FortiSIEM 3500F Hardware Configuration Guide

FORTINET DOCUMENT LIBRARY

https://docs.fortinet.com

FORTINET VIDEO GUIDE

https://video.fortinet.com

FORTINET BLOG

https://blog.fortinet.com

CUSTOMER SERVICE & SUPPORT

https://support.fortinet.com

FORTINET TRAINING & CERTIFICATION PROGRAM

https://www.fortinet.com/support-and-training/training.html

NSE INSTITUTE

https://training.fortinet.com

FORTIGUARD CENTER

https://fortiguard.com/

END USER LICENSE AGREEMENT

https://www.fortinet.com/doc/legal/EULA.pdf

FEEDBACK

Email: techdoc@fortinet.com

10/13/2020

FortiSIEM 5.4.0 3500F Hardware Configuration Guide

TABLEOFCONTENTS

FortiSIEM 3500F Hardware Configuration Guide 1

Change Log 4

Appliance Setup 5

Step 1: Rack mount the FSM-3500F appliance 5

Step 2: Power On the FSM-3500F appliance 5

Step 3: Verify System Information 6

Step 4: Configure Network 6

Step 5: Generate FortiSIEM FSM-3500F License Key file from FortiCare 7

Step 6: Register FortiSIEM License 7

Step 7: Accessing FortiSIEM UI 7

Step 8: Using FortiSIEM 7

Factory Reset 8

Step 1: Uninstall FortiSIEM application 8

Step 2: Reinstall FortiSIEM application 8

Upgrading FortiSIEM 9

Appliance Re-image 10

Step 1: Create Bootable Linux Image 10

Step 2: Copy FortiSIEM Appliance image to USB 10

Step 3: Prepare 3500F by removing FSM 11

Step 4: Configure 3500F BIOS to Boot into USB Drive 11

Step 5: Re-image 3500F boot drive from USB Linux 11

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 3

Fortinet Technologies Inc.

Change Log

Date Description

03/30/2018 Initial release of this guide.

06/13/2019 Revision 1: Updated instructions for "Using FortiSIEM".

09/11/2019 Revision 2: Changed the location where you obtain images to

https://support.fortinet.com.

08/24/2020 Revision 3: Minor edits.

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 4

Fortinet Technologies Inc.

Appliance Setup

Follow the steps below to setup FSM-3500F appliance.

Step 1: Rack mount the FSM-3500F appliance

1. Follow the QuickStart Guide here to mount FSM-3500F into rack.

2. Insert Hard Disks positions as shown below:

3. Connect FSM-3500F to the network by connecting an Ethernet cable to Port0.

Before proceeding to the next step, connecting Ethernet cable to Port0 is required for

Network configuration.

Step 2: Power On the FSM-3500F appliance

1. Make sure the FSM-3500F device is connected to a Power outlet and an Ethernet cable is connected to Port0.

2. Power On the FSM-3500F device.

FSM-3500F appliance does not have a default IP address. To connect to the GUI, an IP

address must be configured using the CLI (Step 4).

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 5

Fortinet Technologies Inc.

Appliance Setup

Step 3: Verify System Information

1. Connect to the FSM-3500F appliance using VGA port or Console port.

2. Login as ‘root’ user with password 'ProspectHills'.

3. Run get to check the available FortiSIEM commands.

4. Use the below commands to check the hardware information. After running each command, ensure that there are

no errors in the displayed output.

Command Description

get system status Displays system name, version and serial number.

diagnose hardware info Displays system hardware information like CPUs, Memory

and RAID information.

diagnose interface detail port0 Displays interface status.

Step 4: Configure Network

1. On the hardware console, selectSet Timezoneand then pressEnter.

2. Select yourLocation, and then pressEnter.

3. Select yourCountry, and then pressEnter.

4. Select yourTimezone, and then pressEnter.

5. Review your Timezone information, select1, and then pressEnter.

6. When theConfigurationscreen reloads, selectLogin, and then pressEnter.

7. Enter the default login credentials:

Password ProspectHills

8. Run thevami_config_netscript to configure the network.

/opt/vmware/share/vami/vami_config_net

9. When prompted, enter the information for these network components to configure the Static IP address:IP

Address,Netmask,Gateway,DNS Server(s).

Note: The authenticated proxy server is not supported in this version of FortiSIEM.

10. PressYto accept the network configuration settings.

11. Enter theHost name,and then pressEnter.

Once the configuration is complete, the system reboots automatically.

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 6

Fortinet Technologies Inc.

Appliance Setup

Step 5: Generate FortiSIEM FSM-3500F License Key file from FortiCare

1. Obtain the Hardware Serial Number from FSM-3500F appliance.

2. Follow Licensing Guide here to generate the license key file - remember to use ‘Hardware Serial Number’ for

Hardware ID.

Step 6: Register FortiSIEM License

1. Note the IP Address assigned to FortiSIEM VM in Step 4.

2. Access FortiSIEM VM from browser (https://<FortiSIEM-IP>).

3. Upload the license file obtained from Step 5 and select the License Type based on your deployment (note this

choice can only be made once and is not reversible):

lEnterprise for single organizations

lService Provider for multiple organizations

4. Click Upload to complete the license registration.

Step 7: Accessing FortiSIEM UI

1. Note the IP Address assigned to FortiSIEM VM in Step 4.

2. Access FortiSIEM VM from browser (https://<FortiSIEM-IP>).

3. Login to FortiSIEM using the default user name, password, and organization:

lUserID:admin

lPassword:admin*1

lCust/OrgID:super (if shown)

Step 8: Using FortiSIEM

Refer to the “Setting Event Storage” section in the User Guide for detailed information about using FortiSIEM and

understanding the storage options.

