Fly Sky FS-T6 User manual

FS-T6
警告
此款产品只适合15岁以上人员使用。
The product is suitable
for 15 years old and
above.
T6

FS-T6
1. Introducion...............................................................2
2. Services....................................................................2
3. The special symbols..................................................3
4. Safty guides..............................................................3
5. Battery charging notes...............................................4
6. Tansmitter parameters...............................................5
7. Receiver parameters.................................................5
8. Receiver connectivity.................................................6
9. 2.4G Operation notes.................................................8
1
10. Definition of key functions.........................................9
11. Features...................................................................10
12. Packs the content...................................................41

FS-T6
T-6.01
T-6.02
2

FS-T6
T-6.03
T-6.04
3
3
3

FS-T6
T-6.05
4
参数说明： Specifications:
频率范围：2.40-2.4835GHz；
波段宽度：500Hz；
波段个数：160个；
发射功率：不高于20dBm（100mW）
2.4G模式：自动跳频率数字系统；
编码方式：GFSK；
天线长度：26毫米；
接收灵敏度：-105dBm;
RF range:2.40-2.4835GHz;
Bandwidth:500Hz;
Band sum:160;
2.4G system:AFHDS;
Code type:GFSK;
ANT length:26mm;
RX Sensitivity:-105dBm;
RF power:less than 20dBm(100mW);
AFHDS（自动跳频数字系统），这个系统是富斯公司专为模型爱好者自主
研发，并具有自主知识产权的一套数字无线系统。它是专门针对模型产品而
研发的，它具有超强的主动和被动抗干扰能力及极低的使用功耗和极高的接
收灵敏度，是目前市面上最好的系统之一。此系统经过研发人员极端严格的
测试及多年市场验证，模型爱好者完全可放心使用！
AFHDS(quiomalic frequency hopping digital system),is developed by FLYSKY for all the Radio Control model
lovers and is patented by FLYSKY at home. The system is specially developed fo all the Radio control models,
that offers super active and passive anti-jamming capabilities, very low power consumption and high receiver
sensitivity. With extreme rigorus testing by engineers and studying the markets for years, FLYSKY AFHDS is
now considered to be the one of the best systems available in the market.

FS-T6
T-6.06
T-6.06.1
5

FS-T6
FS-T6
T-6.07
T-6.08
6
3.发射功率：小于等于20dBm（100mW)；
7.低电压报警功能: 有(低于9伏后)；
8.数据输出接口: 有(3.5英寸变频)；
Specifications:
机种参数：
1.通道个数：6个通道；
2.适合机种：飞机、直升机；
4.调制方式：CFSK；
5.系统模式: AFHDS；
6.数据分辩率: 4096级；
9.充电接口: 有;
10.电源标准：12V DC；
11.整机重量: 590克；
12.天线长度：26毫米；
13.外型尺寸：302*190*93毫米；
14.外观颜色：黑色；
15.安规认证：CE、FCC.
SPECIFICATIONS:
A.Channels: 6channels;
B.Model type: Aircraft/helicopters;
C.RF power: no more than 20dBm(100mW);
D.Modulation: GFSK;
E.System type: AFHDS;
F.Sensitivity: 4096;
G.Low voltage warning: yes(less than 9V);
H.DSC port: yes(3.5mm);
I.Charger port: yes;
J.Power: 12V DC(1.5aa*8);
K.Weight: 590g;
L.ANT length: 26mm;
M.Size: 302*190*93mm;
N.Color: black;
O.Certificate: CE、FCC.
机种参数：
1.通道个数：6个通道；
2.适合机种：飞机/直升机；
3.接收灵敏度：-105dBm；
4.调制方式:GFSK；
5.系统模式:AFHDS；
6.数据分辩率:1024级；
7.失控保护 功能:有(第2通 道)；
8.对码接口:有(第 三通 道)；
9.电源接口:有( VC C)；
10.电源标准:4.5-6.5V DC；
11.整机重量:13克；
12.天线长度:26毫米；
13.外型尺寸:45*23*9毫米；
14.外观颜色:黑色；
15.安规认证:CE、FCC。
SPECIFICATIONS：
A.Channels: 6channels;
B.Model type: car/boat;
C.RF receiver sensitivity: -105dBm;
D.Modulation: GFSK;
E.System type: AFHDS;
F.Sensitivity: 1024;
G.Faisafe: yes(channel 2);
H.Bind port: yes(channel 3);
I.Power port: yes(VCC);
J.Power: 4.5-6.5VDC;
K.Weight: 13g;
L.ANT length: 26mm;
M.Size: 45*23*9mm;
N.Color: black;
O.Certificate: CE、FCC.
MODEL: FS-R6B

