FortiExtender 100B

QuickStart Guide

Table of Contents

May 1, 2014

36-100-234590-20140501

FortiGuard®, are registered trademarks of Fortinet, Inc., and other Fortinet

names herein may also be trademarks of Fortinet. All other product or company

names may be trademarks of their respective owners. Performance metrics

contained herein were attained in internal lab tests under ideal conditions, and

performance may vary. Network variables, different network environments and

other conditions may affect performance results. Nothing herein represents any

binding commitment by Fortinet, and Fortinet disclaims all warranties, whether

express or implied, except to the extent Fortinet enters a binding written contract,

signed by Fortinet’s General Counsel, with a purchaser that expressly warrants

that the identiﬁed product will perform according to the performance metrics

herein. For absolute clarity, any such warranty will be limited to performance in

the same ideal conditions as in Fortinet’s internal lab tests. Fortinet disclaims

in full any guarantees. Fortinet reserves the right to change, modify, transfer, or

otherwise revise this publication without notice, and the most current version of

the publication shall be applicable.

Package Contents 1

Connecting Your Device 2

Conﬁguring Your Device 4

Mounting Your Device 6

Technical Speciﬁcations 8

LED Speciﬁcations 9

Cautions and Warnings 10

Wall Mount Template 12

Regulatory Compliance 17

Documentation and Links 19

Product License Agreement 21

Page 1

This page intentionally left blank

Package Contents

Wall/Pole Mounting

Hardware Kit

Modem

Fastener

PoE Injector

Power Adapter Ethernet Cable

Quickstart Guide

FortiExtender 100B

QuickStart Guide

USB Extension Cable

2 Rubber

Caps

Page 1

Note: Accessories may not be exactly as shown.

Fortinet’s consolidated security solutions provide an integrated set of core security

and network services. The FortiExtender is a wireless WAN extender for 3G/4G

modems.

Your box contains the following:

FortiExtender 100B

QuickStart Guide with Wall Mount Template

Power Adapter

PoE Injector

Ethernet Cable

USB Extension Cable

Wall/Pole Mounting Hardware Kit

Modem Fastener

2 Rubber Caps

Page 3Page 2

Connecting Your Device

Note: Supported modems and ISPs vary by FortiExtender and

FortiGate ﬁrmware. For the hardware compatibility matrix, see the

product data sheet or release notes.

Note: The included PoE injector must be mounted indoors, as it is

not weatherproof.

Caution: Only use the provided PoE injector and power adapter (PN:

P11571) with this device. Using a different PoE injector or power

adapter may cause damage to the unit.

To install the 3G/4G modem:

1. Remove the screw on the back of the unit that secures the lower

housing cover in place then slide the housing cover off of the unit.

2. Use the provided USB extension cable to connect your 3G/4G

modem to the device.

3. Use the provided modem fastener to secure the modem inside the

housing.

To connect the FortiExtender unit:

1. Insert the provided Ethernet cable through one of the the holes on

the bottom of the housing cover, then plug it into the Ethernet port.

2. Slide the rubber plug around the Ethernet cable and ﬁrmly press it

into the hole on the housing cover that the cable passes through.

3. Replace the lower housing cover on the unit then and reinsert the

housing screw.

4. If you are using the provided PoE injector:

a. Insert the other end of the Ethernet cable into the AP/Bridge

port on the injector, then plug the injector into an appropriate

electrical outlet using the provided power adapter.

b. Connect an Ethernet cable from the LAN port of the PoE injector

to a FortiGate, FortiWiFi, or FortiSwitch device.

5. If you are not using the PoE injector:

a. Insert the other end of the Ethernet cable into a PoE LAN port on

an appropriate FortiGate, FortiWiFi or FortiSwitch device.

6. By default, FortiExtender conﬁguration is hidden in the FortiGate

Web-based Manager. Enable it using the following commands in

the FortiGate Command Line Interface (CLI):

cong system global

set fortiextender enable

set wireless-controller enable

end

7. The Control And Provisioning of Wireless Access Points (CAPWAP)

service must be enabled on the port to which the FortiExtender unit

is connected using the following CLI commands:

cong system interface

edit [port]

set allowaccess capwap

end

8. You can now proceed with conﬁguring your FortiExtender unit.

FortiExtender 100B

Length: ≤100m

Page 5Page 4

Conﬁguring Your Device

The FortiExtender unit is designed to require no conﬁguration in most

networks. Once linked, the FortiGate will automatically control the

FortiExtender unit and its modem via a CAPWAP tunnel. Automatic

conﬁguration works if the unit is on the same layer 2/3 network and

subnet as the FortiGate or FortiWiFi unit.

If the FortiExtender’s IP address cannot be determined automatically,

or if the network uses static IP addresses, it can be conﬁgured to use

a static IP address.

To automatically enable the FortiExtender:

1. Connect the FortiExtender unit as described in “Connecting Your

Device” on page 2, the unit requests an IP address from the

DHCP server.

2. In the FortiGate Web-based Manager, go to Network > FortiExtender.

and select Authorize for the the added FortiExtender.

Once the device has been authorized, select Conﬁgure Settings to

conﬁgure the FortiExtender settings as needed.

For more information, see the FortiGate Handbook, available in the

Fortinet Document Library, http://docs.fortinet.com.

To enable the FortiExtender with a static IP address:

1. Connect the FortiExtender device to a separate private switch or

hub, or directly to your management computer via a cross-over

cable.

2. Conﬁgure the management computer to be on the same subnet

as the internal interface of the FortiExtender unit by changing the

IP address of the management computer to 192.168.1.1 and the

netmask to 255.255.255.0.

3. Start a browser of your choice and browse to IP address 192.168.1.2.

4. Type admin in the Name and Password ﬁelds, and press Enter.

5. In the FortiExtender Web-based Manager, go to

System > Connection.

6. In the Connection Type ﬁeld, select Static, then enter the required

IP addresses, netmask, and gateway.

7. Select Submit to apply your changes.

8. Disconnect the device from the management computer, move it to

the intended deployment location, and reconnect it as described in

“Connecting Your Device” on page 2.

9. In the FortiGate Web-based Manager, go to Network > FortiExtender

and select Authorize for the added FortiExtender.

Once the device has been authorized, select Conﬁgure Settings to

conﬁgure the FortiExtender settings as needed.

For more information, see the FortiGate Handbook, available in the

Fortinet Document Library, http://docs.fortinet.com.

Page 7Page 6

Mounting Your Device

Using the provided hardware, the FortiExtender unit can be attached to a

wall or pole.

To attach the unit to a pole:

1. Loop the cable belts through the slots on the rear of the device and then

around the pole.

