© Freescale Semiconductor, Inc., 2011. All rights reserved.

Freescale Semiconductor
User’s Guide
Document Number: KT13892UG
Rev. 3.0, 8/2011
Table of Contents
1 Kit Contents / Packing List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Important Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Required Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 Setup Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8 KIT13892VKEVBEJ Board Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9 KIT13892VLEVBEJ Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10 KITUSBCOMDGL Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
11 KIT13892VxEVBEJ Bill of Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
12 KITUSBCOMDGLEVME Bill of Material. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
13 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
MC13892 Evaluation Board
Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ
Figure 1. MC13892 Evaluation Boards

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
2Freescale Semiconductor
Kit Contents / Packing List
1 Kit Contents / Packing List
• CD13892VxEVBEJ
• KIT13892VxEVBEJ
• Kit KITUSBCOMDGLEVME
• Cables (8):
• 7x2 Flat Ribbon Cable (GPIO)
• 8x2 Flat Ribbon Cable (SPI)
• 3x2 Flat Ribbon Cable (I2C)
• 1x12 Flat Ribbon Cable (3 each) (Application Peripherals)
• 1x8 Flat Ribbon Cable (Touch Screen)
• USB extension cable

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 3
Important Notice
2 Important Notice
Freescale provides the enclosed product(s) under the following conditions:
This evaluation kit is intended for use of ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY. It is
provided as a sample IC pre-soldered to a printed circuit board to make it easier to access inputs, outputs, and supply
terminals. This EVB may be used with any development system or other source of I/O signals by simply connecting it
to the host MCU or computer board via off-the-shelf cables. This EVB is not a Reference Design and is not intended to
represent a final design recommendation for any particular application. Final device in an application will be heavily
dependent on proper printed circuit board layout and heat sinking design as well as attention to supply filtering, transient
suppression, and I/O signal quality.
The goods provided may not be complete in terms of required design, marketing, and or manufacturing related
protective considerations, including product safety measures typically found in the end product incorporating the goods.
Due to the open construction of the product, it is the user's responsibility to take any and all appropriate precautions with
regard to electrostatic discharge. In order to minimize risks associated with the customers applications, adequate design
and operating safeguards must be provided by the customer to minimize inherent or procedural hazards. For any safety
concerns, contact Freescale sales and technical support services.
Should this evaluation kit not meet the specifications indicated in the kit, it may be returned within 30 days from the date
of delivery and will be replaced by a new kit.
Freescale reserves the right to make changes without further notice to any products herein. Freescale makes no
warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does
Freescale assume any liability arising out of the application or use of any product or circuit, and specifically disclaims
any and all liability, including without limitation consequential or incidental damages. “Typical” parameters can and do
vary in different applications and actual performance may vary over time. All operating parameters, including “Typical”,
must be validated for each customer application by customer’s technical experts.
Freescale does not convey any license under its patent rights nor the rights of others. Freescale products are not
designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other
applications intended to support or sustain life, or for any other application in which the failure of the Freescale product
could create a situation where personal injury or death may occur. Should the Buyer purchase or use Freescale products
for any such unintended or unauthorized application, the Buyer shall indemnify and hold Freescale and its officers,
employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and
reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such
unintended or unauthorized use, even if such claim alleges that Freescale was negligent regarding the design or
manufacture of the part.Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc. All other
product or service names are the property of their respective owners. © Freescale Semiconductor, Inc., 2011. All rights
reserved.

