Flight Systems 56-0679-00 User manual

1. ThisproductisdesignedtoreplaceOnanpartnumber300-0679in12-voltsystems.
2. ThisboardisresetbyturningofftheRUN/STOPswitch.
3. Thekeyingslotsinthecircuitboardallowittobepluggedintoa12-voltsystemonlyandalso
preventimproperinsertionintotheconnector.Takecaretoaligntheslotsandthenpresstheboard
downuntilitisfullyseatedintotheconnector.
4. TheadjustmentrangeoftheOVERCRANKalarmtimedelayis20to75seconds.Adjustthe
OVERCRANKDELAY(R1)asneeded,turningclockwisetoincreasethedelay.Theadjustmentis
clearlymarked.
5. TheadjustmentrangeoftheLOWOILPRESSUREalarmtimedelayis8to30seconds.Adjustthe
LOOILP.DELAY(R5)asneeded,turningclockwisetoincreasethedelay.Theadjustmentisclear-
lymarked.Keepingthedelayasshortaspossiblewithoutfalsetrippingwillresultinmaximum
engineprotection.

6. TheIGN/FUELoutput(pin7)andtheALARMoutput(pin8)areeachratedat5Amps(relayrated
at10Amps)regardlessofsystemvoltage.Overloadsonthesecircuitscancausedamagetotherelay
contactsandcircuitboardtracesonoriginalOnanboards.Severedamagetotracesrendersthecir-
cuitboardnon-repairable.
 TheFlightSystemsproducthasaspecialfusiblelinkthatactsasafuseincaseofanoverload.This
featurehelpstopreventdamageandallowstheboardtoberepairedinsteadofdiscarded.
7. Allsensorinputshavelterstoimprovenoiseimmunityandhelppreventfalsealarms.
8. OlderOnanboardshavetin-platedcontactngersononesideonly.LaterOnanboardshavegold
platedcontactsonbothsidesoftheboardwhichensuresamorereliableconnection.TheFlight
Systemsproductalsohasgoldplatedcontactsonbothsides.
(See reverse for Warranty & other details)
Technical Support:
717-590-7330 8-4:30 ET, M-F)
Fax: [phone]
FLIGHT SYSTEMS
207 Hempt Rd, Mechanicsburg PA 17050
www.flightsystems.com
PRODUCT INFORMATION
Replacement for
Onan® P/N 300-0679
Engine Control Monitor 12V
FS P/N 56-0679-00
FEATURES and INSTRUCTIONS

Note: Always Refer to the Specic Generator Set Manual when Troubleshooting Problems.
ThisFlightSystemsmanufacturedreplacementgeneratorcontroliswarrantedtobefreefromdefectsinmaterialsand
workmanshipforaperiodoftwoyearsfromthedateitwassold.(This date appears on unit label)
FlightSystems’LimitedWarrantycoverstherepairorreplacementofdefectiveproductwithinthewarrantyperiod.It
doesnotcoverthecostofinstallation,orremovalcostsincurred,orpossibledamagetootherequipment(includingthe
generatororpartsthereof)asaresultofthisproduct.
FlightSystems(oritsauthorizedagent)shallreservetherighttodeterminethecauseofmalfunction.In the case if we
determine that it was due to abuse, misuse, improper installation, acts of nature (such as storms), failure to perform
recommended gen set maintenance procedure or problems elsewhere in the gen set, the warranty claim shall be disal-
lowed and established repair rates shall apply.Ship defective units directly to:
Flight Systems, 207 Hempt Rd. Mechanicsburg, PA 17050 - Attention: Warranty Repair
Please prepay all freight charges and note the nature of the failure, if known.
Return Policy:Unwanteditemsmay only be returned within 30 days of original purchase date.Refund/creditissued
shallbelessa25%peritemrestocking/re-testfeeaslongasunitisinnew,undamagedcondition.
Shippingchargesare
notrefundable.
REBUILDING SERVICE
Ifthisproductsuffersafailurewhenoutofwarranty,itcanberebuilt.AswithallGeneratorControlsRebuiltbyFlight
Systems,aOne-YearWarrantywillbeissued.Pleasecontactusforcurrentrebuildpricing.Ship units to:
Flight Systems, 207 Hempt Rd. Mechanicsburg, PA 17050 - Attn. Repair Dept.
Please prepay all freight charges and note the nature of the failure, if known.
TECHNICAL SUPPORT
Technical support is available by phone, fax or the internet for all Flight Systems products.
Phone: [phone] (8:00am - 4:30pm ET, M-F)
Fax: [phone] Web: http://www.ightsystems.com/tech_sppt.htm
WARRANTY POLICY
Replacement Onan® Controls Manufactured by FLIGHT SYSTEMS
OEM Part #
ONAN® 300-C859
ONAN® 300-0679, 0680
ONAN® 300-0681, 0682
ONAN® 300-0921/922, 300-1188
ONAN® 300-B1073, B944
ONAN® 300-1006, 1404, 1540
ONAN® 300-2604, 2605
ONAN® 300-2784, 2943
ONAN® 300-2880
ONAN® 300-3056, 3687
ONAN® 300-3763, 3764
ONAN® 300-4296, 4297
ONAN® 300-4320, 4923
ONAN® 300-4901, 4902
ONAN® 305-0782, 0809-01, 0851
305-0826, 305-0897, 305-0911
ONAN® 332-1268, 332-1956, 2045
Description
GEN SET CONTROL
ENGINE CONT. MNTR.
ENGINE CONT. MNTR.
TIME DELAY MODULE
RV GEN SET CONTROL
YD REGULATOR
ENGINE MONITOR (12 - 24V)
RV GEN SET CONTROL
VOLTAGE REGULATOR
RV GEN SET CONTROL
RV GEN SET CONTROL
ENGINE MONITOR (12 - 24V)
RV GEN SET CONTROL
RV GEN SET CONTROL
VOLTAGE REGULATOR
(RV & Mobile Commercial)
VR21 REGULATOR
We offer improved replacements for the following Onan® Controls
Controls Rebuilding Service
Flight Systems rebuilds over 200 differ-
ent Onan®, Kohler®, Generac®, Basler®,
ASCO®,Kato®,GE-Zenith®andotherGen-
erator&ATSControls.Rebuilt-Exchange
Serviceisoftenavailable.
WealsorebuildCruisair®,Kwickee®and
otherMarine&RVcontrols.Pleasecallor
seeourwebsiteforacompletelist.
Order Desk: 800-403-3728
(8-5:00 ET, M-F)
www.ightsystems.com
Other Generator Controls, Test and Monitoring Equipment:
SeeourwebsiteorcallaboutourModel540StandbyController,Model325GeneratorExerciseMonitor,“G-Man”&
“Point-Man”RVGenSetServiceToolsorourlineofreplacementsforBasler,Newage,Marathon&otherregulators.
