Forest SCP90 User manual

FIXING PACK CONTAINS:
It’s vital that you build your new pergola on a level ground in your desired location.
Making British gardens great
SLATTED CORNER PERGOLA
INSTRUCTIONS
Missing Something?
Call our aftersales team on
0333 777 7089
Need more information?
Call our technical team on
0333 321 3142
Visit our website for spare
instructions and more
information
www.forestgarden.co.uk
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
ISSUE: 0120
FIXING PACK CODE: SCP90FP
We recommend using the following tools (NOT SUPPLIED):
Tape
Measure
Pozidrive
Screwdriver
Drill & 2mm
Drill Bit
Hammer Ladder Spirit Level
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
THE ROOF OF THIS PERGOLA IS NOT A LOAD BEARING STRUCTURE
REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 5+
adults.
6 x 120mm Screws
QTY: 12
5 x 80mm Screws
QTY: 20
4 x 50mm Screws
QTY: 24

FRONT
BACK
1
2
Layout the fascia’s on a at surface to help line up accurately. Screw the corners together as shown above. Ensure
all of the faces and edges are ush. Screw into place with 120mm screws.
Once you have secured the fascia’s together, apply the slatted inserts. Screw into position with 2 x 50mm screws at
the top and bottom of each insert. 4 x 50mm screws per insert.
CONSTRUCTION
130mm
750mm
PREPARATION
We strongly advise that you anchor your pergola down with either xtures shown below to enhance stability. You will need to purchase these
separately. Apply each xture to each leg before fully constructing your pergola. 130mm of your post will be supported within the xture.
FOR PATIO/DECKING (HARD SURFACES)
Easy-Fit Fencebase - 65mm
(FBEF65)
FOR GRASS/SOIL
(SOFT SURFACES)
Easy-Fit Fencefast
(FEF6575)
Ensure that the spike can be
inserted into the ground by
750mm.
FRONT CORNERSBACK CORNER
120MM
SCREWS

3
4
Assemble this stage with 3 adults holding onto a post each. If your 3 posts are anchored, use the measurements
provided as a guide for spacing. Lift up the assembled roof and place onto the designated grooves provided on
the posts as shown above. Screw through the fascia’s into the posts with 120mm screws.
Secure the front angled braces to the front fascia. These will have a slightly different angle to position onto the post
compared to the other 4 braces. Use 50mm screws to x the internal faces together. Use 80mm screws at an angle
to secure the brace to the post. Repeat this process on the opposite post.
Attach the back and side angled braces. Ensure the outer brace face is ush to the fascia face and end to end.
Use 80mm screws to secure to the bottom of the fascia and to the post. Repeat this process for all 4 angled braces.
5
120MM
SCREWS
BACK CORNER
120MM
SCREWS
FRONT CORNERS
1748mm
1748mm
INTERNAL
EXTERNAL

Part Code
Description No.
SCP90BP Back Post 1
SCP90LRRAF Side Fascias 2
SCP90FRAF Front Fascia 1
SCP90FP Front Post 2
SCP90AB Sides & Back Angled Braces 4
SCP90RHFAB Right Hand Front Angled Brace 1
SCP90LHFAB Left Hand Front Angled Brace 1
SCP90CINS Centre Slatted Insert 1
SCP90LRHINS Larger Right Hand Slatted Insert 1
SCP90LLHINS Larger Left Hand Slatted Insert 1
SCP90SRHINS Right Hand Triangular Slatted Insert 1
SCP90SLHINS
Left Hand Triangular Slatted Insert 1
Slatted Corner Pergola (SCP90)
CHECK YOU HAVE ALL YOUR PARTS.
(The parts do not have codes on them. They are listed below should you need to order one.)
TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
