0English
AQUATIMER A3000 open shower panel made of mineral composite with a 24 V DC
thermostat
AT3O0044
AT3O0046.................. with integrated tray for shower gel
Please refer to the graphics in the German installation and operating instructions.
0Table of contents
1. Abbreviations and units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Important notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of product
5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7. Properties of MIRANIT-S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
8. Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
9. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
10. Installation example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
11. Spray pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly, function and commissioning
12. Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
13. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
14. Thermal disinfection -manual- . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
15. Thermal disinfection -automatic- . . . . . . . . . . . . . . . . . . . . . . . . . 10
16. Setting the scald protector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
17. Adjusting the flow time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
18. Setting the hygiene flush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Maintenance
19. Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
20. Maintenance information for MIRANIT-S . . . . . . . . . . . . . . . . . . . 13
21. Cleaning the shower head faceplate . . . . . . . . . . . . . . . . . . . . . . 13
22. Replacing the filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
23. Replacing the solenoid valve cartridge. . . . . . . . . . . . . . . . . . . . . 14
24. Replace the thermal element . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
25. Replacing the flow rate regulator . . . . . . . . . . . . . . . . . . . . . . . . . 14
26. Replacing the non-return valve. . . . . . . . . . . . . . . . . . . . . . . . . . . 15
27. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
28. Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
EN

4
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
1. Abbreviations and units
2. Key
Warning!
Failure to observe can result in bodily injury or even death.
Caution!
Failure to observe can result in material damage.
☞Important!
Failure to observe can cause the product to malfunction.
☞Useful information for optimal handling of the product.
3. Warranty
Liability is accepted in accordance with the General Terms and Conditions of
Business and Supply.
Use only genuine spare parts!
4. Important notes
• Installation, commissioning and maintenance are to be performed only by a
qualified expert in accordance with the instructions provided, legal requirements
and recognised engineering standards.
• All technical connection regulations specified by the local water and electricity
supply companies must be observed.
• The instructions for connection provided in the AQUAPAY coin contactor manual
must be taken into account when making use of a prepaid water dispenser.
• We reserve the right to make changes.
DN Nominal diameter in mm
RCD Residual current protective device,
Earth leakage circuit breaker
SELV Safety extra low voltage
EA-Nr. European article number
FAR-Best.-Nr. Franke Aquarotter order number
Conversion 1 mm = 0.03937 inches
1 inch = 25.4 mm
All length specifications in the graphics are in mm.

5
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
5. Application
AQUATIMER - A3000 open mineral composite shower panel for surface installation,
with electronic timer, DN 15 thermostat battery and the option of prepaid water
dispensing by AQUAPAY coin contactors and external controls, such as fitting
adjustment and communication via ECC function controllers. For connection to hot
and cold water supply. The flow time can be set in one-second steps.
With a device for an optional bypass solenoid valve cartridge for carrying out thermal
disinfection, with the option of manual thermal disinfection.
Integrated control functions:
– 30 second flow time.
– Hygiene flush (10 seconds), 24 hours after last operation
Additional functions with ECC function controller (Ethernet):
– Automatic thermal disinfection according to DVGW Work Sheet W 551 and
safety shutdown
– Cleaning deactivation
6. Technical specifications
Minimum flow pressure: 1.0 bar
Recommended flow
pressure:
1-5 bar
Maximum operating
pressure:
10 bar
Calculated flow rate: 0.15 l/s 0.15 l/s
Volumetric flow:
Fitting: 0.20 l/s at a flow pressure of 3 bar
Bypass: 0.06 l/s at a flow pressure of 3 bar
Flow duration: 30 s
Operating voltage: 24 VDC
Power consumption: 2.5 W
Communication: Ethernet via ECC function controller
Protection class: IP 68

6
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
7. Properties of MIRANIT-S
MIRANIT-S resin-bound mineral material is a mixture of aluminium trihydrate,
natural stone, high quality unsaturated polyester resin and colour pigments.
MIRANIT-S ensures high stability and breaking resistance.
The smooth, non-porous and semi gloss surface is very easy to clean and fulfils the
most stringent hygiene requirements.
8. Scope of delivery
9. Dimensions
10. Installation example
11. Spray pattern
12. Assembly
Warning!
Only operate the fitting with non-return valves and the specified filters.
Failure to observe this instruction can result in an increased germ load in the
drinking water and thus pose a health or mortality risk.
Warning!
• Operate the product only with safety extra low voltage (SELV). The components
must not be earthed.
• Place the power supply (not part of the delivery , see accessories, Chapter 28)
outside the wet area in a separate room.
• Protect the power supply with a residual current circuit breaker (RCD).
Failure to observe this instruction can result in death or material damage due to
electric shock or fire, for example.
Quantity Name
1 Shower panel with:
Thermostat, electronic module M1, piezo button, solenoid
valve cartridge, lockable water volume regulators,
connection pipes and AQUAJET Slimline shower head
2 Connection bracket
1 Suspension rail
1 0.15 l/s flow rate regulator
1 Electrical T-distributor
3 Screws, wall plugs
1 Installation and operating instructions

