Flyingvoice FTA1101 User manual

Contents FTA1101 User Manual
I
About This User Guide..............................................................................................................................................1
Contacting FlyingVoice........................................................................................................................2
Purpose................................................................................................................................................3
Cross references..................................................................................................................................3
Feedback............................................................................................................................................. 3
Declaration of Conformity...........................................................................................................................4
Part 15 FCC Rules................................................................................................................................ 4
Warnings and Notes.................................................................................................................................... 5
Warnings..............................................................................................................................................5
Notes................................................................................................................................................... 5
Chapter 1 Product description............................................................................................................................... 6
FTA1101....................................................................................................................................................... 7
LED Indicators and Interfaces......................................................................................................................8
Hardware Installation..........................................................................................................................9
Chapter 2 IVR Voice Prompt..................................................................................................................................11
Voice Gateway Configuration Method (IVR).............................................................................................12
Start IVR.............................................................................................................................................12
IVR Description..................................................................................................................................12
Chapter 3 Basic Settings........................................................................................................................................ 18
Web Page.................................................................................................................................................. 19
About Password................................................................................................................................ 19
URL Format........................................................................................................................................19
WEB Interface Introduction.............................................................................................................. 21
SIP Account configuration....................................................................................................................... 22
Basic Function...........................................................................................................................................23
Calling phone or extension numbers................................................................................................23
Direct IP calls..................................................................................................................................... 23
Call Hold............................................................................................................................................ 23
Call transfer....................................................................................................................................... 23
Conference........................................................................................................................................ 24
Chapter 4 Web Interface............................................................................................................................. 25
Login...........................................................................................................................................................26
Status......................................................................................................................................................... 27
Network and Security................................................................................................................................ 28
Contents

Contents FTA1101 User Manual
II
WAN...................................................................................................................................................28
LAN.................................................................................................................................................... 33
VPN.................................................................................................................................................... 34
Port Forward..................................................................................................................................... 36
DMZ................................................................................................................................................... 37
DDNS..................................................................................................................................................38
Port Setting........................................................................................................................................38
Routing.............................................................................................................................................. 39
Advance............................................................................................................................................. 39
Wireless configuration...............................................................................................................................41
Wireless Security...............................................................................................................................44
WMM.................................................................................................................................................47
WDS................................................................................................................................................... 47
WPS....................................................................................................................................................47
Station Info........................................................................................................................................49
Advanced...........................................................................................................................................50
SIP Account............................................................................................................................................... 52
SIP Settings........................................................................................................................................ 57
Phone.........................................................................................................................................................60
Preferences....................................................................................................................................... 60
Dial Rule.............................................................................................................................................64
Phone.................................................................................................................................................66
Call Log.............................................................................................................................................. 67
Administration..........................................................................................................................................68
Management .................................................................................................................................... 68
Firmware Upgrade............................................................................................................................ 73
Scheduled Tasks................................................................................................................................ 73
Provision............................................................................................................................................74
SNMP................................................................................................................................................. 75
TR-069................................................................................................................................................76
Diagnosis........................................................................................................................................... 77
Operating Mode................................................................................................................................79
System Log.........................................................................................................................................79
Logout................................................................................................................................................79
Reboot............................................................................................................................................... 80
Chapter 5 IPv6 address configuration.................................................................................................................81
Introduction.......................................................................................................................................82
IPv6 Advance..................................................................................................................................... 83
Configuring IPv6................................................................................................................................ 83
Viewing WAN port status..................................................................................................................84
IPv6 DHCP configuration for LAN/WLAN clients.............................................................................. 84

Contents FTA1101 User Manual
III
LAN DHCPv6...................................................................................................................................... 85
Chapter 6 Troubleshooting Guide....................................................................................................................... 86
Configuring PC to get IP Address automatically........................................................................................87
Cannot connect to the Web..............................................................................................................88
Forgotten Password.......................................................................................................................... 88

