Focal Access 165 A1 User manual

©Focal-JMlab - AS050926/2
Focal® est une marque de Focal-JMLab® - BP 374 - 108, rue de l’ venir - 42353 La Talaudière cedex
France - Tél. [phone] - Fax [phone] - www.focal-fr.com - SCSD050727/1
165 A1
6’’ Access 1 woofer (Aftersales Dpt ref: 6A1)
Ø165
Ø155
4 x Ø5.25
626.8
72
Ø85
Ø141
Nominal power 0 W
Maximum power 120 W
Sensitivity 92 dB
Cone Braided glass fi ber®
Surround Butyl
Nom. impedance 4 ohms
DC resistance 3.45 ohms
C diameter 25 mm 1 in
C height 11 mm 7/1 in
Former Kapton®
Layers 2
Wire Copper
Inductance 0.21 mH
Xmax 2.5 mm 1/1 in
Magnet d x h 85 x 15 mm 3-1/3 x 9/1 in
Magnet weight 0.35 kg 0. Ib
Flux density 1.3 T
Gap height 5.5 mm 3/1 in
Net weight 0.85 kg 1.87 Ib
30°
0°
Load (l) Fb (Hz) F-3 (Hz) Ql
Sealed 30 - 74 0.87
Sealed ----
Sealed ----
Suggested application
•
All weather woven
All weather woven
glass fi ber cone
glass fi ber cone
•
Phase plug
Phase plug
•
oice coil cooling system
oice coil cooling system
Unit : mm
Mechanical Drawing
100
95
90
85
80
75
70
65
60
55
50
dB SPL Ohms
110
100
90
80
75
60
55
40
30
20
10
10000100010010
Log Frequency - Hz
Frequency Response / Impedance
Fs 77.95 Hz
as 8.27 I
Qts 0.77
Qes 0.87
Qms 7.1
Re 3.4 ohms
Sd 137 cm2
Cas 5.87E-08 m5/N
Mas 70.97 kg/m4
Ras 4895.39 ohms.ac
Cms 3.14E-04 m/N
Mms 13.29 g
Rms 0.917 kg/s
Ces 514.88 mF
Les 8.1 mH
Res 28.1 ohms
BI 5.08 N/A
SPL 88.3 dB/W/m
Parameters
Specifi cations
