FLORABEST FGS 3.6 A1 User manual

®
CORDLESS GRASS & SHRUB TRIMMER
FGS 3.6 A1
IAN 280350
AKKU-GRAS- UND STRAUCHSCHERE
Originalbetriebsanleitung
CORDLESS GRASS & SHRUB TRIMMER
Translation of the original instructions
BATTERIDREVET MULTIKLIPPE
Oversættelse af den originale driftsvejledning
COUPE-BORDURES/
TAILLE-HAIES SANS FI
Traduction des instructions d‘origine
GRAS- EN STRUIKTRIMMER
MET ACCU
Vertaling van de originele gebruiksaanwijzing
280350_flo_Akku Gras-und Strauchschere_cover_DK_BE_NL.indd 2 25.08.16 12:52

GB Translation of the original instructions Page
DK Oversættelse af den originale driftsvejledning Side
FR / BE Traduction des instructions d‘origine Page
NL / BE Vertaling van de originele gebruiksaanwijzing Pagina
DE / AT / CH Originalbetriebsanleitung Seite
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Avant de lire le mode d‘emploi, ouvrez la page contenant les illustrations et familiarisez-vous ensuite avec
toutes les fonctions de l‘appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
280350_flo_Akku Gras-und Strauchschere_cover_DK_BE_NL.indd 3 25.08.16 12:52
4
21
38
58
77

16
9
12
13
10
1
1
1 3
155 6
7
4
3
5
6
7
8
2
1
9
9
10
11
12
13
14
15
16

4
GB
Introduction
Congratulations on the purchase of your
new device. With it, you have chosen a
high quality product. During production,
this equipment has been checked for qual-
ity and subjected to a nal inspection. The
functionality of your equipment is therefore
guaranteed.
The operating instructions constitute
part of this product. They contain
important information on safety, use
and disposal.
Before using the product, familiarise
yourself with all of the operating
and safety instructions. Use the
product only as described and for
the applications specied. Keep this
manual safely and in the event that
the product is passed on, hand over
all documents to the third party.
Intended use
The unit is to be used for cutting and trim-
ming twigs on hedges, bushes and shrubs
and for trimming grass at the edges and
on smaller surfaces in domestic application
only.
The unit is only to be used by adults. Peo-
ple over 16 should only use this unit under
adult supervision.
Any other use not specically mentioned
in this manual can lead to damage to the
unit and may present a serious hazard to
the user.
The operator or user is responsible for ac-
cidents or damage to other persons or their
property.
This equipment is not suitable for commer-
cial use. Commercial use will invalidate the
guarantee.
Contents
Introduction .................................4
Intended use................................ 4
General description......................5
Extent of the delivery .......................5
Overview.......................................5
Function description.........................5
Technical data..............................6
Safety Instructions........................6
Symbols.........................................6
General safety instructions
for power tools ...............................7
Special Safety Directions for
the cordless grass & shrub cutter .....10
Safety Directions
for the battery charger...................12
Charging process .......................13
Operation ..................................14
Switching on and off .....................14
Inserting/replacing the blade .........14
General working instructions ..........14
Use as a grass trimmer ..................15
Use as a hedge trimmer.................15
Cleaning/Maintenance ...............15
Storage...................................... 16
Disposal and the environment.... 16
Telescopic arm as an accessory ..17
Assembling the telescopic arm........17
Adjust the height
of the telescopic arm .....................17
Adjusting the working angle...........17
Switching on and off
(with telescopic arm) .....................17
Working with the telescopic arm.....17
Spare parts/Accessories.............18
Trouble shooting ........................18
Guarantee .................................19
Repair Service............................ 20
Service-Center............................ 20
Importer .................................... 20
Translation of the original EC
declaration of conformity......... 100
Exploded Drawings..................101

