Fortinet FortiAP 224E User manual

FortiAP 224E
QuickStart Guide

11/10/2017
Copyright© 2017 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®,
FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet,
Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be
registered and/or common law trademarks of Fortinet. All other product or company names
may be trademarks of their respective owners. Performance and other metrics contained
herein were attained in internal lab tests under ideal conditions, and actual performance and
other results may vary. Network variables, different network environments and other
conditions may affect performance results. Nothing herein represents any binding
commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied,
except to the extent Fortinet enters a binding written contract, signed by Fortinet’s General
Counsel, with a purchaser that expressly warrants that the identified product will perform
according to certain expressly-identified performance metrics and, in such event, only the
specific performance metrics expressly identified in such binding written contract shall be
binding on Fortinet. For absolute clarity, any such warranty will be limited to performance in
the same ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make
any commitment related to future deliverables, features, or development, and circumstances
may change such that any forward-looking statements herein are not accurate. Fortinet
disclaims in full any covenants, representations,and guarantees pursuant hereto, whether
express or implied. Fortinet reserves the right to change, modify, transfer, or otherwise
revise this publication without notice, and the most current version of the publication shall be
applicable.

Cautions and Warnings
Environmental specifications
Ambient operating temperature: 0C to 40C
Refer to specific Product Model Data Sheet for Environmental
Specifications (Operating Temperature, Storage Temperature,
Humidity, and Altitude).
Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales
(Température de fonctionnement, température de stockage, humidité et l'altitude).
Safety
Caution: This equipment is to be used in a Network Environment 0 per IECTR
62101. This product is connected only to PoE networks without routing to the
outside plant.
Attention: Ce matériel doit être utilisé dans un Environnement Réseau 0 par
IECTR 62101. Ce produit est uniquement connecté aux réseaux PoE sans
installation externe de routage.
QuickStart Guide

Box Includes
FortiAP device QuickStart Guide
Pole Mount Straps (X2),
Wall Mount Bracket, and
Grounding Cable 6M
Pole and Wall Mounting Kits:
Machine Pan M4x10L screws (X4), Machine pan
M5x10L screw, Self-Tapping Steel Pan P3x20L(X4),
and Plastic Conical wall anchors (X4)
4

Before YouBegin
Write down details typically provided by your network administrator or ISP.
Static IPaddress
IPaddress ___________________
Subnet Mask ___________________
Default Gateway ___________________
Primary/Secondary DNS ___________________
DHCP
It is normal to not require a hostname, but your ISP might require it.
Hostname ___________________
QuickStart Guide Video
https://video.fortinet.com/video/177/
fortigate-and-fortiap
5

FortiAP 224E - Device Front
Device Guide
6

FortiAP 224E - Device Rear
7

FortiAP 224E - Device Side (LEDs)
1
4
3
2
5
6
Green: System is ready
O: Power o
Amber: System is booting up
O: System booted
1: Power
2: Small form-factor pluggable (SFP)
3: 2.4GHz WLAN
4: 5GHz WLAN
5: LAN2
6: LAN1 (PoE)
Green: Connect to optical port
Blinking: Optical activity present
O: No activity or power o
Amber: Reserved
Green: Connect to WLAN port
Blinking: WLAN activity present
O: No activity or power o
Amber: Reserved
Amber: Device connected to
LAN port at 10/100/1000Mbps
Blinking: LAN activity present
O: Not connected
Green: Connect to WLAN port
Blinking: WLAN activity present
O: No activity or power o
Amber: Reserved
Amber: Device connected to
LAN port at 10/100/1000Mbps
Blinking: LAN activity present
O: Not connected
8

Installation
Mount on Wall
9

Mount on Pole
10

Rotating Mount
Fasten the Hold Bracket (1) and the Bracket Sheets (2) to the base using the
M8x32L Hexagon screw bolts and washers:
Fasten the Pole Bracket & Wall Bracket to the pole using supplied M8x160L
Hexagon screw bolts (5 and 6):
11

Fasten the Pole Bracket to the Wall Bracket by securing the supplied M8x32L
Hexagon screw bolts (7, 8, and 9):
12

To adjust the unit to tilt up and down:
13

To adjust the unit to tilt left and right:
14

A
Cabling
The unit requires 48VDC power, which is delivered by the PoE injector over a
straight-through Ethernet cable.
To install the weatherproof connector
1. Unscrew the coupling ring from the waterproof connector, remove the
sealing gland, and thread the RJ-45 plug through the connector
components.
2. Insert the RJ-45 plug into the PoE port on the unit and install the
weatherproof panel connector onto the threaded coupling at the port.
3. Slide the sealing gland along the cable into the panel connector.
4. Thread the coupling ring into the panel connector and tighten it until the
sealing gland is compressed, making a watertight seal on the cable.
15

Basic Connection
WAN/POE
Network Core/FortiGate
Connect the FortiAP device to a FortiGate controller or an Internet connection.
Ensure that the Power over Ethernet (PoE) cable is connected to an applicable
port on your FortiGate device or PoE injector.
Caution: Adequate grounding must be provided to the FortiAP unit and
the PoE injector, in compliance with your local electrical code or
regulations.
Warning: This device complies with IEEE 802.3af PoE specification. Do
not use any PoE injectors that are not IEEE 802.3af compliant as they
may damage your device.
16