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 7

Fortinet Technologies Inc.

Factory Reset

Follow the steps below to perform factory reset on FortiSIEM FSM-3500F.

Step 1: Uninstall FortiSIEM application

1. Connect FortiSIEM device using VGA or Console port.

2. Login as ‘root’ user with password 'ProspectHills'.

3. To check the available FortiSIEM commands, run get.

4. To uninstall FortiSIEM, run execute fsm-clean.

This script will uninstall FortiSIEM application.

Step 2: Reinstall FortiSIEM application

1. Power on the hardware.

2. Login as ‘root’ without password 'ProspectHills'.

3. To configure RAID, run execute format disk.

4. To check Hardware status and RAID information, run diagnose hardware info.

5. To install FortiSIEM, run execute factoryreset.

This script takes 5 minutes to complete FortiSIEM installation.

6. To configure network on FortiSIEM, stop FortiSIEM services by running sudo execute preparebox.

This script will stop running FortiSIEM services and power offs the hardware.

Follow the steps under Appliance Setup to configure FSM-3500F.

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 8

Fortinet Technologies Inc.

Upgrading FortiSIEM

For upgrading FortiSIEM from v4.10.0 to v5.0.1, refer to the section 'Upgrading a FortiSIEM Single Node Deployment'

in the 'Upgrade Guide' here.

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 9

Fortinet Technologies Inc.

Appliance Re-image

Ensure that the following prerequisites are met before re-imaging FortiSIEM.

Hardware Software

Peripherals

lUSB Keyboard

lUSB Mouse

lVGA Monitor

USB Thumbdrive

l4 GB Thumbdrive (for Linux installation)

l8 GB Thumbdrive (for FortiSIEM appliance

image)

lUbuntu Desktop Setup Files

lRufus (Bootable USB Utility)

lFortiSIEM Appliance Image

Follow the below steps to re-image FortiSIEM.

Step 1: Create Bootable Linux Image

1. Connect 4GB USB drive to the system (desktop or laptop).

2. Open Rufus.

3. Select the following settings for the USB:

a. Partition scheme and target system type: MBR partition scheme for BIOS or UEFI

b. File system: FAT32

c. Cluster size: 4096 bytes (Default)

d. Quick Format: Enable

e. Create a bootable disk using: ISO image

4. Click on the 'CD-ROM' icon and select the Ubuntu Setup ISO.

5. Click Start and allow Rufus to complete.

Once finished, the disk is ready to boot.

Note: Alternatively, you can use the Ubuntu guide for creating a USB drive with Ubuntu.

Step 2: Copy FortiSIEM Appliance image to USB

1. Connect 8GB USB Drive to the system (desktop or laptop).

2. Open Windows Explorer > right-click Drive > click Format.

3. Select the following options:

a. File system: NTFS

b. Allocation unit size: 4096 bytes

c. Quick Format: Enable

4. Copy the image file to USB drive.

For example:

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 10

Fortinet Technologies Inc.

Appliance Re-image

FSM_Full_Super-Worker_RAW_HW_VA-5.4.0.1679.zip

5. Safely remove the USB drive from the desktop or laptop by unmounting it through the Operating System.

Step 3: Prepare 3500F by removing FSM

1. Connect to the console/SSH of the FortiSIEM appliance.

2. Run the following command: execute fsm-clean

3. After fsm-clean is complete, format RAID by executing the command: execute format disk

4. Power-off the FortiSIEM appliance.

Step 4: Configure 3500F BIOS to Boot into USB Drive

1. Connect the 4GB USB drive to the FortiSIEM appliance.

2. Power on the FortiSIEM appliance.

3. During the boot screen, press F11 to login to the boot options.

4. Select the option to enter into the BIOS set up.

5. Select the option for Boot options.

6. Select the 'USB drive'.

7. Save the options and quit set up.

Step 5: Re-image 3500F boot drive from USB Linux

1. Power on FortiSIEM appliance.

2. Once the FortiSIEM appliance loads from the USB drive, click Try Ubuntu.

3. Connect the 8GB USB drive to the FortiSIEM appliance.

4. Open a terminal.

5. Type the following command to identify the FortiSIEM boot disk (29.5GiB): sudo fdisk –l.

Note: This drive will be referred as /dev/sdb in the following steps..

6. Enter into root while in the terminal using the following command:

sudo –s

7. Determine the mount point of this drive by using the following command:

df –l

Note: For this guide, the assumption for the 8GB mount point is: /media/ubuntu/123456789/*

8. Copy the image from the 8GB disk to the FortiSIEM boot disk.

9. Extract the zipped raw image and copy the image into SATA disk (32GB).

For example, use the command:

unzip -c FSM_Full_Super-Worker_RAW_HW_VA-5.4.0.1679.zip | dd of=/dev/sdb

status=progress

10. Once this is completed, power off the FortiSIEM appliance using the following command:

shutdown –h now

11. After shutdown, remove both USB drives from the FortiSIEM appliance.

12. Power on the FortiSIEM appliance.

13. Reinstall the FortiSIEM application (as in Factory Reset - step 2).

FortiSIEM 5.4.0 3500F Hardware Configuration Guide 11

Fortinet Technologies Inc.