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
4Freescale Semiconductor
Introduction
3 Introduction
KIT13892VXEVBEJ
This EVB shows the functionality of the MC13892JVxx device set up under specific
operation parameters.
The MC13892 is a Power Management Integrated Circuit (PMIC) component for
Freescale's i.MX51, i.MX37, i.MX35, and i.MX27 application processors, targeting
netbooks, ebooks, mobile internet devices, smart phones, personal media players, and
personal navigation devices. For evaluation purposes this KIT13892KVXXEVBE comes
with the KITUSBCOMDGLEVME board for communication and control purposes.
KITUSBCOMDGLEVME
This KIT is a USB communication dongle that uses the MC9S08JM8CLC MCU to
enable communication between a PC/laptop with a USB port, and the
KIT13892VXEVBEJ, through SPI or I2C terminals.
Beside communication, this board also provides two pins for quick “plug in” identification
as well as three GPIO, four PWM signals, and two ADC. All of these pins can be
configured and used as general purpose I/O pins, getting 11 GPIOs in total, if needed.
These communication signals and GPIOs can be level shifted to 5.0 V, 3.3 V, and 1.8 V,
in order to cover most of the application voltage requirements.
3.1 KIT13892VXEVBEJ Functional Blocks
•Charger: The charge path can be configured for single or serial path using jumpers
J5 and J9 to enable/disable the M3 transistor. CHRGSE1B pin is driven by the USB
dongle MCU through a FET. This saves the need to specify if the charger
connected is a wall or USB charger through hardware.
•LED Backlighting: RGB and backlighting LEDs are provided on the board to test
these features. Jumpers (J4, J7, and J3) have been placed to connect or
disconnect the backlighting LEDs to their respective channel.
•Power: All the regulators and regulators signals have been connected to J17, J18,
and J24 so they can be loaded and tested from there. They also have their
respective test point on the board. Regulators have a 0 resistor that allows the
output to be connected to the feedback signal on the board. The feedback signals
are also available on the load connectors, so the feedback point can be connected
directly to the load by removing these resistors. These resistors are populated by
default. The DVS feature of the regulators can be controlled by means of J31/32
and J35/38 jumpers. LDOs that can be used with either internal or external pass
devices (VCAM and VGEN3) can be set for either one of both configurations by
changing the J27 and J30 jumpers positions.

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 5
Introduction
•Programmability and Control: The MC13892 can be configured to be controlled
by I2C or SPI communication. In I2C mode, J19 ties the CS pin to VCORE, J20 and
J21 connect the pull-up resistors on MISO and CLK respectively, and J22/23 are
intended to set the A0 address at the MOSI pin. The following pins are connected
to the KITUSBCOMDGLEVME, so they can be controlled/monitored through the
GUI: CS, CLK, MISO, MOSI, WDI, INT, RESETB, RESETBMCU, STANDBY,
STANDBYSEC, and PWRON1. The SPIVCC pin can be supplied by SW4 of the
MC13892, by placing the J16 jumper, or by the LDO on the
KITUSBCOMDGLEVME through the SPIVCC signals on the J10, J14, and J15
connectors. PUMS and MODE pins can be configured through the J36/37, J40/41,
and J12/13 jumpers on the board.
•LICELL: The coin cell holder offers the possibility to keep the RTC running and
save the contents of some registers, even if the device is in Off mode.
•USB: The VBUSEN and UID pins can be configured through the J26/28 and J34/39
jumpers. The VBUS of the KITUSBCOMDGLEVME can be connected to the
UVBUS pin of the, by means of the J29 jumper. The UVBUS pin is also available
at J2 for OTG mode.
•ADC: The ADC block can be triggered by hardware by using the SW1 push button.
The J25 connector contains all the necessary signals to connect a touch screen
panel. The R13 potentiometer is provided in order to test the ADIN5 input, as well
as giving the possibility to bias a battery thermistor connected there. ADIN6 and
ADIN7 have their respective test point in order to connect a specific voltage there
and test these inputs.

