FD70ARM-G
Installation and Operation Manual
7 Inch Dual LCD System
TECHNICAL SUPPORT
678-867-6717, or
www.FlightDisplay.com
All manuals and user guides at all-guides.com
all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 2 of 18
FD70ARM-G
7" Dual LCD System
© 2006 Flight Display Systems. All Rights Reserved.
Flight Display Systems
1765 Grassland Parkway
Alpharetta, GA 30004
678-867-6717 Phone
678-867-6742 Fax
[e-mail]
www.flightdisplay.com
For the most current copy of all product manuals, please visit our website at www.flightdisplay.com
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 3 of 18
Table of Contents
General Information......................................................................................................................4
1. Front View..........................................................................................................................4
2. Additional Information....................................................................................................4
Specifications................................................................................................................................5
Installation Instructions .............................................................................................................5
1. Power ..................................................................................................................................5
Wiring Instructions......................................................................................................................7
1. S-Video/Composite & Audio Wiring............................................................................7
2. VGA Wiring .......................................................................................................................8
3. Power & Ground Wiring..................................................................................................9
4. Power/Video ...................................................................................................................10
Operations Instructions ............................................................................................................13
1. Button Control.................................................................................................................13
Technical Drawing.....................................................................................................................14
Troubleshooting.........................................................................................................................15
Technical Support......................................................................................................................16
Instructions for Continued Airworthiness ...........................................................................17
Warranty ......................................................................................................................................17
Log of Revisions.........................................................................................................................18
All manuals and user guides at all-guides.com

Document Number:
MAN –FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 4of 18
General Information
The FD70ARM-G is a 7" Dual LCD System, utilizing the latest version of our popular 7”
Widescreen Display. Each arm unit is made of two separate parts, the metal enclosed
LCD screen and the articulating arm.
Built with retrofit aircraft integration in mind, these displays can switch between three
video input sources using the buttons on the bezel or the Infrared Remote.
The arms have both a hinge and a pivot point, can rotate 150° around the attach point at
the base, and 90° at the bottom of the LCD. This mount will allow the monitors to tilt
forward or backward from the passenger up to 20°.
Angled Views
Additional Information
The FD70ARM-G is made of all metal components. The milled aluminium arms represent
the evolution of several design enhancements for an optimum removable mounting
solution. As a dual LCD system, the FDARM-G was designed to be used with a base
receptacle; the FDBASE-2G. The following bases can be used: FDBASE-FL, FDBASE-
1G, FDBASE Ver SDI and the FDBASE.
The 7” Widescreen LCDs utilize a state of the art digital video decoding chipset for the
analog video input. The three video sources in order of picture quality are VGA
(computer graphics, like Moving Maps), and two Composite Video (DVD, Camera or
VCR). Both NTSC and PAL formats are auto-detected.
The FD70ARM-G can also be connected to existing video switchers and can take
composite video inputs from selector interface boxes. In this case, multiple input sources
can be selected and displayed on the monitors.
The FD70ARM-G is also available as a single unit in either the left or right configuration.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 5 of 18
Specifications
Display Type
7” TFT Color LCD
Supported Resolutions
640x480 ~ 1024x768
Display Brightness
450 cd/m
2
Contrast Ratio
500:1
Dimensions
6.80”(W) x 4.75”(H) x 1.20”(D)
LCD Dimension
6.00”(W) x 3.60”(H)
Mount Dimension
7” (W) x 3.9” (H) x 1.5” (D)
Total Weight (2 Display & Dual Base)
4.6 lbs.
Viewing Angle
140°/120°
Mount Type
Articulating Arm
Power
12VDC @ .6 Amps
28VDC @ .3 Amps
PC Video Input
VGA (Analog RGB 15 pin D-sub)
Standard Video Input
2 Composite Video
Video Type Supported
NTSC, PAL
Screen Control
On-Screen Display Menu
Remote Control
IR, included
Materials
Aluminum
DO-160 Testing
Section 21, Category B
Installation Instructions
All cabin entertainment equipment, such as the FD70ARM-G, should be installed on a
non-essential bus and have a dedicated circuit breaker. It is a requirement that a switch
be installed in the cockpit so that the pilot can de-energize the entertainment system
should it become necessary.
Power
The monitors in this dual system are 12-28VDC monitors that require 0.3 Amps (@28V) to
0.6 Amps (@12V) of power to operate.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 6 of 18
All manuals and user guides at all-guides.com
all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 7 of 18
Video Wiring Suggestions
All shields should be grounded to the connector at the source, and floating at the display.
