FOLD & GO HEAVY-DUTY SIZE User manual

HEAVYDUTY SIZE MODEL
© 1996-2017 FOLD & GO Wheelchairs® – A Division of OneKubedDESIGNS®, LLC.
User/Caregiver Manual

INTRODUCTION
PLEASE READ BEFORE OPERATING YOUR WHEELCHAIR
2
DO NOT OPERATE OR DRIVE THE WHEELCHAIR THROUGH RIVERS,
WATERWAYS, INTO LAKES, PONDS OR THE OCEAN. DO NOT USE THE
BATTERY IN A DIFFERENT CAPACITY OTHER THAN WITH YOUR FOLD
& GO WHEELCHAIR. KEEP TOOLS AND OTHER METAL OBJECTS AWAY
FROM THE POSITIVE AND NEGATIVE ENDS OF THE BATTERY.
User Safety
Caregiver Safety
Thank you for buying the FOLD & GO WHEELCHAIR®, which is designed and manufactured by OneKubedDESIGNS,
which is Trademarked. Before operating this electric wheelchair for the rst time, please read this manual carefully. This
instruction manual will help you to understand the performance, operation, features, and routine maintenance. Please
refer to this manual and or our website for how to videos on operating your new chair.
Please don’t use or operate this electric wheelchair until you have read and understand these instructions. If you can’t
understand these instructions, please contact us for technical guidance and help. Otherwise it may cause harm or danger
to yourself by not operating the chair correctly.
Always turn o the Joystick when entering and exiting the chair. Practice driving operations with the help of family,
friends or a caregiver, until you are independent and skilled in performing these operations while you are exploring the
world we live in.
Each FOLD & GO WHEELCHAIR® can be operated in manual or power mode. If you wish to manually push your client make
sure to move the red levers on each rear wheel motor to disengage the electromagnetic brakes. Also make sure that the
top headrest frame is locked into place, and not in the downward storage position. Before each movement tell your client
what you are doing to avoid any risk of accidental injury because they are not prepared to be moved. Cooperate with
your client and their physical limitations.
Wheelchair Easy Maintenance
There are a few things to do to keep your FOLD & GO WHEELCHAIR® running in top condition. Included with your chair
is a mini travel toolkit. We suggest you keep this tool kit in the storage bag under the seat, that way it is always with you.
Every 3 months we recommend you examine the bolts and screws of your chair to make sure everything is tight and
locked in place. If you take your chair on the airplane with you, then make sure to examine the bolts and frame for ANY
damage that might have happened from baggage handlers and the ight.
Your wheelchair will work best when you take care of it, just like you would your automobile. On your car, you keep oil
in the engine, you keep air in the tires, you ll it with gas to keep it running, and you keep it clean so it will not rust. Your
FOLD & GO WHEELCHAIR® needs a similar type of regular easy maintenance.

MODEL COMPONENTS
Please take a moment to make sure you have all of the following parts with your FOLD & GO WHEELCHAIR®. If
you are missing ANY components please contact us immediately at [email protected]om.
Accessories are sold separately.
HEAVY DUTY WHEELCHAIR
CHARGER
SEAT CUSHIONS
JOYSTICK CONTROLLER
TWO BATTERIES
SEAT BELT
FOLD & GO WHEELCHAIR® in your
desired color
Power charger with connection to
joystick, and power cord to plug
into the wall outlet
Two cushions, one for your seat
and one for the backrest
One joystick to control movement
of the chair. Can be placed on the
either the right or left armrest
Both batteries already come inside
the frame of the wheelchair.
Portable strap for safety while
riding in your chair, and to wrap up
the armrests when folded
3© 1996-2017 FOLD & GO Wheelchairs® – A Division of OneKubedDESIGNS®, LLC.

PARTS OF YOUR FOLD & GO WHEELCHAIR
4
Foot Plate
Joystick Controller
Rear Motor Wheel
Seat Cushions
Battery
Empty Storage Bag
Armrest Lock:
Turn lever to lock &
unlock armrests to
lift up for side entry

INSTRUCTIONS
5
Batteries Already Installed
Manual Mode - No Brakes
The Heavy-Duty model comes with two lithium-ion batteries. We
ship the batteries with your wheelchair. We have already placed each
battery inside the frame of the chair. You do not need to remove the
batteries in order to charge the chair. You can charge both batteries at
the same time, by plugging the charger into the joystick.
Move the red lever on the inside of each rear wheel motor, push it
forward until you feel a click. Then the wheel will spin free, so the chair
can be pushed just like a manual chair. Repeat the same process for
both wheels.
1.
3.
How to Install & Operate
Joystick Installation
Power Mode - Electromagnetic
The Joystick can be mounted on the left or right side armrest. Insert
the Joystick into the tube of the armrest. Tighten the Thumb Screw
bolt on the bottom-side of the armrest. Make sure this bolt is snug to
hold the Joystick in place.
Move the red lever on the inside of each rear wheel motor, pull it
backward until you feel a click. Then the wheel motor will be engaged
and power will move each wheel. Repeat the same process for both
wheels.
2.
4.