FS-T6
T-6.09
7
Figure(图2 )
(如图2)
Figure(2)
BIND KEY
KEY
KEY

FS-T6
T-6.10
T-6.10.1
8
Ch.1
Aileron
Ch.2
Elevator
Ch.3
ESC
Ch.4
Rudder
Ch.5
Gyro Gain
Ch.6 Pitch
(Aileron 2)
Ch.1
Aileron
Ch.2
Elevator
Ch.3
ESC
Ch.4
Rudder
Ch.5
Gyro Gain
Ch.6 Pitch
(Aileron 2)

SW
Handle
2.4Ghz Antenna
C (Defalut Flight Mode Normal / IDLE for Storm 460)
SWA (Defalut Dual Rate for Storm 460)
SWD (Defalut Throttle Hold for Storm 460)
VRA (Defalut Not Used for Storm 460)
VRB (Defalut Not Used for Storm 460)
SWB (Defalut Not Used for Storm 460)
HOOK
MODE1:
CH2 ,CH4
MODE2:
CH3 ,CH4
TRIM Ch1
Charger Port
(Not Used)
TRIM
TRIM
Mode 1 : Ch.2
Mode 2 : Ch.3
CH4
LCD
UP/DOWN
ENTER
OK
Power ON / OFF
Cancel
FS-T6
T-6.11
9
Definition of key functions
TRIM
Mode 1 : Ch.3
Mode 2 : Ch.2
MODE1:
CH1 ,CH3
MODE2:
CH1 ,CH2

开机画面：
此为开机后LCD所显示的画面，在此画面下可显示如下内容：公司LOGO，当前电池电压，系统模式(AFHDS),当前机种编
号，当前机种名称，当前机类型（飞机还是直升机）,以及四个通道微调现在位置。
参数说明：
LOGO：显示的是富斯公司的商标。
TRIM：四个比率通道的微调。
AFHDS:此发射机系统模式为AFHDS（AUTOMATIC FREQUENCYHOPPING DIGITAL SYSTEM).
MODE：MODE0-MODE9共10组MODE可选择，当前是MODE1。
MODE：当前MODE的名称。
BATTERY：当前电池的电压，当电池电压低于9V时此图标会闪烁报警。
MODE TYPE：当前MODE的类型，有两种类型可供选择，一个是直升机，一个是飞机。
LOGO
TRIM
AFHDS
MODE
MODE NAME
TRIM
BATTERY
TRIM
MODE TYPE
TRIM
FS-T6
This is the image of starting LCD power on, the contents are as below: the LOGO of
company, the current voltage of battery, the mode of system (AFHDS), the current
No. of mode, the mode name, mode type (helicopters or aero) and initial position
of four trims.
Parameter instruction
LOGO: To show the LOGO of company
TRIM: The trim of four ratio fine channels
AFHDS is the mode system, which is abbreviation of Automatic frequency hopping
digital system.
MODE: There are totally 10 piece modes to be selected, the initial mode No. is MODE1.
MODE: The current name of MODE.
BATTERY: The current voltage of battery. When the voltage is less than 9V, it will
blink.
MODE TYPE: It shows the current MODE TYPE, there are two mode types to be chosen
one is helicopter and another is aero.
T-6.12
10
Start-up screen