2. Tighten the belts to ensure that the device is ﬁrmly in place.

To attach the unit to a wall:

1. Select an appropriate location and, using the provided mounting template,

mark the location on the wall where the anchors will be located.

2. Drill holes into the wall or ceiling in the marked locations with an

appropriately sized drill bit then insert the provided anchors into the holes.

3. Screw the provided screws into the two anchors, leaving enough of the

screws exposed to ensure that the unit can be mounted on them.

4. Mount the FortiExtender unit onto the screws and ensure that it is

mounted securely.

Note: The included PoE injector must be mounted indoors, as it is not

weatherproof.

FortiExtender 100B

Page 8 Page 9

Technical Speciﬁcations LED Speciﬁcations

12 3

# Interface Type Description

1 USB USB-A USB port for connection to your modem.

2 Console RJ-45 Not in use.

3 Ethernet Port RJ-45 Gigabit Ethernet port with PoE support up to 7.3W.

Default IP address: 192.168.1.2

4 AP/Bridge RJ-45 PoE output. Provides 48V DC and network

connectivity.

5 Ground Copper Electrical ground connection for the the PoE Injector.

6 Network RJ-45 Connection to the network.

7 DC In Provides 48V DC to the PoE injector.

100-240V AC, 50-60Hz, 1.5A max adapter

12 3 4 5

# LED State Description

1 Power

Green The unit is on.

Flashing Green The unit is booting up.

Off The unit is off.

2 Status

Green The unit has successfully connected to the

controller and ISP.

Flashing Green The unit is connecting to the ISP.

Amber The unit has successfully connected to the

controller but not the ISP.

Flashing Amber The unit is connecting to the controller.

Off The unit is not connected.

3 LAN

Green Port is connected at 1Gbps.

Amber Port is connected at 10/100Mbps.

Flashing Green Port is transmitting and receiving data at 1Gbps.

Flashing Amber Port is transmitting and receiving data at

10/100Mbps.

Off Port is not in use.

4 USB

Green USB device recognized.

Amber USB device not active or disabled.

Flashing Amber USB device not recognized or has an error.

Off No device connected or port disabled.

5Signal

Strength

Off No signal, or signal indicator not supported for this

USB device.

1 Bar Weak signal.

2 Bar Okay signal.

3 Bar Good signal.

4 Bar Strong signal.

Page 10

Cautions and Warnings

Environmental Specications

Operating Temperature — 0 to 55°C (32 to 131°F) If this device is installed

in a closed or multi-unit rack assembly, the rack’s ambient temperature

may be greater than the room’s ambient temperature. Make sure the rack

environment is compatible with the manufacturer’s maximum rated ambient

temperature (Tma).

Température ambiante élevée — 0 à 55 ° C (32 à 131 ° F) Si cet appareil

est installé dans un cabinet fermé, la température ambiante du cabinet peut

être supérieure à la température ambiante de la pièce . Assurez- vous que

l’environnement dans le cabinet est compatible avec la température ambiante

maximale du fabricant (Tma).

Storage temperature — -20 to 70°C (-4 to 158°F)

Température d’entreposage — -20 à 70 ° C (-4 à 158 ° F)

Humidity — 5 to 95% non-condensing

Humidité — 5 à 95% sans condensation

Operating altitude — < 2250 m (7380 ft)

Altitude opérationnelle — <2250 m (7380 pi)

Air Flow — For rack installation, make sure that the amount of air ﬂow required

for safe operation of the equipment is not compromised. For free-standing

installation, make sure that the appliance has at least 2 inches (5 cm) of

clearance on each side to allow for adequate air ﬂow and cooling.

Ventilation — Pour une installation dans un cabinet, assurez-vous que

la ventilation nécessaire au fonctionnement de l’équipement n’est pas

compromise. Pour une installation autonome, assurez-vous que l’appareil

dispose d’au moins 2 pouces (5 cm) de dégagement de chaque côté pour

permettre l’écoulement de l’air et un refroidissement adéquat.

Circuit Overloading — To avoid overloading, use the ratings on the label.

Consider the equipment’s connection to the supply circuit and the effect that

circuit overloading might have on current protection and supply wiring.

Surtension — Pour éviter de surcharger le circuit d’alimentation, référez-

vous aux notes sur l’étiquette de l’équipement . Envisagez l’effet que la

surtension du circuit pourrait avoir sur la protection de surtension et le câblage

d’alimentation.

278mm (10.94in)

172mm (6.77in)

144.8mm (5.7in)

FortiExtender 100B

Mounting Template

This page can be removed from

the QuickStart Guide to facilitate

wall mounting your device.

Wall Mount Template

Page 15

Reliable earthing — Make sure all rack-mounted equipment is grounded. This

includes supply connections (e .g . power strips), not only direct connections

to the branch circuit.

Mise à la terre — Assurez-vous que tout l’équipement est mis à la terre

. Ceci comprend les connexions d’alimentation (par exemple, les barres

d’alimentation) en plus des connexions directes au circuit de dérivation.

Power over Ethernet (PoE) — Do not use PoE injectors that are not IEEE

802.3af compliant. They may damage your device.

Alimentation par Ethernet — Cet appareil est conforme aux normes IEEE

802.3af. Ne pas utiliser d’autres injecteurs d’alimentation non conformes

sous peine d’endommager votre matériel.

Interference — If possible, use Shielded Twisted Pair (STP) Ethernet cables

instead of Unshielded Twisted Pair (UTP).

Interférence — Si possible, utilisez des câbles Ethernet de paire torsadée

blindée (STP) plutôt que de paire torsadée non blindée (UTP).

Safety

Mechanical Loading — To avoid personal injury or damage to the appliance,

Fortinet recommends that 2 or more people together install the appliance into

the rack. Balance the equipment to avoid uneven mechanical loading and

tipping. Do not place heavy objects on the appliance.

Installation — Pour éviter des blessures ou des dommages à l’appareil,

Fortinet recommande que deux personnes ou plus installent ensemble cet

équipement dans un cabinet. L’installation du matériel à l’intérieur de la baie

doit être effectuée de façon à éviter toute situation dangereuse liée à une

installation non conforme. Ne placez pas d’objets lourds sur l’appareil, celui-

ci n’étant pas conçu pour soutenir un poids additionnel.

Page 17Page 16

Regulatory Compliance

Federal Communication Commission (FCC) – USA

This device complies with Part 15 of FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received; including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy, and if it is not

installed and used in accordance with the instruction manual, it may cause

harmful interference to radio communications. Operation of this equipment in

a residential area is likely to cause harmful interference, in which case the user

will be required to correct the interference at his own expense.