5
GB
The manufacturer will not be held respon-
sible for damage or injuries caused by use
outside that stipulated by the manual or by
improper handling.
General description
The illustration of the princi-
pal functioning parts can be
found on the front and back
foldout pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete.
Dispose of the packaging material cor-
rectly.
- Device with mounted grass shear
blade, blade guard, safety key
- Shrub shear blade + blade guard
- Recharger
- Instruction Manual
Device is delivered without a
telescopic arm. Alternatively, a
telescopic arm including wheels
can be ordered (see “Spare parts/
accessories”).
Overview
Equipment
1 Cutter head
2 Switch lock, unit
3 Lever to turn the cutter head
4 Unit handle
5 Charging socket + plug socket for
plug connection telescopic arm
6 Charge display (LED)
7 Safety key
8 On/off switch, unit
Cutter
9 Grass cutter blade
10 Unlock buttons
for grass cutter blade
11 Blade guard
for grass cutter blade
12 Shrub shear blade
13 Unlock buttons
for shrub shear blade
14 Blade guard
for shrub shear blade
Battery charger
15 Power supply unit
16 Recharger cable plug
17 Telescopic arm with wheels
(not included in the scope
of delivery)
18 Guide rail
19 Equipment holder
20 Plug connection
21 Adjusting screw
for length adjustment
22 Release switch
23 Switch lock, telescopic shaft
24 On/off switch, telescopic shaft
Function description
The cordless grass & shrub trimmer is a
combination unit with two interchangeable
cutting devices. These are coated with plas-
tic (Teon non-stick coating) to prevent rust.
For use as a shrub trimmer, a double-sided
blade block is used as the cutting head.
The catching blades are round off at the
side to prevent accidents, and positioned
in an offset arrangement to reduce the
risk of injury. A cutting head with several
blades is provided for use as a grass trim-

6
GB
mer. The safety key protects the devices
from being started unintentionally.
Please read the following descriptions for
the function of the various controlling parts
of the unit.
Technical data
Unit
Motor voltage............................ 3.6 V
Rated speed ..........................1000 min-1
Protection class ................................... III
Protection category.......................... IP21
Grass-trimming blade
Cutting width............................73 mm
Blade width..............................80 mm
Shrub-trimming blade
Cutting length ........................120 mm
Dist ance between teeth...approx. 8 mm
Weight (incl. accessories) .. approx 0.85 kg
Sound pressure level
(LpA)....................55.1 dB(A), KpA=3 dB
Sound power level (LWA)
guaranteed ...........................92 dB(A)
measured...........75.1 dB(A); KWA=3 dB
Vibration (ah)
at handle ...........1.2 m/s2, K=1.5 m/s2
Battery (Li-Ion)
Nominal voltage......... 3.6 V 1.3 Ah
Loading time .................. approx. 3-5 h
Charger................. JLH030600400G
Voltage input ....... 100-240 V~, 50-60 Hz
Nominal consumption...................... 8 W
Voltage output ..................................6 V
Recharging current .....................400 mA
Protection class ............................... II
Protection category...........................IPX0
The noise and vibration levels have been
calculated according to the norms stated
in the conformity statement. Technical and
optical alterations to serve progress may be
made without notice. All measurements, in-
structions and other data given in this man-
ual are therefore given without guarantee of
correctness. Legal claims made on the basis
of this manual are therefore excluded.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another. The stated
vibration emission value may also be used
for a preliminary exposure assessment.
Warning: The vibration emission
value may differ during actual use of
the power tool from the stated value
depending on the manner in which
the power tool is used.Safety precau-
tions aimed at protecting the user
should be based on estimated expo-
sure under actual usage conditions
(all parts of the operating cycle are
to be considered, including, for ex-
ample, times during which the power
tool is turned off and times when the
tool is turned on but is running idle).
Safety Instructions
This unit can cause serious in-
jury if not used correctly. Be-
fore using the unit, carefully
read through the instruction
manual and familiarise your-
self with all of its controls.
Symbols
Symbols on the unit
Before using for the rst time, care-
fully read through the user manual.
Attention!

