Fly Fly Hobby Simple easy ASW15 User manual

Basic parts
110
211
Simple easy ASW15 Manual
Model No:FF-B050/FF-B051
Scale Glider Radio control airplane Wingspan:4000mm
Carbon Rod 12*500mm for main wing joinner
Carbon Rod 10*400mm *2pcs for second wing
joinner, 8*180mm/1pcs 6*150mm/1pcs for elevator
M4*20 Butterfly Screws for lock the wings
FF12-05 Linkage Stoppers*10/set
Optional Alum retract
1
2
18
3
456789
10 11 12 13 14 15 16
2
312
413
514
615
716
817
918
UNDER SAFETY PRECAUTIONS
This radio controlled plane is not a toy!
Always keep this instruction manual ready on hand for quick reference.
Assemble this kit only places out of children reach.
First-time builders of RC radio power model should seek the advice of experienced modellers
before beginning assembly and if they do not fully understand any parts of the construction.
Taking out liability insurance is recommended.
You are responsible for this model’s assembly and safe operation.
Plastic Servo tray *5pcs
Carbon pin 6*50mm 6pcs for stable wings
Push Rod M1.5*65 *5pcs for Flap,rudder and
004-00140 Hinges*3
Soft wire*2pcs for elevator
LL04-405B Horns 8pcs for push all the servos
Metal Pinned Hinges*4pcs for canopy
M4*35 Screws*2/pcs for locking the stable tail
2*25mm 6pcs Pin for Wingtips
FF1-130 Optional Alum retract with servo tray*1/set
M3*10 Screws*4pcs for locking motor
Metal Collar*2/set
2*8mm Screws 35 pcs
Metal Clevis M1.5 *3pcs
Page 1

Page 2
You need to purchase the following accessories power system separately to complete the model.
FF4-402 ESC 60A 1pcs
Copyright 2015 Flyfly hobby Designed and Manufactured by: Flyfly hobby Mfg.
Web: www.flyflyhobby.com Email:[e-mail]
FF10-107 Alum Propeller &
sprinner 11*7 φ38mm /1set
FF9-912 MG Servo 17g 7pcs
FF3-309B Motor 720kv 1pcs FF14-03 Servo extension cable: 800mm 8pcs
FF14-06 Y# extension cable: 300mm *2pcs
Battery 5S 35C 3500-4000mAh 1pcs for electric
(1). Installing The wings: need to preparing:17g Servos*4pcs (Flyfly item no:FF9-912) Servos extension cables
800mm*6pcs (Flyfly item no:FF14-03)
Parts:Horns(No:LL04-406A/B),Servo tray ,Push robs(No:NN17-00401),Linkage Stoppers(No:FF12-05)
After installed like this photos
Put the servo in to the servo
tray, with 2 screws locked
Push Rod Fixed to
the servo horns locked with 4 screws
After finished like this photo, Adjust the aileron &
Flaps,then locked the Linkage stoppers,please
remember the servo horns between the Linkage
stoppers always keep in a flat line
Push rod & Lingkage
Stoppers
Page 2

(2). Installing elevator & Tail Rudder: need to preparing 17g metal servos*2 pcs (FF item no:FF9-912)
Servos extension cables 800mm*2pcs (Flyfly item no:FF14-03)
Parts:Horns(FF item no:LL04-406A/B),Soft wire, Metal collar, servo tray, push rod
Linkage Stoppers(FF item no: FF12-05)
A/B Glue 3pcs
Hinges to the tail
& rudder
Soft wire Metal Collar Horns
Elevator After installed
like this photos
Soft wire across from tail to the
nose fuselage here. Use linkage
stoppers to lock the wire
Page 3

(3). Landing gear installing: : need to fit a 17g metal servos*1 pcs (FF item no:FF9-912)
(4). Canopy installing
Servo for retract
Push rod for
work retract
and clevis
Servo for Rudder
After installed
servos,put landing gear
in here Lock with 2
screws
Use this wood
and put here
(5). Joined wings and Decals
Carbon Rod 12*525mm 10*330mm
Carbon pin 6*50mm
Cut the transparent canopy shape, used AB
glue to fixe on the canopy framework like
these photos
A/B Glue Metal
Pinned Hinges
Please made sure the Hole
position is fit to the canopy
lock before d cut the hole
Canopy lock
We suggest add tape on the canopy
for safe when you flight
Page 4

1 On the wing left side & right side
2 Put on the nose fuselage right and left side
3 On the tail right and left side
4On the fuselage rigth and left side
(6). Motor & ESC & Adjustment
1
2
14
3
3
3
4
Copyright 2015 Flyfly hobby Designed and Manufactured by: Flyfly hobby Mfg.
Web: www.flyflyhobby.com Email:[email protected]
90mm