WARNING: Any changes or modiﬁcations to this product not expressly

approved by the party responsible for compliance could void the user’s

authority to operate the equipment

Industry Canada Equipment Standard for Digital Equipment

(ICES) – Canada

CAN ICES-3 (A) / NMB-3 (A)

This digital apparatus does not exceed the Class A limits for radio noise

emissions from digital apparatus set out in the Radio Interference Regula¬tions

of the Canadian Department of Communications.

Le présent appareil numérique n’emet pas de bruits radioélectriques

dép¬assant les limites applicables aux appareils numeriques de la classe A

préscrites dans le Règlement sur le brouillage radioélectrique édicte par le

ministère des Communications du Canada.

Electric shock / re — To avoid risk of damage to your equipment, personal

injury, or death, disconnect cables while servicing. Do not connect or

disconnect cables during lightning. Do not use this product near water for

example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet

basement or near a swimming pool. Do not use a telephone to report a gas

leak while near the leak. Do not install this equipment in a home or public

area accessible to the general population. When installed in schools, this

equipment must be installed in a location where access is restricted to trained

personnel.

Choc électrique / feu — Débranchez les cordons de la source d’alimentation

avant tout entretien. Ne pas brancher ou débrancher les câbles lors d’un

orage aﬁn de ne subir aucun dommage corporel et éviter d’endommager

votre appareil. Ne pas utiliser ce produit près de l’eau par exemple, près

d’une baignoire, d’un lavabo, d’un évier de cuisine ou cuve à lessive, dans

un sous-sol humide ou près d’une piscine. Ne pas utilisez un téléphone pour

signaler une fuite de gaz à proximité de la fuite. Le produit n’a pas vocation à

être installé dans un foyer ou un lieu public pour l’ensemble de la population.

Dans les écoles, ce matériel doit être installé en lieu sûr, de façon à le rendre

accessible seulement aux personnels qualiﬁes.

Grounding — To prevent damage to your equipment, connections that enter

from outside the building should pass through a lightning / surge protector,

and be properly grounded. Use an electrostatic discharge workstation (ESD)

and/or wear an anti-static wrist strap while you work. In addition to the

grounding terminal of the plug, on the back panel, there is another, separate

terminal for earthing.

Mise à la terre — Pour éviter d’endommager votre matériel, assurez-vous que

les branchements qui entrent à partir de l’extérieur du bâtiment passent par

un parafoudre / parasurtenseur et sont correctement mis à la terre. Utilisez un

poste de travail de décharge électrostatique (ESD) et / ou portez un bracelet

anti-statique lorsque vous travaillez. Ce produit possède une borne de mise

à la terre qui est prévu à l’arrière du produit, à ceci s’ajoute la mise à la terre

de la prise.

Page 19

The following Fortinet web pages provide information and resources for your

Fortinet product:

1. Fortinet Customer Service & Support: https://support.fortinet.com

On this page you can create a support account with Fortinet, register

and manage your products, download updates, ﬁrmware images and

release notes, and create technical support tickets.

2. Fortinet Document Library: http://docs.fortinet.com

This page provides the most up-to-date versions of Fortinet publications

for the entire family of Fortinet products.

3. Technical Discussion Forums: https://support.fortinet.com/forum

This page allows you to communicate with other customers and Fortinet

partners about Fortinet products, services, and conﬁguration issues in a

forum environment.

4. Training Services: http://campus.training.fortinet.com

This page provides course descriptions, availability, schedules, and

locations of training programs in your area.

5. FortiGuard Threat Research and Response:

http://www.fortiguard.com

This page provides up-to-date information on vulnerabilities and threats,

and includes a virus scanner, Internet Protocol (IP) signature look-up,

web ﬁltering tools, and related information.

Comments on Technical Documentation

Please send comments or information about any errors or omissions in this

or any Fortinet technical documents to [email protected].

Page 18

Documentation and Links

European Conformity (CE) - EU

This is a Class A product. In a domestic environment, this product may cause

radio interference, in which case the user may be required to take adequate

measures.

Voluntary Control Council for Interference (VCCI) – Japan

この装置は、クラスＡ情報技術装置です。この装置を家庭環境で使用

すると電波妨害を引き起こすことがあります。この場合には使用者が適

切な対策を講ずるよう要求されることがあります。ＶＣＣＩ－Ａ

Bureau of Standards Metrology and Inspection (BSMI) – Taiwan

這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在

這種情況下，使用者會被要求採取某些適當的對策。

China

此为A级产品，在生活环境中，该产品可能会造成无线电干扰。这种情况

下，可能需要用户对其采取切实可行的措施

Page 20 Page 21

If you have not registered your Fortinet product, please register your product

now.

• Technical Support • New product features • Protection from new threats

Enregistrer

Vous devez enregistrer le produit pour recevoir:

• Support technique • Nouvelles fonctionnalitées du produit • Protection

contre de nouvelles menaces

Registra

La reistrazione ti permette di usufruire di:

• Supporto Tecnico • Nuove funzionalita • Proteezione dalle ultime

minaccce

Registrar

Debe registrar el producto para recibir:

• Apoyo técnico • Nuevas funcionalidades del producto • Protección contra

ataques

登録のお願い

本日、フォーティネット製品の登録をしてください。

登録すると次のメリットがあります。

テクニカルサポート • 新機能の追加 • 新しい脅威への防御

请马上注册

您的飞塔产品

您在注册以后才能得到技术支持、新产品特点信息、最新威胁防护

Web: https://support.fortinet.com/

Toll free: 1 866 648 4638

Phone: 1 408 486 7899

Fax: 1 408 235 7737

Email: [email protected]

Fortinet Product License Agreement / EULA and Warranty Terms

Trademarks and Copyright Statement

Fortinet®, FortiGate®, and FortiGuard® are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be trademarks, registered

reserved. Contents and terms are subject to change by Fortinet without prior notice. No part of this publication may be reproduced in any form or by

any means or used to make any derivative such as translation, transformation, or adaptation without permission from Fortinet, Inc., as stipulated by the

United States Copyright Act of 1976.