Avoid routing video wiring parallel to:
•AC wiring
•Strobe wiring
•DC motor supply cables
•Inverter cabling
•Or any other potential noise source.
S-Video/Composite and Audio Wiring
Recommended cable for s-video and audio purposes is PIC 75 Ohm Coax, P/N V76261.
This is a lightweight, flexible, and low signal loss cable which meets FAA flammability
requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).
Similar aviation coaxial cable can be used from other vendors, as well.
Some aircraft are prone to AC noise - we recommend adding to the composite source a
75 Ohm video isolation transformer such as Deerfield Laboratory, Inc. Part No. 162-1
(www.deerfieldlab.com, [phone]). In most cases this should be added to the video
output of the source.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 8 of 18
VGA Wiring
Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded
cable containing 5 separate coaxial cables, color-coded to match the functions of the
wires.
We recommend coax cables be terminated using solder sleeve coaxial cable
terminators such as Raychem Part Number CWT-4174-W122-5/9.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 9 of 18
Power and Ground Wiring
This is a 28VDC monitor that requires 1.5 amps of power to operate. To operate properly
this monitor requires an input voltage of 18-29VDC.
The rated current of the equipment and associated voltage drop should be taken into
consideration when selecting wire gauge. The following example is based on an install
with a 28VDC power system and a total of 50 feet of wire between the circuit breaker,
monitor and ground.
Example: 22awg wire has 16.2 Ohms per 1000 feet, this equates to .81 Ohms for 50 feet.
1.5 Amps of current on .81 Ohms will drop 1.22 Volts.
Resistance of Wire Type M22759/16-**
(** = Gauge)
Gauge (AWG)
OHMS/1000’
24
26.20
22
16.20
20
9.88
16
4.81
12
2.02
10
1.26
8
.701
Also, use short heavy gauge wire and a clean tight connection for ground.
It is the installer’s responsibility to understand the product’s requirements to install the
product in compliance with industry standards and safety.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 10 of 18
Pinout for High Density DB-15 Receptacle
Connector P/N: M24308/2-286 or Equivalent
Crimp Contacts P/N: M39029/57-354 or Equivalent
Pin
Number Description
1 12-28VDC Power
2 12-28VDC Ground
3
N/C
4
Composite Video 1 - Signal
5 Composite Video 1 - Shield
6 N/C
7
Composite Video 2 - Signal
8
Composite Video 2 - Shield
9 Red Video (Pin 1 on Standard VGA)
10 Green Video (Pin 2 on Standard VGA)
11
Blue Video (Pin 3 on Standard VGA)
12
Red Ground (Pin 6 on Standard VGA)
13
Green Ground (Pin 7 on Standard
VGA)
14
Horizontal Sync (Pin 13 on Standard
VGA)
15
Vertical Sync (Pin 14 on Standard
VGA)
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 11 of 18
For Use with the Select CMS
Supplied mounted in Arm Mount
Connector P/N: M24308/2-286 or Equivalent
Crimp Contacts P/N: M39029/57-354 or Equivalent
Pin
Number
Description
1
28VDC Power
2
28VDC Ground
3 N/C
4 N/C
5
N/C
6
N/C
7 N/C
8 N/C
9
Video Red (-) (T568B Cat5 Pin 1)
10
Video Red (+) (T568B Cat5 Pin 2)
11 Video Blue (-) (T568B Cat5 Pin 3)
12 Video Blue (+) (T568B Cat5 Pin 6)
13
Video Green (-) (T568B Cat5 Pin 5)
14
Video Green (+) (T568B Cat5 Pin 4)
15 Video Ground (T568B Cat5 Pin 8)
Note: Cat5 Pin 7 is not used
All manuals and user guides at all-guides.com
all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 12 of 18
Pin out for P1 (5W1 Combo-D Female Receptacle)
Supplied, mounted in FDBASE Ver SDI
Connector P/N: Conec – 3005W1SM99A10X
Coax Contact P/N: Conec – 132J30029X (for use with RG179)*
*Other cable type contacts available from Conec
MATING FACE
Pin
Number
Description
1 28VDC Power
2 28VDC Ground
3 N/C
4
N/C
A1 HDSDI IN
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 13 of 18
Operation Instructions
The FD70ARM-G is continuously on but can be de-energized by removing power from
the entertainment system. No pilot or aircrew action is necessary during flight or ground
operation. Passengers can change the video output from the FD70ARM-G using the
video source select switch on the LCD monitor, or remotely throughout the cabin with the
included IR remotes.