7
GB
Remember that the cutting equip-
ment will continue to move after
switching the unit off.
Do not use the unit during rain, bad
weather damp surroundings or on
wet grass or hedges.
Danger due to materials blown out
of machine!
Remove persons in the vicinity from
the danger area.
dB
LWA Guaranteed sound power level
III
Protection class III
Cutting length Shrub shear blade
Do not dispose of the device
with the battery installed in
household waste.
Symbols on the recharger
Read the manual.
Pole orientation
The recharger is for indoor use
only.
Protection class II
Machines do not belong with do-
mestic waste.
Disconnect the power plug from
the socket when the power cable is
damaged or entangled and before
maintenance and repair work.
Symbols in the manual
Warning symbols (instead of
the exclamation mark, the
danger may be explained)
with information on damage
and injury prevention.
Instruction symbols (the instruction
may be explained at the place of
the exclamation mark) with informa-
tion on preventing damage.
Help symbols with information on
improving tool handling.
General safety instructions
for power tools
WARNING! Read all safety direc-
tions and instructions. Omissions
in the compliance with safety directions
and instructions can cause electrical
shock,  re and/or severe injuries.
Retain all safety directions and in-
structions for future use.
The term “Power Tools” used in the safety
instructions refers to mains-operated power
tools (with power cord) and to battery-op-
erated power tools (without power cord).
1) WORK AREA SAFETY
a) Keep work area clean and well
lit. Cluttered or dark areas invite ac-
cidents.
b) Do not operate power tools in
explosive atmospheres, such as
in the presence of  ammable
Iiquids, gases or dust. Power tools
create sparks which may ignite the
dust or fumes.

8
GB
c) Keep children and bystanders
away while operating a power
tool. Distractions can cause you to
lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match
the outlet. Never modify the
plug in any way. Do not use
any adapter plugs with earthed
(grounded) power tools. Unmodi-
ed plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with
earthed or grounded surfaces,
such as pipes, radiators, ranges
and refrigerators. There is an
increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to
rain or wet conditions. Water
entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never
use the cord for carrying, pulling
or unplugging the power tool.
Keep cord away from heat, oil,
sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a
damp location is unavoidable,
use a residual current device
(RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense
when operating a power tool.
Do not use a power tool while
you are tired or under the inu-
ence of drugs, alcohol or medi-
cation. A moment of inattention white
operating power tools may result in
serious personal injury.
b) Use personal protective equip-
ment. Always wear eye protec-
tion. Protective equipment such as dust
mask, non-skid safety shoes, hard hat,
or hearing protection used for appro-
priate conditions will reduce personal
injuries.
c) Prevent unintentional starting.
Ensure the switch is in the off-
position before connecting to
power source and/or battery
pack, picking up or carrying
the tool. Carrying power tools with
your nger on the switch or energising
power tools that have the switch on
invites accidents.
d) Remove any adjusting key or
wrench before turning the pow-
er tool on. A wrench or a key left at-
tached to a rotating part of the power
tool may result in personal injury.
e) Do not overreach. Keep proper
footing and balance at all times.
This applies especially when
working on slopes. This enables
better control of the power tool in unex-
pected situations.
f) Dress properly. Do not wear
loose clothing or jewellery.
Keep your hair, clothing and
gloves away from moving
parts. Loose clothes, jewellery or long
hair can be caught in moving parts.

9
GB
g) If devices are provided for the
connection of dust extraction
and collection facilities, ensure
these are connected and prop-
erly used. Use of dust collection can
reduce dust-related hazards.
h) Walk when holding the device
in your hand. Do not run.
i) Do not touch any of the dange-
rous moving parts before you
have removed the battery and
all moving parts have come to a
complete standstill. There is a risk
of injury.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool
will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the
switch does not turn it on and
off. Any power tool that cannot be
controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the
power source and/or the bat-
tery pack from the power tool
before making any adjust
-ments, changing accessories, or
storing power tools. Such preven-
tive safety measures reduce the risk of
starting the power tool accidentaIly.
d) Store idle power tools out of the
reach of children and do not al-
low persons unfamiliar with the
power tool or these instructions
to operate the power tool. Power
tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check
for misalignment or binding
of moving parts, breakage of
parts and any other condition
that may affect the power tool’s
operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly main-
tained power tools.
f) Keep cutting tools sharp and
clean. Properly maintained cutting
tools with sharp cutting edges are less
Iikely to bind and are easier to control.
g) Use the power tool, accessories
and tool bits etc. in accordance
with these instructions, taking
into account the working condi-
tions and the work to be per-
formed. Use of the power tool for op-
erations different from those intended
could result in a hazardous situation.
5) CAREFUL HANDLING AND USE
OF BATTERY DEVICES
a) Charge the batteries only in
chargers that are recommended
by the manufacturer. Risk of re if a
charger that is suitable for a specic type
of battery is used with other batteries.
b) In the power tools, use only the
batteries designed for the pur-
pose. The use of other batteries may
result in injuries and risk of re.
c) Keep the unused battery away
from paper clips, coins, keys,
nails, screws and other small
metal objects, which could
cause bridging of the contacts.
A short circuit between the battery con-
tacts may cause burns or re.
d) If used incorrectly, liquid may leak
from the battery. Avoid contact
with this. In the event of accidental
contact, rinse off with water. If the
liquid gets into eyes, seek medical

