Fora Care
Blood Pressure Monitoring System
Model number: P80
Owner’s Manual
Version 1.0
2013-06

A2.1‐2of30
Dear FORA Blood Pressure Monitoring System Owner:
Thank you for purchasing the FORA Blood Pressure Monitoring System.
This manual provides important information to help you operate this system
correctly. Before using this product, please read the following contents
thoroughly and carefully.
With the compact size and easy operation of this system, you can easily
monitor your blood pressure by yourself at any time or place. In addition, this
system can help you and your healthcare professionals to monitor and adjust
your treatment plans, and keep your blood pressure under control.
If you have other questions regarding this product, please contact the place of
purchase.

A2.1‐3of30
IMPORTANT SAFETY PRECAUTIONS
READ BEFORE USE
1. Use this device ONLY for the intended use described in this manual.
2. Do NOT use the device if it is not working properly or damaged.
3. Do NOT use the equipment where aerosol sprays are being used, or where
oxygen is being administered.
4. Do NOT use under any circumstances on newborns.
5. This device does NOT serve as a cure for any symptoms or diseases. The
data measured are for reference only. Always consult your doctor to have
the results interpreted.
6. Keep the equipment away from hot surfaces.
7. Do NOT apply the cuff to areas other than the place directed.
8. Use of this instrument in a dry environment, especially if synthetic materials
are present (synthetic clothing, carpets etc.) may cause damaging static
discharges that may cause erroneous results.
9. Do not use this instrument in close proximity to sources of strong
electromagnetic radiation, as these may interfere with the accurate
operation.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE

A2.1‐4of30
TABLE OF CONTENTS
BEFORE YOU BEGIN
Intended Use
Test Principle
Contents of System
Meter Overview
Display Screen
HOW TO INSTALL AND UPDATE THE TDLink BP
BLUETOOTH PAIRING
IMPORTANT INFORMATION ABOUT PERFORMING YOUR BLOOD
PRESSURE TEST
Before Measurement
Fitting the Cuff Properly
Proper Measurement Position
HOW TO TEST YOUR BLOOD PRESSURE
Taking Measurement by the Device Itself
Taking Measurement with the TDLink BP App
VIEWING PAST TEST RESULTS
Data
Analysis
FAQ
MAINTENANCE
Battery
Caring for Your Meter
DETAILED INFORMATION
SYSTEM TROUBLESHOOTING
Result Readings of App
Error Messages of Meter
Troubleshooting
SPECIFICATIONS

A2.1‐5of30
BEFORE YOU BEGIN
Intended Use
FORA Blood Pressure Monitoring System is a system designed to measure
the systolic and diastolic blood pressure and pulse rate by using a non-invasive
technique in which an inflatable cuff is wrapped on the upper arm. It is intended
for individuals age 18 and above use at home and in clinical settings. The
device is not to be used for the diagnosis of hypertension or for testing on
newborns.
Test Principle
Blood pressure is measured non-invasively at the arm based on oscillometric
method.
This device is NOT able to take measurements in the presence of common
arrhythmia, such as atrial or ventricular premature beats or atrial fibrillation. It
may produce reading error.
Contents of System
Your new FORA Blood Pressure Monitoring System includes:
(1) Meter with cuff
(2) Owner's manual
(3) Warranty card
(4) 4 x AAA batteries
(5) Protective Wallet

A2.1‐6of30
Meter Overview
1. CUFF
2. BT INDICATOR
Download test results with a Bluetooth connection.
3. DISPLAY SCREEN
4. BATTERY COMPARTMENT
5. ON/OFF BUTTON
6. BT PAIRING BUTTON
1.
2.
3.
4.
5. 6.

A2.1‐7of30
Display Screen
1. Systolic Pressure Value 5. Pulse Rate
2. Diastolic Pressure Value 6. Diastolic Pressure Symbol
3. Pulse Rate Symbol 7. Systolic Pressure Symbol
4. Low Battery Symbol 8. Units of Blood Pressure
1. 2. 3.
4.
5.
6.
7.
8.

