Freedom Won RL1 Series User manual

CONTENT
I. Product Introduction
II. Operation Step
III. Working mode
IV. Parameter meaning
V. Notes

1. PRODUCT INTRODUCTION

RL1 Series FWE-8K-1P-LV
01
FWE - Freedom Won Encore
8K - Size
1P - One Phase
LV - Low Voltage
02 03 04
FWE-3K-1P-LV and
FWE-5K-1P-LV
MODEL
FWE-8K-1P-LV and
FWE-10K-1P-LV
FWE-12K-3P-HV and
FWE-15K-3P-HV

CONNECTION PORT
Object Description
A/B Battery +/Battery -
C/D PV1+/PV1-
J/K PV2+/PV2-
E DC switch
F WiFi port for external WiFi
L Reserved port
G DRM/BMS
HCT
M USB port for upgrading
NCAN
I Pressure valve
O EPS output
P Grid output
FWE-3K-1P-LV and FWE-5K-1P-LV

DIAGRAM WIRING
FWE-3K-1P-LV and FWE-5K-1P-LV Hybrid Inverter

CONNECTION PORT
FWE-8K-1P-LV and FWE-10K-1P-LV

DIAGRAM WIRING
FWE-8K-1P-LV and FWE-10K-1P-LV Hybrid Inverter

2. OPERATION STEP

OPERATION STEP
STEP 1: Following the diagram wiring and check the wiring connection is correct or not. Note that the CT crosses the L line, and the Arrow direction must forward to
the grid, the terminal of RJ45 is connected to CT port on the inverter.
STEP 2: After power on the inverter, Select "Language" and set "Date/Time".
STEP 3: Please choose “Grid standards”，“ANTI-REVERSE”.
STEP 4: Please choose the battery type and communication mode. If the battery is lithium battery , it should connect the CAN cable from Battery to Inverter , or the
inverter will occur the BMS communication error.
STEP 5: Please choose the corresponding working mode (self-consume, peak shift, BAT priority).
After setting, the inverter will automatically run.

First, set the corresponding grid standard
LCD interface user
ESC key Input password
restart
Select the
corresponding
grid standard
Select the grid
standards
Press enter Press enter
The default password is 00000.
Press up / down to adjust
Select 1 setting
QUICK SETUP GUIDE

Next, Set battery parameters
Setup Input password
Press enter
2: Battery
parameters
Set corresponding
parameters of
battery
Press enter
QUICK SETUP GUIDE

Finally, set the system operation mode
set up
Input password
Press enter
1: System
settings
1: Working
mode
Peak-shifting;
Self-use;
Battery priority;
Restart
Press enter
Press enter
Press enter
QUICK SETUP GUIDE

3. WORKING MODE

WORKING MODE - SELF-CONSUME
Energy priority: load>battery>grid
*Battery power only from PV Energy
Power flow ：
Priority to load Supply power to
Load and charge
The battery
Enough power to
Feedback to the grid
PV and Battery supply
Power to the load at
the same time
No PV and low capacity of
Battery , the grid will offer the
Power to the load directly；
Grid
Encore Range Inverter
PV panel
Battery Load

WORKING MODE - BATTERY PRIORITY
Energy priority: battery>load>grid
Power flow ：
Priority to battery Supply power to
Load and charge
The battery
Enough power to
Feedback to the grid
When no PV , Grid will
Offer the power to the
load.
When No grid , the battery will
discharge the power to the load.
Grid
Encore Range Inverter
PV panel
Battery Load

E n e r g y p r i o ri ty : b att er y >load> grid (wh i le cha rging)
Load >B at tery> Grid ( w hen d i sc har ging )
* Se t differen t time to c h arg e a nd d i sch arge t he bat te ry.
WORKING MODE - PEAK SHIFTING
Grid
Encore Range inverter
PV panel
Battery Load

4. PARAMETER MEANING

SYSTEM SETTING

BATTERY SETTING