FS-T6
主菜单:
操作方式:
在开机画面下;长按ENTER键进入此菜单。然后通过DOWN或UP进行选择，选择好后再按ENTER键进入相对应的菜单操作。
功能说明：
此为MENU主菜单，在此画面下有两个菜单可选择；分别是SYSTEM SETTING 和FUNC SETTING;分别进行系统设定和功能
设定。
MENU 菜单
Main menu
Instruction of operation
Switch on the transmitter and press the ENTER button for 3 seconds. The menu will
be shown and press DOWN or UP button to choose, and then press ENTER button to confirm
the next operation which you have chosen.
Instruction of function
This is main menu and there are two options. One is SYSTEM SETTING and another is
FUNC SETTING.
SYSTEM SETUP菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键进行选择,选择好需要的菜单后再按ENTER键可进入相对应的菜单进行操作。
功能说明：
此为SYSTEM SETUP菜单，在此菜单下有6项子菜单可选择；
参数说明：
MODE SELE:存贮MODE选择，此发射机共存贮了10组MODE,分别是MODE0-MODE9。
MODE NAME:每组MODE名称，都可用7位的字符加字母组成,由用户自己设定。此项菜单可完成此 项设定。
T-6.13
T-6.14
11

FS-T6
TYPE SELE:有两种类型可供选择，由用户自已跟具实际自己设定，一个是直升机，一个是飞机,
STICK SETUP:有四种操作杆模式供用户跟具实际选择，分别是MODE1到MODE4。
MODE COPY:用户可跟具实际对任一MODE进行复制。
MODE REST:用户可跟具实际对任一MODE进行初始化并还原到工厂参数设定.
SYSTEM SETUP MENU
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SYSTEM. Press the Enter button and go into the menu. Press
DOWN or UP button to choose which function will be modified to be the one you want.
Instruction of operation
Instruction of function
This is SYSTEM SETUP menu; there are 6 sub-menus to be selected.
Instruction of parameter
MODE SELE: There are 10 pieces MODE from MODE0 to MODE 9, which can be saved.
MODE NAME: The MODE NAME can be named by 7 characters or letters by user.
TYPE SELE: There are two modes to be chosen by user. One is helicopter and another
is aero.
STICK SETUP: There are 4 modes to be selected by user, which is from MODE1 to MODE4.
MODE COPY: Any MODE can be copied by user.
MODE RESET: Any MODE can be initialized or revert to the factory initial setting.
T-6.15
12

FUNC SETUP菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择FUNC SETUP菜单，再按ENTER键进入此菜单,在此菜
单下通过DOWN 或UP键进行选择,选择好需要的菜单后再按ENTER键可进入相对应的菜单进行操作。
功能说明：
此为FUNC SETUP菜单，在此直升机模式菜单下有15项子菜单可选择；
参数说明：
FS-T6
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SETTING. Press the Enter button and go into the menu.
Press DOWN or UP button to choose which function will be modified to be the one you
want. Finally press ENTER to go into the sub-menu.
Instruction of function
This is FUNCTION SETUP menu and there are 15 sub-menus for helicopter to be selected.
Instruction of parameter
REVERSE: The function is for setting the output data of normal or reverse, which
can set up 6 channels separately.
THR/CV: The function is for setting the throttle curve, which includes L, 1, 2, 3,
H.
PIT/CV: The function is for setting the pitch curve, which includes L, 1, 2, 3, H.
SUBTRIM: The function is for setting the sub trim, which can set up 6 channels
separately.
E.POINT: The function is for setting the Max value of output channel. There are 6
channels and can be set up separately.
REVERSE:输出通道数据正反向设定，可单独对6个通道做设定。
SUBTRIM:辅助微调设定，可单独对6个通道做设定。
E.POINT:通道输出最大值设定,共6个通道，可单独对单边进行设定。
THR/CV:油门曲线设定，分5点设定。
PIT/CV:螺距曲线设定，分5点设定。
SWASHAFR:十字盘参数设定。
D/R EXP:双重比率及指数设定。
THR HOLD:油门锁定值设定。
TRIM:四个通道的微调值参数设定。
HOV-THR:油门悬停参数设定。
HOV-PIT:螺距悬停参数设定。
DISPLAY:通道数据输出显示检查。
GYROSENS:锁尾陀螺仪参数设定。
AUX-CH:辅助通道输出参赛数设定。
PROG.MIX:特殊功能混控设定，共三组。
13

