SS-276ULT BUILT-IN RECTANGULAR WARMER
I T E M N O .
WE L L S M A N U F A C T U R I N G
Features
• 1/3 larger capacity than standard
12” x 20” units.
• Warming pan is deep-drawn, stainless
steel construction for maximum strength
and durability.
• The tubular element, located under the
warming pan, allows for quick heating.
• The positive-off thermostat controls
the element allowing for adjustable and
more consistent temperatures. A signal
light indicates that the heating element
is energized.
• Control is recessed in a one-piece, drawn,
stainless steel panel to help prevent
accidental temperature changes.
• Available with optional drain (D).
• Wellslok provides quick and easy installation
in stainless steel countertops.
• Warmer is designed for wet or dry operation.
• The SS-276ULT/TD Warmers are
Underwriters Laboratories, Inc. LISTED and
meet NSF International and Canadian
standards.
• A one-year warranty against defects covers
parts and labor.
Specifications
Overall Dimensions: Inches MM
Width 13 1/2 343
Depth 28 1/2 724
Temperature Settings: OFF/LO to HI
Weights: Lbs. KG
Installed 19 9
Shipping 21 10
Wells SS-276ULT Built-In Rectangular Food
Warmer is designed for top mount installation.
This dependable and practical unit is made with a
heavy-duty 12” x 27” stainless steel warming pan
and is thermostatically controlled.
SS-276ULT BUILT-IN
RECTANGULAR WARMER
Accessories / Options
Adapter Top, to convert SS-276ULT to hold
three 7-quart insets, 22589
Inset, 7-quart capacity with lid, 20587
Wellslok Extension Kit, designed for
countertops up to 1 1/2˝ thick, refer to
installation instructions, 22593
Drain Valve Extension Kit, extension from
drain to counter front with remote handle,
for use with "D" models only, 20385
Individual drain (D models) available
SS-276ULT

STD.4
R
R
R
LISTED
E6070
(149)
5 7/8
(75)
2 15/16
(159)
6 1/4
(221)
8 11/16
(724)
28 1/2
(95)
3 3/4
(724)
28 1/2
(683)
26 7/8
(302)
11 7/8
(343)
13 1/2
1/2 IN CONDUIT
(SS-276ULTD ONLY)
1/2 IN DRAIN NPT
WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
2001 WELLS MANUFACTURING • PRINTED IN THE U.S.A. • 2/01 • REV(F) • PART NO. 49484
MODEL
S S - 2 7 6 U LT B U I LT- I N
R E C TA N G U L A R W A R M E R
DIMENSIONS: INCH
(MM)
WE L L S M A N U F A C T U R I N G
WELLS
MINIMUM CLEARANCE
UNIT TO THE NEAREST SURFACE
BACK SIDE BOTTOM FRONT*
2 2 6 3/4 4 1/8
(51) (51) (171) (105)
* 2" if control box is located below the unit.
S S - 2 7 6 U LT E L E C T R I C A L S P E C I F I C AT I O N S :
SS-276ULT 120 1650 13.8 SINGLE NONE
SS-276ULT 208 1240 6.0 SINGLE NONE
SS-276ULT 240 1650 6.9 SINGLE NONE
MODELS VOLTS WATTS AMPS PHASE POWER SUPPLY CORD
NOTE: Specifications are subject to change without notice. See installation instructions prior to installing the unit.
This document is not for installation purposes.
All models with a 'D' suffix have the same electrical specifications as the standard models.