10
GB
assistance. Leaking battery uid may
cause skin irritations or burns.
6) SERVICE
a) Have your power tool serviced
by a qualied repair person us-
ing only identical replacement
parts. This will ensure that the safety
of the power tool is maintained.
Special Safety Directions
for the cordless grass &
shrub cutter
1) SPECIAL SAFETY DIREC-
TIONS FOR HEDGE TRIM-
MERS
a) Keep all body parts away
from the blade. Do not
attempt to remove clip-
pings while the blade is
operating or to hold on
to material which is to be
cut. Only remove trapped
clippings when the tool is
switched off. One moment
of carelessness in the usage of
the hedge trimmer can lead to
severe injury.
b) Carry the hedge trimmer
at the handle with an idle
blade. Always pull on the
protective cover during
transport and storage of
the hedge trimmer.
Careful handling of the tool re-
duces the risk of injury from the
blade.
c) Hold the power tool only
on the insulated handle
surfaces, as the cutting
blade may come into con-
tact with concealed power
cables. Contact between the
cutting blade and a live cable
may render metallic compo-
nents live and result in an elec-
tric shock.
d) Before the work, search
the hedge for concealed
objects, e.g. cable etc. To
avoid damaging the equipment.
e) Hold the hedge trimmer
correctly, e.g. with both
hands on the handles, if
there are two handles.
Loss of control of the equipment
may result in injuries.
f) Wear suitable clothing
and work clothes when
working with the equip-
ment. Do not hold the
equipment by the cutting
blade or lift it on the cut-
ting blade. Contact with the
cutting blade can cause inju-
ries.
2) SPECIAL SAFETY DIREC-
TIONS FOR BATTERY-OPER-
ATED TOOLS
a) To reduce the electric
shock hazard, unplug the
battery charger from the
mains before cleaning the
charger.
b) Do not subject the battery
to strong sunlight over
long periods and do not
leave it on a heater. Heat
damages the battery and there
is a risk of explosion.
c) Allow a hot battery to
cool before charging.
d) Do not open up the bat-
tery and avoid mechanical

11
GB
damage to the battery.
Risk of short circuit and fumes
may be emitted that irritate the
respiratory tract. Ensure fresh
air and seek medical assistance
in the event of discomfort.
3) FURTHER SAFETY
DIRECTIONS
Warning! Children, individu-
als with limited physical, sen-
sory or mental capabilities,
as well as those who have
insuf cient experience or
knowledge or are not famili-
ar with the instructions must
never be permitted to use
the device. Local regulations
may specify an age restricti-
on for the user.
The device must never be
used if people – especially
children – or pets are nearby.
For your personal safety:
Wear suitable work clothes
such as boots with non-slip
soles, sturdy long trousers,
gloves and goggles. Hearing
protection must be used in
case the device is used over
prolonged periods of time.
Do not wear long  owing
clothing or jewellery, as this
may be caught by moving
parts. Do not use this tool
while walking barefooted or
while wearing open sandals.
a) Only switch on the tool
when hands, feet and all
other body parts are at
a secure distance to the
tool. Risk of injury from cuts.
b) Take care that you do not
injure your hands and feet
with the cutting elements.
c) Remove the power supply
unit before working with
the equipment. Do not
use extension cables. The
power supply unit is to be
used only in enclosed spa-
ces. Water entry increases the
risk of electric shock.
d) Do not use the shrub cut-
ter in combination with
the telescopic shaft. There is
a risk of cut wounds.
e) The tool is designed to trim
hedges. Do not use the
tool to cut branches, hard
wood or other. To avoid da-
maging the equipment.
f) Do not attempt to dislod-
ge a blocked/trapped
blade before switching
the tool off. There is a risk of
injury.
g) Always switch off the de-
vice  rst and remove the
safety key
- if you leave the tool unsuper-
vised
- before removing jams
- before control- maintenance-
or cleaning tasks
- if you have come into contact
with a foreign object
- whenever the machine starts
to vibrate uncontrollably
How to avoid accidents and
injuries.
h) In the case of an accident
or malfunction during
operation, the device must

