FPV Model Skywalker X8 User manual

Skywalker X8 Installation Manual

Thank you for Purchasing the Skywalker X8 FPV Plane from FPV Model. The Skywalker X8 is specially designed for First
Person View (FPV) purpose.
Technical Parameters
Wingspan: 2120mm
Weight: 880G
Take-off weight:3200G
Required Parts
Motor: 2820 KV730
ESC: 60A
Battery Pack: 4S 8000MAH
Propeller: 12X6~13X8
1
WWW.FPVMODEL.COM

KIT version configuration: Fuselage, wing, wing let, tube, accessories bag, sticker
Parts Listing
2
WWW.FPVMODEL.COM

Assembly
Glue the winglet layers, spread the glue evenly over the wing and both sides of the layers ( the layer marked with T board
belongs to parts of the main wing).
3
WWW.FPVMODEL.COM

Wait for 5 minutes to allow glue to dry until it is non-sticky, then they can be glued in alignment.
4
WWW.FPVMODEL.COM

Glue the hatch magnets , after compressing the magnet tightly, fix them with CA glue.
5
WWW.FPVMODEL.COM

Glue the wood chip onto the hatch and fuselage, pay attention to the direction of SN of the magnetic pole
6
WWW.FPVMODEL.COM

After gluing, put it together and inspect the mounting spacing.
Glue the servo, please choose the standard servo provided by skywalker or servo with moment more than 2.5 KG
7
WWW.FPVMODEL.COM

Glue the rudder horn, spread the glue evenly and wait for its dryness, then Glue the rudder horn
8
WWW.FPVMODEL.COM

Power on the servo and place it in the mid-position , then lock the regulator screw, tighten the steel wire. And shorten the extra
length of the wire.
9
WWW.FPVMODEL.COM

Glue the fixed layer of the winglets, please be sure to spread the glue evenly and wait until it is completely dry, afterwards you
can glue the layer.
10
WWW.FPVMODEL.COM

Cut out the pre-reserved slot on the aileron only about 1,5 mm wide by a new blade.
11
WWW.FPVMODEL.COM

Wing plate bonding, please to smear evenly on all surfaces, please not to spread the glue over the tube slot!
Settle the extending line in the line slot previously and spread the glue evenly over the plate.
12
WWW.FPVMODEL.COM

Wait for the two planes' dryness, later spread some glue over the vertical planes, and then fix and flatten them.
13
WWW.FPVMODEL.COM

The side plate bonding: spread the glue on both sides of the plate
14
WWW.FPVMODEL.COM

It is recommended to insert the tube into the wing to guide the butt plate, which is more accurate.
15
WWW.FPVMODEL.COM

The line slot of early product also need to be widened to let the the extending line with plug directly into the fuselage.
16
WWW.FPVMODEL.COM

Install the motor, and cement it to the fuselage in advance, you can also first fix the layer board base, and afterwards install the
motor.
17
WWW.FPVMODEL.COM

18
WWW.FPVMODEL.COM

Spread the glue on both sides of the fuselage, note:please avoid the tube slot!
19