About This User Manual FTA1101 User Manual
1
Table
Table 1 Features at-a-glance.................................................................................................................................... 7
Table 2 FTA1101 Interfaces.......................................................................................................................................8
Chapter 2 IVR Voice Prompt...................................................................................................................................11
Table 3 IVR Menu Setting Options......................................................................................................................... 13
Table 4 WEB Interface Introduction.......................................................................................................................21
Table 5 Config SIP the Web Management Interface............................................................................................22
Table 6 Login details............................................................................................................................................... 26
Table 7 Internet....................................................................................................................................................... 28
Table 8 DHCP.......................................................................................................................................................... 29
Table 9 PPPoE......................................................................................................................................................... 30
Table 10 Bridge Mode............................................................................................................................................ 31
Table 11 LAN port................................................................................................................................................... 33
Table 12 PPTP......................................................................................................................................................... 34
Table 13 L2TP..........................................................................................................................................................35
Table 14 OpenVPN..................................................................................................................................................36
Table 15 Port Forward............................................................................................................................................36
Table 16 DMZ..........................................................................................................................................................37
Table 17 DDNS......................................................................................................................................................... 38
Table 18 Port setting............................................................................................................................................... 38
Table 19 Routing.....................................................................................................................................................39
Table 20 Advance.................................................................................................................................................... 39
Table 21 Basic......................................................................................................................................................... 41
Table 22 Wireless security.......................................................................................................................................44
Table 23 WiFI Security Setting.................................................................................................................................44
Table 24 WPA-PSK................................................................................................................................................... 45
Table 25 WPAPSKWPA2PSK.................................................................................................................................... 46
Table 26 Wireless Access Policy............................................................................................................................. 46
Table 27 WMM....................................................................................................................................................... 47
Table 28 WDS..........................................................................................................................................................47
Table 29 WPS.......................................................................................................................................................... 48
Table 30 Station info...............................................................................................................................................49
Table 31 Advanced.................................................................................................................................................. 50
Table 32 Line...........................................................................................................................................................52
Table 33 Audio configuration................................................................................................................................. 53
Table 34 Supplementary service........................................................................................................................... 54

About This User Manual FTA1101 User Manual
2
Table 35 Advanced.................................................................................................................................................. 55
Table 36 SIP Settings............................................................................................................................................... 57
Table 37 VoIP QoS.................................................................................................................................................. 58
Table 38 Preferences.............................................................................................................................................. 60
Table 39 Regional................................................................................................................................................... 60
Table 40 Features and call forward........................................................................................................................61
Table 41 Miscellaneous........................................................................................................................................... 63
Table 42 Dial Plan................................................................................................................................................... 64
Table 43 Adding one dial plan.................................................................................................................................65
Table 44 Dial Plan Syntactic.....................................................................................................................................65
Table 45 Blacklist..................................................................................................................................................... 66
Table 46 Call log.......................................................................................................................................................67
Table 47 Save Config File.........................................................................................................................................68
Table 48 Administrator settings..............................................................................................................................69
Table 49 NTP settings............................................................................................................................................. 70
Table 50 Daylight Saving Time................................................................................................................................71
Table 51 System log Setting.................................................................................................................................... 71
Table 52 Factory Defaults Setting.......................................................................................................................... 72
Table 53 Factory Defaults.......................................................................................................................................72
Table 54 Firmware upgrade................................................................................................................................... 73
Table 55 Scheduled Tasks.......................................................................................................................................73
Table 56 Provision................................................................................................................................................... 74
Table 57 Firmware Upgrade....................................................................................................................................75
Table 58 SNMP........................................................................................................................................................75
Table 60 Diagnosis...................................................................................................................................................77
Table 61 Operating mode.......................................................................................................................................79
Table 62 System log.................................................................................................................................................79
Table 63 Logout...................................................................................................................................................... 79
Table 64 IPv6 Modes.............................................................................................................................................. 82
Table 65 Enabling IPv6............................................................................................................................................83
Table 66 Configuring Statefull IPv6......................................................................................................................... 83

About This User Manual FTA1101 User Manual
1
This guide contains the following chapters:
Chapter 1: Product description
Chapter 2: Configuring Basic Settings
Chapter 3: Web Interface
Chapter 4: IPv6 address configuration on WAN interface
Chapter 5: Troubleshooting Guide
About This User Guide
FTA1101, which has one FXS port , one LAN port and one WAN
port, is one of the most popular VoIP ATAs researched and
produced by FlyingVoice. This product can not only provide
one SIP lines for users to make calls, but also it is a wire-speed
NAT router, make you enjoy easy network atmosphere. What’s
more, FTA1101 support T.38 real time FAX and T.30 FAX with
G.711.FTA1101 is a stand-alone device, which requires no PC
to make Internet calls. This ATA guarantees clear and reliable
voice quality on Internet, which is fully compatible with SIP
industry standard and able to interoperate with many other
SIP devices and software on the market.The Flyingvoice
powerful VoIP Wireless Router FTA1101, Users can also take
FTA1101 as a FTP server, to share LAN files, pictures and other
resources. Meanwhile, 1 FXS port can be well adapted to small
and micro enterprises, FXS can work for telephone or for Fax,
no need to add additional equipment. FTA1101 VoIP wireless
router is ideally suited for small and medium enterprises (SMB)
to build wireless office.The FTA1101 is based on SIP V2.0 and
802.11n standard and compatibility with most service
providers. It features 1phone port telephone ports, 2
10M/100M Ethernet ports which brings great convenience
when deploying VoIP network.

