Fluke Reliable Power Meters 1941 User manual

Multipoint Power Recorder®
Installation Guide
PN 2010675
December 2003 Rev.3, 1/04
© 1999, 2000, 2004 Fluke Corporation. All rights reserved. Printed in USA
All product names are trademarks of their respective companies.

i
WARNING
The Multipoint Power Recorder is for use by
qualified personnel only. Do not install the
Multipoint on a power line unless you are
qualified to do so. High voltages that can cause
burns and lethal shocks are present during power
monitoring.
To assure operator safety: When making
connections to power lines, always start by
connecting the instrument power, which contains
the safety earth ground. Be sure to provide
adequate strain relief for wires going to the
terminal blocks.
Use standard high-voltage, high-current safety
precautions.
Workers who open energized power panels are
required to abide by the instructions of
ANSI/NFPA 70E-1988 [B2] concerning
appropriate protective equipment, as well as
government regulations codified in ASHA CFR
1910 [B3] and 1926 [B4], and in ANSI C2-1990
[B1].
CAUTION
Communications and digital data connections to
the Multipoint Power Recorder must be made
with low voltage shielded computer data cables
and compatible components must be used.

ii
RADIO
INTERFERENCE
STATEMENT
INFORMATION
FOR THE USER
This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case
the user will be required to correct the interference
at his own expense.
The user may find the following publication
prepared by the Federal Communications
Commission helpful:
“How to Identify and Resolve Radio-TM
Interference Problems” (Stock Number 004-000-
00345-4).
Available exclusively from the Superintendent of
Documents, Government Printing Office,
Washington, DC 20402 (telephone [phone]).
FCC
WARNING
Changes or modifications not expressly approved by
the party responsible for compliance to Part 15 of
the FC Rules could void the user’s authority to
operate the equipment.
INDUSTRY
CANADA
ICAN CLASS A
DIGITAL
EQUIPMENT
This digital apparatus does not exceed the Class A
limits for radio noise emissions from digital
apparatus as set out in the interference-causing
equipment standard entitled “Digital Apparatus,”
ICES-003 of the Industry Canada.
Cet appareil numerique respecte les limites de bruits
radioelectriques applicables aux appareils
numeriques de Classe A prescrites dans la norme sur
le materiel brouilleur : “Appareils Numeriques,”
NMB-003 edictee par le minstre des
Communications du Canada.

iii
Trademark Information
The "r" logo and InSite Power Recorder are registered trademarks of
Fluke Corporation. Reliable Power Meters, Full Disclosure, PR/Link,
Scenario, and Power Recorder are trademarks of Fluke Corporation.
Technical Support
For technical support, contact Fluke Power Quality at:
Address: Fluke Corporation
1201 Shaffer Road
P.O. Box 1820
Santa Cruz, CA 95061-1820
Voice: In the US and Canada 888-257-9897
Other countries 831-458-4281
Fax: [phone]
E-mail [email protected]
Web site http://www.reliablemeters.com

iv
Table of Contents
Preface................................................................................. vi
Warning Symbols on the Multipoint Power Recorder ..................vi
Introducing the Multipoint Power Recorder....................... 1
Before You Install................................................................. 4
Installing the Multipoint Power Recorder........................... 5
Installing the Multipoint with Acquisition Unit Model 1941
or 1948 .................................................................................. 6
Overview of the Installation Process ................................................6
De-energizing Relevant Power...........................................................7
Mounting the Multipoint Base Unit ..................................................8
Connecting the Safety Ground...........................................................9
Connecting to the Meter Power Source .........................................10
Connecting to Voltage.......................................................................12
Connecting to Current .....................................................................14
Wiring Diagrams.................................................................................15
Connecting Ethernet ......................................................................16
Checking Connections Before Restoring Power...........................17
Restoring Power..................................................................................17
Putting the Acquisition Unit in Place..............................................18
What Next?..........................................................................................19
Installing the Multipoint with Acquisition Unit Model 1942
or 1949 ................................................................................ 20
Overview of the Installation Process ..............................................20
De-energizing Relevant Power.........................................................21
Mounting the Multipoint Base Unit ................................................22
Connecting the Safety Ground.........................................................23
Connecting to the Meter Power Source .........................................24
Connecting to Voltage.......................................................................26
Wiring Diagrams.................................................................................27
Checking Connections Before Restoring Power...........................29
Restoring Power..................................................................................29
Putting the Acquisition Unit in Place..............................................30
Connecting to Current Using Reliable Power Meter Current
Clamps ..........................................................................................32
What Next?..........................................................................................33