12
GB
be switched off immedia-
tely. Injuries must be pro-
perly treated or medical
assistance sought. Read the
„Trouble shooting“ section to
correct any malfunctions or con-
tact our Service Centre.
i) Operation of the machine
in bad weather is to be
avoided, especially if the-
re is a risk of lightning.
There is a risk of personal injury
from an electric shock.
4) RESIDUAL RISKS
Even if properly operating and hand-
ling this electric tool, some residual
risks will remain. Due to its const-
ruction and build, this electric tool
may present the following hazards:
a) Cuts
b) Ear damage if working without
ear protection.
c) Eye damage if suitable eye pro-
tection is not worn.
d) Damage to your health caused
by swinging your hands and
arms when operating the appli-
ance for longer periods of time
or if the unit is not held or main-
tained properly.
Warning! During operation,
this electric tool generates an
electromagnetic eld which,
under certain circumstances,
may impair the functionality
of active or passive medical
implants. To reduce the risk of
serious or lethal injuries, we
recommend that persons with
medical implants consult their
doctor and the manufacturer
of their medical implant befo-
re operating the machine.
Safety Directions for the
battery charger
1) CORRECT HANDLING OF
THE BATTERY CHARGER
a) The charger must only be
connected to a mains socket via
a residual-current circuit breaker
(RCD) with a rated leakage cur-
rent of not more than 30 mA.
Fuse: at least 13 ampere.
b) To charge the battery, use
only the charger supplied.
Risk of re and explosion.
This ensures that the safety of
the device is maintained.
c) Before each use, check the
charger, cable and plug
and have them repaired by
qualied professionals and
only with original parts. Do
not use a defective charger
and do not open it up your-
self. This ensures that the safety
of the device is maintained.
d) Ensure that the mains vol-
tage matches the speci-
cations on the charger ra-
ting plate. Risk of electric
shock.
e) Disconnect the charger
from the mains before clo-
sing or opening connecti-
on to the battery / power
tool / device. This ensures
that the battery and charger are
not damaged.
f) Keep the charger clean
and away from wet and
rain. Do not use the char-

13
GB
ger outdoors. Dirt and the
entry of water increase the risk
of electric shock.
g) Operate the charger only
with the appropriate ori-
ginal batteries. Charging
other batteries may result in
injuries and risk of re.
h) Avoid mechanical damage
to the charger. This can result
in internal short circuits.
i) Do not operate the char-
ger on a combustible sur-
face (e.g. paper, textiles).
Risk of re due to heating du-
ring charging.
k) If the power cable for this
equipment is damaged, it
must be replaced by the
manufacturer, a customer
service agent of the same
or a similarly qualied per-
son in order to prevent hazards.
l) Do not use the charger to
charge non-rechargeable
batteries.
m)Do not connect a dama-
ged cable to the power
supply. Do not touch a da-
maged cable before it has
been disconnected from
the power supply, as you
could come into contact
with active parts.
Charging process
Do not expose the battery to
extreme conditions such as
heat and impact. There is a
risk of injury from leaking
electrolyte solution! In case
of contact, rinse with water
or neutraliser and consult a
doctor if contact has occurred
with eyes etc.
Charge the battery only in
dry areas.
Do not switch on the device
while charging it and make
sure that the safety key (
7) has been removed.
There is a risk of injury from
electric shock.
Ensure that the equipment is
charged for no longer than
3-5hours without interruption. The
battery and equipment could be
damaged and they consume energy
unnecessarily in case of longer
charging time. Overcharging invali-
dates the guarantee.
• The device may only be powered with
SELV (Safety Extra Low Voltage) as
marked on the device.
• Before initial use, charge the battery
installed in the equipment. Do not
charge the battery for several short pe-
riods in succession.
• Use the charger supplied to charge
the Li-ion battery installed in the equip-
ment.
• Recharge the battery if the equipment
runs too slowly.
• In all cases, observe the applicable
safety information as well as the regu-
lations and directions for environmen-
tal protection.
• Defects resulting from improper han-
dling are not subject to the guarantee.
1. Remove the safety key (7).
2. Connect the charger cable plug
(16) with the charger socket on
the tool (5).