Product License Agreement

The parties to this agreement are you, the end customer, and either (i) where you have purchased your Product within the Americas, Fortinet, Inc., or (ii)

where you have purchased your Product outside of the Americas, Fortinet Singapore Private Limited (each referred to herein as “Fortinet”) .CAREFULLY

READ THE FOLLOWING LEGAL AGREEMENT (THE OR THIS “AGREEMENT” OR “EULA”). USE OF FORTINET PRODUCT(S) AND ANY UPDATES THERETO, IN-

CLUDING HARDWARE APPLIANCE PRODUCTS, SOFTWARE AND FIRMWARE INCLUDED THEREIN BY FORTINET, AND STAND-ALONE SOFTWARE PRODUCTS

SOLD BY FORTINET (TOGETHER, THE “PRODUCTS”) CONSTITUTES ACCEPTANCE BY YOU OF THE PROVISIONS IN THIS AGREEMENT. FORTINET SHALL NOT

BE BOUND BY ANY ADDITIONAL AND/OR CONFLICTING PROVISIONS IN ANY ORDER, RELEASE, ACCEPTANCE OR OTHER WRITTEN CORRESPONDENCE OR

OTHER WRITTEN OR VERBAL COMMUNICATION UNLESS EXPRESSLY AGREED TO IN A WRITING SIGNED BY THE GENERAL COUNSEL OF FORTINET. YOUR

INSTALLATION OR USE OF ANY PRODUCT REPRESENTS AGREEMENT TO THE TERMS HEREIN, AS AMENDED OR UPDATED FROM TIME TO TIME IN FORTI-

NET’S DISCRETION BY FORTINET PUBLISHING AN AMENDED OR UPDATED VERSION. IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS AGREEMENT,

DO NOT START THE INSTALLATION PROCESS OR USE THE PRODUCTS. IF YOU DO NOT AGREE TO THE PROVISIONS OF THIS AGREEMENT, YOU SHOULD IM-

MEDIATELY, AND IN NO EVENT LATER THAN FIVE (5) CALENDAR DAYS AFTER YOUR RECEIPT OF THE PRODUCT RETURN THE PRODUCTS TO THE LOCATION

WHERE YOU OBTAINED THEM FOR A FULL REFUND FROM THE PARTNER SELLING TO YOU.

1. License Grant.

This is a license, not a sales agreement, between you and Fortinet. The term “Software”, as used throughout this Agreement, includes all Fortinet and

third party rmware and software provided to you with, or incorporated into, Fortinet appliances and any stand-alone software provided to you by

Fortinet, with the exception of any open source software contained in Fortinet’s Products which is discussed in detail in section 15 below, and the term

“Software” includes any accompanying documentation, any updates and enhancements of the software or rmware provided to you by Fortinet, at its

option. Fortinet grants to you a non-transferable (except as provided in section 5 (“Transfer”) and section 15 (“Open Source Software”) below), non-

exclusive, revocable (in the event of your failure to comply with these terms or in the event Fortinet is not properly paid for the applicable Product) license

to use the Software solely for your internal business purposes (provided, if a substantial portion of your business is to provide managed service provider

services to your end-customers, you may use the Software embedded in FortiGate and supporting hardware appliances to provide those services, subject

to the other restrictions in this Agreement), in accordance with the terms set forth in this Agreement and subject to any further restrictions in Fortinet

documentation, and solely on the Fortinet appliance, or, in the case of blades, CPUs or databases, on the single blade, CPU or database on which Fortinet

installed the Software or, for stand-alone Software, solely on a single computer running a validly licensed copy of the operating system for which the

Software was designed, or, in the case of blades, CPUs or databases, on a single blade, CPU or database. For clarity, notwithstanding anything to the

contrary, all licenses of Software to be installed on blades, CPUs or databases are licensed on a per single blade, solely for one blade and not for multiple

blades that may be installed in a chassis, per single CPU or per single database basis, as applicable. The Software is “in use” on any Fortinet appliances

when it is loaded into temporary memory (i.e. RAM). You agree that, except for the limited, specic license rights granted in this section 1, you receive no

license rights to the Software.

2. Limitation on Use.

You may not attempt to, and, if you are a corporation, you are responsible to prevent your employees and contractors from attempting to, (a) modify,

translate, reverse engineer, decompile, disassemble, create derivative works based on, sublicense, or distribute the Software; (b) rent or lease any rights

in the Software in any form to any third party or make the Software available or accessible to third parties in any other manner; (c) except as provided

in section 5, transfer assign or sublicense right to any other person or entity, or (d) remove any proprietary notice, labels, or marks on the Software,

Products, and containers.

3. Proprietary Rights.

All rights, title, interest, and all copyrights to the Software and any copy made thereof by you and to any Product remain with Fortinet. You acknowledge

that no title to the intellectual property in the Software or other Products is transferred to you and you will not acquire any rights to the Software or other

Products except for the specic license as expressly set forth in section 1 (“License Grant”) above.

4. Term and Termination.

Except for evaluation and beta licenses or other licenses where the term of the license is limited per the evaluation/beta or other agreement or in the

ordering documents, the term of the license is for the duration of Fortinet’s copyright in the Software. Fortinet may terminate this Agreement, and the

licenses and other rights herein, immediately without notice if you breach or fail to comply with any of the terms and conditions of this Agreement. You

agree that, upon such termination, you will cease using the Software and any Product and either destroy all copies of the Fortinet documentation or

return all materials to Fortinet. The provisions of this Agreement, other than the license granted in section 1 (“License Grant”), shall survive termination.

5. Transfer.

If you are a Fortinet contracted and authorized reseller or distributor of Products, you may transfer (not rent or lease unless specically agreed to in

writing by Fortinet) the Software to one end user on a permanent basis, provided that: (i) you ensure that your customer and the end user receives a copy

of this Agreement, is bound by its terms and conditions, and, by selling the Product or Software, you hereby agree to enforce the terms in this Agreement

against such end user, (ii) you at all times comply with all applicable United States export control laws and regulations, and (iii) you agree to refund any

fees paid to you by an end user who purchased Product(s) from you but does not agree to the terms contained in this Agreement and therefore wishes to

return the Product(s) as provided for in this Agreement. Further, if you are a non-authorized reseller of Products, you are not authorized to sell Product(s)

or Software, but, regardless, by selling Product(s) or Software, you hereby agree you are bound by the restrictions and obligations herein and are bound

to: (i) ensure that your customer and the end user receive a copy of this Agreement and are bound in full by all restrictions and obligations herein (ii)

enforce the restrictions and obligations in this Agreement against such customer and/or end user, (iii) comply with all applicable United States export

control laws and regulations and all other applicable laws, and (iv) refund any fees paid to you by a customer and/or end user who purchased Product(s)

from you but does not agree to the restrictions and obligations contained in this Agreement and therefore wishes to return the Product(s) as provided for

Page 22 Page 23

in this Agreement. Notwithstanding anything to the contrary, distributors, resellers and other Fortinet partners (a) are not agents of Fortinet and (b) are not

authorized to bind Fortinet in any way.