7
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
☞Important!
Prior to the assembly process, flush the pipework in accordance with DIN 1988.
☞To protect the tiles, use masking tape when marking and drilling. Drill at low speed.
☞Depending on the composition of the wall, special wall plugs may have to be used
(to be provided by the customer).
☞Lay the system line (not included in delivery) in the empty pipe (to be provided by the
customer) from the power supply to the fittings and loop through.
Fig. A: Water connection from above
Fig. B: Water connection from the rear
12.1 Only for water connection from the rear: Install the connection brackets (a) leak-tight.
12.2 Screw in the water volume regulators (b) leak-tight.
12.3 Align the water volume regulators so that the locking screw and operating element
are freely accessible.
12.4 For a shower head height of 2.10 m to 2.30 m, mark drill holes for installation at a
height (c) of 2.12 m to 2.32 m from the top of the finished floor.
12.5 Drill holes in accordance with these markings.
12.6 Insert the wall plugs.
12.7 Screw on the suspension rail.
12.8 Suspend the shower panel.
12.9 Mark the remaining drill hole.
12.10 Remove the shower panel.
12.11 Drill hole in accordance with the marking.
12.12 Insert the wall plug
Install the electrical T-distributor
☞Important!
The components of the electrical T-distributor may only be installed after the power
has been switched off.
☞Recommended system cable see Chapter 28., accessories.
When using cables other than the system cable, pay attention to the different colour
code. The outer diameter must not exceed 7.5 mm.
12.13 Remove the sheathing (a) of the system cable (approx. 40 mm).
12.14 Push the cap nut (c) onto the system cable (b) up to the limit stop.

8
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
☞The various wire guides are marked with numbers 1 to 4.
12.15 Engage the wires (d) on the wire guides (e) according to their colours.
12.16 Cut off the projecting wire ends flush, i.e. without protrusions.
12.17 Push the union nut (c) onto the electrical T-distributor (f) and tighten it to the required
torque (1.2 Nm).
Caution!
Note the polarity.
The same wire colour must be in the same wire guide for both union nuts.
☞When tightening the union nut, the electrical contact and tension relief are created
automatically.
Special seals act as protection from dust and water.
12.18 Connect the wires between the electronic module, the solenoid valve cartridge and
the piezo button.
A: Solenoid valve cartridge for mixed water
B: Solenoid valve cartridge for thermal disinfection bypass (optional)
C:0-10 V analogue output
D:Cold water temperature sensor (optional)
E: Hot-water temperature sensor (optional)
F: Sensor connection 2/3
G:Piezo button
H:Electrical T-distributor system cable (power)
K: Electronic module
12.19 Only for water connection from the rear: Prioritise work steps 12.21 to 12.23.
12.20 Mount the shower panel on the suspension rail and screw tight.
12.21 Establish the water connections.
12.22 Open the water volume regulatorsusing an Allen key.
d: closed
e: open
12.23 Check the water connections for leaks.
A: Union nut
B: FAR-Best.-Nr. 2000104272
FAR-Best.-Nr. 2000104274
FAR-Best.-Nr. 2000100801
FAR-Best.-Nr. 2000100852
AB
1brown red
2 white white
3 blue blue
4 black black