A2.1‐8of30
HOW TO INSTALL AND UPDATE THE
TDLink BP
. You can use the device, FORABlood Pressure Monitoring System, by itself or
with the TDLink BPApp. TDLink BPApp is available on the App Store/Play
Store for free download. You must be connected to the internet to download
the App.
TDLink BPApp is designed to assist you in easy blood pressure testing,
recording, tracking and monitoring.
It is simple and intuitive to use, for better understanding of your current
condition and to achieve better hypertension control.
System Requirement
iOS version 5.0.1 or higher.
Updating
When new features are added to the TDLink BPApp, the App Store will notify
you automatically. Please perform the updates accordingly to provide you with
the latest features that we have developed in your best interest.

A2.1‐9of30
BLUETOOTH PAIRING
Please note that you must complete the pairing between meter and
Bluetooth receiver before transmitting data.
NOTE:
This step is recommended when the user needs to pair this meter to a
Bluetooth receiver for the first time, or when user needs to pair this meter to
another new Bluetooth receiver.
1. Installing the TDLink BP app
For more information, please refer to the section” HOW TO INSTALLAND
UPDATE THE TDLink BP”.
2. Connecting blood pressure meter with your mobile device
Turn on the Bluetooth on both your blood pressure meter and your mobile
device (iOS with 5.0.1 or higher and Android with 2.3.3 or higher). “PCL” will
appear on the meter display and the BT indicator will start to flash.
Your mobile device will now begin searching for the Bluetooth signal to pair
with.
Once the mobile device has found the blood pressure meter; the name of the
meter will appear on the pairing list. Please select and add to the list.
On the mobile phone, the blood pressure meter will be shown as a paired
device and on the blood pressure meter the Bluetooth Indicator LED will light
solid, indicating that the devices have been successfully paired.
3. Data transmission
The data transmission will begin spontaneously right after the measurement
when the Bluetooth is turn on.

A2.1‐10of30
Bluetooth indicator on the blood pressure meter:
BluetoothIndicator Status
Flashfast ThemeterissearchingthedeviceofBluetooth
signal.
Flashslowly ThemeterispairingwiththedeviceofBluetooth.
Litsolid Themeteristransmittingthedatanowthe
connectionisestablished.
Mobile Phone Compatibility Issues
The Bluetooth functionality is implemented in different ways by the various
mobile phone manufacturers. Unfortunately, in some mobile phone models,
even with Bluetooth functionality, they may be compatible only with certain
types of devices. If a problem occurs in the connection between your mobile
phone and the blood pressure meter, or if you are uncertain regarding your
mobile phone’s Bluetooth capabilities, please consult your mobile phone
manual or blood pressure meter manual or alternatively contact your local
customer service for assistance.

A2.1‐11of30
IMPORTANT INFORMATION ABOUT
PERFORMING YOUR BLOOD PRESSURE TEST
Before Measurement
Avoid caffeine, tea, alcohol and tobacco for at least 30 minutes before
measurement.
Wait 30 minutes after exercising or bathing before measurement.
Sit or lie down for at least 10 minutes before measurement.
Do not measure when feeling anxious or tense.
Take a 5-10 minute break between measurements. This break can be
longer if necessary, depending on your physical condition
Keep the records for your doctor as reference.
Blood pressure naturally varies between each arm. Always measure your
blood pressure on the same arm.
Apply the Cuff Properly
1. Stretch your left (right) arm in front of you with your palm facing up. Slide and
place the cuff onto your arm, the arrow should point toward the upper arm.
2. Wrap and tighten the cuff above your elbow. The red line on the edge of the
cuff should be approximately 0.8ʺto 1.2ʺ(2 cm to 3 cm) above your elbow.

A2.1‐12of30
3. Leave a little free space between the arm and the cuff; you should be able to
fit two fingers between them. Clothing must not restrict the arm. Remove all
clothing covering or constricting the measurement arm.
4. Press the hook material firmly against the pile material. The top and bottom
edges of the cuff should be tightened evenly around your upper arm.
Proper Measurement Position
1. Sit down for at least 10 minutes before measuring.
2. Place your elbow on a flat surface. Relax
your hand with the palm facing up.
3. Make sure the cuff is about the same height
as the location of your heart.
4. Press ON/OFF Button. Remain still and do not talk or move during the
measurement.
WARNING:
►If the cuff is relatively lower (higher) than the heart, the obtained blood
pressure value could be higher (lower) than the actual value. A 15 cm
difference in height may result in an error around 10 mmHg.
5. Measurement is in progress.
After the meter is turned on, the cuff will begin to inflate automatically.