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
6Freescale Semiconductor
Introduction
3.2 KITUSBCOMDGLEVME Functional Blocks
Table 1. SPI Interface.- Pin Header Configuration for SPI Interface at J9
PIN NUMBER DESCRIPTION PIN NUMBER DESCRIPTION
Table 2. I2C Interface.- Pin Header Configuration for I2C Interface at J7
PIN NUMBER DESCRIPTION PIN NUMBER DESCRIPTION
Table 3. UART Interface.- Pin Header Configuration for UART Interface at J6
PIN NUMBER DESCRIPTION PIN NUMBER DESCRIPTION
Table 4. GPIO Interface.- Pin Header Configuration for GPIOs Interface at J8
PIN NUMBER DESCRIPTION PIN NUMBER DESCRIPTION
Communication voltage selection - This communication board allows the user to
select one of the following three communication voltages through hardware, which are
very common on most of the applications:
1GND - Ground 9SPSCK - SPI Serial Clock
2ADC1 - Analog-to-Digital Regulator 10 PWM3 - Pulse Width Modulation Signal
3COMM_V - Communication Voltage 11 MOSI - SPI Master Output Slave Input
4ADC0 - Analog-to-Digital Regulator 12 PWMSYNC - PWM Synchronization Signal
55.0 V - Voltage from USB Port 13 MISO - SPI MAster Input Slave Output
6PWM0 - Pulse Width Modulation Signal 14 ID1 - Board Identifier 1
7PWM2 - Pulse Width Modulation Signal 15 SS - Slave Select
8PWM1 - Pulse Width Modulation Signal 16 ID0 - Board Identifier 0
1ID0 - Board Identifier 0 4GND - Ground
2ID0 - Board Identifier 1 5SCL - I2C Serial Clock
3SDA - 12C Serial Data 6COMM_V - Communication Voltage
1ID0 - Board Identifier 0 4GND - Ground
2ID0 - Board Identifier 1 5RXD - Receive Data
3TXD - Transmit Data 6GND - Ground
1ID0 - Board Identifier 0 8PWM2 - Pulse Width Modulation Signal
2ID0 - Board Identifier 1 9PWM1 - Pulse Width Modulation Signal
3GPIO2 - General Purpose I/O 10 PWM0 - Pulse Width Modulation Signal
4GPIO1 - General Purpose I/O 11 ADC0 - Analog-to-Digital Regulator
5GPIO0 - General Purpose I/O 12 ADC1 - Analog-to-Digital Regulator
6PWMSYNC - PWM Synchronization Signal 13 GND - Ground
7PWM3 - Pulse Width Modulation Signal 14 COMM_V - Communication Voltage

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 7
Introduction
•5.0V - This voltage comes directly from the USB port and can be selected by
connecting J3(1-2). This selection ignores the voltage coming from the LDO,
and sets the USB voltage as the maximum level for communication.
•3.3V - This voltage can be selected by connecting J5(1-2) and J3(2-3).This
selection configures the LDO to supply 3.3 V, and set the voltage as the
maximum voltage reference of communication.
•1.8V - This communication voltage is selected by connecting J5(2-3) and
J3(2-3). By connecting these two jumpers, the LDO supplies 1.8 V, and set this
voltage level as the maximum voltage reference of communication.
3.3 EVBs Operating Parameters
KIT13892VXEVBEJ Board
• Input voltages:
• Battery: 3.7 V
• USB/Wall charger: 5.0 V
• Power supply for backlighting: 9.0 V
• Default output voltages:
• Regulators: SW1 = 1.05 V; SW2 = 1.22 V; SW3 = 1.2 V; SW4 = 1.8 V; 
SWBST = 5.0 V (when a charger is attached, otherwise 0 V).
• Linear regulators: VUSB = 3.3 V; VUSB2 = 2.6 V; VPLL = 1.8 V; VDIG = 1.25 V;
VIOHI = 2.775 V; VGEN1 = 0 V; VGEN2 = 3.15 V; VGEN3 = 0 V; VSD = 0 V;
VVIDEO = 0 V; VAUDIO = 0 V; VCAM = 0 V.
• Switching frequency in regulators: 3.1457 MHz (SWBST operates at 2.0 MHz).
• Communication interfaces:
• SPI - Frequency up to 26 MHz
•I
2C - Frequency at 400 kHz
• Power control signals - RESETB, RESETBMCU, WDI, INT, STANDBY,
STANDBYSEC, CHRGSE1B, and CS
KITUSBCOMDGLEVME Board
• Power supply = 5.0 V (supplied by computer USB port)
• Communication Interfaces:
•I
2C - Frequency up to 3.5 MHz (100 kHz, 400 kHz or 3.5 MHz); 
Voltage Level = Selectable (5.0 V, 3.3 V, or 1.8 V)
• SPI - Frequency up to 4.0 MHz; Voltage Level = Selectable (5.0 V, 3.3 V, or
1.8 V)
• UART - Frequency from 2400 bps to 115200 bps; Voltage Level = 12 V (Typ.)
• USB - Frequency fixed at 12 Mbps; Voltage Level = 5.0 V (Typ.)

