Elo TouchSystems M467 Installation and operating instructions

U
Us se er r M Ma an nu ua al l / / I In ns st ta al ll la at ti io on n G Gu ui id de e
M
Mo od de el l N No o. . M M4 46 67 7
Warning! It will cause malfunction if the monitor is operating with unspecified power supply unit
or incorrect power voltage. Do not exposure this unit in the rain or moisture environment to reduce the
risk of fire or electric shock.
Content:
I. Introduction.............................................................................................................................1
Features....................................................................................................................................1
Unpack the monitor .................................................................................................................2
Ⅱ. Installation...............................................................................................................................3
I/O placement...........................................................................................................................3
To PC .......................................................................................................................................3
Touch driver.............................................................................................................................4
MSR (optional)........................................................................................................................6
Control Buttons........................................................................................................................8
Structure of OSD settings.........................................................................................................9
Ⅲ. For your safety........................................................................................................................10
Ⅳ. Support timing........................................................................................................................10
Ⅴ. Mechanical dimension............................................................................................................10
Ⅵ. FCC Warning Statement........................................................................................................11
Ⅶ. Product General Specification...............................................................................................12

Version. 1.0 1
I. Introduction
M467 is color TFT LCD monitor, integrate with ELO or TWN resistive touch, suitable for many types of
application. Optional MSR and 2nd display, please contact our regional distributor for further information.
¾Features
-Optimal display resolution 1024 * 768
-VESA 75 * 75 mm wall mount standard
-Durable and sturdy base design
-Optional 3 tracks Magnetic Strip Reader (MSR)
-Optional variety of 2nd display (8.4”)
-Adjustable viewing angel freely up to 90 degrees horizontally
-Low power consumption only 20W with CCFL backlight

Version. 1.0 2
¾Unpacking the monitor
-Put the monitor on a clean surface, make sure the box in upright position.
-Remove packing materials from inside of box.
Check accessory
Please make sure all the accessory are included:
Standard Items
a. b. c.
d. e. f.
Optional Items
a. b.
a. MSR b. 2nd display ( 8.4” )
a. LCD Monitor b. VGA cable
c. Touch driver / User Manual CD d. Touch cable (USB or RS232)
e. Power adaptor f. Power cable

Version. 1.0 3
Ⅱ. Installation
¾I/O placement:
1 DC JACK 2 DVI
3 VGA 4 USB B Type
5 Dual USB AType 6 RS232
7 RJ45(RS232)
¾To PC:
1. Connect VGAcable from monitor to PC
2. Connect USB touch cable to PC
3. Connect DC plug to monitor and the other side to wall outlet
1234567

Version. 1.0 4
¾Touch Driver installation：
TWN Touch：
1. Double click “setup.exe” from driver menu 2. Click “next” from welcome window
3. Click “next” from choose destination location window 4. Click “next” from ready to install the
program
5.Click“next”fromsetuptype 6.Click“finish”whensetupcompleted
Calibration procedures:
1. Double click “POS Touch+” icon to run calibration function
2. Follow 9 points linearity calibration procedures and save the data
3. Follow free draw calibration
4. Exit calibration menu
5. Reboot PC

Version. 1.0 5
ELO Touch：
1.Install ELO Touchscreen Driver 2. Click “Unzip” from WinZip
Self-Extractor-ELO_v463.exe
3. Click “next” from Select Language 4.Select Install Serial or USB Touchscreen
Driver
5.Click-on “Yes” after Installation 6.Click-on“Finish”
Calibration procedures:
1. Double click “Elo Touchscreen” icon to run calibration function
2. Follow 3 points linearity calibration procedures and save the data
3. Follow free draw calibration
4. Exit calibration menu

Version. 1.0 6
¾MSR installation (optional)：
Components of MSR Kit:
1. Slide the MSR into the right position of the System.
2. Fasten the screws (x2).
Screws
USB
MSR

Version. 1.0 7
¾Control Buttons
Auto Adjusting
a.) Pressing to execute AUTO-Adjusting function. This function will set the
monitor display area to the optimal position.
b.) Sometimes this function can't achieve the optimal effects. Please follow the
manual adjusting procedure.
Menu
When the light bar move other item, the key are used to select it, and read to adjust.
Press the MENU key to activate the On Screen Display (OSD). Press twice to turn
off the OSD. After 30 sec idle time, the OSD screen will automatically turn off.
Power Use the power switch to turn the power ON or OFF. We recommend to turn your
system power on first, then the LCD monitor.
Up
Down
a.) When OSD mode is activated (When “MENU” key is pressed). The two keys
areusedtoselecttheadjustmentitems.
b.) When adjustment item is selected, the two keys are defined to decrease or
increase the value of each selected item.