About This User Manual FTA1101 User Manual
2
Contacting FlyingVoice
M ain website:
http://www.flyingvoice.com/
Sales e nquiries:
[e-mail]
S upport enquiries:
s [e-mail]
Hotline:
010-67886296 0755-26099365
Address:
Room508-509, Bldg#1, Dianshi Business Park, No.49 BadachuRd,Shijingshan
District, Beijing, China

About This User Manual FTA1101 User Manual
3
Purpose
The documents are intended to instruct and assist personnel in the operation, installation and
maintenance of the FlyingVoice equipment and ancillary devices. It is recommended that all personnel
engaged in such activities be properly trained.FlyingVoice disclaims all liability whatsoever, implied or
express, for any risk of damage, loss or reduction in system performance arising directly or indirectly
out of the failure of the customer, or anyone acting on the customer's behalf, to abide by the
instructions, system parameters, or recommendations made in this document.
Cross references
References to external publications are shown in italics. Other cross references, emphasized in blue text
in electronic versions, are active links to the references.
This document is divided into numbered chapters that are divided into sections. Sections are not
numbered, but are individually named at the top of each page, and are listed in the table of contents.
Feedback
We appreciate feedback from the users of our documents. This includes feedback on the structure,
content, accuracy, or completeness of our documents. Send feedback to [e-mail].

About This User Manual FTA1101 User Manual
4
Declaration of Conformity
Part 15 FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
 This device may not cause harmful interference, and

This device must accept any interference received, including interference that may cause
undesired operation.
Class B Digital Device or Peripheral
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment can generate, use and radiate radio
frequency energy. If not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is no guarantee that interference does
not occur in a particular installation.
Note
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interferences by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 I ncrease the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
 Consult the dealer or an experienced radio/TV technician for help.

About This User Manual FTA1101 User Manual
5
Warnings and Notes
The following describes how warnings and notes are used in this document and in all documents of the
FlyingVoice document set.
Warnings
Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert
the reader to possible hazards that could cause loss of life or physical injury. A warning has the
following format:
Warning
Warning text and consequence for not following the instructions in the warning.
Notes
A note means that there is a possibility of an undesirable situation or provides additional
information to help the reader understand a topic or concept. A note has the following format:
Notes
Notes text and consequence for not following the instructions in the Notes.

Product description FTA1101 User Manual
6
Chapter 1 Product description
This chapter covers:
·FTA1101
·LED Indicators and Interfaces
·Hardware Installation
·Voice Prompt

IVR Voice Prompt FTA1101 User Manual
7
FTA1101
Table 1 Features at-a-glance
Port/Model
FTA1101
WAN
1
LAN
1
FXS
1
Ethernet interface
2* RJ45 10/100M
Fax
T.30, T.38 Fax
Wire-speed NAT
Support
Voice Code
G.711 (A-law, U-law), G.729A/B, G.723, G.722 (Wide band)
Management
Voice menu, Web Management, Provision:TFTP/HTTP/HTTPS, TR069, SNMP
VLAN
Support

IVR Voice Prompt FTA1101 User Manual
8
LED Indicators and Interfaces
Table 2 FTA1101 Interfaces
Interface
Description
PHONE
Analog phone connector
USB
Connect USB
WAN
Connector for accessing the Internet
LAN
Connectors for local networked devices

IVR Voice Prompt FTA1101 User Manual
9
Hardware Installation
Before configuring your router, please see the procedure below for instructions on connecting the device
in your network.
Procedure 1 Configuring the Router
1. Connect analog phone to ATA Port with an RJ11 cable.
2. Connect the WAN port to the Interne your network’s modem/switch/router/ADSL
3.
equipment using an Ethernet cable.
4.
Connect one end of the power cord to the power port of the device. Connect the other end to the
wall outlet.
5. Check the Power, WAN, and LAN LED to confirm network connectivity.
Warning
Please do not attempt to use unsupported power adapters and do not remove power during
configuring or updating the device. Using other power adapters may damage
FTA1101and will void the manufacturer warranty.

