Forest POTATO PLANTER User manual

REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
Tape Measure Drill & 2-3mm
Drill Bits
Pozidrive
Screwdriver
50MM
SCREWS
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
POTATO PLANTER
INSTRUCTIONS
ISSUE: 0122
We recommend using the following
tools (not supplied):
FIXING PACK CONTAINS:
FIXING PACK CODE: POTPLANTFP
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS
AWAY FROM CHILDREN
4 x 50mm Screws
QTY: 12
3.5 x 30mm Screws
QTY: 12
3 x 15mm Screws
QTY: 18
Ensure the edge of Back Panel is ush to the Base on
the one side as shown above. Secure the Side Panel to
the Back Panel as shown above.
Position the Base and sit your Side Panel onto the
bearers. Slot the Side Panel and Back Panel together.
1
CHECK AND TIGHTEN ALL THE FIXINGS APPLIED TO THIS PRODUCT
ON A REGULAR BASIS.
SIDE PANEL
BASE
Butt Hinges
QTY: 2
Bolt & Receiver
QTY: 1
BACK PANEL
Making British gardens great

50MM
SCREWS
30MM
SCREWS
30MM
SCREWS
30MM
SCREWS
3
4
Position and secure the Back Panel to the Base.
Ensure the Back Panel is ush top and bottom to the
Side Panel.
Position and secure the Side Panel to the Base. Ensure
the Side Panel is ush top and bottom to the Back Panel
and ush when slotting them together.
Secure the Side Panel and Back Panel together.
Place the Front Panel onto the oor and position the Door into the opening. The xings can be secured based on
the 2 x options above and based on your preference.
2
Position and secure the Side Panel to the Base.
SIDE PANEL
FRONT PANEL
DOOR
FRONT PANEL
DOOR
SIDE PANEL BACK PANEL

50MM
SCREWS
30MM
SCREWS
15MM
SCREWS 15MM SCREWS
6
5
Once you are happy with your bolt and receiver
positions, secure them in place.
Position and secure the Front Panel to the Base.
Ensure the Front Panel is ush top and bottom to the
Side Panels and ush when slotting in place.
Secure the Front Panel and Side Panels together.
Once you are happy with your hinge positions, secure
them in place.
HEALTH & SAFETY
We strongly recommend that PPE (Personal Protective Equipment) is used throughout your build to ensure you are
protected from any potential health and safety risks. Do not exempt yourself from wearing PPE.

TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
Use the labelled components to help identify the part code and description.
CHECK YOU HAVE ALL YOUR PARTS PRIOR TO ASSEMBLY.
(The parts do not have codes on them. They are listed below should you need to order one.)
Timber is a natural material of which will shrink and swell as a result of varying moisture content.
Assembly of damaged parts may be deemed to be acceptance and this may affect the remedies you are entitled to. If the product is not constructed
in accordance with the instructions, or is altered in anyway (e.g. painted), the manufacturer cannot be held liable for any resulting damage.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
Label Part Code Description No.
APOTPLANTBASE Base 570x600mm 1
BPOTPLANTSIDE Side Panel 600x665mm 2
CPOTPLANTBACK Back Panel 600x665mm 1
DPOTPLANTFRONT Front Panel 600x665mm 1
EPOTPLANTDOOR Door 284x395mm 1
Potato Planter (POTPLANT)
A B CD E
