USER MANUAL
CW
FCS4054

Read the user manual before working on the equipment.
Keep the manual with the equipment and pass the manual on to the next
user if the equipment is sold or transferred to a third party.

Franke Kaffeemaschinen AG Table of contents
iii / 16
TABLE OF CONTENTS
1 For your safety......................................................................... 4
2 Instructions ............................................................................. 6
2.1 Installation............................................................................... 6
2.2 Intended use............................................................................ 6
2.3 Non-authorized use.................................................................. 7
2.4 Function of the cup warmer ..................................................... 7
2.5 Operation and maintenance ..................................................... 8
2.6 Malfunctions............................................................................ 8
2.7 Transport, storage, decommissioning ....................................... 8
2.8 Disposal .................................................................................. 9
3 Technical data - CW............................................................... 10

1 | For your safety Franke Kaffeemaschinen AG
4 User manual
1 FOR YOUR SAFETY
WARNING
Risk of fatal injury from electrocution
Damaged power cords, lines or plug connections can lead to electrocution.
aDo not connect any damaged power cords, lines or plug connections to
the power supply.
bReplace damaged power cables, lines or plug connections.
If the power cord is permanently attached, contact the service techni-
cian. If the power cord is not permanently attached, order and use a new,
original power cord.
cEnsure that the machine and the power cord are not near any hot sur-
faces such as gas or electric stoves or ovens.
dEnsure that the power cord is not pinched and does not chafe on sharp
edges.
WARNING
Risk of burns
The heating surfaces of the cup warmer can cause burns or a fire.
aDo not touch the hot heating surfaces of the cup warmer.
bIN CASE OF BURNS: Immediately cool the affected area and consult a
doctor depending on the severity of the injury.
cDo not place anything flammable on the cup warmer.

Franke Kaffeemaschinen AG For your safety | 1
User manual 5
NOTICE
Damage to the machine
Connection lines could be damaged by tensile load.
Incoming moisture could cause damage.
An unsuitable location could lead to damage.
aNever pull on the connection lines.
bLay the connection lines in such a way that they do not form tripping haz-
ards.
cDo not use jets of water or steam for cleaning.
dDo not expose the machine to the elements, such as rain, frost or direct
sunlight.
ePlace the machine only on a level, stable subsurface.
Do you have any questions that are not addressed in these instructions?
Please do not hesitate to contact your local customer service partner, Franke
Customer Service, or Franke Kaffeemaschinen AG in Aarburg.

2 | Instructions Franke Kaffeemaschinen AG
6 User manual
2 INSTRUCTIONS
2.1 Installation
Installation may only be performed by an authorized Franke specialist.
Tasks
– Unpack the device
– Check that there is the required free space
– Check the electrical power connection
– Attach the device
– Connect the power supply
– Switch on the device
The top heating plate is made of aluminum. It takes a few minutes for the
heating plate to heat up.
2.2 Intended use
– The cup warmer is intended only for preheating coffee cups and glasses
used when preparing drinks.
– The cup warmer is intended exclusively for operation in interior rooms.
– Please also observe the Declaration of Conformity delivered with the de-
vice.

Franke Kaffeemaschinen AG Instructions | 2
User manual 7
2.3 Non-authorized use
– Children under the age of 8 years are not permitted
to use the device.
– Children or persons who are challenged with respect
to physical, sensory or mental abilities must not use
the device except under supervision, nor should they
play with the device.
– The device is not designed to dry dish towels or other cloths. It is not
necessary to cover the cups with a cloth to warm them up.
– Alcoholic or explosive substances must not be used or stored in the ma-
chine.
– Do not use the machine:
– If you are not familiar with its functions.
– If the machine, power cord or connection lines are damaged.
– If the machine has not been cleaned or filled as specified.
2.4 Function of the cup warmer
The cup warmer has the following function:
– Pre-warming the cups and glasses for preparing hot beverages.

2 | Instructions Franke Kaffeemaschinen AG
8 User manual
2.5 Operation and maintenance
You can find more information regarding operation and maintenance of the
cup warmer in the operating instructions supplied with your coffee machine.
Cleaning
1. Switch off the cup warmer.
2. Do not clean until the work
surfaces have cooled.
3. Clean the now cooled work
surfaces with a damp mi-
crofiber cloth. In the case of
gross contamination use a
mild cleaner.
2.6 Malfunctions
Error messages will appear on the coffee machine's display in the case of
malfunctions. The error messages contain information regarding the cause
and resolution of the malfunction.
2.7 Transport, storage, decommissioning
– Clean the device
– Secure the device against accidents and do not set it up in an inclined
position
– Use suitable packaging for transport and storage
– Comply with the ambient conditions provided in the technical data

Franke Kaffeemaschinen AG Instructions | 2
User manual 9
2.8 Disposal
– Observe the information on the label when disposing of any unused
cleaning agent.
The machine complies with European Directive 2012/19/EU regarding Waste
Electrical and Electronic Equipment (WEEE) and must not be disposed of with
household waste.
Dispose of electronic parts separately.
Dispose of plastic parts in accordance with their marking.

3 | Technical data - CW Franke Kaffeemaschinen AG
10 User manual
3 TECHNICAL DATA - CW
Device type FCS4054
Capacity Up to 120 cups (depending on cup
size)
Ambient conditions Humidity: max. 80%
Ambient temperature: 10–32 °C
Noise emission <70dB(A)
Weight Approx. 20 kg
Dimensions (width/height/depth) 270 mm/540 mm/475 mm
Electrical connection data
Type Country
CW
(FCS4054)
CN Voltage 220V
Frequency 50Hz
Power 110W
Current consumption
(max.)
0.5 A
Fuse 10A
Connection 1L N PE
Power cord 560.0005.151
CW
(FCS4054)
CH, EU,
GB
Voltage 220–240V
Frequency 50–60Hz
Power 110–130W
Current consumption 0.5–0.54 A
Fuse 10A
Connection 1L N PE

Franke Kaffeemaschinen AG Technical data - CW | 3
User manual 11
Type Country
Power cord 560.0004.833 (CH)
560.0004.870 (EU Schuko
(CEE 7/4 plug))
560.0005.118 (GB)
CW
(FCS4054)
JP Voltage 100V
Frequency 50–60Hz
Power 80W
Current consumption
(max.)
0.8A
Fuse 10A
Connection 1L N PE
Power cord 560.0004.859
CW
(FCS4054)
USA Voltage 100–127V
Frequency 60Hz
Power 80-130W
Current consumption 0.8-1.024 A
Fuse 10A
Connection 1L N PE
Power cord 560.0004.859
CW
(FCS4054)
BR Voltage 127V
220V
Frequency 60Hz
Power rating 135W (127V)
110W (220V)
Fuse 10A
Connection 1L N PE (127V)
2L PE (220V)

3 | Technical data - CW Franke Kaffeemaschinen AG
12 User manual
Type Country
Power cord 560.0006.378 (127V)