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
8Freescale Semiconductor
Introduction
• Other Signals:
• Four PWM signals (Adjustable frequency up to 4.0 MHz)
• Open Drain signals with selectable voltage Level (5.0 V, 3.3 V or 1.8 V)
• Three GPIOs (General Purpose I/O pins) Open Drain signals with selectable
voltage Level (5.0 V, 3.3 V, or 1.8 V)
• Two ADCs (10 bits)
• Identifiers - Two ADC signals pulled up to 5.0 V thru 10 kohm resistors. These
inputs are designated to identify the Slave device and automatically OPEN its
corresponding Graphical User Interface (GUI). This feature only applies if a
slave board was designed for it.
3.4 EVBs Features
KIT13892KVxEVBEJ Board
• Four Layer Board
• Low Noise Design
• Top and bottom Layer component placement
• Three 12 pin connectors (J17, J18, and J24) for regulators, linear regulators, and
NMOS power gate switches accessibility. Review Figures 10 and 11 schematics
for connections
• Banana jack connectors (J6-J8 and J1-J2) for battery and charger attachments
• Battery holder for a CR2477 Li-Ion/Li-Pol coin cell
• Several jumper configurations for PMIC mode of operation
• Scattered test points for different measurements
•I
2C and SPI communication interface connectors (J10 and J14)
• Power control interface connector (J15)
• Three RGB LEDs for color mixing or general purpose signaling
• 17 white LEDs for backlighting applications. Note that an external Boost regulator
voltage needs to be attached at TP SWLED
• Two green LEDs for RESETB and RESETBMCU signaling
• One red LED for charger attachment signaling
• Four-wire resistive touch screen interface connector (J25)
KITUSBCOMDGLEVME Board
• Four Layer Board
• Low Noise Design
• Top Layer Placement
•UART,I
2C, and SPI communication interface connectors (J6, J7, and J9)
• USB type A connector

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 9
Introduction
• Communication Voltage Level Shifting configuration (J3 and J5)
• BDM connector for MCU programming (J2)
• Pull-up resistors for I2C and SPI line communication voltage jumper configurations
(J4)
3.5 MC13892 Device Description/Features
• Battery charger system for wall charging and USB charging
• 10 bit ADC for monitoring battery and other inputs, plus a coulomb counter support
module
• Four adjustable output buck regulators for direct supply of the processor core and
memory
• 12 adjustable output LDOs with internal and external pass devices
• Boost regulator for supplying RGB LEDs
• Serial backlight drivers for displays and keypad, plus RGB LED drivers
• Power control logic with processor interface and event detection
• Real time clock and crystal oscillator circuitry, with coin cell backup and support for
external secure real time clock, on a companion system processor IC
• Touch screen interface
•SPI/I
2C bus interface for control and register access

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
10 Freescale Semiconductor
Required Equipment
4 Required Equipment
•3.7V Li-Ion battery to be connected at J6-J8
•9.0V, 500 mA power supply to be connected at test point SWLED.
•5.0V, 5.0 A, Adjustable Power Source to be connected at J1-J2
• Computer Central Processing Unit (CPU) System Requirements:
• Windows eXPerience (XP)
(Note: The USB drivers for the KITUSBCOMDGLEVME MCU were developed under Windows XP
operating system)
•1.0Gigabyte Random Access Memory
• 100 Megabyte Hard Disc Drive Available Memory

