purchase and / or the warranty card of the device,
because you can only enforce your warranty claim if you have them. During the warranty period, we
will replace any defective main unit, accessory or software of the product in the event of any defect
attributable to a manufacturing, material or software defect. Subsequent repairs to the device or its
accessories are not permitted by the manufacturer due to the design of the device.
The warranty does not cover a product (or accessory) that has been damaged or rendered inoperable
due to attempts to modify or repair the software, physical impact, poor voltage, improper use.
To ensure proper, effective and safe use of the product, read the instruction manual carefully and
keep it for future reference. Flexcom Kommunikációs Kft. Shall not be liable for any damage, product
damage, short-term or long-term health damage that may occur as a result of use, repair, storage
and transport other than those described in this manual.
Rights, trademarks
© 2019, Flexcom Kommunikációs Kft.
All rights reserved. No part of our printed or online publications may be reproduced, distributed or
transmitted in any form or by any means, including photocopying, recording or other electronic and
mechanical methods, without the prior written permission of the publisher. To obtain a permit,
contact your dealer:
Contact

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Flexcom Communication Ltd.
2151 Fót, Szent Imre str. 94. HUNGARY
Email: [email protected]
Website: https://nyomkovetes.net
Office
2151 Fót, Dózsa György str. 34. HUNGARY
Phone: [phone]
Mobile 1: [phone]
Mobile 2: [phone]
Phone service: (Monday-Thursday) 9.00–15.00
Every effort has been made to ensure that the information in our documents is accurate. Flexcom
Kommunikációs Kft. Is not responsible for typographical errors and misspellings.
Flexcom GPS Tracking Solutions, GPS Positioning System, Nyomkovetes.net is a registered trademark
and domain name of Flexcom Kommunikációs Kft. In Hungary. Other company and product names
mentioned herein may be trademarks of their respective companies.
Protection of personal data
The product is a complete product as a combination of hardware and software components. For safe
and correct use, proceed as described in this manual during installation and use. Keep the device or
software out of the reach of unauthorized persons. Our company provides all technical and regulatory
conditions to ensure that data management complies with legal requirements and that your data does
not fall into unauthorized hands. We accept no liability for damage resulting from unauthorized use of
the product and software.

2022/09/09 09:03 3/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Formats and notations
The following style settings are used in descriptions, guides, and other documents:
Bold text Name of product components, instructions, options, processes, services, user interface
elements.
Italic text Links to other publications, emphasis.
Courier text System messages, internet addresses, document names.
Warning and cautionary signs:
Tips, advice, ideas.
Document download option.
General attention to information about the product or its operation.
Indication of situations with a lower risk to the user or the product (minor injuries,
inconveniences).
Indication of situations which present a higher risk to the user (serious injury, possibly
death) or which may cause damage or destruction of the product.

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Product description
Hogyan működik a
nyomkövetés a Flexcom-
nál?
The device combines several
functions of accurate
positioning, safety,
monitoring, emergency
alarms and full tracking. It
supports GPRS / Internet
data transfer functions and
can be widely used in many
areas of location-based
services, traffic safety and
management.
Based on its design and
mounting, the device is
primarily designed to track
bicycles - as a result, its
users are primarily vehicle
owners (adults or children).
Settings that affect the operation of the device can only be changed from another device
(smartphone, computer) with the help of our software application - so users can be sure that the
device always works according to the parameters they specify.

2022/09/09 09:03 5/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
How to use
The device has a built-in SIM card that can be used anywhere in the world, a strong battery and a
rugged, waterproof aluminum cover that is resistant to external influences. With the help of the built-
in motion sensor, you can receive an immediate alarm if the device or the bicycle is moved by
unauthorized persons. It works continuously, it cannot be switched off. When discharged, it turns on
automatically when the charger is connected.
The device can be mounted under the bottle holder of the bicycle with special custom safety screws
manufactured by us. Communication is via the SIM card built into the device and the internet
connection provided by the mobile service providers. The current position of the device, previous
route, statistics, etc. are provided by the computer or mobile phone application we have developed.
The device is already set up and handed over ready for use. After commissioning, the device
automatically connects to the GPS / BEIDOU and GSM networks (if available) using the satellite
receiver and SIM card and starts collecting position data.
When switched on
The device continuously registers position data, which can be queried with SMS commands at a
limited level.
The device sends the position data to the software service center - their processed results (eg
map route display, list of route events, real-time tracking) - can be viewed in the phone or
computer application.
You can find detailed information on the installation, use, maintenance and decommissioning of the
device in the further sections of the documentation.
The device is protected by a safety label - it must not be disassembled, as breaking the
insulation may damage the device and void the warranty. The built-in SIM card in your
device cannot be replaced at home. If you wish to transfer the device to another person,
please contact our customer service to make the necessary settings!