Version. 1.0 8
¾Structure of OSD settings:
First Level Second Level Third
Level Operating Procedure
Auto Adjust Press “UP” or “DOWN” to adjust H-phase &
H-position & V-position clock automatically.
Luminance Brightness Contrast
Exit
Press “UP” key to increase brightness, “DOWN” key to
decrease brightness.
Press “UP” key to increase contrast, “DOWN” key to
decrease contrast.
Geometry
H. Position
V. Position
Clock
Phase
Exit
Press “UP” key to shift screen right, “DOWN” key to
shift screen left.
Press “UP” key to shift picture upward, “DOWN” key
to shift picture downward.
Adjust sampling clock of analog to digital converter
until clock is equal to pixel frequency of video input.
By varying this “UP” “DOWN” control the exact
sampling time within the pixel can be adjusted.
9300K
6500K
5800K
User Preset
Red
Green
Blue
Exit
Color
Exit
Press “UP” or “DOWN” to choose three types of color
temperature 9300°k, 6500°k and user define.
OSD
H. Position
V. Position
OSD Timeout
Exit
Adjust OSD frame horizontal location, press “UP” key
to shift frame right, “DOWN” key to shift frame left ,
timeout and preset OSD.
Adjust OSD frame vertical location, press “UP” key to
shift frame upward, “UP” key to shift frame
downward , timeout and preset OSD.
Language
English
French
German
Italian
Spanish
Japanese
T. Chinese
S. Chinese
Press “UP” or “DOWN” to choose any one of the
following language, English, French, Germany, Italy,
Spain , Japanese, Traditional Chinese and Simplified
Chinese.
Recall Color Recall Recall All
Exit Recall the default value.
Miscellaneous
Sharpness
Display
Information
Exit
Press “UP” key to increase sharpness, “DOWN” key to
decrease sharpness.
Main
Menu
Exit

Version. 1.0 9
III. For your safety
1. When move the monitor, always switch off power and disconnect all cables to avoid any danger.
2. Please use the power and signal cables correctly when install or bend it.
3. In case of notice any abnormal smell or noise, please stop operation and call the nearest dealer or
service center.
IV. Support timing chart:
Timing
Mode
Reference
Standard Resolution Pixel MHz FH KHz FV Hz Interlace H Polarity
V
Polarity
Mode 1 VESA 1024×768 65.000 48.363 60.004 NO - -
Mode 2 VESA 1024×768 75.000 56.476 70.069 NO - -
Mode 3 VESA 1024×768 75.011 57.524 72.000 NO
Mode 4 VESA 1024×768 78.750 60.023 75.029 NO
V. Mechanical Dimension:
361,6
339,3
278,660,7
70,8 220
47,1
40 47,1
220
139,3
?58
35 67,55
118,57175,48

Version. 1.0 10
VI. FCC Warning Statement
WARNING
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Notice:
(1) AUnshielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied power cord by
used.
(2) Use only shielded cables to connect I/O devices to this equipment.
(3) Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

Version. 1.0 11
Product General Specification
Model M467 series
Color Black
Display size 15"
Active Area 304*228 mm
Optimal Resolution 1024*768
Color Arrangement RGB-stripe
LCD PANEL 250 cd/m² (typ)
Brightness With Touch 160 cd/m²
Contrast Ratio 600 : 1
Response Time 8 ms (typ)
160 degrees (H)
Viewing Angle 160 degrees (V)
Input Video Format VGA
Input Video signal connector D-Sub 15 pins/ DVI-D
I/O port DC JACK/DVI/VGA/USB B/USB A/
RS -232/RJ45
Power consumption 20W
Horizontal : 31.5 kHz~60.2 kHz
Input Frequency Vertical : 56.3Hz~75Hz
Power supply DC 12V +/- 10%
Operating : 0℃~40℃
Temperature Storage : -10℃~50℃
Operating : 20%~80%
Humidity Storage : 10%~90%
Touch Technology 5W Resistive touch
Certificate CE，FCC，LVD
Wall Mount VESA 75 * 75 mm
Optional items
Wall Mount Bracket
MSR 3 Tracks
2nd Display 8.4＂