A2.1‐13of30
HOW TO TEST YOUR BLOOD PRESSURE
Taking Measurement by the Device Itself
Always apply the pressure cuff before turning on the meter.
1. Press ON/OFF Button. All the LCD symbols will appear with a long
“beeping”sound. Then the cuff will begin to inflate automatically.
2. Pump starts to inflate and pressure in cuff increases to working pressure.
3. The heart symbol “ ” will show silently when pulse is detected during the
deflation. When signal of pulse becomes strong, “ ” icon starts to flash.
4. After the measurement, the meter displays the systolic pressure, diastolic
pressure and pulse rate.
5. Press ON/OFF Button to switch off. Or it will switch off automatically after
being idle for 3 minutes.
NOTE
If you press ON/OFF Button during measurement, the meter will be turned
off.

A2.1‐14of30
Taking Measurement with the TDLink BP App
1. Turn on the Bluetooth switch on your mobile and connect with “FORA Blood
Pressure Monitoring System” before doing the test.
2. Turn on TDLink BPApp; always apply the pressure cuff before turning on
the meter.
3. Press ON/OFF Button. All the LCD symbols will appear with a long
“beeping” sound on the device monitor. Then the cuff will begin to inflate
automatically until it reaches the working pressure.
4. Pulse rate is detected during the deflation.
5. After the measurement, the meter displays the systolic pressure, diastolic
pressure and pulse rate.

A2.1‐15of30
6. Press ON/OFF Button to switch off. Or it will switch off automatically after
being idle for 3 minutes.
NOTE
If you press ON/OFF Button during measurement, the meter will be turned
off.

A2.1‐16of30
VIEWING PAST TEST RESULTS
Data
Reviewing Data Record
The meter stores the blood pressure test results along with respective dates
and times in memory under the mobile device.
Data Record Screen
1. Press “Data” on the main menu bar to review the records. The first reading
you see is the last blood pressure result.
2. Swipe left or right to recall the previous test results stored in the memory.
Blood Pressure Test Result
Blood Pressure unit
Pulse Rate Test Result
Pulse Rate Unit

A2.1‐17of30
VIEWING PAST TEST RESULTS
Analysis
Reviewing Blood Pressure Day Average Results
The TDLink BPApp offers you 7-, 14-, and 30- day average results and Pie
Chart to assist you to monitoring your blood pressure.
Day Average Screen
1. Press “Analysis” on the main menu bar to enter the Day AVG records.
2. You will see the current 7 Days of blood pressure control ratio in
percentage and the distribution of all the results.
3. Click at Detail Information (red circle) to find out more information.
4. To quickly switch between, simply press “7”, “14” and “30” icon on the
top.
7-Days of Blood Pressure Control Ratio
in Percentage
Detail Information
Blood Pressure Day AVG Result
Distribution of 14 Days Blood Pressure Results
Pulse Rate Day AVG Result

A2.1‐18of30

A2.1‐19of30
FAQ
1. Select the FAQ mode from the Main Menu Bar.
Select FAQ in the Main Menu Bar to enter, and then the Sub Menu will appear.
You will see the information categorized into different sections, such as
Self-Monitoring, Diet Control, Exercise, Medication and Overview.
If you wish to find the specific information much quicker, you can also search
by typing key words in the search bar on the top of each section page.

A2.1‐20of30
MAINTENANCE
Battery
Your meter comes with four (4)1.5V AAA size alkaline batteries.
Low Battery Signal
The meter will display either of the two messages below to alert you when the
meter power is getting low.
1. The symbol appears along with display messages: The meter is
functional and the result remains accurate, but it is time to change the
batteries.
2. The symbol appears with E-b:
The power is not enough to do a test. You must change the batteries
immediately.
