Flowserve Automax Aviator Assembly instructions

LML0002-0 Page 1of 2
©Flowserve Corporation
Flowserve Corporation 11444 Deerfield Road Phone: [phone]
Flow Control Division Cincinnati, Ohio 45242 Facsimile: 513 489 5243
Automax Valve Automation Systems www.flowserve.com Email: [email protected]
Automax Aviator
TM
Installation, Operating & Maintenance Instructions
Figure 1
Figure 2
Mechanical Installation
Installation is best performed with the NAMUR
mounting kits. These kits allow direct mounting of
the Aviator™ shaft to the actuator pinion without a
coupler. The NAMUR mounting kits will work with
any actuator conforming to the NAMUR standard for
accessory mounting hole locations and pinion
dimensions. Simply attach bracket to actuator and
Aviator™ to bracket with the included fasteners. The
Aviator™ shaft features an integral alignment pin
which engages the tapped pinion hole. Automax
also offers a full line of non-NAMUR kits.
Electrical Connections
The Aviator™ features three (3) ½” NPT conduit
entries. The switches and pilot solenoid are wired to
a printed circuit board to simplify customer wiring
connections. A wiring diagram is included under the
lid. Simply make desired connections to the circuit
board using the attached screw terminal blocks.
Secure a grounding wire under the green grounding
screw. Make sure the solenoid control voltage is the
same as the solenoid electrical rating.
For hazardous locations, U.L. and National Electric
code require an approved sealing fitting within 18
inches of the switch enclosure. Sealing fittings are
not required for Division 2 non-incendive
applications. Open conduit entries must be closed
after installation using a close-up plug approved for
hazardous locations. Conduit and plugs must
engage a full five (5) threads.
Spool and Tubing Configuration
1. For spring return actuators, a 4-way spool valve
is provided with port #2 plugged. For double
acting actuators, the same valve is provided with
no plugs. Make sure the correct spool is
selected before installing tubing. (Note: the
APS2 module can be supplied on spring return
actuators to purge the spring chamber with
supply air.)
2. Make sure all air pressure is removed before
installing tubing.
3. Attach tubing according to Figures 1 or 2 below,
depending upon application. Attach supply
tubing to Port 1 and use 3 and 5 exhaust.
4. To prolong actuator life use only clean, dry plant
air. Lubricated air is not required, although it is
recommended particularly for high cycle
applications.
Switch Setting
1. Rotate actuator to desired position.
2. Loosen five captive cover screws and
remove lid, turning slightly while lifting.
3. To adjust the limits, lift or depress
cam against spring to disengage
splines and turn cam until switch
activates / deactivates as desired
(Figure 3).
4. Release cam, assuring that the
splines are engaged.
5. Clean base and lid flanges and
replace lid on base. Make sure wires
are NOT caught between flanges, and
tighten captive screws. Figure 3
Cam Adjustment
Caution
To prevent ignition of hazardous
atmospheres, keep cover bolts tight
while circuits are live. Disconnect
supply circuit before opening.
2
4
1
3
5

LML0002-0 Page 2of 2
©Flowserve Corporation
Flowserve Corporation 11444 Deerfield Road Phone: [phone]
Flow Control Division Cincinnati, Ohio 45242 Facsimile: 513 489 5243
Automax Valve Automation Systems www.flowserve.com Email: [email protected]
Automax Aviator
TM
Lubrication
All Aviator™ spool valves are pre-lubricated and
will operate dry (with no additional lubrication). The
use of lubricated air will not interfere with the
Aviator’s functioning.
If air lubrication is used, the oils listed below are
popular, easily obtainable fluids that are
recommended for use with the Aviator Spool
valve: Gulf Harmony 47, Mobil DTE Medium, Shell
Tellus 29, Texaco Rondo B, Sohivis 47 and Sunnis
921. Many other lubricants are acceptable providing
they do not contain detergents that will attack Buna
N or Viton Seals.
Item Part # Description Qty
1XM0268 Housing Base 1
2X00903 1/8” Muffler 1
3X00878 Spool Valve 1
4X00838 10-32 x 1 1/8 SHCS 3
5 1079352 Breather 2
6X00892 O-Ring 2
7X00814 O-Ring 1
8X00779 O-Ring 3
9X00837 1/8 x 2 Tubing 1
10A Varies 2 Watt Solenoid Pilot 2
11A 100158 4-40 x 1 PHS 1
12A X00893 O-Ring 1
13A XM0276 Manifold Block 1
10B Varies .67 Watt Solenoid Pilot 1
11B X00895 O-Ring 1
12B X00894 O-Ring 1
13B XM0292 Manifold Block 1
Bill of Material
Item Part # Description Qty
14 100167 8-32 x ½ PHS 4
15 X00410 1/8” Tube Fittings 2
16 X00410G Gasket 2
17 Varies Switch Card 1
18 105915 #6-32 x ¼ PHS 2
19 103627 Ground Screw 1
20 105626 Cup Washer 1
21 X00801 5/16-18 bolts 5
22 XM0269 Housing Cover 1
23 X00663 Rotor 1
24 X00677 O-Ring 1
25 X00662 Dome 1
26 X00676 #10-24 x ½ PHS 4
27 Varies Shaft Assembly 1
28 103603 O-Ring 2
29 101810 Snap Ring 1