9
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
13. Function
Trigger the flow of water
13.1 Press the piezo button.
• The water will flow.
• The water stops automatically following the set flow time or if you press the piezo
button once more.
Flow duration
The flow duration is factory-set to 30 seconds. You can adjust the flow time in
0.1 second increments from
1 to 6,500 seconds.
Temperature selection
14. Thermal disinfection -manual-
This shower fitting offers thermal disinfection to reduce the risk of a legionella
infection.
The thermal disinfection process is triggered by overturning the thermostat.
Warning!
Personal protective measures (scald protection) must be implemented for the
duration of the thermal disinfection. This might include cordoning off the shower
facilities.
Failure to observe this instruction can result in injuries due to scalding.
The operator is responsible for the execution, monitoring, and logging (room,
tapping point, date, time, temperature and duration).
The manufacturer does not accept any liability for claims by third parties relating to
the improper execution of thermal disinfection on the part of the operator.
The thermostat fitting has been prepared to carry out a thermal disinfection process
when the thermostat is overturned. The thermostat fitting can be manually thermally
disinfected (flushed with water at a temperature of 70°C) by unlocking the covered
stop on the temperature selector.
14.1 A shower pipe (e.g. HT pipe, di= 100 mm) should be placed under the shower head
to deflect the hot water to avoid scalding during the thermal disinfection process.
14.2 Turn the temperature selector (a) to the hot water stop.
14.3 Use the Allen key to push in the stop.
14.4 Turn the temperature selector (a) in an anti-clockwise direction up to the stop.
14.5 Trigger the fitting.
14.6 Measure the hot water temperature.

10
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
14.7 If the hot water temperature is > 70°C, the fitting should be flushed for at least 3
minutes. Trigger the fitting several times for this purpose.
☞The thermal disinfection process must be recorded (room, tapping point, date, time,
temperature, duration).
14.8 Turn the temperature selector (a) clockwise until it engages.
Caution!
The temperature selector (a) may not be turned beyond the stop in an anti-
clockwise direction.
14.9 Test the limit stop.
14.10 Trigger the fitting to drain the remaining hot water.
14.11 Measure the water temperature. The maximum water temperature may not exceed
40°C (see Chapter 16.).
☞Once thermal disinfection has been completed, the scald protector does not need to
be reset.
15. Thermal disinfection -automatic-
Caution!
The directions in the Thermal Disinfection Planning Aid (01805618) must be
adhered to.
Required accessories
ECC2 function controller (60 W)
with Ethernet connection . . . . . 2000108123
Bypass solenoid valve cartridge . . 2000100431

11
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
16. Setting the scald protector
Warning!
If the hot water supply temperature is above 45°C, the scald protector should be set.
Failure to observe this instruction can result in injuries due to scalding.
☞The scald protector (hot water stop) has been set to 38°C at the factory. Set the
system-specific parameters before use.
16.1 Remove the cover platelet (d).
16.2 Release the screw (c) with its disk.
16.3 Remove the temperature selector (b).
16.4 Remove the stop ring (a).
16.5 Trigger the fitting.
16.6 The temperature is freely selectable:
Set the maximum water temperature on the adjustment nut (e), e.g. to 40 °C.
16.7 Mount the stop ring (a) in such a way that the marking (f) is centred below the
markings (g) for the rosette.
☞Important!
Mount the temperature selector (a) in such a way that the stop is flush against the
stop ring crosspiece.
16.8 Slide the temperature selector (a) onto the stop ring (b).
16.9 Attach the temperature selector (b) and its screw (c) and disk to the fitting.
16.10 Fit the cover platelet (d).
17. Adjusting the flow time
The flow time can be adjusted with an ECC2 function controller via the web appli-
cation.
18. Setting the hygiene flush
The hygiene flush can be adjusted with an ECC2 function controller via the web
application.

12
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
19. Maintenance and care
The fitting must be checked and maintained at regular intervals, depending on the
water quality and in accordance with the local conditions and rules and regulations
applicable at the site.
Maintain the following components:
• Shower head (see Chapter 21.)
• Filters (see Chapter 22.)
• Non-return valve (see Chapter 26.)
Use suitable cleaning agents which do not attack the fitting in a proper manner and
rinse with water after use. High-pressure cleaners must not be used for cleaning.
Removing the shower panel
For some maintenance tasks, the shower panel must be removed.
Caution!
Do not allow the shower panel to hang by the connecting hoses.
Water connection from above:
19.1 Close the water volume regulators.
a: closed
b: open
19.2 Trigger the fitting.
19.3 Disconnect the water supply.
19.4 Release the screws on the shower panel.
19.5 Unhook the shower panel.
19.6 Insert the side of the shower panel into the suspension rail.
Water connection from rear:
19.7 Release the screw on the shower panel.
19.8 Unhook the shower panel.
19.9 Insert the side of the shower panel into the suspension rail.
19.10 Close the water volume regulators (see Work step 19.1).
19.11 Trigger the fitting.
19.12 Disconnect the water supply.