6. Limited Warranty.

Fortinet provides this limited warranty for its product only to the single end-user person or entity that originally purchased the Product from Fortinet or

its authorized reseller or distributor and paid for such Product. The warranty is only valid for Products which are registered on Fortinet’s Support Website:

https://support.fortinet.com; or on the TalkSwitch support website: http://global.talkswitch.com; or such other website as provided by Fortinet. For the

below software warranty to start, registration must take place within three hundred sixty-ve (365) days from the date the Product was originally shipped

from Fortinet’s facilities or the warranty is null and void and will not be honored. For the hardware warranty, such warranty starts on the earlier of the

date of Product registration on Fortinet’s Support Website or ninety (90) days from the date that the Product was originally shipped from Fortinet’s facili-

ties. It is the Fortinet distributor’s and reseller’s responsibility to make clear to the end user the date the product was originally shipped from Fortinet, and

it is the end user’s responsibility to understand the original ship date from the party from which the end user purchased the product. All warranty claims

must be submitted in writing to Fortinet before the expiration of the warranty term or such claims are waived in full, i.e. ninety (90) days from the earlier

of registration or the automatically started term for hardware and spare parts claims and three hundred sixty-ve (365) days from registration within

three hundred sixty-ve (365) days from shipment for software claims. Fortinet provides no warranty for any beta, donation or evaluation Products, for

any spare parts not purchased directly from Fortinet by the end-user, for any accessories, or for any stand-alone software.

Fortinet warrants that the hardware portion of the Products, including spare parts unless noted otherwise (“Hardware”) will be free from material defects

in workmanship as compared to the functional specications for the period set forth as follows and applicable to the Product type (“Hardware Warranty

Period”): a three hundred sixty-ve (365) day limited warranty for the Hardware excluding spare parts, , power supplies, and accessories (provided,

solely with respect to FortiAP indoor Wi-Fi access point Hardware appliance products and FortiSwitch Hardware appliance products other than the

FortiSwitch-5000 series (for both excluding spare parts, power supplies, and accessories), the warranty herein shall last from the start of the warranty

period as discussed above until ve (5) years following the product announced end-of-life date), and, for spare parts, power supplies, and accessories,

solely a ninety (90) days limited warranty. Fortinet’s sole obligation shall be to repair or replace the defective Hardware at no charge to the original owner.

This obligation is exclusive of transport fees, labor or installation costs, and any other cost which are not directly associated to the Product. Such repair or

replacement will be rendered by Fortinet at an authorized Fortinet service facility as determined by Fortinet. The replacement Hardware need not be new

or of an identical make, model, or part; Fortinet may, in its discretion, replace the defective Hardware (or any part thereof) with any reconditioned Product

that Fortinet reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware. The Hardware Warranty

Period for the repaired or replacement Hardware shall be for the greater of the remaining Hardware Warranty Period or ninety days from the delivery of

the repaired or replacement Hardware. If Fortinet determines in its reasonable discretion that a material defect is incapable of correction or that it is not

practical to repair or replace defective Hardware, the price paid by the original purchaser for the defective Hardware will be refunded by Fortinet upon

return to Fortinet of the defective Hardware. All Hardware (or part thereof) that is replaced by Fortinet, or for which the purchase price is refunded, shall

become the property of Fortinet upon replacement or refund.

Fortinet warrants that the software portion of Hardware Products will substantially conform to Fortinet’s then current functional specications for the

Software, as set forth in the applicable documentation for a period of ninety (90) days (“Software Warranty Period”), if the Software is properly installed

on approved Hardware and operated as contemplated in its documentation. Fortinet’s sole obligation shall be to repair or replace the non-conforming

Software with software that substantially conforms to Fortinet’s functional specications. Except as otherwise agreed by Fortinet in writing, the replace-

ment Software is provided only to the original licensee, and is subject to the terms and conditions of the license granted by Fortinet for the Software. The

Software Warranty Period shall extend for an additional ninety (90) days after any replacement software is delivered. If Fortinet determines in its reason-

able discretion that a material non-conformance is incapable of correction or that it is not practical to repair or replace the non-conforming Software,

the price paid by the original licensee for the non-conforming Software will be refunded by Fortinet; provided that the non-conforming Software (and all

copies thereof) is rst returned to Fortinet. The license granted respecting any Software for which a refund is given automatically terminates immediately

upon refund. For purpose of the above hardware and software warranties, the term “functional specications” means solely those specications autho-

rized and published by Fortinet that expressly state in such specications that they are the functional specications referred to in this section 6 of this

Agreement, and, in the event no such specications are provided to you with the Software or Hardware, there shall be no warranty on such Software.

7. Disclaimer of Other Warranties and Restrictions.

EXCEPT FOR THE LIMITED WARRANTY SPECIFIED IN SECTION 6 ABOVE, THE PRODUCT AND SOFTWARE ARE PROVIDED “AS-IS” WITHOUT ANY WARRANTY

OF ANY KIND INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY, IMPLIED OR EXPRESS WARRANTY OF MERCHANTABILITY, OR WARRANTY

FOR FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT. IF ANY IMPLIED WARRANTY CANNOT BE DISCLAIMED IN ANY TERRITORY WHERE

A PRODUCT IS SOLD, THE DURATION OF SUCH IMPLIED WARRANTY SHALL BE LIMITED TO NINETY (90) DAYS FROM THE DATE OF ORIGINAL SHIP-

MENT FROM FORTINET. EXCEPT AS EXPRESSLY COVERED UNDER THE LIMITED WARRANTY PROVIDED HEREIN, THE ENTIRE RISK AS TO THE QUALITY,

SELECTION AND PERFORMANCE OF THE PRODUCT IS WITH THE PURCHASER OF THE PRODUCT. NOTWITHSTANDING ANYTHING TO THE CONTRARY, THE

HARDWARE WARRANTY PERIOD DISCUSSED ABOVE DOES NOT APPLY TO CERTAIN FORTINET PRODUCTS, INCLUDING FORTIFONE WHICH HAS A NINETY

(90) DAY LIMITED WARRANTY AND FORTITOKEN WHICH HAS A 365 DAY WARRANTY FROM THE DATE OF SHIPMENT FROM FORTINET’S FACILITIES,AND

THE SOFTWARE WARRANTY DOES NOT APPLY TO CERTAIN FORTINET PRODUCTS, INCLUDING FORTIGATE-ONE AND VDOM SOFTWARE.

The warranty in Section 6 above does not apply if the Software, Product or any other equipment upon which the Software is authorized to be used (a)

has been altered, except by Fortinet or its authorized representative, (b) has not been installed, operated, repaired, or maintained in accordance with

instructions supplied by Fortinet, (c) has been subjected to abnormal physical or electrical stress, misuse, negligence, or accident; (d) is licensed for beta,

evaluation, donation, testing or demonstration purposes or for which Fortinet does not charge a purchase price or license fee. In the case of beta, testing,

evaluation, donation or free Software or Product, the end user acknowledges and agrees that such Software or Product may contain bugs or errors and

could cause system failures, data loss and other issues, and the end user agrees that such Software or Product is provided “as-is” without any warranty

whatsoever, and Fortinet disclaims any warranty or liability whatsoever. An end user’s use of evaluation or beta Software or Product is limited to thirty

(30) days from original shipment unless otherwise agreed in writing by Fortinet.