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03

2022/09/09 09:03 7/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Technical parameters
Physical characteristics
Parameter Value
DImensions (mm) W: 41, L: 85, H: 22,3
Weight (g) 130
Cover Aluminum and plastic
Humidity from 5% to 95% (non condensing)
Water resistance IP65 (protected against dust-free, low-pressure
water jets)
Operating temperature from -20C to +70C
Storage temperature from -40C to +85C
Memory
Parameter Value
Built-in No
SD card No
Energy supply
Parameter Value
Battery Li-ion polimer 3.7V 2000mAh
Charging 5V/1A
Power consumption at rest 2.5 mAh
Power consumption in active state 40 mAh
Operating time
Parameter Value
Standby time 30 days
Network
Parameter Value
GNSS GPS, BEIDOU sat system + Wifi + LBS + AGPS
Type of data traffic GSM/GPRS
SIM card Micro
GSM frekvencies 850, 900, 1800, 1900 MHz
GSM chip MT2503
GSM signal strength measurement Yes
Satellite receiver chip MT5931
Satellite receiver sensitivity -143 - -159 dbm
Signal L1,1575.42MHz C/A code
Measurement accuracy 5 m
Communication
Parameter Value
TCP Yes

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Sensors
Parameter Value
Motion sensor Yes
Interface
Parameter Value
GSM antenna Internal
Satellite receiver antenna Internal
Charger connector Micro USB
Display LED

2022/09/09 09:03 9/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Használati útmutató
Transport and storage
The packaging is designed to protect the product from the usual physical effects during transport. Be
careful to avoid effects other than these.
The packaging of the product is not water, flame and heat resistant and only moderately pressure
resistant. Therefore, do not keep the box in a humid environment, out of the reach of heat-emitting
equipment, or place heavy objects on it.
Commissioning
The package consists of a box containing the device and its accessories.
Unpacking
Open the box.1.
Remove the product.2.
Remove the retaining insert to protect the device.3.
Remove the accessories below.4.
Contents of the package
1 tracking device
1 charger
1 charging cable

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
2 pieces of security screws and 1 piece of wrench
1 installation instructions
Installing the device
You can attach the device to the frame of the bicycle with the safety screws included in the package,
as follows:

2022/09/09 09:03 11/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Application installation, access
In order to operate the device and other services based on it, the distributor provides mobile and
computer applications in the subscription system. The PC program is accessible via a browser at
https://gpspositions.net/map/, and you can install the phone application on your phone in one of the
following ways:
For Android phones
Open the Google Play app on your phone.1.
Search for “Flexcom” or “Flexcom tracking” on Google Play.2.
Install the tracking application.3.
or
Scan the QR code shown here with your phone.1.
Open the web address decoded from this.2.
Install the Flexcom tracking application.3.
For iPhones
Use the browser on your phone to access the service (https://gpspositions.net/map/).

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Use of the product
User interface
A készülék csatlakozói és kezelő szervei a védőfedél alatt találhatók.
LED display statuses
LED Device status
Red Constantly lit Charging
Off Charged
Kék
Constantly lit Satellite connection on
Flashes No satellite connection
Off Device in sleep mode or off
Zöld
Constantly lit GSM connection on
Flashes No GSM connection
Off Device in sleep mode or off

2022/09/09 09:03 13/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Micro USB connector
Charging cable connector.
Charging the battery
The device is powered by a built-in battery, which needs to be charged at different intervals
depending on the intensity of use.
The corresponding USB charging cable is included in the package. It is connected to the tracking
device via a MICRO USB connector - if you do not use the factory cable, make sure that it is type-
compliant!
Charging takes 2-3 hours, during which the LED indicator lights up red. When the device is fully
charged, the light turns off.
When the battery is fully charged, disconnect the charging cable. The device does NOT
have overcharge protection, so prolonged or continuous charging will shorten the life of
the device or, in worse cases, damage it.
For the device with a voltage of 5V 1 Use a charger that provides current. Chargers with
a higher capacity can damage the battery.