13
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
20. Maintenance information for MIRANIT-S
Soap cleaners with a neutral pH-value are sufficient for cleaning and care. Apply the
cleaner with a soft, clean cloth, leave to soak briefly and then rinse with a large
volume of water.
Caution!
The following must not be used:
• Cleaning agents with an abrasive effect
• Cleaning sponges / cleaning cloths with an abrasive effect
• Steel wool or other hard objects
• Solvents
☞Important!
Possible minor damage to the surface, e.g. small scratches, can be directly polished
out. A repair kit is available for larger damaged areas. The surface is polished with
Type 1000 grinding paper after application and drying of the repair material.
21. Cleaning the shower head faceplate
21.1 Release the screw using an Allen key.
21.2 With a screwdriver, carefully lever out the spray faceplate.
21.3 Clean the shower head faceplate.
21.4 Reassemble in reverse order.
22. Replacing the filters
Water volume regulator filters
22.1 Remove the shower panel (see Chapter 19.).
22.2 Unscrew the locking screws (a) on the water volume regulators.
22.3 Replace the filters (b).
☞Important!
Note the installation position of the filters.
22.4 Reassemble in reverse order.
Solenoid valve cartridge filter
22.5 Remove the solenoid valve cartridge (see Chapter 23.).
22.6 Use flat-nosed pliers to remove the filter (c).
22.7 Replace the filter.
☞Important!
Note the installation position. The crosspiece of the filter may not be on top of the
flow hole.
22.8 Reassemble in reverse order.

14
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
23. Replacing the solenoid valve cartridge
23.1 Remove the shower panel (see Chapter 19.).
23.2 Loosen the cable connection between the solenoid valve cartridge and the
electronics module.
23.3 Loosen the screws (a).
23.4 Remove and replace the solenoid valve cartridge (b).
23.5 Reassemble in reverse order.
24. Replace the thermal element
Warning!
Set the scald protection after installing the fitting or removing the thermal element.
Failure to observe this instruction can result in injuries due to scalding.
24.1 Remove the shower panel (see Chapter 19.).
24.2 Remove the screw (b)
Caution!
Apply the pliers to the area with the largest diameter (a) behind the small sprocket
wheel.
If the sprocket wheel is damaged, the temperature selector cannot be installed.
24.3 Use pliers to remove the thermal element (c).
☞Important!
Note the installation position of the thermal element.
24.4 Reassemble in reverse order.
24.5 Set the scald protection (see Chapter 16.).
25. Replacing the flow rate regulator
25.1 Release the grub screw with an Allen key.
25.2 Pull the shower head out of the connection pipe.
25.3 Remove the locking ring on the inside using appropriate pliers for locking rings.
25.4 Pull out the flow rate regulator using flat-nosed pliers.
25.5 Replace the flow rate regulator. Observe the table.
☞Important!
Note the installation position of the flow rate regulator. The struts must point towards
the shower head.
25.6 Insert the flow rate regulator and secure with the locking ring.
a: Struts
b: Direction of flow
25.7 Reassemble in reverse order.
Flow rate Flow rate regulator
0.15 l/s (orange) FAR-Best.-Nr. 2000104782
0.20 l/s (red) FAR-Best.-Nr. 2000104783

15
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
26. Replacing the non-return valve
Warning!
All non-return valves must be replaced at the same time.
Failure to observe this instruction can result in an increased germ load in the
drinking water and thus pose a health or mortality risk.
26.1 Remove the shower panel (see Chapter 19.).
26.2 Loosen the cap nuts (b).
26.3 Remove the hoses (a).
26.4 Remove the existing seals (c).
26.5 Remove the locking ring (d) on the inside using appropriate pliers for locking rings.
26.6 Pull the non-return valve (e) out of the function block using a special tool (FAR-Best.-
Nr. 2000105636) or a bent wire.
Optional:
Fittings with optional thermal disinfection have a third non-return valve.
26.7 Remove the lock (f) using an Allen key.
26.8 Remove the spacer (g).
26.9 Pull the non-return valve (h) out of the function block (i) using a special tool (FAR-
Best.-Nr. 2000105636) or a bent wire.
Caution!
Note the installation position of the non-return valves.
26.10 Reassemble in reverse order.