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 11
Setup Configuration
5 Setup Configuration
Please refer to the following figures for setting up the connections between the
USBCOMDGL, and either the KIT13892VKEVBEJ or the KIT13892VLEVBEJ, by I2C or
SPI communication.
(+) (+)(‐)(‐)
Wall/USBcharger
Voltagesandcurrentsfori.MX
processorandapplicationperipherals
USB Cable
KITUSBCOMDGLEVME
3.7 V 5.0 V
Touc h
Screen
LiCell
(Coin Cell)
Battery
(J18, J24, J17)
Cables (Fig. 3, 4, 5, and 6)
9.0 V
Figure 2. MC13892 Basic Hardware Setup

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
12 Freescale Semiconductor
Setup Configuration
Figure 3. SPI Configuration for the MC13892JVL Board alongside the USB Dongle
Figure 4. I2C Configuration for the MC13892JVL Board alongside the USB Dongle

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 13
Setup Configuration
Figure 5. SPI Configuration for the MC13892JVK Board alongside the USB Dongle
Figure 6. I2C Configuration for the MC13892JVK Board alongside the USB Dongle

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
14 Freescale Semiconductor
Setup Configuration
5.1 KIT13892VxEVBEJ Jumper Location and Configuration
2
3
45
6
7
8
9
1
Figure 7. KIT13892VLEVBEJ Default Jumper Location and Configuration
Location Jumper Reference Position
1 J40-41 2
2 J7 Shorted
3 J9 Shorted
4 J27 2-3
5 J30 2-3
6 J16 Shorted
7 J22-23 3
8 J33 Shorted
9 J36-37 3

1
2
3
4
5
6
7
8
9
MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 15
Setup Configuration
Figure 8. KIT13892VKEVBEJ Default Jumper Location and Configuration
Location Jumper Reference Position
1 J40-41 2
2 J36-37 3
3 J33 Shorted
4 J9 Shorted
5 J30 2-3
6 J22-23 3
7 J27 2-3
8 J16 Shorted
9 J7 Shorted

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
16 Freescale Semiconductor
Setup Configuration
Jumper
Reference
General
Description Position Function
J34-J39 USB ID Connection Open (default) B type plug (USB Host, OTG default master or no device) is attached
1Grounded: A type plug (USB default slave) is attached
2Resistor to ground: Non-USB accessory is attached
3Tied to SWBST: Factory mode
J26-J28 Control VBUSEN pin Open (default) VBUSEN feature not used
1Grounded: VBUS supplied from USB cable
2For future usage
3Tied to SW4: VBUS supplied from SWBST if VUSBIN and OTGSWBSTEN bits = 1 (OTG
mode), or VUSB supplied from VBUS if VUSBIN = 0 and a valid VBUS is present
J31-J32 DVS1 Control Open (default) Dynamic Voltage Scaling feature disabled for SW1
1Tied to SW4: DVS feature activated. The regulator output voltage will transition to the set
point indicated in the SW1DVS bits on programmed steps
2For future usage
3Grounded: DVS feature deactivated and the regulator will be working on the set point
indicated by the SW1 bits
J35-J38 DVS2 Control Open (default) Dynamic Voltage Scaling feature disabled for SW2
1Tied to SW4: DVS feature activated. The regulator output voltage will transition to the set
point indicated in the SW2DVS bits on programmed steps
2For future usage
3Grounded: DVS feature deactivated and the regulator will be working on the set point
indicated by the SW2 bits
J40-J41 PUMS1 Control
(Controls the power up
default values of the
regulators)
Open Open (Check MC13892 Data Sheet for further reference on the default values)
1Tied to VCORE (Check MC13892 Data Sheet for further reference on the default values)
2 (default) Tied to VCOREDIG (Check MC13892 Data Sheet for further reference on the default
values)
3Grounded (Check MC13892 Data Sheet for further reference on the default values)
J13-J12 PUMS2 Control
(Controls the power up
default values and
sequence of the
regulators)
Open (default) Open (Check MC13892 Data Sheet for further reference on the default values)
1Tied to VCORE: No usage on version 2.0 A of the device. For future usage
2Tied to VCOREDIG: No usage on version 2.0 A of the device. For future usage
3Grounded (Check MC13892 Data Sheet for further reference on the default values)
J36-J37 Control MODE pin Open No mode selected, the device will not work
1Tied to VCORE: Test mode
2Tied to VCOREDIG: Low Power Boot allowed
3 (default) Grounded: Normal operation
J3 LEDMD String Control Open
(default) LEDMD string open. LEDMD pin unconnected
Shorted LEDMD string enabled and connected to LEDMD pin
J4 LEDAD String Control Open
(default) LEDAD string open. LEDAD pin unconnected
Shorted LEDAD string enabled and connected to LEDAD pin