FS-T6
THR HOLD: The function is for setting or holding the data of throttle
SWASHAFR: The function is for setting the data of swash planet
D/R EXP: The function is for setting the dual ratio and exponent
TRIM: The function is for setting the data of four channels
HOV-THR: The function is for setting the data of throttle hover
HOV-PIT: The function is for setting the data of pitch hover
DISPLAY: The function is for checking the data of output channel
GYROSENS: The function is for setting the data of locked tail GYRO
AUX-CH: The function is for setting the output data of auxiliary channel
PROG.MIX: The function is for setting up the 3 special mixed control functions
SYSTEM SETUP
MODE SELE菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择MODE SELE菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过DOWN或UP键进行MODE0
到MODE9的选择。
选择好后长按ENTER键进行存贮并返回上一及菜单,
功能说明：
此为MODE SELE菜单，在此菜单下有10个MODE可选择，分别是MODE0到MODE9，此10组MODE分别可存贮10种机种参数，而
下面所显示的内容为当前MODE下相对应的机种名称及所对应的机型（直升机还是飞机类型）。
MODE SELE menu
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SYSTEM. Press the Enter button and go into the menu. Press
DO WN or UP bu tton to c hoose w hich MO DE will b e neede d. Fina lly pre ss the EN TER but ton
fo r 3 seco nds to save and retur n to the pre vious men u. If do n't need to save the
changes.
Instruction of function
Th is is MOD E SELE me nu and th ere are 1 0 MODES t o be sele cted. T hey are f rom MOD E0
to MODE9, which can save 10 sets data. The content below displayed are the
corresponding Mode name and Mode type (helicopter or aero)
T-6.16
14
按EXIT退出并自动保存
Press EXIT to exit and save automatically

MODE NAME菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择MODE NAME菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过END键进行名称1-7位的
选择,选择好后通过DOWN或UP键进行字符字母的选择，依此类推进行名称1-7位的编辑。
编辑完成后长按ENTER返存贮并返回上一级菜单。
功能说明：
此为MODE NAME菜单，用于机种名称的编写，以方便记忆。名称由7位字母及字符组成。
FS-T6
MODE NAME menu
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
pr ess DOW N or UP to ch oose SY STEM. P ress th e Enter b utton a nd go int o the men u. Choo se
th e MOD E NAM E men u and press ENT ER bu tton. Press the E ND button and c hoose no m ore
than 7 characters or letters to name the MODE. Finally press the ENTER button for
3 seconds to save and return to the previous menu. If don't need to save the changes,
Instruction of function
MO DE NAME m enu is fo r editi ng the mo de name a nd easy t o remem ber. Th e MODE NA ME is
ma de by 7 cha racte rs or let ters.
TYPE SELE菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择TYPE SELE菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过DOWN或UP键进行HELIC-
OPTER和AIRPLANE的选择,如果选择的是HELICOPTER再按ENTER将进入下一级菜单的选择。
选择好后长按ENTER键进行存贮并返回上一及菜单,
T-6.17
T-6.16.1
15
按EXIT退出并自动保存
Press EXIT to exit and save automatically
按EXIT退出并自动保存