FortiAPSetup
Deployment through a FortiGate
Ensure that you are running the Fortinet recommended version of
software. Please check support.fortinet.com for more information.
If FortiGate is on the same network as the FortiAP:
1. Use FortiGate to preauthorize the FortiAP device.
2. Refer to the “Access Point Deployment” section of the FortiWiFiand
FortiAP Configuration Guide found at http://forti.net/ap-docs.
3. Plug the FortiAP into your local Ethernet connection. The FortiAP will self-
configure.
Or
1. Instead of preauthorizing, you can use the FortiGate to authorize the
FortiAP device after you have connected the FortiAP to the network.
2. Within two minutes of connecting the FortiAP to the FortiGate, the device
appears on the Managed FortiAP page in the Web-based Manager:
authorize and assign a profile to the device.
17

If FortiGate is not on the same network as the FortiAP:
1. Log into FortiAP directly (IP address: 192.168.1.2) with username admin
and no password, and specify the IP address of the controlling FortiGate.
2. Connect to FortiAP via the CLI using the instructions in the “Connecting
to FortiAP CLI” section of the FortiWiFi and FortiAPConfiguration guide.
3. Specify the IP address of the controlling FortiGate:
config capwap wtp acIpAddr 0.0.0.0
where 0.0.0.0 is the address of the FortiGate.
4. The FortiAP device connects to FortiGate, and then you can authorize the
FortiAP.
18

Cautions and Warnings
Environmental specifications
Ambient operating temperature: -30C to 60C
Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature,
Storage Temperature, Humidity, and Altitude)
Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température
de fonctionnement, température de stockage, humidité et l'altitude).
Safety
Warning: Equipment intended for installation in Restricted Access Location.
Avertissement: Le matériel est conçu pour être installé dans un endroit où l’accès est restreint.
Caution: This equipment is to be used in a Network Environment 0 per IECTR 62101. This product is
connected only to PoE networks without routing to the outside plant.
Attention: Ce matériel doit être utilisé dans un Environnement Réseau 0 par IECTR 62101. Ce produit
est uniquement connecté aux réseaux PoE sans installation externe de routage.
This product is intended to be supplied 48-57 Vdc from PoE source.
Le produit doit être alimenté par à de 48-57 Vdc (PoE).
Grounding — To prevent damage to your equipment, connections that enter from outside the building
should pass through a lightning / surge protector, and be properly grounded. Use an electrostatic
discharge workstation (ESD) and/or wear an anti-static wrist strap while you work. In addition to the
grounding terminal of the plug, on the back panel, there is another, separate terminal for earthing.
Mise à la terre — Pour éviter d’endommager votre matériel, assurez-vous que les branchements qui
entrent à partir de l’extérieur du bâtiment passent par un parafoudre / parasurtenseur et sont
correctement mis à la terre. Utilisez un poste de travail de décharge électrostatique (ESD) et / ou portez
19

un bracelet anti-statique lorsque vous travaillez. Ce produit possède une borne de mise à la terre qui
est prévu à l’arrière du produit, à ceci s’ajoute la mise à la terre de la prise.
This product has a separate protective earthing terminal provided on the back of the product in
addition to the grounding terminal of the attachment plug. This separate protective earthing terminal
must be permanently connected to earth with a green with yellow stripe conductor minimum size # 14
AWG and the connection is to be installed by a qualified service personnel.
Ce produit a une borne de mise à la terre séparé sur le dos de l'appareil, en plus de la borne de mise à
la terre de la fiche de raccordement. Cette borne de mise à la terre séparée doit être connecté en
permanence à la terre avec un conducteur vert avec la taille bande jaune de minimum # 14 AWG et la
connexion doit être installé par un personnel qualifié.
The connecting cable between the outdoor equipment and the indoor ITE devices should comply with
Class 3 wiring methods as listed in NEC, Table 725.154(G) for Class 3 Cable Substitutions.
Le câble connectant l’équipement extérieur et ceux d’intérieur de type ITE doit être conforme avec les
méthodes de câblage de classe 3 tel que listé dans le standard NEC, Table 725.154(G) pour les câbles
de substitutions de classe 3.
PoE input cable type should be CL3, CL3P, CL3R, CL3X, marked "SUNLIGHT RESISTANT", "SUN.
RES.", or "SR." and "water resistant" or "W".
Le type de câble PoE d'entrée doit être CL3, CL3P, CL3R, CL3X marqué "SUNLIGHT RESISTANT".
"SUN RES.» Ou «SR». et "waterproof" ou "W".
If further assistance is needed with purchasing a power source and POE input cable, please contact
Fortinet, Inc.
Si vous avez besoin de plus d'aide à l'achat de l'alimentation et le fil d'entrée PoE, s'il vous plaît
communiquer avec Fortinet, Inc.
The Console port is not intended to be connected to the computer after the outdoor installation is
completed.
20