8. Governing Law.

Any disputes arising out of this Agreement or Fortinet’s limited warranty shall be governed by the laws of the state of California, without regard to the

conict of laws principles. In the event of any disputes arising out of this Agreement or Fortinet’s limited warranty, the parties submit to the jurisdiction of

the federal and state courts located in Santa Clara County, California, as applicable.

9. Limitation of Liability.

TO THE MAXIMUM EXTENT PERMITTED BY LAW AND NOTWITHSTANDING ANYTHING TO THE CONTRARY, FORTINET IS NOT LIABLE UNDER ANY CONTRACT,

NEGLIGENCE, TORT, STRICT LIABILITY, INFRINGEMENT OR OTHER LEGAL OR EQUITABLE THEORY FOR ANY LOSS OF USE OF THE PRODUCT OR SERVICE

OR ANY DAMAGES OF ANY KIND WHATSOEVER, WHETHER DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, BUT NOT LIMITED TO,

DAMAGES FOR LOSS OF GOODWILL, LOSS OF PROFIT, LOSS OF OPPORTUNITY, LOSS OR DAMAGE RELATED TO USE OF THE PRODUCT OR SERVICE IN

CONNECTION WITH HIGH RISK ACTIVITIES, DAMAGE TO PERSONAL OR REAL PROPERTY, WORK STOPPAGE, COMPUTER FAILURE OR MALFUNCTION,

COMPUTER SECURITY BREACH, COMPUTER VIRUS INFECTION, LOSS OF INFORMATION OR DATA CONTAINED IN, STORED ON, OR INTEGRATED WITH ANY

PRODUCT INCLUDING ANY PRODUCT RETURNED TO FORTINET FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO

WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THE LIMITED WARRANTY IN SECTION 6 ABOVE, EVEN IF FORTINET HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFEC-

TIVE OR NON-CONFORMING PRODUCT AS SPECIFICALLY STATED IN SECTION 6 ABOVE.

10. Import / Export Requirements; FCPA Compliance.

You are advised that the Products may be subject to the United States Export Administration Regulations and other import and export laws; diversion con-

trary to United States law and regulation is prohibited. You agree to comply with all applicable international and national laws that apply to the Products

as well as end user, end-use, and destination restrictions issued by U.S. and other governments. For additional information on U.S. export controls see

www.bis.doc.gov. Fortinet assumes no responsibility or liability for your failure to obtain any necessary import and export approvals. You represent that

neither the United States Bureau of Industry and Security nor any other governmental agency has issued sanctions against you or otherwise suspended,

revoked or denied your export privileges. You agree not to use or transfer the Products for any use relating to nuclear, chemical or biological weapons,

or missile technology, unless authorized by the United States Government by regulation or specic written license. Additionally, you agree not to directly

or indirectly export, import or transmit the Products contrary to the laws or regulations of any other governmental entity that has jurisdiction over such

export, import, transmission or use. Furthermore, you represent that you understand, and you hereby agree to comply with, all requirements of the U.S.

Foreign Corrupt Practices Act and all other applicable laws. For beta, testing, evaluation, donation or free Products and/or related services, you hereby

agree, represent and warrant to Fortinet that (a) receipt of the Products and/or services comply with all policies and you have obtained all necessary

approvals for such Products and/or services, (b) the Products and/or services are not provided in exchange for Fortinet maintaining current business

or for new business opportunities, and (c) the Products and/or services are not being received for the benet of, and are not being transferred to, any

government entity, representative or afliate.

11. U.S. Government End Users.

The Software and accompanying documentation are deemed to be “commercial computer software” and “commercial computer software documenta-

tion,” respectively, pursuant to DFAR Section 227.7202 and FAR Section 12.212, as applicable. Any use, modication, reproduction, release, performance,

display or disclosure of the Software and accompanying documentation by the United States Government shall be governed solely by the terms of this

Agreement and shall be prohibited except to the extent expressly permitted by the terms of this Agreement and its successors.

12. Tax Liability.

You agree to be responsible for payment of any sales or use taxes imposed at any time on this transaction.

13. General Provisions.

Except as specically permitted and required in section 5 (“Transfer”) above, you agree not to assign this Agreement or transfer any of the rights or

obligations under this Agreement without the prior written consent of Fortinet. This Agreement shall be binding upon, and inure to the benet of, the suc-

cessors and permitted assigns of the parties. The United Nations Convention on Contracts for the International Sales of Goods is expressly excluded. This

Agreement and other Fortinet agreements may be amended or supplemented only by a writing that refers explicitly to the agreement signed on behalf

of both parties, or, for this Agreement, as otherwise expressly provided in the lead-in above Section 1 above, provided, notwithstanding anything to the

contrary and except for this Agreement which may be amended or updated as expressly provided in the lead-in above Section 1 above, for any amend-

ment or other agreement to be binding on Fortinet, such amendment or other agreement must be signed by Fortinet’s General Counsel. No waiver will be

implied from conduct or failure to enforce rights nor effective unless in a writing signed on behalf of the party against whom the waiver is asserted. If any

part of this Agreement is found unenforceable, that part will be enforced to the maximum extent permitted and the remainder shall continue in full force

and effect. You acknowledge that you have read this Agreement, understand it, and agree to be bound by its terms and conditions.

14. Privacy.

By entering into this Agreement, you agree and consent that Fortinet may collect, retain and use personal information supplied, including name, address,

and e-mail address of individuals and payment details and other information. Personal information will be used primarily to provide services and product

functionality to end users. Fortinet may also use personal information for additional communication, subject to an opt-out notice provided by you in

writing per below. Fortinet may engage other companies and individuals to perform functions on its behalf, such as payment processing, order fulllment,

marketing programs and customer service. Fortinet may share personal information with such subcontractors in order to perform these and other func-

tions, but such subcontractors may not use your personal information for other purposes, unless you agree. By entering into this Agreement, you agree

and consent to the transfer the supplied personal information to Fortinet’s ofces in the United States and elsewhere, for the purposes stated above. For

more detailed information on the collection, use and transfer of your personal information, and for information on how to opt out of or unsubscribe from

the communications described above, please read the Fortinet privacy policy on the Fortinet web site (www.Fortinet.com).