14
GB
3. Connect the power supply unit
(15) to a socket.
The charging indicator (6) lights up:
Red: Equipment charging.
Green: Charging nished.
The recommended charging time
is max. 3 – 5 hours.
4. After the recharging process
is completed, rst unplug the
charger from the wall outlet, and
then remove the charger cable
plug (16) from the tool.
Operation
Keep to noise abatement regula-
tions and other by-laws.
Switching on and off
1. Remove the blade guard (11/14)
before switching the unit on.
2. Insert the safety key (7) into the
device.
3. To switch on, hold the switch
lock (2) depressed and operate
the on/off switch (8). Then re-
lease the switch lock.
The equipment runs at top
speed.
4. In order to switch off, let go of
the on/off switch (8).
After switching the unit
off, the blades take a short
time to stop moving. Let the
blades come to a complete
standstill. Do not touch the
blades or slow them down
before the moving parts have
come to a standstill.
Inserting/replacing the blade
Prior to each exchange of the
blades, make sure the device
is switched off and the safety
key and in order to avoid
danger and injuries!
Remove blade
1. Press the unlock buttons (10/13)
on the blade and remove the
entire blade.
Insert blade
2. Insert the grass shear blade (9) or
the shrub shear blade (12) into
the recess in the cutter head (1).
3. Press the blade into the direction
of the cutter head (1). It locks
into place audibly.
General working instructions
While trimming, take care that there
are no objects such as wire, metal
parts, stones etc. come into contact
with the blades. This can lead to
cutting head damage. If the blades
become blocked by solid objects,
switch off the unit at once.
• Check the grass and bush trimmer
blades for obvious defects such as
loose, worn or damaged parts. Check
that the screws are seated rmly in the
blade block.
• Remove the power supply unit ( 15)
before working with the equipment. Do
not use extension cables. The power
supply unit is to be used only in en-
closed spaces.
• Only use sharp blades to achieve a
good cutting performance and pre-
serve the battery.

15
GB
• Do not work the unit so hard that it
comes to a standstill.
• Pay attention to the instructions on unit
maintenance and cleaning.
Use as a grass trimmer
• Grass is best cut when dry and not too
long.
Adjusting the working angle
For a comfortable edge cut, the cutter head
(1) can be rotated by 90° to the right or left.
1. Operate the lever (3) and turn
the cutter head (1) into the de-
sired position.
2. Release the lever (3), the cutter
head locks into place.
Use as a hedge trimmer
• Move the unit forward evenly.
• The double-sided cutting heads enable
cutting in both directions or by swing-
ing the unit from side to side.
Cleaning/Maintenance
Leave any work not covered
in this manual to our Service
Centre. Only use original
parts. There is a risk of injury!
Ensure that the safety key ( 7) is
removed before all tasks.
Never use cleaning agents or sol-
vents, which can cause irreparable
damage to the unit. Chemicals can
attack the plastic components on
the unit.
Wear gloves when handling the
blades ( 9/12). There is a risk of
injury from cuts!
Clean and service the unit regularly as fol-
lows. This guarantees a long life for your
unit:
• Check the covers and guards for dam-
age and correct position. If necessary,
replace.
• Never operate the machine with defec-
tive guards or covers or without protec-
tion or with damaged or worn cables.
• Keep the ventilation slits, motor housing
and handles on the equipment clean. To
do this, use a damp cloth or brush.
• Always keep the blade clean.
After using the equipment, it is impera-
tive to:
- Clean the blade
(with an oily cloth);
- Oil the blade shaft
with an oil can or
spray.
• Slight notches on the blades can be
evened out. For this, sand down the
blades with an oil stone. Only sharp
blades can cut properly.
• Blunt, bent or damaged blades must
be changed.
We are not liable for damage caused by
the use of the unit if the original cause was
improper repair or the use of non-original
parts or through use other than that desig-
nated in this manual.