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 17
Setup Configuration
J7 LEDKP String Control Open LEDKP string open. LEDKP pin unconnected
Shorted
(default) LEDKP string enabled and connected to LEDKP pin
J16 SPIVCC Supply Open SPIVCC pin allowed to be supplied through connectors J10, J15, or J14
Shorted
(default) SPIVCC supplied by SW4 (1)
J19 CS pin Control Open (default) CS pin allowed to be controlled by connector J15. If it is grounded or left open at startup, the
device will be configured on SPI mode.
Shorted Tied to VCORE: If this pin is tied to VCORE at startup, the device will be configured for I2C
mode.
J20 MISO Pull-up Open (default) Pull-up resistor on MISO pin disabled for SPI communication
Shorted Pull-up resistor on MISO pin enabled for I2C communication
J21 CLK Pull-up Open (default) Pull-up resistor on CLK pin disabled for SPI communication
Shorted Pull-up resistor on CLK pin enabled for I2C communication
J29 UVBUS Supply Open (default) UVBUS pin disconnected from J14
Shorted UVBUS pin connected to J14 connector for it to be supplied from the USB cable connected
to the MCU board, or to supply a USB cable in OTG mode
J27 VCAMDRV Open VCAM regulator not used
1-2 VCAM regulator configured with external pass device 
(VCAMCONFIG bit needs to be set to 1)
2-3 (default) VCAM regulator configured with internal pass device (VCAMCONFIG bit needs to be
cleared
J30 VGEN3DRV Open VGEN3 regulator not used
1-2 VGEN3 regulator configured with external pass device 
(VGEN3CONFIG bit needs to be set to 1)
2-3 (default) VGEN3 regulator configured with internal pass device 
(VGEN3CONFIG bit needs to be cleared
J5 M3 FET Control 1 Open (default) Charge path configured as Serial Path (J9 needs to be shorted)
Shorted Charge path configured as Single Path (J9 needs to be open)
J9 M3 FET Control 2 Open M3 FET not controlled. Charge path configured as Single Path
Shorted
(default) M3 FET controlled by BATTFET pin. Charge path configured as Serial Path
J33 PWRON1 pin Control Open PWRON1 pin can only be controlled through Switch 2
Shorted
(default)
PWRON1 pin can be controlled by either Switch 2 or an MCU board connected to J15
connector
J22-J23 MOSI Control Open MOSI pin not connected. Not recommended
1Grounded: A0 address = 0 on I2C communication
2Tied to VCORE: A0 address = 1 on I2C communication
3 (default) MOSI pin tied to J14 connector for SPI communication
Notes:
1. Due to the effect the level shifter of the KITUSBCOMDGLEVME produces on SW4, the latter will need a minimum extra load of 10 kOhm
to work properly when it is supplying SPIVCC.
Jumper
Reference
General
Description Position Function

MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
18 Freescale Semiconductor
Setup Configuration
5.2 KITUSBCOMDGLEVME Jumper Location and Configuration
12
Figure 9. KITUSBCOMDGLEVME Default Jumper Location and Configuration
Location Jumper Reference Position
Jumper
Reference General description Position Function
1J5 2-3
2J3 2-3
J5 Level shifted
Communication voltage
1 - 2 Adjust LDO voltage to 3.3 V
2 – 3 (Default) Adjust LDO voltage to 1.8 V
J3
Level shifting
Communication voltage
enablement
1 - 2 Set communication voltage to 5.0 V
2 – 3 (Default) Set communication voltage to LDO voltage
J4 Pull up resistor enablement
for low voltage side
1 - 2 SDA pull-up resistor enable
3 - 4 SCL pull-up resistor enable
5 - 6 MISO pull-up resistor enable
7 - 8 SS pull-up resistor enable
9 - 10 SPSCK pull-up resistor enable
11 - 12 MOSI pull-up resistor enable

