WiSilica Lumos Controls Iris E User manual

WED-W-EUSER GUIDE
Please read and follow the instructions in this guide before operating the unit
Iris E
PRODUCT OVERVIEW
SPECIFICATIONS
FEATURES
Lumos Controls Iris E facilitates the data flow between
multiple Lumos controls BLE mesh networks and a BMS. It
helps to set up two-way communication between the BMS
and Lumos controls mesh networks. This enables Lumos
Controls devices to respond to commands from the BMS
system and BMS components like HVAC to respond to
triggers from Lumos Controls sensors
The light blinking status enables users to
know the current state of the device.
Supports two-way communication between Lumos
Controls Mesh networks and BMS
Connects multiple Lumos Controls gateways to the BMS
Network connectivity for Iris E can be established using
Wi-Fi or ethernet
Supports 2.4 and 5GHz Wi-Fi bands
Specifications Value
Input voltage 5VDC
Input current 3A
Electrical
GREEN
Device Status
Red
Power Status
Power ON device
with 5VDC Adapter
Specifications RemarksValue
Dimensions
Net weight
Case material SS
3.93 x 3.25 x 1.28in
(100 x 82.7 x 32.5mm)
143gm(5.04oz)
Mechanical
Specifications Value
Operating temperature
Case temperature
Relative humidity
0 to 50ºC (32 to 122°F)
50ºC (122°F)
20-90%
Environmental
L x W x H
INTERFACE DESCRIPTION
Ethernet
Device ready to use
Light Blinking pattern
Iris E State LED pattern
Ethernet LED color Indication
Yellow Initiating connection with network
Data transferGreen
Initializing Solid ON
Configuration mode 100ms ON
100ms OFF
500ms ON
500ms OFF
1sec ON
1sec OFF
3sec ON
3sec OFF
5sec ON
5sec OFF
Unconfigured/Invalid configuration
Waiting for IP
Time not configured
Critical error Fast blink

Power ON the Iris E
Ethernet
Power ON
INSTALLATION
FCC ID: 2AG4N-WED-W-E
Iris E
WED-W-E
Edge Gateway
CONFIGURATION STEPS
1
Wait for 30 seconds and then connect to the hotspot that is advertised by the Iris E
2
Once hotspot is connected, within 5 minutes
3
https://192.168.50.5/
user can access the Iris E Web UI with IP
Login credentials will be Username: “admin” and Password:”Admin@1234”

IRIS E : WEB UI GUIDE
This will explain how user can access web UI of Iris E and configure it.
Settings
In this tab, user can provide the account details to which a fresh Iris E device needs to be synced from cloud. Once user apply the
settings cloud syncer service will sync details from server corresponding to the account mentioned.
In WiFi mode user can enter SSID, Password and security type.
User can select SSID from the dropdown list which contains
SSIDs in Proximity
Once configuration is done, the hotspot will go off. If the IP
is not known, user needs to repower the edgebox, connect
to the hotspot again and navigate to Settings -> Network
Settings to view the IP address.
If Hidden option is selected user can manually
enter the SSID and Password
In ETH mode user has 2 options STATIC and DHCP
1
2
3
Select Network Settings from Settings page.
User can select WIFI or ETH mode based on requirement
1.a)
3.a)
3.b)
1.b) 1.c)

When the Apply button is clicked selected network
configs are applied.This will take around 20 seconds
and redirected to the following page.
Since the hotspot is disabled after 2 or 5 minutes, the
Web UI will not be available from IP 192.168.50.5.
To get the new IP, repower Iris E and connect to hotspot.
Then go to Network Settings page again and view WIFI
or ETH ip.
Dashboard
DETAILS AVAILABLE FROM THE IRIS E WEB UI
This tab will show the current diskspace usage.
Gateway Management
This tab list the gateways belonging to the
current account for which the Iris E is
configured. From here we can do gateway
update. Our gateway will only communicate
with Iris E, not with the Cloud.
4
5
Currently assigned WIFI & ETH IP will be displayed. IP corresponding to previously configured interface will be highlighted here.
Note
Only the gateway with the time stamp will connect with Iris E. Rest of the gateways will connect with Cloud.
If using a DHCP LAN network, it is recommended to reserve the edge IP address in network so that the edge IP doesn't change in the
event of device reboot or network interruption.
The Cloud API End Point, Bundle Package, Bundle Id will
be same to the mobile application it’s commissioned
from
The Username and Password will be different
Initially the Iris E device will depend on Cloud but
once it gets synced from there on it will take details
from the local database

Device Management
To list the devices belonging to the
current account.
Gateway Diagnostics
To upload OTA file for gateway’s OTA
Group Management
To list groups belonging to the current account.
Space Management
To list spaces belonging to the current account.
Scene Management
To list scenes belonging to the current account.
Zone Management
To list zones available in the current account.

Edge Diagnostics
This tab will show the status of currently running services.
Check all the serviecs are active.
We can pull the Iris E log and do Iris E OTA from this page.
If the Green LED on the device is blinking every 5 seconds, it’s
working fine.
VPN access is required to pull the logs remotely, else the logs need
to be downloaded and shared.
If the Green LED on the device is blinking very fast, then the
device is not working.
Edge OTA
To upload edge patch file for upgrading
the Iris E
Users can also view the version details of
previous patches applied on the same page.
It provides 2 options
Pull Edge Log
Users can pull edge logs from here.
Refreshing the page after the edge log pull
request is triggered will list the log in the
table. Users can download it from there.
The Subnet has to be same for Jace Box, Gateway and Iris E. Make sure the network is fine for proper sync.
For both Jace Box and Iris E, we need to use static IP. So that the IP doesn’t change.
All Rights Reserved WiSilica Inc
www.lumoscontrols.com
20321 Lake Forest Dr D6,
Lake Forest, CA 92630
[phone]
Ver 1.2 Apr 2023