v
Confirming Connections and Finishing Up...................... 34
Check the Range Lights (LEDs) for Current.................................34
Check the Range Lights (LEDs) for Each Voltage.......................35
Make Sure Voltage Phases and Current Phases are Paired
Correctly .......................................................................................35
Checking Connections Through Software .....................................35
Checking Voltage and Current Pairing............................................36
Checking for Ground and Neutral Current Connections............36
Configuring the Multipoint...............................................................37
Finishing Up........................................................................................38
What Next?..........................................................................................38
Appendix A. Multipoint Specifications ............................. 39
Appendix B. Current Clamps............................................. 42
Appendix C. Wiring Diagrams ........................................... 45
Appendix D. Ethernet Wiring............................................. 49

vi
Preface
This guide describes the Multipoint Power Recorder and tells you how
to install it and connect it to power.
After installation you will need to connect it to a computer running
either the Power Recorder System Software or the Scenario software,
and then configure the Multipoint. Configuration tells the Multipoint
the specific type of power to be monitored at the installation location
and sets the initial monitoring intervals and other settings. For details
about configuring the Multipoint Power Recorder, see the Power
Recorder System User Guide or the Scenario User Guide.
Warning Symbols on the Multipoint Power
Recorder
Two warning symbols appear on the Multipoint Power Recorder.
When you see
this symbol It means
There is a risk of electric shock.
This symbol appears adjacent to the
power and voltage measuring terminals.
Attention—consult accompanying
documents (this Multipoint Power Recorder
Installation Guide) for information.
This symbol appears adjacent to:
Voltage measuring terminals (pages 12 and 26)
Communication port (pages 16 and 28)
Current measuring terminals (page 14)
Internal battery (page 40)

1
Introducing the Multipoint
Power Recorder
The Multipoint Power Recorder is designed for permanent or semi-
permanent installation of a Power Recorder in a non-hostile
environment. The Multipoint provides the same quality and features of
other Reliable Power Meters power recorders at a lower cost.
Lethal voltages are present. In order to ensure
safety the Multipoint Power Recorder must be
installed in a protective enclosure that limits access
to the electrical connections of the device and
requires a tool or key for such access. Multipoint
Power Recorders are not weatherproof. If you need
a weatherproof unit, contact Reliable Power Meters
about obtaining a Power Recorder with a Hostile
Environment Enclosure.
The Multipoint Power Recorder actually contains two units—a Base
Unit, and an Acquisition Unit, as shown on page 2. The base unit can be
installed permanently—bolted to a wall, shelf, or panel—while the
Acquisition Unit is removable to allow for repair or calibration, if
necessary, without having to unwire anything or even turn the power off.
Several different models of base and acquisition units are available.
Description Model # 1
Base Unit Multipoint base with internal metering CTs 1950
Multipoint low-speed acquisition unit for use
with CTs embedded in Base Unit
1941
Acquisition
Units
Multipoint hi-speed acquisition unit for use
with CTs embedded in Base Unit
1948
Multipoint low-speed acquisition unit for use
with Reliable Power Meters current clamps
1942
Multipoint high speed acquisition unit for use
with Reliable Power Meters current clamps
1949
1NOTE: The first four digits of the serial number on the Acquisition Unit
indicate the “model” number.

Introducing the Multipoint Recorder
2
The Multipoint Base Unit
ABCNG+-
LNG-+
The Multipoint Acquisition Unit
CAUTION:
Riskofelectricshockdonotremovecover.
Refertoservicingtoqualifiedservicepersonnel.
VOLTAGE
CURRENT
ReliablePowerMeters
LosGatos,CA95032
Phone[phone]
Guide pins slide into
the back of the
Acquisition Unit.
These thumb screws
are used to tighten
the Acquisition Unit
onto the Base Unit.