Monitor Control Buttons
BUTTON
FUNCTION
DESCRIPTION
1
POWER
Press to turn the monitor on if currently off. Hold to turn the monitor off.
2
SOURCE
Press to switch between sources.
3
UP
Press to increase the value of a menu item.
4
DOWN
Press to decrease the value of a menu item.
5
MENU
Press to activate Menu.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 14 of 18
Technical Drawing
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 15 of 18
Troubleshooting
Video Noise
Check for an incorrect ground in the installation wiring. See specific examples of video
noise below, or visit http://flightdisplay.com/Grounding.pdf
VGA Shadowing
Most of shadowing problems are due to shielding on the wire. Locate the point where all
of the shields are connected. Cut away the shields, one at a time, while viewing the
display on the screen to observe which shield is causing the noise. Cutting away one
shield at a time will allow you to focus and isolate the video noise issue.
•Twisted pair wiring is prone to video noise. ECS VGA Wire (Detailed under “Video
Wiring Suggestions”) is recommended.
Snow or Sweeping Lines
Lines that slowly sweep up and down are a result of AC noise. This AC noise can be
generated by a power cart on the aircraft. Take the power cart off of the aircraft. Be
careful of inverter wiring, which can also cause noise. Stand off the wires, if necessary.
If snow or sweeping lines persist, it is possible that the ground is at an incorrect point in
the aircraft. Try moving the ground to another location.
No power to Monitor, or No video Input
•Verify correct wiring. Check the base receptacle connectors for possibly damaged
pins.
•Check that the video source is:
1. Powered on,
2. In Play mode, and
3. Displaying video.
Color Distortion
•Adjust brightness and contrast settings using the buttons on the monitor.
Remote Control Inoperable
•Confirm that the infrared eye on the LCD screen is visible.
•Replace battery in remote control.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 16 of 18
Technical Support
Should you have any questions concerning this product or other Flight Display Systems
products, please contact our Product Support representatives at [phone].
Flight Display Systems
1765 Grassland Parkway
Alpharetta, GA 30004
Phone: [phone]
Fax: [phone]
Email: [e-mail]
For further product information, technical data and sample wiring diagrams, please click
on the Dealers section of our web site at www.flightdisplay.com
All manuals and user guides at all-guides.com
all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 17 of 18
Instructions for Continued Airworthiness
The FD70ARM-G is designed not to require regular general maintenance.
Warranty Information
Flight Display Systems warrants the FD70ARM-G against material or manufacturing
defects for a *two-year period. Warranty begins on date of installation. *The warranty
registration card must be returned upon installation in order to validate the two-year
warranty. Any warranty registration not returned during this time period will default to the
date of purchase as the warranty start date.
If product support is required, please call our Technical Support team at 678-867-6717 to
obtain assistance. If the return of the unit to the factory is required, an RMA number will
be issued at that time. Flight Display Systems will, upon receipt of the failed hardware,
remanufacture or replace the unit at our discretion.
Flight Display Systems will pay Ground Shipping charges for warranted items. Charges
for express shipment will be the responsibility of the sender.
This warranty is not transferable. Any implied warranties expire at the expiration date of
this warranty. We shall not be liable for incidental or consequential damages.
This warranty does not cover a defect or failure that has resulted from improper or
unreasonable installation, use or maintenance, as determined by Flight Display Systems.
This warranty is void if there is any attempt to disassemble or open this product without
factory authorization.
Any labor charges associated with the removal of product or related troubleshooting by a
firm other than Flight Display Systems or its designee will not be covered.
All manuals and user guides at all-guides.com

Document Number:
MAN – FD70ARM-G
Rev:
D
Revision Date:
04/11/2011
Page 18 of 18
Log of Revisions
Rev
Date
Page
Description
A
09/12/2007
---
---
B
02/26/2009
2,10
Updated specifications, warranty info
C
01/08/2010
1,2,5,6,7,11
Update picture, specs, pinout, monitor buttons, assembly drawing
D
04/11/2011
8
Added pinout for FD70ARM-G Ver SDI, updated VGA wiring
All manuals and user guides at all-guides.com