5
5
4
4
3
3
2
2
1
1
DD
CC
BB
A A
Battery
Licell base must be populated
but battery must not be placed
1.2/1.25/1.65/1.8V 50mA
1.05/1.25/1.65/1.8V 50mA
DNP
DNP
2.40/2.60/2.70/2.775V 50mA
DNP
2.3/2.5/2.775/3.0V 150mA
1.8/2.0/2.6/2.7/2.8/2.9/3.0/3.15 250mA
2.5/2.6/2.75/3.0V 65/250mA
1.8/2.9 250mA
3.3V 100mA
VCC_BP =3.6V
ChargerGND
2.775V 100mA
1.2/1.5/2.775/3.15V 200mA
1.2/1.5/1.6/1.8/2.7/2.8/3.0/3.15V 350mA
2.7/2.775/2.5/2.6V 250/350mA
GND
DNP Because of an order from the United States Internat ional Trade Commission,
BGA-packaged product lines and part numbers indicat ed here currently are not
available from Freescale for import or sale in the United States prior to September
2010: MC13892VK and MC13892VL in 139, 186 MAPBGA pa ckages.
DNP
DNP
DNP
RESETBMCU
RESETB
VCOREDIG
ID0
VCORE
VCOREDIG
VCORE
ADIN5
INT
GPO1
TSY2
TSREF
TSX1
TSX2
TSY1
GPO2
VCOREDIG
VCORE
WDI
GPO3
ADIN6
ADIN7
BATTISNS
CHRGISNS
TSX2
TSY1
TSY2
TSX1
UID
STANDBY
Licell
PWRON3
ID1
UVBUS
BATTISNS
WDI
TSREF
STANDBYSEC
CLK32K
UVBUS
ID0
GPO4
BATT
VCORE
VCOREDIG
REFCORE
ID0
CLK32KMCU
INT
RESETBMCU
STANDBY
RESETB
STANDBYSEC
UVBUS
PWRON2
ID1
BATT
PWRON1
RESETB
RESETBMCU
VCORE
BATT
ID0 ID1
GPO1
PWRON1
ID1
ACIC_SW1FB
ACIC_SW1
ACIC_SW4 PWR_GT2_SW4
ACIC_ VIOH I
ACIC_SW4
VBUSEN
ACIC_VGEN3
ACIC_SWBSTFB
DVS1
CLK
SPIVCC
DVS2
ACIC_SW1FB
ACIC_SWBST
ACIC_SWBSTFB
ACIC_SW4
ACIC_VAUDIO
MISO/SDA
PWR_GT1_SW1
VCC_BP
VCC_BP
ACIC_SW4
VCC_BP
SPIVCC
VCC_BP
VCC_BP
VCC_BP
ACIC_VPLL
ACIC_VIOHI
ACIC_VGEN1
ACIC_VGEN2
ACIC_SW4FB
VCC_BP
VCC_BP
VCC_BP
ACIC_VVIDEO
VCC_BP
ACIC_VUSB2
ACIC_SWBST
VCC_BP
VCC_BP
VCC_BP
VCC_BP
ACIC_SWBST
ACIC_SWLED
VCC_BP
ACIC_VPLL
CS
ACIC_SWBST
SPIVCC
ACIC_VUSB
ACIC_SW2FB
ACIC_ VIOH I
ACIC_VDIG
ACIC_SW4
ACIC_SWBSTFB
VCC_BP
ACIC_SW1
VCC_BP
VCC_BP
VCC_BP ADTRIG
ACIC_SW2
ACIC_SW3
ACIC_SW4
VCC_BP
SPIVCC
ACIC_SW4
ACIC_VSRTC
ACIC_VGEN1
ACIC_VGEN2
ACIC_VSRTC
ACIC_VUSB
ACIC_VGEN3
ACIC_VCAM
ACIC_VSD
