FOSSIBOT F800 User manual

F800 Power Station
User Manual
Thank you very much for purchasing the 800W portable power station. Be sure to read this manual
carefully before using the product in order to use it correctly. This manual is needed for after-sales
service. Please keep this manual together with the invoice and other purchase certificates.
In order to ensure the safety of this product during transportation, it is only charged to about 30%
when it is packaged. Please recharge when you get the product/Please recharge the product as soon
as you receive it. The product can be charged directly by the wall socket, please do not use
extension cords and cable taps.
When charging the product, do not plug other products in the same socket.

Warning
1. Please avoid using the product near high temperature, high humidity, direct sun environment and
fire place.
2. Do not disassemble or modify this product, it will cause malfunction and fire.
3. Please discard or recycle the product according to the methods prescribed by local laws.
4. Be careful not to drop the product from a high place and give the product a strong impact.
5. Keep or use the product in a place out of the reach of children.
6. Please use our company's genuine accessories. The damage caused by the use of non-genuine
accessories cannot be repaired free of charge.
7. Please leave a space of about 30cm away from the side suction and exhaust ports, so as not to
affect the heat dissipation of the product.
8. When not using this product, please turn off the power and unplug the power cord. Please avoid
storing the product in a place exposed to direct sunlight with high temperature and humidity.
9. For long-term storage, please consume power from full power to no power once every 3 months,
and then recharge to about 50%.
10. Please do not use this product and its accessory cables and connecting equipment when there is
a defect.
11. Please do not store the product for a long time in extremely high and low temperature places
such as in the car and in the field warehouse to avoid shortening the battery life.

12. Always operate or store the unit within the specified temperature range.
13. DO NOT place the unit on an unstable or tilted surface.
14. Make sure the area where you are using the unit is well-ventilated and spacious.
15. DO NOT ignore those warning signs on components or products made by manufacturers.
16. DO NOT insert foreign objects into the fan, vents, ports, or other openings.
17. DO NOT dismantle, cut, crush, puncture, or otherwise damage the unit in any way.
18. DO NOT insert foreign objects into the fan, vents, ports, or other openings.
19. NEVER use a damaged battery or component. Improper use or misuse of damaged batteries
may cause damage to your device or injury to yourself as a result of battery fluid leakage, fire,
overheating, or explosion.
20. Turn off the unit IMMEDIATELY in case of malfunction.
21. Use dry powder fire extinguisher in case of fire.
22. Keep the unit in a dry and cool place.
23. DO NOT place the unit on its side or upside down.
24. DO NOT stack anything on top of the unit, either in storage or in use.
25. Recommended storage temperature: 32-104°F/0-45°C.
26. FOSSiBOT Power Stations are NOT permitted to be carried on board as checked or carry-on
baggage.

Content
Packing List...................................................................................................1
Product Introduction..................................................................................... 1
Introduction of Button Function................................................................... 2
Display Icon Introduce..................................................................................5
Charge & Discharge Simultaneously........................................................... 6
Solar Panel Connection.................................................................................7
Car Charging................................................................................................. 8
Product Specification....................................................................................9
Battery Specification.....................................................................................9
Troubleshooting Table................................................................................10
Warranty Card.............................................................................................11

1
Packing List
Power Station
AC Charger
User Manual
MC4 to XT60
Plug Charging Cable
Product Introduction
This product is a 512Wh large-capacity 800W high-power portable power station
supplied with 1.5 hours of high-speed charging, using a LiFePO4 battery with high
safety performance.
It can be used as a backup power supply in case of emergency power cut or a disaster,
as well as for camping and vehicles, and can provide power for various power tools
in any situation.
800W high power, pure sine wave AC output, can be used for household appliances
such as dryers, microwave ovens, refrigerators, induction cookers; it can also be used
for other electronic devices such as personal computers.
Through the 400W ultra-fast charging, this model can be fully charged within 1.5
hours. The AC input/output voltage frequency can be automatically or manually
switched between 50Hz/60Hz.
This product also supports a maximum 200W solar charge, allowing you to charge it
even when the power is cut or in outdoor situations.

