Fluke Biomedical 7010 User manual

PN 3255163 February 2008 ©2008 Fluke Corporation. All rights reserved. 1
7010
Selectable Defibrillator Load
Instruction Sheet
Introduction
The Impulse 7010 Selectable Defibrillator Load
(hereafter the Load) provides multiple loads of
25, 50, 75, 100, 125, 150, 175, and 200 ohms for
testing defibrillators. In conjunction with an
Impulse 7000DP Defibrillator Analyzer (hereafter
the Analyzer), it is designed for performance
testing of defibrillators. It is not intended to be
used for calibration of medical equipment.
XW Warning
To avoid possible electrical shock or
personal injury, follow these
guidelines:
•Use this instrument only in the
manner specified by the
manufacturer or the protection
provided may be impaired.
•Read the Instruction sheet before
operating the Load.
•Do not use the product if it operates
abnormally.
•Do not use the product in wet
locations, around explosive gases or
dust.
•Observe all precautions noted by the
Device Under Test (DUT) equipment
manufacturer when analyzing the
DUT.
•Use extreme caution when working
with voltages above 30 volts.
Table 1 lists the symbols found on the Load and
describes their meaning.
Table 2 shows the front-panel controls and
connectors of the Load.
Table 1. Symbols
Symbol Description
WImportant information; refer to manual.
~Do not dispose of this product as unsorted
municipal waste. Go to Fluke’s website for
recycling information.
;Conforms to relevant Australian EMC
requirements
)Conforms to relevant Canadian and US
standards
XHazardous voltage
PConforms to European Union directives
CAT I
IEC Measurement Category I – CAT I
equipment designed to protect against
transients in equipment on circuits not
directly connected to MAINS. Under no
circumstances should the terminals of the
Load be connected to any MAINS voltage.
Preparing for Operation
Connect the Load ouput connectors to the input
connectors of the Analyzer as shown in Figure 2.
As shown in Figure 1, the selectable resistors of
the Load are connected in series and/or parallel
with the load across the defib connectors of the
Analyzer. The various connection combinations
available through the rotary switch, provide eight
different loads for a defibrillator discharge.
Using the Load for Testing
To use the Load for a defibrillator test:
1. Select the desired defibrillator load by
moving the rotary switch to one of the eight
load settings.
2. Setup the Analyzer for use with the
selectable load by pressing Qand then
the More soft key. Then press Defib Load to

Selectable Defibrillator Load
Using the Load for Testing
2
select Ext Load. The selection is saved in
non-volatile memory for future use.
When running a defibrillator Energy, Sync, or
Charge Time test, press the Load softkey to
select the load using Gand H. When done,
press Load again to close the selection box.
Note
The selected load must be the same
value on both the Anaylzer and the
Load to get correct energy, voltage,
and current readings.
When set to 50Ω, the Load is bypassed and
the load inside the Analyzer is used for the
test. It is not necessary to remove the Load
when using the load within the Analyzer.
3. If using defibrillator paddles, place the
paddles firmly on the defib pads of the Load.
4. Run a defibrillator test in the regular way. For
all defibrillator test menus, the load value is
displayed on the top display line. The
selected load value is included in the energy,
voltage, and current calculations, so the data
shown is correct for that load.
5. Discharge the defibrillator and read the
results in the Analyzer’s display.
Table 2. Impluse 7010 Front-Panel Controls and Connectors
3
2
1
4
feo003.eps
Item Description Item Description
AOutputs to Analyzer CDefibrillator paddle pads
BRotary switch DBanana jacks for defibrillator connections

Selectable Defibrillator Load
Using the Load for Testing
3
DEFIBRILLATOR
5000
Vp MAX
275 V MAX
R2
50 Ω
R1
50 Ω
R3
50 Ω
R4
50 Ω
50 Ω
NC
Defibrillator Under Test
Fluke Biomedical
Impulse 7000DP
Fluke Biomedical
Impulse 7010
feo001.eps
Firgure 1. Impulse 7010 Load Schematic
OFF
DEFIB
PACER
+
+
+
+
Fluke Biomedical
Impulse 7000DP
Fluke Biomedical
Impulse 7000DP
Fluke Biomedical
Impulse 7010 Fluke Biomedical
Impulse 7010
OR
Defibrillator/Pacer
feo002.eps
Figure 2. Load Test Connections

Selectable Defibrillator Load
General Specifications
4
General Specifications
Maximum Voltage ................................................. 5000 V
Maximum continuous power...............................12 W, equivalent to 10 defib pulses of 360 J every 5 minutes.
Inductance............................................................. < 2 μH, @25 Ω
< 3 μH, @50 Ω
< 4 μH, @75 Ωand 100 Ω
< 5 μH, @125 Ω
< 6 μH, @150 Ω
< 7 μH, @175 Ω
< 8 μH, @200 Ω
Temperature
Operating Temperature ...................................... 10 °C to 40 °C
Storage Temperature ......................................... -20 °C to +60 °C
Humidity ................................................................ 10 % to 90 % non-condensing
Dimensions (HxWxL)............................................ 138.7 mm X 154 mm X 272 mm (5.46 in X 6.07 in X 10.71 in)
Weight (net)........................................................... 1.54 kg (3 lbs 6.2 oz)
Safety class........................................................... Complies with EN61010-1 2nd Edition, Class II product.
Safety and EMC marks......................................... P,),;
Warranty................................................................2 years, if calibrated at one year at a designated FBC service center. Otherwise, 1 year.
Calibration interval ............................................... 1 year
Electrical Specifications (for Load and Analyzer together)
Load settings ........................................................ 25, 50, 75, 100, 125, 150, 175, and 200 ohms ±1 %
Accuracy
Energy (All except Pulsed Biphasic)................... ±2 % of reading + 0.1J with 25, 75 through 200 ohm loads
±1 % of reading + 0.1J with 50 ohm load
Energy (Pulsed Biphasic) ................................... ±2.5 % of reading + 0.3J with 25, 75 through 200 ohm loads
±1.5 % of reading + 0.3J with 50 ohm load
Note
AC Pulsed Bi-Phasic waveform has not been approved in the United States.
Voltage................................................................±1 % of reading + 2 V with 25 and 50 ohms loads
±2 % of reading + 2 V with 75 through 200 ohm loads
Current................................................................ ±2 % of reading + 0.1 A with 25 ohm load
±1 % of reading + 0.1 A with 50 through 200 ohm loads
Replaceable Parts
Table 3 lists the replaceable parts for the Load. To contact Fluke, visit Fluke’s web site at
www.fluke.com or call one of the following numbers.
USA and Canada: 1-888-99-FLUKE (1-888-993-5853)
Europe: [phone]
Japan: [phone]
Table 3. Replaceable Parts
Description Fluke PN
Defibrillator Plates Assembly 3156262
Cable Assembly, Right Angle, (Red) 3187040
Cable Assembly, Right Angle, (Black) 3187057

5
Cleaning the Analyzer
WCaution
Do not pour fluid onto the Load
surface; fluid seepage into the
electrical circuitry may cause the
Load to fail.
WCaution
Do not use spray cleaners on the
Load; such action may force cleaning
fluid into the Load and damage
electronic components.
Clean the Load occasionally utilizing a damp
cloth and mild detergent. Take care to prevent
the entrance of liquids.
Wipe down the adapter cables with the same
care. Inspect them for damage and deterioration
of the insulation. Check the connections for
integrity.
