FOR-A W310 User manual

FORA W310 / W320
Weight Scale
English
311-0000000-011
Version 1.0 2011/04

2
IMPORTANT SAFETY PRECAUTIONS
Thank you for purchasing the FORA W310 / W320 Weight Scale. This
instruction manual provides important information which helps you use
this device smoothly. If you have any other questions regarding this
product, please contact the place of purchase.
1. Use this device ONLY for the intended use described in this manual.
2. Read all the instructions and information in this manual before using
this device.
3. Do NOT use the device if it is not working properly or damaged.
4. Consult your physician or healthcare provider before beginning a
weight loss or exercise program.
5. Consult your physician before using this device if you are pregnant.
6. Do NOT step on the edge of the weighing platform or jump on the
weighing platform.
7. Do NOT step on the weighing platform when your body or feet are
wet.

3
8. Do not use the device on slippery surfaces such as wet oors.
9. Do NOT use cell phones, microwaves or other devices that gener-
ate strong electrical or electromagnetic elds near the device. This
may result in an operational failure.
10.Do NOT disassemble or try to modify the device.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE

4
TABLE OF CONTENTS
BEFORE YOU BEGIN 05
Body Mass Index 05
Recommended Measurement Time 05
Contents of the System 06
Scale Overview 06
Screen Display 08
SETTING THE SCALE 09
Setting the Unit of Weight 09
Adjusting Scale Settings 10
TAKING MEASUREMENTS 12
Before Measuring 12
Measuring the Body Mass Index (BMI) 13
Measuring Weight Only 15
SCALE MEMORY 16
MAINTENANCE 17
Low Battery Signal 17
Replacing the Battery 18
Cleaning 19
Scale Storage 19
SYSTEM TROUBLESHOOTING 20
Error Messages 20
SPECIFICATIONS 21
SYMBOL INFORMATION 22

5
BEFORE YOU BEGIN
Body Mass Index
The Body Mass Index (BMI) is a number that is often called upon to
evaluate body weight.
Recommended Measurement Time
To obtain an accurate reading, we recommend that you always take
the measurement in the same environment and at the same time of
day. Avoid taking measurements under the following conditions:
• Immediately after a bath or exercise
• After drinking alcohol or a large amount of water
• Less than 2 hours after a meal
If you take a measurement under any of the above conditions, the
calculated body composition may be signicantly different from the
actual composition due to changes in water content in the body.
BMI =
BMI =
body weight (Kg )
(height(m))2
body weight (lb)x703
(height(in))2

6
W310c-USB Cable
W310b-Bluetooth
W310a-RS232
W310d-No communication
Your new FORA W310/ W320 kit contains:
Scale Overview
Contents of the System
1. Weight Scale
2. Owner's Manual
3. Warranty Card
4. Four 1.5V Alkaline Batteries
(W310) Front
(W310) Back
LCD Screen
Down Button
SET Button
UP Button
Heel Position
Toe Position
Weight Unit Switch
Battery Cover /
Compartment
Data Port
Supporting Stand
1
1
4
4
5
5
2
2
3
3
6
6
7
8
9
10
10
1010
10
8
7
9
9
9

7
W320c-USB Cable
W320a-RS232
W320d-No communication
(W320) Front
(W320) Back
LCD Screen
Heel Position
Toe Position
Weight Unit Switch
Battery Cover /
Compartment
Data Port
Supporting Stand
1
1
4
4
5
5
2
2
3
3
6
7
7
77
7
6
6

8
Screen Display
(W310)
(W320)
Measurement Results
Measurement Results
Height Unit
Weight Unit
Weight Unit
Personal Prole Number
Age Indicator
Gender Indicator

9
SETTING THE SCALE
Before using the scale for the rst time, input these settings. To en-
sure accuracy, make sure you complete the steps below and save
the desired settings.
► Setting the Unit of Weight
The unit of weight can be set to lb (pounds), st (stones) or kg (kilo-
grams).
You can select the unit of weight by sliding
the switch to the desired unit indication.
When the weight unit is set to pounds or stones, the unit of height will
be automatically set to feet and inches. When the weight unit is set to
kilograms, the unit of height will be automatically set to centimeters.
Ib Stkg

10
► Adjusting Scale Settings (for W310 only)
Start with the scale off. Press SET to turn the scale on. All default set-
tings appear on the LCD. The default settings are as follows:
Item Gender Height Age
Setting Female 165cm / 5'4" 25
1. Select the personal prole number.
Press ▲ or ▼ to select a number from P0 to P9. Press SET.
2. Enter the personal prole data.
Press ▲ or ▼ to select the gender of male or female. Press SET.
Press ▲ or ▼ to set the height between 100 cm and 220 cm / 3' 3" and
7' 3". Press SET.