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Switching on and off
The device switches on automatically when charged and runs continuously until the battery is
discharged - it cannot be switched off.
After switching on, the device starts searching for GPS satellites immediately. If the appropriate
satellite connections are available, positioning will be based on these data. If not, the device performs
position calculation (LBS) based on the position of the transmission towers of the mobile service
providers.
Normal operation of the device
Separate software is available for setting or adjusting the operating parameters of the device, for
retrieving information or for using more advanced services (eg map route display, waiting and travel
points, diagrams, timetable, etc.). This is provided by the distributor in the form of an application that
can be downloaded on an Android mobile phone as part of a subscription system on a desktop
computer and tablet browser.
To use the software, an active internet connection is required on your device (mobile
phone, computer).
Setting options via the software
When using the desktop or mobile application of Flexcom Kft, the setup operations related to tracing
can be accessed in the following ways.
The settings and commands that can be issued depend on the type of device. See the
rest of this guide for information on options for this device.
When using a desktop application:

2022/09/09 09:03 15/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Select the desired device on the
map or in the menu.
Click the Settings or Commands
button to select the general setting
or behavior you want.
When using a mobile application:
From the application menu, select
Map.

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Switch to the Tools panel.
Find your device in the list of
devices and tap the Setup icon next
to the ID.
Select the desired setting or, when
sending a command, select
Commands.
Control the device with SMS commands sent from a mobile phone
The device can only be operated via the services of the Flexcom tracking software, not

2022/09/09 09:03 17/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
with the help of independent SMS messages!

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Troubleshooting and repair
Conditions for safe use of devices
Information for people with long-term health problems or disabilities
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
Their casing is made of plastic or metal, which currently has no known health risk (e.g., toxic or
allergenic effects).
Technical service life of products
If the device contains a battery, its life is usually approx. 3 years.
If you find that the operating time is significantly reduced, replace the battery as soon as
possible to avoid malfunction.
Have the battery replaced by a qualified service technician - contact your product dealer for
information.
Possible problems with proper use
Cracks, breaks or deformation of the cabinet may cause skin injury or injury to the user's hands.
Restrictions on the use of products
Do not use the products under water or expose them to strong water jets or excessive vibration.
Maintenance
The products do not require regular technical maintenance.
Disconnect the device from the charger before cleaning. Do not use abrasives or cutting or
abrasive tools for cleaning.
Decommissioning
Products do not contain harmful, toxic substances.
Their internal components, outer casings and accessories are not made of or only slowly
degradable materials - they must be treated in accordance with the appropriate waste disposal
procedure.

2022/09/09 09:03 19/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Identifying problems and possible solutions
Symptom Possible cause Solution
The device does not turn
on or turns off
immediately after turning
it on.
The battery may be
exhausted. Charge the battery.
Phone calls and / or SMS
communication between
the device and the phone
do not work.
No GSM connection.
Check the strength of the GSM connection. If the
LED is solid amber, there is no connection to the
service provider's network. You may be in a
shaded area - change position.
The SIM card is
defective or there is a
contact error.
Remove the SIM card, or clean it with a soft
eraser or stylus and reinsert it. If it still does not
work, have it tested by a professional (eg a
mobile service provider).
Phone application
services do not work.
Your device, phone or
none of them have a
GPS satellite and / or
GSM / Wifi connection.
Check GPS, GSM and wifi connection. If the LED
is solid yellow or blue, there is no satellite and /
or mobile service connection. Also check the wifi
connection on your phone. Look for a place that
is not shaded by trees, buildings, or other
landmarks, or a place where the signal strength
is higher.
Service provider system
error
If you do not find a problem with the above,
there may be a system error with your telephone
application provider.
APN setting error Check the APN settings of the tracking device.
The device does not
respond to SMS
commands
There may be an
incorrect SIM card in
your device.
A card with voice call, SMS and GPRS data traffic
is required for the device to work properly.
SMS mode works, but the
app does not.
The device may be in
sleep mode.
Check the operation of the device. For example:
send an alarm SMS to the device (see Chapter
5).
Troubleshooting and warranty repair
If you can identify the error based on the above or the recommended solution does not work, contact
your dealer:
Contact
Flexcom Communication Ltd.
2151 Fót, Szent Imre str. 94. HUNGARY
Email: [email protected]
Website: https://nyomkovetes.net
Office
2151 Fót, Dózsa György str. 34. HUNGARY
Phone: [phone]
Mobile 1: [phone]
Mobile 2: [phone]
Phone service: (Monday-Thursday) 9.00–15.00

Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
During the warranty period, if the conditions of the warranty have not been violated, the distributor
will take care of the professional investigation of the cause of the failure, repair of the error or
replacement of the device.