2
Introduction of Button Function
1Main power control
2LED Light control
3USB control
4DC control
5LCD display
6Air intake/outlet
7AC on/off control (50Hz/60Hz
switching control)
8XT60 input port(for solar panel)
9AC input port
①Main Power Control
Main Control for the whole system turn on/off.
Operate method: long press the button for 3s to turn on/off the system.
②LED light control
Operate method: short press to turn on and change the light mode (SOS/Flash).
Notice: you can turn off the light by long press the button(1-2s) in any mode.
③USB button
Operate method: short press to turn on/off.
USB-A×2
TYPE-C×1
TYPE-C×2
QC 3.0
PD-100W
PD-20W

3
④DC button
Operate method: short press to turn on/off.
DC6530 Output×1
Cigar Lighter×1
12V/10A
12V/10A
⑤LCD display
Present the remaining power and using data.
⑥Cooling system
When the fans are working, please don' t block the channel.
⑦AC button (AC output, total share 800W)
Operate method: short press to turn on/off.
Notice: 1. Please confirm the output voltage or frequency before using
2. Long press the button for 3s to enter the frequency changing mode, 50Hz and 60Hz will
blink in the display, press again the button to chose the right frequency, wait till the
frequency is not blinking, then you will get the frequency you want.
3. Quick short press for 10 times to switch the voltage.
⑧Solar panel input
Use the included XT60→MC4 conversion cable to connect the solar panel.
1. Solar panels can have a maximum input of 200W and a maximum voltage of 50V.
2. If exceeding the maximum voltage leads to equipment damage, it is beyond the scope of
warranty.

4
⑨AC Input
Use wall socket to get 400W fast charging, which can full charge from 0 to 100% in
1.5 hours.
※The product can be charged directly by the wall socket, please do not use extension cords and
cable taps. When the product is charging, do not plug other products in the same socket.
※Please do not plug several devices together in a extension socket at once, the current will be to
high and bring damage to the cable and fire risk.
※If the extension socket is plugged in to charge this product, please do not connect other
electrical appliances to this socket, otherwise the household meter may trip.

5
Display Icon Introduce
①Charging/using time
②Total input power
③Battery Progress Bar
④Power percentage
⑤Total output
power
⑥LED light
⑦AC output
⑧DC output
⑨Type-c output
⑩USB output
⑪Fan state
⑫Cigar lighter
output
⑬XT60 charging
⑭AC charging
⑮High/low temperature
protection
Display Attention
When this icon light up. Please keep Air intake/outlet unobstructed.
Please note that the device is now with high/low temperatures and may
cease functioning until the temperature returns to the normal standard.
When this icon is blinking, represent that the AC input is faulty, please
recheck (Power/Hz/cable).
When the icon is blinking, represent the output is fault,
please recheck.

6
Charge & Discharge Simultaneously
●UPS function
This product has a bypass mode, does not need to pass through the battery, can
directly output from the AC.
In UPS mode, when the AC input power of the mains is cut off due to a power outage,
the ac input power of the mains can be used in about automatic switch to product
battery power within 10 ms to ensure AC output.
●UPS Connections
As shown in the figure below, connect the product between the socket on the wall
and the electrical appliances, and the power of the product is in the ON state. When
you turn on the power of the electrical appliances, they will directly use the AC
power of the power grid.
In this state, when the power grid is cut off, it will automatically switch to the
product's internal battery to supply power.
※In UPS mode of the China, United Kingdom, Europe and South Korea, AC output of the
maximum power below 800W, AC output over 800W, " " AC output icon flashes indicating
overload.
※The charging and discharging at the same time function of the UPS can work properly only
when the F800 is connected with AC plug.

7
Solar Panel Connection
Our products can be connected to solar panels and can be charged through solar
panels.
※Solar panel charging power, according to the weather and climate conditions.
※Solar panel voltage exceeding 50V will damage the equipment and may not be covered by
warranty.
●By solar panels
Connecting Pattern①
The area of charging
Connecting Pattern②
The area of charging

8
Car Charging
This product can be charged by the cigarette lighter in the car with an ACC cable
(accessory: ACC hereinafter).
Turn on the power of this product, connect the ACC charging cable to the cigarette
lighter in the car and the XT60 interface on the side of the product, turn on the engine
of the car, and the LCD of this product will show the input power.
※On-board charging should be carried out with the car engine turned on. If the engine is not
turned on, the battery might run out.
※Car charging is usually low power of 90-120W, and the charging time will be long. If you need
quick charge, it is recommended to use the mains.