11
Press ▲ or ▼ to set the age between 10 and 80. Press SET.
3. Press SET to exit the setting mode.
If you make a mistake before you have nished setting, repeat the
steps from " Select the personal prole number. "

12
TAKING MEASUREMENTS
Before Measuring
• Place the scale on a hard, at surface. Soft or uneven ooring (e.g. car-
pets, rugs) may cause the scale to give an inaccurate weight reading.
• Take the measurement with dry feet, and position your feet correctly
on the electrodes. Remove your shoes and socks before stepping onto
the scale.
• Step onto the scale with your feet parallel to each other and your weight
evenly distributed.
• Weigh yourself on the same scale at the same time every day, before
breakfast or before getting dressed.

13
Measuring Body Mass Index (BMI)(for W310 only)
1. Press SET or tap on the weighing platform to turn on the scale.
The scale displays the prole setting of the last user.
Press ▲ or ▼ to select the number.
2. The scale displays the prole setting of the last user. Wait for “0.0 kg”
to appear on the LCD.
3. Step onto the weighing platform.
Stand still and distribute your weight evenly while the scale is measur-
ing your weight.

14
When the value is stabilized, it will ash three times and the scale will then calcu-
late your BMI.
4. Display the Result.
The scale shows your measurement results as follows:
5. Step off the weighing platform.
The result is saved in the scale memory (W310a, W310b, W310c) and
the scale turns itself off automatically.
Your Weight
Your BMI
BMI Symbol
Gender:Male
Personal Prole Number
Gender:Male

15
2. Step onto the weighing platform.
3. Step off the weighing platform.
Your weight is displayed on the LCD screen. The result is saved in the
scale memory (W320a,W320c) and the scale turns itself off automati-
cally.
Measuring Weight only (for W320)
1. Tap on the weighing platform to turn on the scale.
Wait for “0.0 kg” to appear on the LCD.
NOTE
The scale will not work properly if you step on the scales before it
shows . If this happens, please start from the beginning.

16
SCALE MEMORY
Your scale stores measurement results with the corresponding per-
sonal prole number in the scale memory.
Results in memory can be transmitted to the personal computer by
either cable or wireless connection for model W310a, W310b, W310c,
W320a, and W320c.
This allows you to transmit and review your measurement data on a
computer for up to 135 sets of measurement results.
During the data transmission, “PCL” appears on the LCD.

17
MAINTENANCE
Your scale is supplied four 1.5V AAA alkaline batteries.
► Low Battery Signal
The scale will display the message shown to alert you when the scale
power is running low. This means it is about time to replace the bat-
tery.
WARNING!
If the incorrect type of battery is used, it may cause damage to the
scale.

18
When replacing the battery, make sure that the scale is turned off.
1. Press the edge of the battery cover and lift it up.
2. Remove the old batteries and replace them with four 1.5V alkaline batteries
3. Close the battery cover.
NOTE
● Replacing the battery does not affect the test results stored in memory.
● Properly dispose of the batteries according to your local environmental
regulations.
● Batteries may leak chemicals if left unused for a long time. Remove the
battery if you are not going to use the device for an extended period (i.e.
3 months or more).
► Replacing the Battery

19
► Cleaning
1. To clean the outside of the scale, wipe it with a slightly damped cloth
and water or a mild cleaning agent, then dry the device with a soft dry
cloth. Do NOT immerse the device in water.
2. Do NOT use chemical or organic solvents to clean the scale.
3. Wipe the scale clean at once if any grease, sauce, vinegar, juice or
other substances that may cause damage are spilt on the scale.
► Scale Storage
● Storage condition: -20°C - 60°C (-4°F -140°F), below 95% relative
humidity.
● Avoid dropping the scale or heavy impact.
● Avoid direct sunlight and high levels of humidity.

20
SYSTEM TROUBLESHOOTING
► Error Messages
MESSAGE WHAT IT MEANS WHAT TO DO
The weighing
subject exceeds the
maximum capacity
of the device.
Remove the weigh-
ing subject from the
platform to avoid
damage.
The weighing sub-
ject is under detect-
able range.
Review the instruc-
tions and repeat the
measurement.
If you follow the recommended action but the problem persists, or if er-
ror messages other than the ones shown above appear, please contact
local customer service. Do not attempt to repair the device by yourself
and do not try to disassemble the scale under any circumstances.