IVR Voice Prompt FTA1101 User Manual
10
Warning
Changes or modifications not expressly approved by the party responsible for
compliance can void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency cause harmful interference to radio
communications. However, there is no energy and, if not installed and used in accordance
with the instructions, may guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
 R eorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.

Consult the dealer or an experienced radio/TV technician for help.

IVR Voice Prompt FTA1101 User Manual
11
This chapter contains:
·Voice Gateway Configuration Method (IVR)
·IVR description
Chapter 2 IVR Voice Prompt

Chapter 2:IVR Voice Prompt FTA1101 User Manual
12
Voice Gateway Configuration Method (IVR)
The device can be configured in two ways, as follows:
(1) Use IVR (Interactive Voice Response)
(2) the use of web pages
This chapter mainly introduces how to configure the voice gateway through IVR.
Start IVR
Users follow these steps to achieve IVR:
(1) Go off-hook and press the "****" key to start the IVR. Then the user will hear the voice prompt "1 WAN port
configuration...".
(2) According to different options, press any digit between 0 and 9, the device will broadcast the corresponding
content, the numbers 0 to 9 represent the details as shown in the chart below.
(3) After each setting will play "Please input option, 1 WAN port configuration...".
IVR Description
The following chart lists the IVR requirements and a detailed description:
Note
Before using IVR,please confirm analog phone is connected with ATA correctly.

Chapter 2:IVR Voice Prompt FTA1101 User Manual
13
Table 3 IVR Menu Setting Options
Operation
code
Menu
Navigation
1
Network port
configuration
(1)WAN Port
Configuration
1.
Pick up phone and press “****”to start IVR
2. Select "1", then the device will continue to broadcast to remind users to
choose 1.WAN port connection type; 2.WAN port IP address; 3. WAN subnet
mask; 4. Gateway; 5. DNS
3.
Choose “1”, and The router reports the current WAN port connection
type2)
4. Prompt "Please enter password”, user needs to input password and press
“#”key, if user wants to configuration WAN port connection type.
The password in IVR is same as web management interface login, the user may
use phone keypad to enter password directly
For example: WEB login password is “admin”, so the password in IVR is
“admin”. The user may “23646”to access and then configure the WAN
connection port. The unit reports “Operation Successful”if the password is
correct.
5. Prompt "Please enter password”, user needs to input password and press
“#”key if user wants to configuration WAN port connection type.
6.
Choose the new WAN port connection type (1) DHCP or (2) Static
The unit reports “Operation Successful”if the changes are successful. The
router returns to the prompt “please enter your option …”
7. To quit, enter “*”

Chapter 2:IVR Voice Prompt FTA1101 User Manual
14
(2)WAN Port
IP Address
1.
Pick up phone and press “****”to start IVR
2. Choose “2”, and The router reports current WAN Port IP Address
3.
Input the new WAN port IP address and press “#”key:
4. Use “*”to replace “.”, for exampleuser can input 192*168*20*168 to set
the new IP address 192.168.20.168
5. Press # key to indicate that you have finished
6.
Report “operation successful”if user operation is ok.
7. To quit, enter “**”.
(3)WAN Port
Subnet Mask
1. Pick up phone and press “****”to start IVR
2. Choose “3”, and router reports current WAN port subnet mask
3. Input a new WAN port subnet mask and press # key:
4. Use “*”to replace “.”, user can input 255*255*255*0 to set the new
WAN port subnet mask 255.255.255.0
5. Press “#”key to indicate that you have finished
6. Report “operation successful”if user operation is ok.
7. To quit, enter “**”.
(4)Gateway
1.
Pick up phone and press “****”to start IVR
2. Choose “4”, and the router reports current gateway
3. Input the new gateway and press “#”key:
4. Use “*”to replace “.”, user can input 192*168*20*1 to set the new
gateway 192.168.20.1.
5. Press “#”key to indicate that you have finished.
6.
Report “operation successful”if user operation is ok.
7. To quit, press “**”.
