FOUNTAINLINE ProLine V4 User manual

Suggested LineMarking Liquids & Powders
MAX Concentrate ULTRA Line Marking Liquid 10L
• Most Advanced Formulation Specifically designed for use on premium turf
• Maximum Concentrate Makes up to 90L saving you storage + handling costs
• Stronger, Brighter Formula Choose dilution depending on ground condition
• Economical Goes 3 times further than other liquids
• More Durable Reduce remarking saving you time and effort
• Eco-Friendly Environmentally friendly, VOC, APEO and Solvent Free
NEW Concentrate ECO Line Marking Liquid 15L
• Longer Storage Life Forget all that wasted stock and small order hassles
• Concentrate Makes up to 75L saving you storage and handling costs
• Economical Goes two times further than other liquids
• Durable Reduce remarking saving you time and effort
• Versatile Non-Settling Formula Trouble free operation in ALL Liquid Line Markers
• Eco-Friendly Environmentally friendly, VOC, APEO and Solvent Free
EZY Colours Line Marking Liquid 10L
• Large Range Of Colours Red, yellow, blue, orange, green & more
• Very Bright Perfect for all logos and decorative details
• Easy To Apply Goes on with a spray or boom
• Removable Feature Great for special events
• Eco-Friendly Environmentally friendly, VOC, APEO and Solvent Free
Concentrated Marking Powder 5kg Bag
• Strong, Bright Formula Very white
• Maximum Concentrate makes up to 50L saving you storage + handling costs
• Convenient Smaller pack for use and storage
• Long Lasting Perfect for wet line marking over long distances
• Eco-Friendly Environmentally friendly
Whiting 25kg Bag
• Strong, Bright Formula Very white
• Maximum Concentrate makes up to 50L saving you storage + handling costs
• Convenient Comes in economical bulk packs
• Long Lasting Perfect for wet line marking over long distances and may be remarked
• Eco-Friendly Environmentally friendly and non-hazardous

The New FountainLine ProLine V4
Liquid Line Marker
We’ve listened to you and FountainLine are proud to present their all
NEW ProLine V4 Line Marker. The new upgraded model means even
sharper, brighter, lines than ever before!
Proudly manufactured by

Your New FountainLine ProLine V4 Liquid LineMarker
Congratulations!
FountainLine would like to congratulate you on your decision to purchase Australia most recognised and trusted brand
of sports field line marker. We trust that you will be completely satisfied with your new ProLine V4 and many of the new
design features, making it the most versatile, reliable and easiest LineMarker to ever use!
Unpacking and Setting Up
1. Loosen off handle locking screws & slide in handle into vertical handle support tubes, set to desired height and
lock screws into position
2. Remove from tank the marking disc assembly and slide into position onto the front of the marker and lock
screw in desired position
3. Using the allen key provided with the marker, set the marking discs to the appropriate width and lock screws
with key
4. Fit the nozzle assembly onto spigot on the marking disc frame and lock screw and set nozzle to correct height
to achieve line width
5. Lift front cover and pass the spiral host through the hole in front cover and insert end of hose into elbow lo-
cated at the top of the nozzle assembly
6. Ensure battery is completely charged by plugging in the charger located in the battery compartment
Directions
1. Check the FastClean™ valve is turned to Spray
2. Lift out tank filter and pour in the required amount of water followed be the required amount of paint and stir
thoroughly ensuring all paint and water is mixed. (Please ensure that a minimum of 15 Litres is mixed for initial
use as this is required for initial priming of the pump)
3. Place tank filter back into container and secure lid
4. Switch line marker on for approximately 45 second to allow paint solution to pump through entire delivery sys-
tem (for first use and after dry running)
5. After line marking is completed, clean the delivery system by plugging the standard garden hose into the quick
connect fitting of the FastClean™ system and turn handle on the FastClean™ valve to Flush
6. Turn on hose and Switch on the Pump until clean water is spraying out of the nozzle (Approx 1-2 minutes)
7. Disconnect garden hose and pack away for next use.
IMPORTANT NOTE : Please ensure the FastClaen™ lever is left on “Flush” after cleaning to avoid paint entering the discharge
system. And causing possible damage to pump!
Recommendations
1. Recharge battery after each use
2. Clean paint tank out if line marking not required for more than 1 week
3. Use genuine FountainLine marking liquids
4. Always use FountainLine spare parts to maintain warranty

Trouble Shooting and Maintenance
Athletics Boom
• Fits both ProLine V3 & V4 Fits to your machine in less than 30 seconds
• Convenient Reduces your marking time by more than 60%
• Adjustable & Consistent Line spacing to 2.65m and line widths to 100mm with
the ability to mark 1, 2 or 3 lines
• Long Lasting Perfect for wet line marking over long distances
Sport Marking Pin Sets
• Available In Sets of 1-20 and 21-40 Comes to you in a sturdy, easy to carry case
• Ideal For All Sport Uses; Placings, handicap positions, distance marking, closest to
the pin games, baton change positions, assembly points and event starts
NEW Acculine™ Sports Field Marking Kit
• Straight, Accurate Lines Ensures improved accuracy
• Convenient, Easy & Quick Halves the time it takes to layout the field
• Kit Includes; 50m Tape Reel, 3m/4m/5m Triangles, 500m High Tensile Cord, 12 Heavy
Duty Metal Pegs and comes supplied to you in a convenient plastic pail
PROBLEM CAUSE SOLUTION
My ProLine V4 line marker is
not switching on?
Flat Battery Charge Battery ensuring correct voltage set
on charger (12V) .
Damaged on/off switch. Replace Switch
Loose wiring terminals at pump, battery or
switch
Secure loose terminals
Worn Pump Replace Pump unit
The line width is not
achievable.
Battery charge low Charge battery
Nozzle tip damaged or worn Replace Nozzle tip
Liquid dilution too thick Ensure dilution at recommended rates
Blocked delivery line system Ensure cleaned and flushed correctly
Diaphragm seal worn or damaged Replace diaphragm seal
My ProLine V4 line marker
turns on but there is no or
low liquid flow?
FastClean™ valve set to Flush Set FastClean™ valve to Spray
Low Battery Charge Recharge Battery
Blocked Nozzle Clean nozzle with soft brush and water
Liquid in tank too low Re fill tank with diluted liquid
Pump contaminated with Paint Flush while pump is running