9
Specifications
Product name
800W Portable Power station
Product size
L*W*H=276*209*230mm
Product weight
6.5kg
Capacity
512Wh
AC Charging
50/60Hz 400W max，220V-240V
MPPT input
11.5-50V 8A 200W max
AC output
800W 50Hz/60Hz, pure sine wave, 220V-240V
USB-A output
(QC 3.0 18W)x2
Type-C output
(PD 100W)x1; (PD 20W)x2
DC 6530 output
12V/10A
Cigar lighter output
12V/10A
Power off current
<500uA
Operating temperature
-10~40°C
Charging temperature
0~40°C
Environment humidity
≤ 90%RH
Battery Specification
Battery type
40135 LiFePO4
Single cell rated voltage
3.2V
Single cell rated capacity
20Ah
Battery pack rated voltage
25.6V
Battery pack output voltage
21V-29V
Battery pack rated capacity
512Wh

10
Troubleshooting Table
Phenomenon
Cause
Processing method
The above output icon flashes
and beeps.
The output exceeds
the standard and it's
short-circuited.
Remove the load, and then short press the
switch in the area corresponding to the
icon to remove the alarm
The temperature warning icon
flashes and beeps.
The temperature of
the product is too
high or too low.
Take the product out of the charging state
remove all loads, turn the power off, wait
for the device to reach a suitable working
temperature, then the alarm is removed.
The icon of connecting to the
AC mains flashes and the
product cannot be charged.
The charging cable
is poorly connected.
The overload protection function is
enabled.

11
Warranty Card
Warranty Card
Model
Name
Address
Tel
Mail
Name of the store
Buying date
Please fill in all the above items.
This product provides a 24-month warranty service from the date of purchase
●If there is a quality problem within the range of normal use, we provide warranty service.
●After purchasing our company' s products, please keep this product together with invoices and
other items. When maintenance services are needed, please provide information according to
our company's request.
●In the case where the warranty is damaged or altered, and no stamp of the sales store on the
warranty, the warranty service may not be provided.
●Damage caused by use beyond the normal range of use is not covered by the warranty service.
●The content of the warranty scope shall be subject to the content recognized by the company.
●Even within the scope of the warranty, sometimes it will be exchanged for products with the
same function. The shipping and repair fees for products outside the warranty range shall be
paid by the customer.
●Sometimes the specifications and functions of the product will be updated without prior notice.
Manufacturer: Shenzhen Qichang Intelligent Technology Co., Ltd.
Address: Room 510, 5th Floor, Building 7, Yunli Smart Park, Bantian Street, Longgang District,
Shenzhen, GD CN.
Website: www.fossibot.com
Technical service email: [email protected]

F800 Centrale électrique
Manuel d'utilisation
Merci beaucoup d'acheter la centrale électrique portable 800W. Assurez-vous de lire attentivement
ce manuel avant d'utiliser le produit pour l’utiliser correctement. Ce manuel est nécessaire pour le
service après-vente. Veuillez conserver ce manuel avec la facture et les autres certificats d'achat.
Afin d'assurer la sécurité de ce produit pendant le transport, il n'est chargé qu'à environ 30% lors de
l'emballage. Veuillez recharger lorsque vous recevez le produit. Le produit peut être chargé
directement par la prise murale, veuillez ne pas utiliser de rallonges et de prises de câble.
Lorsque vous chargez le produit, ne branchez pas d'autres produits sur la même prise.