15. Open Source Software.

Fortinet’s products may include software modules that are licensed (or sublicensed) to the user under the GNU General Public License, Version 2, of June

1991 (“GPL”) or GNU Lesser General Public License, Version 2.1, of February 1999 (“LGPL”) or other open source software licenses which, among other

rights, permit the user touse, copy, modify and redistribute modules, or portions thereof, and may also require attribution disclosures and access to the

source code (“Open Source Software”). The GPL requires that for any Open Source Software covered under the GPL, which is distributed to someone

in an executable binary format, that the source code also be made available to those users. For any Open Source Software covered under the GPL, the

source code is made available on this CD or download package. If any Open Source Software licenses require that Fortinet provide rights to use, copy

or modify a Open Source Software program that are broader than the rights granted in this agreement, then such rights shall take precedence over the

rights and restrictions herein. Fortinet will provide, for a charge reecting our standard distribution costs, the complete machine-readable copy of the

modied software modules. To obtain a complete machine-readable copy, please send your written request, along with a check in the amount of US

$25.00, to General Public License Source Code Request, Fortinet, Inc., 899 Kifer Rd, Sunnyvale, CA 94086 USA. In order to receive the modied software

modules, you must also include the following information: (a) Name, (b) Address, (c) Telephone number, (d) E-mail Address, (e) Product purchased (if ap-

plicable), (f) Product Serial Number (if applicable). All open source software modules are licensed free of charge. There is no warranty for these modules,

to the extent permitted by applicable law. The copyright holders provide these software modules “AS-IS” without warranty of any kind, either expressed

or implied. In no event will the copyright holder for the open source software be liable to you for damages, including any special, incidental or consequen-

tial damages arising out of the use or inability to use the software modules, even if such holder has been advised of the possibility of such damages. A

full copy of this license, including additional open source software license disclosures and third party license disclosures applicable to certain Fortinet

products, may obtained by contacting Fortinet’s Legal Department at [email protected].

GNU GENERAL PUBLIC LICENSE GNU GENERAL PUBLIC LICENSE

Version 2, June 1991

59 Temple Place, Suite 330, Boston, MA 02111-1307 USA

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of

this General Public License. The “Program”, below, refers to any such program or work, and a “work based on the Program” means either the Program

or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modications and/or

translated into another language. (Hereinafter, translation is included without limitation in the term “modication”.) Each licensee is addressed as “you”.

Activities other than copying, distribution and modication are not covered by this License; they are outside its scope. The act of running the Program is

not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made

by running the Program). Whether that is true depends on what the Program does.

1. You may copy and distribute verbatim copies of the Program’s source code as you receive it, in any medium, provided that you conspicuously and

Page 24 Page 25

appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and

to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program. You may charge a fee for the

physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and distribute such

modications or work under the terms of Section 1 above, provided that you also meet all of these conditions:

a) You must cause the modied les to carry prominent notices stating that you changed the les and the date of any change.

b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be

licensed as a whole at no charge to all third parties under the terms of this License.

c) If the modied program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the

most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying

that you provide a warranty) and that users may redistribute the program under these conditions, and telling the user how to view a copy of this License.

(Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print

an announcement.)

These requirements apply to the modied work as a whole. If identiable sections of that work are not derived from the Program, and can be reasonably

considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as

separate works. But when you distribute the same sections as part of a whole which is a work based on the Program, the distribution of the whole must

be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who

wrote it.. Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the

right to control the distribution of derivative or collective works based on the Program. In addition, mere aggregation of another work not based on the

Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under

the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and

2 above provided that you also do one of the following:

a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections1 and 2 above

on a medium customarily used for software interchange; or,

b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing

source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on

a medium customarily used for software interchange; or,

c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncom-

mercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.)

Source code for a work means the preferred form of the work for making modications to it. For an executable work, complete source code means all

the source code for all modules it contains, plus any associated interface denition les, plus the scripts used to control compilation and installation

of the executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source

or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component

itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering

equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to

copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy,

modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received

copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the

Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program

(or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or

modifying the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically receives a license from the original licensor to

copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients’ exercise of

the rights granted herein. You are not responsible for enforcing compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are

imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the condi-

tions of this License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then

as a consequence you may not distribute the Program at all. For example, if a patent license would not permit royalty-free redistribution of the Program

by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely

from distribution of the Program.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the

section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this

section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices. Many

people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that

system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that

choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright

holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution

is permitted only in or among countries not thus excluded. In such case, this License incorporates the limitation as if written in the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time. Such new versions will be

similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version

number. If the Program species a version number of this License which applies to it and “any later version”, you have the option of following the terms

and conditions either of that version or of any later version published by the Free Software Foundation. If the Program does not specify a version number

of this License, you may choose any version ever published by the Free Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for

permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions

for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and

reuse of software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE

LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FIT-

NESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM

PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY

MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDEN-

TAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR

DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER

PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

GNU LESSER GENERAL PUBLIC LICENSE

Version 2.1, February 1999

59 Temple Place, Suite 330, Boston, MA 02111-1307 USA

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License Agreement applies to any software library or other program which contains a notice placed by the copyright holder or other authorized

party saying it may be distributed under the terms of this Lesser General Public License (also called “this License”). Each licensee is addressed as “you”.

A “library” means a collection of software functions and/or data prepared so as to be conveniently linked with application programs (which use some of

those functions and data) to form executables.

The “Library”, below, refers to any such software library or work which has been distributed under these terms. A “work based on the Library” means

either the Library or any derivative work under copyright law: that is to say, a work containing the Library or a portion of it, either verbatim or with modi-

cations and/or translated straightforwardly into another language. (Hereinafter, translation is included without limitation in the term “modication”.)

“Source code” for a work means the preferred form of the work for making modications to it. For a library, complete source code means all the source

code for all modules it contains, plus any associated interface denition les, plus the scripts used to control compilation and installation of the library.

Activities other than copying, distribution and modication are not covered by this License; they are outside its scope. The act of running a program using

the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the Library (independent of the

use of the Library in a tool for writing it). Whether that is true depends on what the Library does and what the program that uses the Library does.

1. You may copy and distribute verbatim copies of the Library’s complete source code as you receive it, in any medium, provided that you conspicuously

and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License

and to the absence of any warranty; and distribute a copy of this License along with the Library. You may charge a fee for the physical act of transferring

a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Library or any portion of it, thus forming a work based on the Library, and copy and distribute such modi-

cations or work under the terms of Section 1 above, provided that you also meet all of these conditions:

a) The modied work must itself be a software library.

b) You must cause the les modied to carry prominent notices stating that you changed the les and the date of any change.

c) You must cause the whole of the work to be licensed at no charge to all third parties under the terms of this License.

d) If a facility in the modied Library refers to a function or a table of data to be supplied by an application program that uses the facility, other than as

an argument passed when the facility is invoked, then you must make a good faith effort to ensure that, in the event an application does not supply such

function or table, the facility still operates, and performs whatever part of its purpose remains meaningful.

