Clevertronics L10 LIFELIGHT PRO LWPLIFE-PRO-CM Series Installation and operating instructions

1942142
V1.1
3 March 2020
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Zoneworks and DATA Monitored Options
Fittings with part numbers -ZW, -HV, -DATA are fitted with Zoneworks communications modules (nodes).
These fittings are monitored using either Powerline Carrier Technology that utilize the power cable to
provide data communication, RF transceiver modules operating in the ISM band or a dedicated data cable
to/from data routers installed on a dedicated data trunk connected to a central Server (can also be
connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor, coordinate
testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a single push
of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides a
multifunction indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
ZW, HV, DATA
Commissioned
LED on Solid (Green)
ZW, DATA Un-commissioned Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green
250mS, yellow 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at yellow 5s , 0ff 1s
HV
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI Option
Lifelights with part numbers LWPLIFE-PRO-DALI-CM are fitted with DALI modules (nodes) that facilitate
connection and integration to 3rd Party Lighting Control Systems. Before installing the LWPLIFE-PRO-
DALI-CM please confirm that the Lighting Control System has the capability to monitor DALI Emergency
Luminaires. The LWPLIFE-PRO-DALI-CM will be addressed and configured into the control system by
the Lighting Control System Commissioning Technicians and not Clevertronics.
State LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND” Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network OR a 5/6way
“structured wiring system” lead and plug facilitating the power and DALI connection. DALI connections
are marked as Da Da.
L10™ Weatherproof LIFELIGHT PRO Ceiling
Mount
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements of
AS2293.3: 2005 and AS/NZS CISPR15: 2011
NOTE: Standard product codes with this symbol are enabled
with Clevertest Plus capability. Please refer to the operation
guide supplied with the product for details.
Models:
LWPLIFE-PRO-xx-CM-yy
Testing:
Options:
Manual Test
xx = Blank
Zoneworks
xx = ZW
Colour variants
yy=BLK, MSLV
Z/W DATA
xx = DATA
DALI
xx = DALI
HIVE
xx = HV
Clevertest
xx = CT
(NOTE: -CT Products supplied with the Clevertest Plus Symbol are activated with Clevertest
PLUS capability. Please refer to the operation guide supplied with the product for details).
Spare Parts:
1530230
Battery, 3.3 Volt 5Ah Li-ion 200mm Lead and Bracket
1100817
Lifelight Pro Head Assembly, Round, LT, Blk, Gen 2
(For -BLK)
1100819
Lifelight Pro Head Assembly, Round, LT, Gen 2
AUM01370120001
LLIFE-PRO-CKIT-NP, LifelightPro,Control Only,Batten,L10, CTP, OWC, NP
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1942142
V1.1
3 March 2020
Installation:
This LWPLIFE-PRO-CM is a ceiling mount Emergency.
•Loosen the grub screw and remove the mounting plate from the fitting.
•Locate the installation position.
•Using the mounting plate as a template, mark out the holes required to mount.
•Position the plate to the surface while routing the power cable through the gland.
•Use suitable fixings to fasten the mounting plate to the mounting surface.
•Route and terminate the supply cables to the L, N & E terminals in the gear tray.(in the case of the
–DALI or –DATA fittings terminate the DALI or DATA cable to the terminals marked Da Da or
DATA).
•Reinstall the main assembly and secure with the grub screws.
•Apply power to the fitting and check operation.
•If the CTP capabilities are activated, please affix the CTP status label to a visible surface and Four
Segment Marking on the product will include an ‘’F’’ in third segment block.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, HIVE, DALI) simply insert
the relevant Smart Node PCA.
Dimensions:
Testing:
When the LWPLIFE-PRO-CM unit is connected to the un-switched active, it must be allowed to charge
the battery for at least 24 hours. The emergency lamp only illuminates during a power failure. Conduct
the following tests:
•During the first commissioning test the emergency lamp must illuminate for at least 2 hours after
disconnection from the main supply. The results of all tests are required to be recorded in a service
logbook, which is to be kept on-site at all times. If the unit fails to illuminate for the requisite time,
remedial action must be taken to repair the situation and once completed, the unit must pass a
subsequent test.
•To test, remove the screws holding the glass cover to the fitting to access the test button.
•Press and hold Test Button check that the emergency lamp is On.
•Alternately, turn off Mains Supply to the fitting. Verify the lamp is on.
•Release the Test Button or Switch on Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Below are a list of common problems and their possible causes:
Fault: The Green LED indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1, (refer to
spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