16
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
27. Troubleshooting
If you cannot rectify a fault or if it is not in the list, please contact our customer service
department!
Fault Cause Remedy
Water does not flow – Water supply interrupted ➯Restore it
– Water volume regulator closed ➯Open it
– Power supply interrupted ➯Restore it
– Filter/non-return valve in dirty or
defective
➯Clean and replace
if necessary
– Piezo button faulty ➯Replace it
– Electronics module faulty ➯Replace it
– Solenoid valve cartridge faulty ➯Replace it
Water flows continu-
ously
– Solenoid valve cartridge faulty ➯Replace it
– Flow rate regulator in shower head
blocked with scale
➯Clean and replace
if necessary
Flow time too short
or too long
– Incorrect flow time setting ➯Set it
Water too hot – Scald protection set incorrectly ➯Set it
– Thermal element faulty ➯Replace it
Water too cold – Scald protection set incorrectly ➯Set it
– Hot water flow blocked ➯Open it
– Filter/non-return valve in dirty or
defective
➯Clean and replace
if necessary
– Hot water supply pressure too low ➯Check it
– Hot water temperature too low ➯Increase it
– Thermal element faulty ➯Replace it
Water volume too
low
– Water volume regulator not fully
open
➯Open it
– Shower head blocked with scale ➯Clean it
– Filter/non-return valve in dirty or
defective
➯Clean and replace
if necessary
– Supply pressure too low ➯Check it
Thermostat controls
unevenly
– Flow rate regulator in shower head
blocked with scale
➯Clean and replace
if necessary
– Thermal element dirty ➯Clean it

17
ZMI_001_2030019735-AT3O0044_#SEN_#AQU_#V1.fm
28. Spare parts
Accessories Order No.
Connecting pipe
Hot/cold . . . . . . . . . . . . . . . . . .2000105647
Mixed water . . . . . . . . . . . . . . .2000105648
Temperature sensor red. . . . . . . . .2000100972
Temperature sensor blue . . . . . . . .2000100976
Function controller with
Ethernet and CAN Bus connector (60 W)
ECC2 . . . . . . . . . . . . . . . . . . . .2000108123
Power pack (12 W) . . . . . . . . . . . .2000100375
Power pack (60 W) . . . . . . . . . . . .2000101174
System cable for long-term use in water,
halogen-free
100 m . . . . . . . . . . . . . . . . . . . .2000104272
25 m . . . . . . . . . . . . . . . . . . . . .2000104274
System cable,
not halogen-free
100 m . . . . . . . . . . . . . . . . . . . .2000100801
25 m . . . . . . . . . . . . . . . . . . . . .2000100852
1)
When ordering, please specify the fitting ID!
The fitting ID can be found on the side of the
electronic module.
Description Order No.
1 Temperature selector. . . . . . . . . . . 2030003254
1a Cover platelet . . . . . . . . . . . . . . . . 2030003258
2 Temperature stop. . . . . . . . . . . . . . 2030003296
3 Thermal element . . . . . . . . . . . . . . 2030003300
4 Push-on rosette . . . . . . . . . . . . . . . 2030022722
5 Piezo button. . . . . . . . . . . . . . . . . . 2000104441
6 Electronic module M1
1)
. . . . . . . . 84-100-17.108
7 Solenoid valve cartridge . . . . . . . . 2000100431
8 Shower head spares kit. . . . . . . . . 2000104849
9 Flow rate regulator
0.15 l/s . . . . . . . . . . . . . . . . . . . 2000104782
0.20 l/s (12 l/min) . . . . . . . . . . . 2000104783
10 Lockable
water volume regulator. . . . . . . 2000104885
11 Mounting kit consisting of:
Non-return valve
O-rings
Filters
Seals . . . . . . . . . . . . . . . . . . . . 2000104777