16
GB
Storage
• Keep the equipment in the blade guard
supplied, dry and out of reach of chil-
dren.
• Store the battery only in a partially
charged state. The state of charge
should be 40 – 60 % over a longer
storage period.
• Store the equipment between 10° C
and 25° C. During storage, avoid ex-
treme cold or heat so the battery does
not lose power.
• During a longer storage period, check
the state of charge of the battery and
recharge if necessary roughly every
3months.
Disposal and the
environment
Be environmentally friendly. Return the tool,
accessories and packaging to a recycling
centre when you have nished with them.
Machines do not belong with do-
mestic waste.
Do not dispose of the device
with the battery installed in
household waste, re (risk of
explosion) or water. Damaged
batteries may damage the envi-
ronment and your health if toxic
fumes or liquids leak out.
• Dispose of the equipment with the
battery discharged. Do not open the
equipment or the battery.
• Dispose of the equipment in accord-
ance with the local regulations. Take
the equipment to a collection point,
where it will be recycled in an environ-
mentally friendly manner. For informa-
tion about this, ask your local waste
management company or our service
centre.
• Defective units returned to us will be
disposed of for free.
• Place cut branches in compost and not
in the dustbin.

17
GB
Telescopic arm as an
accessory
Ensure that the safety key ( 7) is
removed before all tasks.
Caution! Device is delivered with-
out a telescopic arm. Alternatively,
a telescopic arm including wheels
can be ordered (see “Spare parts/
accessories”).
Assembling the telescopic
arm
Putting the telescopic arm
together:
1. Put both parts of the telescopic
arm (17) together and tighten
the screw.
Make sure that the cable is
not clamped.
Assembling/dismantling
the telescopic arm:
2. Push the device along the guide
rail (18) into the equipment hold-
er (19) of the telescopic arm. It
locks into place audibly.
3. Plug the plug connection (20)
into the charging socket (5) on
the back of the equipment han-
dle (4).
4. To dismantle, release the plug
connection (20). Press the unlock
button on the bottom side of the
equipment holder (19) of the tel-
escopic arm and pull the device
out (see small image).
Adjust the height of the tel-
escopic arm
Adjust the length of the telescopic
arm for your size with the help of
the adjusting screw (21).
Adjusting the working angle
For a comfortable edge cut, the equipment
holder (19) of the telescopic arm can be
rotated to the right or left (90°).
Set the desired position by pulling
the release switch (22) and rotating
the equipment holder (19) of the tel-
escopic arm. The equipment holder
locks into the desired position when
the release switch is released.
Switching on and off
(with telescopic arm)
1. Remove the blade guard (
11/14) before switching the de-
vice on.
2. Insert the safety key ( 7) into
the device.
3. To switch on, hold the switch
lock (23) on the handle of the
telescopic arm and simultaneous-
ly press the on/off switch (24).
Release the switch lock, device
runs at top speed.
4. To turn it off, release the on/off
switch (24).
Working with the telescopic
arm
• Slowly push the device on the wheels
over the oor. By doing so, you will
achieve an even cutting height.

18
GB
Spare parts/Accessories
Spare parts and accessories can be obtained at
www.grizzly-service.eu
If you do not have internet access, please contact the Service Centre via telephone
(see “Service-Center” page 20). Please have the order number mentioned below ready.
Item Description
Order No.
7 Safety key 91103520
9 Grass shear blade 13700005
11 Blade guard for grass shear blade 91103523
12 Shrub shear blade 13700023
14 Blade guard for shrub shear blade 91103524
15/16 Battery charger EU 80001064
17 Telescopic shaft with carrier 80002070
Trouble shooting
Problem Possible Cause Error correction
Device doesn‘t
start
Equipment is not charged Charge equipment (see „Charging
process“)
Switch lock ( 2) has not
been operated properly Switch on (see „Operation“)
On/off switch ( 8) may be
defective Repair by Service Centre
Safety key ( 7) not inserted Insert safety key (see "Operation")
Bad cutting results
Too much friction due to lack
of lubrication Lubricate blade ( 9/12)
(see „Cleaning/Maintenance“)
Dirty blade( 9/12) Clean blade (see „Cleaning/Main-
tenance“)
Blade ( 9/12) is blunt or
has nicks
Sharpen blade (see „Cleaning/
Maintenance“) or replace (see
„Spare parts/Accessories“)
Blade ( 9/12) is damaged Replace blade (see „Spare parts/
Accessories“)