Warming
1. Veuillez éviter d'utiliser le produit à une température élevée, à une forte humidité, à un
environnement directe du soleil et à une cheminée.
2. Ne démontez pas ou ne modifiez pas ce produit, sinon cela causera des pannes et des incendies.
3. Veuillez jeter ou recycler le produit selon les méthodes prescrites par les lois locales.
4. Veuillez à ne pas laisser tomber le produit d'une hauteur, et ne pas créer un fort impact.
5. Conservez ou utilisez le produit dans un endroit hors de la portée des enfants.
6. Veuillez utiliser les accessoires d'origine de notre société. Les dommages causés par l'utilisation
d'accessoires non authentiques ne peuvent pas être réparés gratuitement.
7. Veuillez laisser une distance d'environ 30cm autour des orifices d'aspiration et d'évacuation
latéraux, afin de ne pas affecter la dissipation thermique du produit.
8. Lorsque vous n'utilisez pas ce produit, veuillez l'éteindre et débrancher le cordon d'alimentation.
Évitez de stocker le produit en plein soleil, dans des endroits où la température et l'humidité
sont élevées.
9. Pour le stockage à long terme, veuillez consommer l'énergie de la pleine puissance à la
puissance nulle une fois tous les 3 mois, puis recharger à environ 50%.
10. Veuillez ne pas utiliser le produit, ses câbles accessoires et son équipement de connexion s'ils
sont défectueux.
11. Veuillez ne pas stocker le produit pendant une longue période dans des endroits où les
températures sont extrêmement élevées ou basses, comme dans une voiture ou un entrepôt, afin
de ne pas réduire la durée de vie de la batterie.

12. Utilisez ou stockez toujours l'appareil dans la plage de température spécifiée.
13. NE PAS placer l'appareil sur une surface instable ou inclinée.
14. Assurez-vous que l'endroit où vous utilisez l'appareil est bien ventilé et spacieux.
15. NE PAS ignorer les avertissements sur les composants ou les produits fabriqués par les
fabricants.
16. NE PAS insérer d'objets étrangers dans le ventilateur, les évents, les orifices ou autres
ouvertures.
17. NE PAS démonter, couper, écraser, percer ou endommager l'appareil de quelque manière que ce
soit.
18. NE PAS insérer d'objets étrangers dans le ventilateur, les évents, les orifices ou autres
ouvertures.
19. N'utilisez JAMAIS une batterie ou un composant endommagé. Une utilisation incorrecte ou
une mauvaise utilisation d'une batterie endommagée peut endommager votre équipement ou
vous blesser en raison d'une fuite de liquide de batterie, d'un incendie, d'une surchauffe ou
d'une explosion.
20. Éteignez l'appareil IMMÉDIATEMENT en cas de panne.
21. Utilisez un extincteur à poudre en cas d'incendie.
22. Placez l'appareil dans un endroit sec et frais.
23. NE PAS placer l'appareil sur le côté ou à l'envers.
24. NE PAS empiler sur le dessus de l'appareil, qu'il soit en stockage ou en cours d'utilisation.
25. Température de stockage recommandée : 32-104°F/0-45℃.
La centrale électrique FOSSiBOT ne sont PAS autorisées à transporter comme bagage enregistré ou
bagage à main.

Contenu
Liste d'emballage........................ .................................................................. 1
Introduction du produit................................................................................. 1
Introdction de la fonction des boutons..........................................................2
Introduction d’icône d'affichage................................................................... 5
Charge et décharge simultanées. .................................................................. 6
Connexion du panneau solaire...................................................................... 7
Charge de la voiture...................................................................................... 8
Spécifications................................................................................................ 9
Spécifications de la batterie ........................................................................ 9
Tableau de dépannage................................................................................. 10
Carte de garantie......................................................................................... 11

1
Liste d'emballage
Centrale électrique
Chargeur AC
Manuel d'utilisation
MC4 vers XT60
Câble de chargement
Introduction du produit
Ce produit est une centrale électrique portable de grande capacité 512Wh et de haute
puissance 800W, avec une charge à grande vitesse de 1,5 heure, il utilise une batterie
LiFePO4 à haute performance en matière de sécurité.
Il peut être utilisé comme une alimentation de secours en cas de panne de courant
d'urgence ou de catastrophe, ainsi que pour le camping et les véhicules, et peut
alimenter divers outils électriques en toute situation.
800W haute puissance, sortie AC à onde sinusoïdale pure, peut être utilisée pour les
appareils électroménagers tels que les séchoirs, les fours à micro-ondes, les
réfrigérateurs, les cuisinières à induction haute puissance ; Peut également être
utilisée pour d'autres appareils électroniques tels que les ordinateurs personnels.
Avec une charge ultra-rapide de 400W, ce modèle peut être complètement chargé en
1,5 heure. La fréquence de tension d'entrée/sortie AC peut être commutée
automatiquement ou manuellement entre 50Hz/60Hz.
Le produit prend également en charge une charge solaire maximale de 200W, ce qui
vous permet de le charger même en cas de panne de courant ou dans des situations
extérieures.