18
ZMI_001_2030019735-AT3O0044_#SFR_#AQU_#V1.fm
0Français
Panneau de douche AQUATIMER A3000 open en fonte minérale avec thermostat,
24 V DC
AT3O0044
AT3O0046.................. avec support pour gel de douche intégré
Les graphiques figurent dans la notice de montage et de mise en service allemande.
0Table des matières
1. Abréviations et unités . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2. Pictogrammes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4. Remarques importantes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Description du produit
5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6. Caractéristiques techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7. Propriétés du MIRANIT-S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8. Contenu de la livraison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10. Exemple d'installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11. Schéma du jet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Montage, fonctionnement et mise en service
12. Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
13. Fonctionnement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
14. Désinfection thermique -manuelle-. . . . . . . . . . . . . . . . . . . . . . . . 24
15. Désinfection thermique -automatique- . . . . . . . . . . . . . . . . . . . . . 26
16. Régler la protection contre les brûlures . . . . . . . . . . . . . . . . . . . . 26
17. Réglage de la durée d'écoulement. . . . . . . . . . . . . . . . . . . . . . . . 27
18. Réglage du rinçage hygiénique . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Entretien
19. Maintenance et entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
20. Conseils d'entretien du MIRANIT-S . . . . . . . . . . . . . . . . . . . . . . . 28
21. Nettoyage de la base de la pomme de douche . . . . . . . . . . . . . . 28
22. Remplacement des filtres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
23. Remplacement de la cartouche d'électrovanne . . . . . . . . . . . . . . 29
24. Remplacer le thermocouple . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
25. Remplacement du régulateur de débit d'eau . . . . . . . . . . . . . . . . 30
26. Remplacement des clapets de non-retour . . . . . . . . . . . . . . . . . . 30
27. Dépannage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
28. Pièces de rechange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
FR

19
ZMI_001_2030019735-AT3O0044_#SFR_#AQU_#V1.fm
1. Abréviations et unités
2. Pictogrammes
Avertissement !
Le non-respect des consignes est susceptible de présenter un danger de mort ou de
provoquer des blessures.
Attention !
Le non-respect des consignes est susceptible de provoquer des dommages
matériels.
☞Important !
Le non-respect des consignes est susceptible de provoquer des dysfonctionne-
ments sur le produit.
☞Informations utiles pour une utilisation optimale du produit.
3. Garantie
La responsabilité est conforme à celle décrite dans les conditions générales de
vente et de livraison.
Utiliser exclusivement des pièces de rechange d'origine !
4. Remarques importantes
• Seul un spécialiste est habilité à effectuer le montage, la mise en service et
l'entretien de l'installation, et ceci tout en veillant à ce que ces opérations soient
réalisées conformément aux instructions fournies, aux prescriptions légales et
aux règles techniques en usage.
• Les prescriptions techniques des sociétés de distribution d'eau et d'électricité
doivent également être respectées.
• En cas de distribution d'eau payante avec les monnayeurs AQUAPAY, suivre les
consignes de raccordement de la notice d'utilisation du monnayeur AQUAPAY.
• Sous réserve de modifications.
DN Diamètre nominal en mm
RCD Residual Current Protective Device, interrupteur
de protection contre les courants de court-circuit
SELV Safety Extra Low Voltage, très basse tension de
sécurité
EA-Nr. Numéro d'article européen
FAR-Best.-Nr. Référence de commande Franke Aquarotter
Conversion 1 mm = 0,03937 pouce
1 pouce = 25,4 mm
Sur les graphiques, toutes les longueurs sont exprimées en mm.

20
ZMI_001_2030019735-AT3O0044_#SFR_#AQU_#V1.fm
5. Application
Panneau de douche AQUATIMER - A3000 open en matière minérale pour un
montage en saillie, avec commande électronique temporisée, mitigeur thermosta-
tique DN15, distribution payante en option avec les monnayeurs AQUAPAY et possi-
bilité de commande externe d'options telles que le réglage de la robinetterie ou la
communication via un contrôleur de fonction ECC. Pour un raccordement à l'eau
chaude et froide. Durée d'écoulement réglable à la seconde près.
Avec dispositif pour cartouche d'électrovanne de dérivation en option, pour la réali-
sation d'une désinfection thermique et la possibilité de réalisation d'une désinfection
thermique manuelle.
Fonctions de commande intégrées :
– durée d'écoulement 30 secondes
– rinçage hygiénique (10 secondes), 24 heures après le dernier actionnement
Fonctions supplémentaires avec le contrôleur de fonction ECC (Ethernet) :
– désinfection thermique automatique conformément à la fiche de travail W 551
de la DVGW et arrêt de sécurité
– arrêt pour nettoyage
6. Caractéristiques techniques
Pression dynamique
minimale : 1,0 bar
Pression dynamique
recommandée : 1–5 bar
Pression de service
maximale : 10 bar
Débit théorique : 0,15 l/s 0,15 l/s
Débit volumétrique :
Robinetterie : 0,20 l/s pour une pression dynamique de 3 bar
Dérivation : 0,06 l/s pour une pression dynamique de 3 bar
Durée d'écoulement : 30 s
Tension de raccordement : 24 VDC
Puissance absorbée : 2,5 W
Communication : Ethernet via un contrôleur de fonction ECC
Degré de protection : IP 68