6
How to FOLD the FOLD & GO Electric Wheelchair
How to UNFOLD the FOLD & GO Electric Wheelchair
●Turn o the Joystick.
●Locate the black safety latch on the back of the wheelchair.
●Flip the black latch up to unlock the frame
●With one hand on the top frame and one hand on the footrest, bring both ends of the wheelchair together.
●You can also fold with one hand by pushing to top part of the frame towards the ground. The wheelchair
will fold up easily using one hand or two.
●Push apart the head rest and the footrest of the wheelchair.
●Place one hand on the top of the backrest, and with your other hand push the footrest down.
●Locate the black safety latch on the back of the frame.
●Push the latch down to snap it into place to lock the frame.
●You can also unfold the wheelchair with one hand. Simply place on hand on the headrest and lean the rest
of the chair towards the ground. With a slight jerk, let gravity pull the chair apart for you.

Specications of the Heavy-Duty FOLD & GO Electric Wheelchair
7
Net Weight 55 LBS
Weight Capacity 365 LBS
Motor 250 Watt x2 Brushless
Battery Lithium-Ion 24V/10AH Standard
Max Speed 4 MPH - 5-Speed Control Modes: 0.5 MPH, 1 MPH, 2 MPH, 3 MPH, 4 MPH
Turning Radius 31.5 inches
Grade/Slope 25 degrees
Charging Time 5 Hours
Seat Width 19 inches
Back Rest Height 16 inches
Seat Height 18 inches
Brake Type Electromagnetic
Driving Range 16 Miles per Battery
Overall Length 38 inches
Unfolded Width 24 inches
Folded Width 13 inches

8
Joystick Functions
Movement Direction to Move Joystick
FORWARD Move the joystick FORWARD
REVERSE Move the joystick BACKWARD
RIGHT TURN Move the joystick RIGHT
LEFT TURN Move the joystick LEFT
STOP Release your hand from the joystick
Increase Speed
Power OFF
5-Speed Modes
Decrease Speed
Battery Life
Power ON

9
When the LED light on the Joystick ickers, it means that there is something wrong with the wheelchair. An
alarm may also sound from the rear motor wheels, brakes, batteries, wire connections, or from the wheelchair
itself. Below are the diagnostic codes to help you identify any problems you may be experiencing while using
your FOLD & GO Wheelchair:
Joystick Diagnostics
Power Light Warnings Description & Troubleshoot
Flash Once Joystick cable is loose to black junction box under the seat
Flash Twice Left rear motor wheel is not connected
Flash 3 Times Right rear motor wheel is not connected
Flash 4 Times Battery is not getting the correct voltage to charge
Flash 5 Times Check left rear motor, power cable is loose or not connected
Flash 6 Times Check right rear motor, power cable is loose or not connected
Flash 7 Times Check left brake motor, power cable is loose or not connected
Flash 8 Times Check right brake motor, power cable is loose or not connected
Flash 9 Times Contact FOLD & GO Customer Service
Flash 10 Times Contact FOLD & GO Customer Service
Beeps in Any Direction The rear wheels are in manual mode. Move the red lever backwards
One Click at Start This sound means the brakes have released to start driving...This is GOOD!
One Click at Stop This sound means the brakes have engaged to stop...This is GOOD!

212 S. Meadowlark Street, Austin, TX 78734
Customer Service: 512-817-FOLD
[e-mail]
https://www.foldandgowheelchairs.com
© 1996-2017 FOLD & GO Wheelchairs® – A Division of OneKubedDESIGNS®, LLC.
DRIVING CONDITIONS & ENVIRONMENT
• Don’t try to drive the FOLD & GO WHEELCHAIR® when you are on a transport vehicle, like a bus, subway, trains,
planes, etc.
• While using public transportation vehicles, look for a place to x the wheels to the oor of the bus. This will
help you avoid harm that can be caused by the vehicle’s sudden stop or a trac accident.
• In many countries and regions, power wheelchairs are not allowed on public roads. The user must realize
that driving a wheelchair on the road instead of the sidewalk is dangerous.
• For easy recognization at night, a reective sticker is placed on the FOLD & GO WHEELCHAIR®. The user can
also wear reective clothing or add a ashing taillight.
• When confronting with other vehicles, please ensure that the driver has noticed you. Before you continue to
operate your wheelchair, make eye contact with the driver, and let the driver know your intention until you
are sure that it is safe.
• When driving the FOLD & GO WHEELCHAIR® keep the chair in balance, in order to avoid being bent over in the
forward or backward position.
• If you desire to modify or adjust the FOLD & GO WHEELCHAIR®, please consult us in advance. The modied
wheelchair may need to have additional adjustments to keep the chair working properly.
• Making any modications to your FOLD & GO WHEELCHAIR® might void ALL warranties.
• When you are entering or exiting the FOLD & GO WHEELCHAIR®, you must turn o the power supply.
Otherwise, if you touch the joystick, it may lead to the unexpected movement.
• The FOLD & GO WHEELCHAIR® is not suitable for driving up staircases, or on an escalator.
• When an elevator is not available, fold up the chair to move it from oor to oor by way of the stairs.
