Foxun SX-EX13 User manual

50m HDMI Extender over single Cat5e/6 cable
with loop out
Support 1080P60hz YUV4:4:4

Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read
these instructions carefully before connecting, operating or adjusting this product. Please keep
this manual for future reference.
Notice
The information in this document is subject to change without notice. Every effort has been
made in the preparation of this document to ensure accuracy of the contents, but all statements,
information, and recommendations in this document do not constitute the warranty of any
kind, express or implied.
Features
Each set includes one transmitter with loop out and one receiver
Audio sampling rate up to 48KHz, support 7.1 channels
Support 1080P60HZ@YUV4:4:4 Maximum extension of 50m
DC12V1A, support POC power supply
RX end one-way infrared transmission to TX end
Copy local and remote EDID functions
Setting of distance extension dialing switch: cat5e/cat6 10m ~ 50m
Support Dolby True-HD, DTS-HD Master audio.
2
Operating Instructions
MAIL-IN SERVICE
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably
in the original carton. Include a letter detailing the complaint and provide a day time phone
and/or email address where you can be reached.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage.
The Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or
failures which are caused by products not supplied by warrantor, or failures which result from
accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation,
set-up adjustments, misadjustment of consumer controls, improper maintenance, power line
surge, lightning damage, modification, or service by anyone other than a Factory Service
center or other Authorized Servicer, or damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED
WARRANTY COVERAGE". THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT,
OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install an installed unit if
applicable, travel to and from the service, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration only.)
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
7

Operating Instructions
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this
unit.
PRODUCT SERVICE
1) Damage requiring service:
The unit should be serviced by qualified service personnel if:
(a) The DC power supply cord or AC adaptor has been damaged;
(b) Objects or liquids have gotten into the unit;
(c) The unit has been exposed to rain;
(d) The unit does not operate normally or exhibits a marked change in performance;
(e) The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described in
these operating instructions. Refer all other servicing to authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses parts
specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety checks
to confirm that the unit is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or workmanship, our
Company (referred to as "the warrantor" ) will, for the length of the period indicated as below,
(Parts(2)Year, Labor(90) Days) which starts with the date of original purchase ("Limited
Warranty period"), at its option either(a) repair your product with new or refurbished parts, or
(b) replace it with a new of a refurbished product. The decision to repair or replace will be
made by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must mail-in your
product during the warranty period. This Limited Warranty is extended only to the original
purchaser and only covers product purchased as new. A purchase receipt or other proof of
original purchase date is required for Limited Warranty service.
6
Operating Instructions
SPECIFICATIONS
Operating Temperature Range -5 to +40℃(+23 to +104℉)
Operating Humidity Range 5 to 90%RH (No Condensation)
Connectors on Transmitter
HDMI Receptacle x 2 (1xHDMI input, 1xHDMI loop output)
Power DC Receptacle x 1
IR Receptacle x 1(for IR TX )
Connectors on Receiver
HDMI Receptacle x 1
IR Receptacle x 1(for RX cable)
Resolution outputs 1080p/1080i/720p/576p/480p
Audio format supported DTS-HD Master Audio, Dolby True HD, multi-channel 7.1, stereo etc
Output Video Signal HDMI
Dimension (L×W×H) TX: L79.3xW68xH16.5mm; RX: L79.3xW68xH16.5mm
Power supply DC 12V1A Power supply
Power consumption 2W(MAX)
Transmission Distance 1080p up to 50m
Net Weight TX: 120g; RX:115g
Note 1 :Under perfect transmission conditions including straight cable runs with no electrical
interference, bends, kinks, patch panels or wall outlets.
Package Contents
1xHDMI Transmitter
1xHDMI Receiver
1 x IR TX Emitter
1x IR RX Receiver
1x12V DC Adapter
1xUser Manual
3

Operating Instructions
PANEL DESCRIPTIONS
Transmitter Panel
①HDMI loop out port ②EDID Switch
③HDMI input port ④IR Out port
⑤Cat5e/6 output port ⑥DC 12V port
Note :The transmitter of this product has the function of EDID copy, Dial to the left side
means copy loop EDID, and dial to the right side means copy remote EDID.
Receiver Panel
①DIP switch ②HDMI output port
③IR In port ④Cat5e/6 input port
Note :Its receiver has 3 bit dialing switch.
From left to right, 1 is the high position, 3 is the low position, Corresponding to binary,
dial up to 0, dial down to 1, for the extension cord distance adjustment.Different network
cable lengths need to be set according to the following table.
000
1~15meters
network
cable
distance
011
16~30meters
network
cable
distance
101
31~40meters
network
cable
distance
111 41~50meters network cable distance
*When the distance up to 41~50m, please make sure the UTP cable upto 24AWG.
4
Operating Instructions
Connecting and operating
1. Connect 1 source such as a Blu-Ray Player, game console, STB, etc. to the HDMI input on
the transmitter
2. Connect 1 display such as an HDTV or HD Projector to the Loop HDMI output on the
transmitter.
3. Connect 1 display such as an HDTV or HD Projector to the HDMI output on the receiver .
4. Connect a single Category 5e/6/7 up to (50m) to both transmitter and receiver.
5. Plug in the IR-RX cable and IR-TX cable to the IR jack port located on the Receiver and
transmitter banal.
6. Power on the transmitter firstly, then power on the source and sink.
Connection Diagram
5