FS-T6
功能说明：
此为TYPE SELE菜单，在此菜单下有两个TYPE可选择，分别是HELICOPER和AIRPLANE，HELICOPTER代表直升机模式，
AIRPLANE代表飞机固定翼模式。其中直升机模式还有下一级菜单选择。
HELICOPTER菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择TYPE SELE菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过DOWN或UP键选择HELIC-
OPTER菜单并按ENTER键进入此菜单操作。
选择好后长按ENTER键进行存贮并返回上一及菜单,
功能说明：
此为TYPE SELE菜单下的一个子菜单，在此菜单下有三个TYPE可选择，分别是HELI-1和heli-2,以及HELI-3。其中
HELI-1为单伺服器90度模式，HELI-2为双伺服器90度模式，HELI-3为CCPM120度模式。分别适应不同直升机的安装结
构要求。
TYPE SELE menu
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SYSTEM. Press the Enter button and go into the menu. Choose
the TYPE SELE menu and press ENTER button. Press the DOWN or UP button and choose
MODE TYPY, helicopter or airplane. If helicopter is opted, please press ENTER button
and go in next menu. Finally press the ENTER button for 3 seconds to save and return
to the previous menu. If don't need to save the changes.
Instruction of function
In the TYPE SELE menu there are two types to be chosen. They are helicopter and aero.
If helicopter is chosen, there is sub- menu for helicopter for more detail and choice.
HELICOPTER MENU
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SYSTEM. Press the Enter button and go into the menu. Choose
the TYPE SELE menu and press ENTER button. Press the DOWN or UP button and choose
HELICOPTER. Press the ENTER button and operate.
Finishing the operation, press the ENTER button for 3 seconds to save and return
to the previous menu.
Instruction of function
This is on e of s ub-men us o f TYPE SELE and t he re a re 3 TYP E unde r this sub-men u to
be selected. They are HELI-1(single servo for 90°), HELI-2(double servos for 90
°) and HELI-3(CCPM for 120°)， which designed for helicopters with different
structures.
T-6.17.1
16
Press EXIT to exit and save automatically
按EXIT退出并自动保存
Press EXIT to exit and save automatically

STICK SETUP菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择STICE SETUP菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过DOWN或UP键进行MODE1
到MODE4的选择。
选择完成后长按ENTER返存贮并返回上一级菜单。
功能说明：
此为STICK SETUP菜单，用于适应用户不同的操作习惯，共4种模式可供选择。
MODE COPY菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择MODE COPY菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过END键进行COPY和被COPY
的项目，选择好后通过DOWN或UP键进行MODE0到MODE9的选择。选择完成后按ENTER会弹出另一个对话框如下图。此时如
果您确定要复制，则通过DOWN或UP键选择YES并长按存贮并返回上一级菜单，如果您不需复制则选择NO并按ENTER键退出。
功能说明：
此为MODE COPY菜单，用于将一个机种数据复制到另一个机种里面，此功能可用于机种间相互COPY.这样可以最简单的
设定另一个机型参数.
FS-T6
STICK SETUP MENU
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SYSTEM. Press the Enter button and go into the menu. Press
DOWN or UP to choose the STICK SETUP menu and press ENTER button. Press the DOWN
or UP button and choose MODE (1to 4). Finishing the operation, press the ENTER button
for 3 seconds to save and return to the previous menu. If don't need to save the
changes
Instruction of function
The STICK SETUP menu is suit for different users and different operation habits.
There are 4 MODE to be selected totally.
MODE COPY MENU
Instruction of operation
T-6.17.2
T-6.17.3
17
按EXIT退出并自动保存
Press EXIT to exit and save automatically
按EXIT退出并自动保存