19
GB
Guarantee
Dear Customer,
This equipment is provided with a 3-year
guarantee from the date of purchase.
In case of defects, you have statutory rights
against the seller of the product. These
statutory rights are not restricted by our
guarantee presented below.
Terms of Guarantee
The term of the guarantee begins on the
date of purchase. Please retain the original
receipt. This document is required as proof
of purchase.
If a material or manufacturing defect
occurs within three years of the date of
purchase of this product, we will repair or
replace – at our choice – the product for
you free of charge. This guarantee requires
the defective equipment and proof of pur-
chase to be presented within the three-year
period with a brief written description of
what constitutes the defect and when it oc-
curred.
If the defect is covered by our guarantee,
you will receive either the repaired product
or a new product. No new guarantee pe-
riod begins on repair or replacement of the
product.
Guarantee Period and Statutory
Claims for Defects
The guarantee period is not extended by
the guarantee service. This also applies for
replaced or repaired parts. Any damages
and defects already present at the time of
purchase must be reported immediately af-
ter unpacking. Repairs arising after expiry
of the guarantee period are chargeable.
Guarantee Cover
The equipment has been carefully pro-
duced in accordance with strict quality
guidelines and conscientiously checked
prior to delivery.
The guarantee applies for all material and
manufacturing defects. This guarantee
does not extend to cover product parts that
are subject to normal wear and may there-
fore be considered as wearing parts (e.g.
cutter bars and carbon brushes) or to cover
damage to breakable parts (e.g. switches,
batteries).
This guarantee shall be invalid if the prod-
uct has been damaged, used incorrectly or
not maintained. Precise adherence to all of
the instructions specied in the operating
manual is required for proper use of the
product. Intended uses and actions against
which the operating manual advises or
warns must be categorically avoided.
The product is designed only for private
and not commercial use. The guarantee
will be invalidated in case of misuse or
improper handling, use of force, or inter-
ventions not undertaken by our authorised
service branch.
Processing in Case of Guarantee
To ensure quick handling of you issue,
please follow the following directions:
• Please have the receipt and identica-
tion number (IAN 280350) ready as
proof of purchase for all enquiries.
• Please nd the item number on the rat-
ing plate.
• Should functional errors or other de-
fects occur, please initially contact the
service department specied below
by telephone or by e-mail. You will
then receive further information on the
processing of your complaint.

20
GB
• After consultation with our customer
service, a product recorded as defec-
tive can be sent postage paid to the
service address communicated to you,
with the proof of purchase (receipt)
and specication of what constitutes
the defect and when it occurred. In or-
der to avoid acceptance problems and
additional costs, please be sure to use
only the address communicated to you.
Ensure that the consignment is not sent
carriage forward or by bulky goods,
express or other special freight. Please
send the equipment inc. all accessories
supplied at the time of purchase and
ensure adequate, safe transport pack-
aging.
Repair Service
For a charge, repairs not covered by
the guarantee can be carried out by
our service branch, which will be happy to
issue a cost estimate for you.
We can handle only equipment that has
been sent with adequate packaging and
postage.
Attention: Please send your equipment to
our service branch in clean condition and
with an indication of the defect.
Equipment sent carriage forward or by
bulky goods, express or other special
freight will not be accepted.
We will dispose of your defective devices
free of charge when you send them to us.
Service-Center
Service Great Britain
Tel.: [phone]
(£ 0.10/Min.)
E-Mail: [email protected]
IAN 280350
Importer
Please note that the following address is
not a service address. Please initially con-
tact the service centre specied above.
Grizzly Tools GmbH & Co. KG
Stockstädter Straße 20
63762 Großostheim
Germany
www.grizzly-service.eu
GB