These requirements apply to the modied work as a whole. If identiable sections of that work are not derived from the Library, and can be reasonably

considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as

separate works. But when you distribute the same sections as part of a whole which is a work based on the Library, the distribution of the whole must be

on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote

it. Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to

control the distribution of derivative or collective works based on the Library. In addition, mere aggregation of another work not based on the Library with

the Library (or with a work based on the Library) on a volume of a storage or distribution medium does not bring the other work under the scope of this

License.

3. You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the Library. To do this, you must

alter all the notices that refer to this License, so that they refer to the ordinary GNU General Public License, version 2 instead of to this License. (If a

newer version than version 2 of the ordinary GNU General Public License has appeared, then you can specify that version instead if you wish.) Do not

make any other change in these notices.

Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License applies to all subsequent copies and

derivative works made from that copy. This option is useful when you wish to copy part of the code of the Library into a program that is not a library.

4. You may copy and distribute the Library (or a portion or derivative of it, under Section 2) in object code or executable form under the terms of Sections

1 and 2 above provided that you accompany it with the complete corresponding machine-readable source code, which must be distributed under the

terms of Sections 1 and 2 above on a medium customarily used for software interchange.

If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from

the same place satises the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the

object code.

5. A program that contains no derivative of any portion of the Library, but is designed to work with the Library by being compiled or linked with it, is called

a “work that uses the Library”. Such a work, in isolation, is not a derivative work of the Library, and therefore falls outside the scope of this License.

However, linking a “work that uses the Library” with the Library creates an executable that is a derivative of the Library (because it contains portions of

the Library), rather than a “work that uses the library”. The executable is therefore covered by this License. Section 6 states terms for distribution of such

executables.

When a “work that uses the Library” uses material from a header le that is part of the Library, the object code for the work may be a derivative work of

the Library even though the source code is not.

Whether this is true is especially signicant if the work can be linked without the Library, or if the work is itself a library. The threshold for this to be true

is not precisely dened by law.

If such an object le uses only numerical parameters, data structure layouts and accessors, and small macros and small inline functions (ten lines or less

in length), then the use of the object le is unrestricted, regardless of whether it is legally a derivative work. (Executables containing this object code plus

portions of the Library will still fall under Section 6.) Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work

under the terms of Section 6. Any executables containing that work also fall under Section 6, whether or not they are linked directly with the Library itself.

6. As an exception to the Sections above, you may also combine or link a “work that uses the Library” with the Library to produce a work containing

portions of the Library, and distribute that work under terms of your choice, provided that the terms permit modication of the work for your own use and

reverse engineering for debugging such modications. You must give prominent notice with each copy of the work that the Library is used in it and that

the Library and its use are covered by this License. You must supply a copy of this License. If the work during execution displays copyright notices, you

This page intentionally left blank

Page 26

must include the copyright notice for the Library among them, as well as a reference directing the user to the copy of this License. Also, you must do one

of these things:

a) Accompany the work with the complete corresponding machine-readable source code for the Library including whatever changes were used in the

work (which must be distributed under Sections 1 and 2 above); and, if the work is an executable linked with the Library, with the complete machine-

readable “work that uses the Library”, as object code and/or source code, so that the user can modify the Library and then relink to produce a modied

executable containing the modied Library. (It is understood that the user who changes the contents of denitions les in the Library will not necessarily

be able to recompile the application to use the modied denitions.)

b) Use a suitable shared library mechanism for linking with the Library. A suitable mechanism is one that (1) uses at run time a copy of the library already

present on the user’s computer system, rather than copying library functions into the executable, and (2) will operate properly with a modied version of

the library, if the user installs one, as long as the modied version is interface-compatible with the version that the work was made with.

c) Accompany the work with a written offer, valid for at least three years, to give the same user the materials specied in Subsection 6a, above, for a

charge no more than the cost of performing this distribution.

d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy the above specied materials

from the same place.

e) Verify that the user has already received a copy of these materials or that you have already sent this user a copy.

For an executable, the required form of the “work that uses the Library” must include any data and utility programs needed for reproducing the execut-

able from it. However, as a special exception, the materials to be distributed need not include anything that is normally distributed (in either source or

binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself

accompanies the executable. It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally

accompany the operating system. Such a contradiction means you cannot use both them and the Library together in an executable that you distribute.

7. You may place library facilities that are a work based on the Library side-by-side in a single library together with other library facilities not covered

by this License, and distribute such a combined library, provided that the separate distribution of the work based on the Library and of the other library

facilities is otherwise permitted, and provided that you do these two things:

a) Accompany the combined library with a copy of the same work based on the Library, uncombined with any other library facilities. This must be

distributed under the terms of the Sections above.

b) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and explaining where to nd the accompany-

ing uncombined form of the same work.

8. You may not copy, modify, sublicense, link with, or distribute the Library except as expressly provided under this License. Any attempt otherwise to

copy, modify, sublicense, link with, or distribute the Library is void, and will automatically terminate your rights under this License. However, parties who

have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance.

9. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the

Library or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Library

(or any work based on the Library), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or

modifying the Library or works based on it.

10. Each time you redistribute the Library (or any work based on the Library), the recipient automatically receives a license from the original licensor

to copy, distribute, link with or modify the Library subject to these terms and conditions. You may not impose any further restrictions on the recipients’

exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties with this License.

11. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are

imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the condi-

tions of this License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then

as a consequence you may not distribute the Library at all. For example, if a patent license would not permit royalty-free redistribution of the Library by

all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely

from distribution of the Library.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply, and the

section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this

section has the sole purpose of protecting the integrity of the free software distribution system which is implemented by public license practices. Many

people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that

system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that

choice. This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

12. If the distribution and/or use of the Library is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder

who places the Library under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution is permit-

ted only in or among countries not thus excluded. In such case, this License incorporates the limitation as if written in the body of this License.

13. The Free Software Foundation may publish revised and/or new versions of the Lesser General Public License from time to time. Such new versions

will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version

number. If the Library species a version number of this License which applies to it and “any later version”, you have the option of following the terms

and conditions either of that version or of any later version published by the Free Software Foundation. If the Library does not specify a license version

number, you may choose any version ever published by the Free Software Foundation.

14. If you wish to incorporate parts of the Library into other free programs whose distribution conditions are incompatible with these, write to the author

to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make

exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the

sharing and reuse of software generally.
