fomex RollLite RL21-75 Technical manual

RollLiteRL21-75/RL31-100/RL31-150

Please read this operation instruction before using the product.
Stop using this product when abnormal operation is detected and contact the authorized
dealer of its purchase location.
Contents
IntheBox
ControllerOverview
SetUpX-Mount &HowtoConnect
HowtoInstall Clamp Shoe
TechnicalSpecifications
Notice & Warranty
InapplicableWarranty
2
3
4
5
6
7
8

IntheBox
2
RL21Kit
Kit Bag
X-MountBracket Controller
PowerSupply PowerCord(5m) ExtensionCable Clamp Shoe
RL21-75
(5m)
(2m)
RL31Kit
Kit BagController
PowerSupply PowerCord(5m) ExtensionCable Clamp Shoe
(5m)
(2m)
RL31-100/RL31-150
X-MountBracket

ControllerOverview
9
12
6 8
10
7
5
4
3
DETAIL
DCInput
ON/OFFSwitch
DMXOut
USB(5VDCOut)
DMXIn
(IfDMXconnection worksproperly,thestatusindicatorwillturnongreen)
CCTKnob–ColorTemperatureAdjustment
OutputPort
DimmerKnob - Brightness Adjustment
Battery Plate(Standard:V-Mount,Optional:GoldMount)
1
2
3
4
5
6
7
8
9
10
ButtonControlGuide
DefaultMode→QuickMode→DMXChannelSettingMode→DefaultMode
LockCCTandDIM:PressMODE buttonfor2~3seconds.LOCKwill displayandturn to lockmode.
IfinLockmode,CCT andDIMcannot be changed.)
Unlock:PressADJUST button for2~3seconds torelease.
QuickMode:ShortPressMODE button tochangeto Quick Mode.TheDefaultsettingof Q1(3200K),Q2(5600K) canbechanged.
DIMandCCT canbeadjusted to desiredvalue.
SetdesiredCCT:PressADJUST buttonon Quick Mode.
WhenCCTandDIMvalue blink,changetothe desiredvalueusing the dial,thenpressADJUST button again.
DefaultMode:Longpress Q1▲buttononQuickMode then pressQ2▼buttonto returntoDefaultMode.
ReleaseQUICKMode:Press MODE buttononceto getDMXchannelsetting screen.
(CCTand DIM valuewillgo back totheprevious valueinnormal mode)
SetDMXChannel:ShortpressMODE button twice,DMXwill be displayedandchannel blinks forchange.
Thensetthe channel using▲▼ buttonand press ADJUST buttontosave.
(WhenconnectingDMX Console,DMXchannel mode willdisplayautomatically.
PressMODE button once andchangethe channel using▲▼ buttonand pressADJUST buttonto save.)

4
Set Up X-Mount
HowtoConnect
Please connect the power supply or battery in the following order.
* Please use the supplied extension cable only.
PowerCord
Controller
RollLiteMat
PowerSupply
ExtensionCable
TheincludedX-Mount framecanbe quicklyand easily mounted
totheRollLite using thepush-pin one-touch locking inserts.
Battery (Optional)

5
HowtoInstallClampShoe
Mount the clamp with the Clamp Shoe to a light stand then,
the controller.

TechnicalSpecifications
CRI96~98 /TLCI98
2700K~6500K
0~100% DIM /DMX 512 /Manual
100KSteps
6Pin×1
IP64
12-24VDC (4Pin)
5VDC Out (USB forWDMX)
5PinXLR
120°
V-Mount/ Gold Mount
Input:12-24VDC
Display: Mono LCD
CCT:2700K~6500K
DIM:0~100%
Dimensions(mm) : 234 ×108 × 79.7
Weight(g) : 934
Spec. RL21-75 RL31-100 RL31-150
3100lux@1m;2700K,
3500lux@1m;6500K
2000lux@1m;2700K,
2300lux@1m;6500K
Input : AC100~240V50/60Hz
Output : 19V11.58A,220W
1500lux@1m;2700K,
1720lux@1m;6500K
100W
432
3’×1’( 91×46cm )
700
75W
312
2’×1’(66×34cm )
440
150W
684
3’×1’( 91×46cm )
720
LightOutput
PowerConsumption
CRI/TLCI
ColorTemperature
Dimmer
ColorTemp.Control
OutputConnector
(Waterproof)
MatIP Rating
Input
DCOut
DMXIn / Out
BeamAngle
LEDs
Battery Mounts
Dimensions(ft)
Weight(g)
Controller
PowerSupply

7
Notice
Please read this operation instruction before using the product.
- Please use the supplied AC Adapter only.
- IP64 has a protection against dust and splashed water,but should not be used in water.
When Mat is wet,dry surface and store in dry place.(Controllers are not waterproof.)
- Keep away from flammable objects.
-The proper operating temperature is from 0°C ~ 40°C.Do not expose the product to extreme cold or hot.
- Keep away from children.
- Do not drop or give a shock to the product.
-Turn off power after use and store the product in the supplied bag after fully cooling and drying.
Warranty
Warranty provisions for the product are listed below.Fomex is not responsible for damage arising from failure to
follow instructions relating to the Fomex product’s use.
If a defect of the product arises and a valid claim is received within the warranty period,Fomex will either repair
the defect at no charge,using new or refurbished replacement parts,or exchange the product with a product
that is new or which has been manufactured from new or serviceable used parts and is at least functionally
equivalent to the original product.
This warranty applies only to products manufactured by Fomex that can be identified by the trademark,trade
name,or logo affixed to the product.

8
InapplicableWarranty
CustomerInformation
SellerInformation
Product
Name
ContactNumber
Address
Name
ContactNumber
Address
Purchasingdate
Name
Pleasekeeptheproofofpurchaseand this warranty card for futureservice.
1.Expired warranty period
2.Breakage or damage caused by inappropriate usage,repair,maintenance and accident.
1) Installation and removal with improper external equipment or improper usage.
2) Damage to the product caused by external fault or any accident.
3) Exposure to the extreme environment such as abnormal temperature,
a solvent,an acid,a base,a flood and a humidity.
4) External damage like scratch,crush or crack.
3.Damage caused by installation,repair,improvement,addition,disassembly
by unauthorized institution or person.
4.Modified,replaced,removed information identifying the original product
5.Absence of valid warranty card
6.Unusable or damage caused by use of illegal nonstandard and unofficial software
7.Damage caused by accident,abuse,misuse,flood,fire,earthquake or other external causes.

VER.201903
www.fomex.com
Unit701,31-18Gil,Seongsui-ro,Seongdong-gu,Seoul Korea 04787
Tel:[phone] Fax:[phone] E-mail:[email protected]
Allproduct specifications aresubject tochangewithout notice.