MODE REST菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择SYSTEM SETUP菜单，再按ENTER键进入此菜单,在此
菜单下通过DOWN 或UP键选择MODE REST菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过DOWN或UP键进行MODE0
到MODE9的选择。选择完成后按ENTER键,此时如果您确定要初始化，则通过DOWN或UP键选择YES并长按存贮并返回上一级
菜单，如果您不需初始化则选择NO并按ENTER键退出。
功能说明：
此为MODE REST菜单，用于将一个机种数据还原到出厂时的设定，此功能可用于用户使用时不小心将数据调乱后无法还
原时用。此功能可对MODE0到MODE9共10个机种单独还原到出厂值。
FS-T6
MODE RESET MENU
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose SYSTEM. Press the Enter button and go into the menu. Press
DOWN or UP to choose the MODE RESET menu and press ENTER button. Press the DOWN or
UP button and choose MODE (0to 9). Finishing the operation, press the ENTER button.
If the initial setting is confirmed, please choose YES and press ENTER button for
3 seconds to save and return to the previous menu. If don't need to save the changes,
Instruction of function
The MOED RESET menu is for resetting or returning the MODE data to the factory initial
one. It can help user to avoid the situation when can not find out the recover data
when testing carelessly. Ten MODE data can be reset from MODE 0 to MODE 9 separately.
The initial image will be shown when starting on and press the ENTER button for 3
seconds to enter the menu. The SYSTEM and SETTING will be shown on the screen. Then
press DOWN or UP to choose MODE COPY. Press the Enter button and go into the menu.
Copy A to B through pressing END and choose MODE NO. Through pressing DOWN or UP,
then press ENTER, there is a dialog box (refer to the figure). If you confirm to
copy, please press DOWN or up to choose YES for 3 seconds to previous menu. If don't
need to copy, please choose NO and press ENTER. If don't need to save the changes,
T-6.18
18
Press EXIT to exit and save automatically
按EXIT退出并自动保存
Press EXIT to exit and save automatically

REVERSE菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择FUNC SETUP菜单，再按ENTER键进入此菜单,在此菜
单下通过DOWN 或UP键选择REVERSE菜单,选择好后再按ENTER键进入此菜单'在此菜单下通过DOWN或UP键进行CH1到CH6的
选择,选择好要变更的通道后按END键进正反转的设定.
设定完成后长按ENTER返存贮并返回上一级菜单。
功能说明：
此为REVERSE菜单，用于适应用户不同机种及不同伺服器安装时的伺服反向问题，共6个通道路每一个都可单独调整，
初始值全部为NOR。
FUNC SETUP FOR HELICOPTER
FS-T6
REVERSE MENU
Instruction of operation
The initial image will be shown when starting on and press the ENTER button for 3
se conds to e nter the m enu. The SYS TEM an d SETT ING wi ll be shown on th e scre en. Th en
pr ess DOW N or UP to ch oose SY STEM. P ress th e Enter b utton a nd go int o the men u. Pres s
DO WN or UP to cho ose the R EVERS E menu an d press E NTER bu tton. P ress th e DOWN or UP
button and choose different channels. Finish the operation and press the END button
to set up. Pres s EN TER butto n fo r 3 seco nds to s ave, then ret urn to the pre vious
me nu. If do n't nee d to save t he chan ges,
Instruction of function
Th e REVER SE menu i s for adj ustin g rever se of dif feren t MODE TY PY and di ffere nt serv os.
Th ere are 6 chann els whi ch can be a djust ed sepa ratel y, the in itial d ata is NO R.
THR/CV菜单:
操作方式:
在开机画面下;长按ENTER键进入MENAU菜单。然后通过DOWN或UP选择FUNC SETUP菜单，再按ENTER键进入此菜单,在此菜
单下通过DOWN 或UP键选择THR/CV菜单,选择好后再按ENTER键进入此菜单，在此菜单下通过END键进行L到H的选择,选择
好要变更的通道后通过DOWN或UPEND键进行数据的设定.
设定完成后长按ENTER返存贮并返回上一级菜单。
功能说明：
此为THR/CV菜单，此功能用于适应用户不同机种引擎及动力系统输出要求，以达到最佳的动力输出性能。此项功能分
期分5点进行设定，分别是L.1,2,3,5,H.其设定按FLY MODE模式不同分两组，一组是在正常模式（NOR）下，另一组为
T-6.19
T-6.19.1
19
按EXIT退出并自动保存
Press EXIT to exit and save automatically
按EXIT退出并自动保存