Introducing the Multipoint Recorder
3
Combining the Base and Acquisition Units
CAUTION:
Riskofelectricshockdonotremovecover.
Refertoservicingtoqualifiedservicepersonnel.
VOLTAGE
CURRENT
ReliablePowerMeters
LosGatos,CA95032
Phone[phone]
ABCNG+-
LNG-+
The Multipoint System Front View
CAUTION Risk of electric shock, do not remove cover.
Refer servicing to qualified service personnel. Made in U.S.A
C
VOLTAGE
A
B
CURRENT
N B A C G
ETHERNET
DIGITALI/OPORT 2
1
18
17
PORT
20Amax.
C
ACCURRENT
A
RMS
B
N
G
ACVOLTAGEINPUT
600Vmax.
RMS
ABCNG
METERPOWER
N
VoltsAC100-240V
50/60Hz,40VAmax.
L
VoltsDC10-15Vdc40W
RMS
Phone [phone]
Los Gatos, CA 95032
Reliable Power Meters
Note: If you’re using an Acquisition Unit model 1942 or 1949 with
connections for Reliable Power Meter current clamps, you will not use
the current connections shown above.
Meter power
c
onn
ec
tion
Voltage
connection
Current
connection
(internal)
(Factory use
only. DO NOT
connect.)
Ethernet
connection
to computer
or network (Factory use
only. DO NOT
connect.)
Safety ground

Installing the Multipoint:
Before You Install
4
Before You Install
Installation Considerations
Before installing your Multipoint Power Recorder, be sure to consider
the following:
1. Location: The Multipoint Power Recorder must be installed
according to applicable electrical codes. When choosing an
installation location, keep in mind that you may need to supply a
suitable enclosure, conduit, and other materials.
2. Instrument Power: The Multipoint Power Recorder requires
single-phase instrument power in addition to the measurement
connections.
3. Location Accessibility: Make sure that you locate the recorder
where connections can be safely made.
4. Power Type: You will need to know the power type in order to
make proper connections.
5. Communications Availability: The Multipoint Power Recorder
requires an Ethernet connection.
Tools and Supplies Provided
Multipoint Power Recorder
Installation Template
Clip-On Ferrite Bead for AC connections
This booklet (Multipoint Power Recorder Installation Guide)
Additional Tools and Supplies Needed
Mounting hardware
Screwdriver
Category 5 Ethernet cable (or a crossover cable, if connecting
directly to a PC)
Suitable wire for connecting to instrument power, voltage, and (for
models 1941 and 1948) current, according to applicable electrical
codes
For models 1942 and 1949, appropriate current clamps
Safety gear
Tamper seals, if required

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
5
Installing the Multipoint Power
Recorder
Acquisition Unit Models 1941*, 1948*
To install the Multipoint Power Recorder with Acquisition Unit 1941
or 1948, follow the instructions on pages 6 through 19.You use
these units with the CTs embedded in the Base Unit.
Acquisition Unit Models 1942, 1949
To install the Multipoint Power Recorder with Acquisition Unit 1942
or 1949, follow the instructions on pages 20 through 38. You use
these Acquisition Units with Reliable Power Meter current clamps.
*NOTE: The first four digits of the serial number on the Acquisition Unit
indicate the “model” number.

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
6
Installing the Multipoint with
Acquisition Unit Model 1941 or
1948*
Overview of the Installation Process
To install the Multipoint Power Recorder with either Acquisition Unit
model 1941 or 1948, follow the process described below. Each of the
steps in this process is described in detail on the next pages (pages 7
through 19).
Note: If you’re using Acquisition Unit model 1942 or 1949 (for use
with Reliable Power Meters current clamps), turn to page 20 for
instructions.
1. De-energize relevant power – Make sure that all equipment,
wiring, and connections are de-energized. (See page 7.)
2. Mount the Multipoint Base Unit - Put the Multipoint Base
Unit in place, mounting it to a panel adequate to support its
weight. (See page 8.)
3. Connect the Safety ground. (See page 9.)
4. Connect instrument power - Connect the Multipoint Base
Unit to the meter power source. (See page 10.)
5. Connect monitored voltage(s) - Connect the Multipoint Base
Unit to the voltage to be monitored. (See page 12.) You’ll find
diagrams of the wiring for various power configurations in
Appendix C.
6. Connect monitored current(s) - Connect the Multipoint Base
Unit to the current to be monitored. (See page 14.)
7. Connect the Ethernet communications - Connect the
Multipoint to Ethernet. (See page 16.)
8. Check the connections. (See page 17.)
9. Restore power. (See page 17.)
10. Put the Multipoint Acquisition Unit in place. (See page 18.)
*NOTE: The first four digits of the serial number on the Acquisition Unit
indicate the “model” number.

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
7
11. Finish up. (See pages 34-38.)
Note: Mounting hardware and connection wires are not included.
BEFORE YOU
CAN USE AN
INSTALLED
MULTIPOINT
In addition to being physically installed at a
facility, the Multipoint Power Recorder also needs
to be
configured to measure and store data about
a particular site and location. For more
information, see “Configuring the Power
Recorder” in the Power Recorder System User Guide
or in the Scenario User Guide.
De-energizing Relevant Power
XSafety First: Make sure that all equipment, wiring, and
connections are de-energized.
Warning: Before connecting the Multipoint Power
Recorder to AC power, potential transformers, or
current transformers, be sure these circuits are de-
energized.

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
8
Mounting the Multipoint Base Unit
The Multipoint Base Unit must be mounted to a support adequate to
support its weight (18.5 pounds/8.39 kg).
1. Use the Multipoint Template included in the package to mark
where you need to drill holes on the support panel.
2. Drill the four holes, as marked.
3. Secure the Multipoint Base Unit to the support panel (hardware
not included).

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
9
Connecting the Safety Ground
XConnect the ground first. Screw the ground wire securely to the
Safety ground stud.
CAUTION Risk of electric shock, do not remove cover.
Refer servicing to qualified service personnel. Made in U.S.A
C
VOLTAGE
A B
CURRENT
N B A C G
ETHERNET
DIGITALI/OPORT
2
1
18
17
PORT
20Amax.
C
ACCURRENT
A
RMS
B
N
G
ACVOLTAGEINPUT
600Vmax.
RMS
ABCNG
METERPOWER
N
VoltsAC100-240V
50/60Hz,40VAmax.
L
VoltsDC10-15Vdc40W
RMS
Phone [phone]
Los Gatos, CA 95032
Reliable Power Meters
Safety ground

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
10
Connecting to the Meter Power Source
Warning: Before connecting the Multipoint Power
Recorder to a power source the ground wire should be
securely screwed to the Safety ground stud.
You can connect to the Multipoint meter power using either AC or
DC. The meter power requires 10-15 volts DC, negative ground, or
100 -240 volts AC. You may connect to both AC and DC at the same
time. No switch settings are required.
k
, do not remove cover.
a
lified service personnel. Made in U.S.A
C
VOLTAGE
A
B
CURRENT
N B A C G
METERPOWER
N
VoltsAC100-240V
50/60Hz,40VAmax.
L
VoltsDC10-15Vdc40W
RMS
AC Line
AC Neutral
DC return
+10 to 15V DC
No Connection
No Connection

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
11
To hook up power to the Multipoint Power Recorder
XMake the connection between the power source and the meter
power terminal strip on the Multipoint Base Unit.
For an AC connection,
connect line and neutral, ,
as labeled.
For a DC connection, connect the
positive and negative terminals, as
labeled.
For AC connections, a Clip-On Ferrite Bead (Reliable Power Meter
part number 13-043-0004) is included with the Multipoint Base Unit.
Use of this device will ensure compliance with the Class A limits for
radio noise emissions. It should be snapped over the Safety ground,
AC Neutral, and AC Line wires such that it encloses all three wires
simultaneously, and then positioned within 6 inches (150 mm) of the
power terminal strip on the Multipoint.
For an AC connection power must be provided through a dedicated
UL recognized circuit breaker. The wire used must be UL recognized
with a gauge to match the current rating of the dedicated circuit
breaker.
DC power is limited by an internal 5-ampere fuse that is not user
replaceable.
10 to 15 V DC return
No connection
+10 to 15 V DC
No connection
No connection
No connection
No connection
No connection
No connection
AC Neutral
AC Line
No connection

Installing the Multipoint with
Acquisition Unit Model 1941 or 1948
12
Connecting to Voltage
WARNING: Make sure that all equipment, wiring,
and connections are de-energized before proceeding.
Note: All connections should be wired in accordance with local
electrical codes.
1. Starting at the Multipoint unit, attach the voltage wires to the
voltage measurement terminal strip on the Multipoint Base Unit.
Gauge 20-6 AWG/10 mm2
Stripping length 0.3"/8mm
2. Screw down the wires.
3. Attach the wires to the voltage source being monitored.
Phase US
Color
Code
European
Color Code
U.K.
Color
Code
Single-
phase
Split
Single-
phase
3-
phase
Wye
3-
phase
Delta
A Black Black Red X X X X
B Red Red Yellow X X X
C Blue White Blue X X
Neutral White Blue Black X X X
Ground Green Yellow and
green
stripe
Yellow
and
green
stripe
X X X X