ACIC_SW4
ACIC_VCAM
ACIC_SWLED
ACIC_ VIOH I
CLK
SPIVCC
ACIC_SW4
CHRGSE1B_CTRL
ACIC_SW2FB
VCORE
ACIC_VDIG
ACIC_VSD
ACIC_SW3FB
ACIC_SW4
ACIC_SW2
CLK
MOSI/ A0
MISO/SDA
CS
MOSI/ A0
ACIC_SW4FB
CHRGSE1B_CTRL
VCC_BP
PWR_GT1_SW2
MISO/SDA
ACIC_SW3FB
CS
ACIC_VVIDEO
ACIC_VUSB2
ACIC_VAUDIO
ACIC_SW1
ACIC_SW2
ACIC_SW2FB
ACIC_SW1FB
ACIC_SW3
ACIC_SW3FB
ACIC_SW4
PWR_GT1_SW1
PWR_GT2_SW4
PWR_GT1_SW2
PWR_GT1_SW3
ACIC_SW4FB
ACIC_SW3 PWR_GT1_SW3
ACIC_ VIOH I
ACIC_SWBST
SPIVCC
Drawing Title:
Size Document Number Rev
Date: Sheet of
Page Title:
ICAP Classification: FCP: FIUO: PUBI:
SCH-XXXXX PDF: SPF-XXXXX X
<Title>
C
Monday, February 22, 2010
<PageTitle>
11
______ X
Drawing Title:
Size Document Number Rev
Date: Sheet of
Page Title:
ICAP Classification: FCP: FIUO: PUBI:
SCH-XXXXX PDF: SPF-XXXXX X
<Title>
C
Monday, February 22, 2010
<PageTitle>
11
______ X
Drawing Title:
Size Document Number Rev
Date: Sheet of
Page Title:
ICAP Classification: FCP: FIUO: PUBI:
SCH-XXXXX PDF: SPF-XXXXX X
<Title>
C
Monday, February 22, 2010
<PageTitle>
11
______ X
VSW3VSW3
SW4
FSMSM
SW4
FSMSM
1 2
RSTBRSTB
C51
0.1UF
C51
0.1UF
M2
FDZ193P
M2
FDZ193P
B2 C2
A1 C1
A2 B1
C45
0.1UF
C45
0.1UF
TPGND7TPGND7
D9
LED WHITE
D9
LED WHITE
21
D16
LED WHITE
D16
LED WHITE
2
1
SW3
FSMSM
SW3
FSMSM
1 2
Q10
NSS12100UW3
Q10
NSS12100UW3
1
23
R20
560
R20
560
C19
0.1UF
C19
0.1UF
SW2
FSMSM
SW2
FSMSM
1 2
D24
LED_GREEN
D24
LED_GREEN
1 2
C48 2.2UFC48 2.2UF
TSREFTSREF
VCOREVCORE
C8
10.0uF
C8
10.0uF
Q7
NSS12100UW3
Q7
NSS12100UW3
1
23
VUSBVUSB
Q11
NSS12100UW3
Q11
NSS12100UW3
1
23
J35
HDR_1X3
J35
HDR_1X3
1 2 3
J24
CON PLUG 12
J24
CON PLUG 12
1
2
3
4
5
6
7
8
9
10
12
11
STBYSECSTBYSEC
C13
10UF
C13
10UF
MISO/SDAMISO/SDA
DVS1DVS1
R9 51R9 51
VSW1VSW1
STBYSTBY
Q2 MGSF1N02LT1GQ2 MGSF1N02LT1G
1
23
VSDVSD
J41
HDR_1X3
J41
HDR_1X3
1
2
3
TPGND13TPGND13
TSX2TSX2
D17
LED WHITE
D17
LED WHITE
2
1
D8
LED WHITE
D8
LED WHITE
2
1
Q5 MGSF1N02LT1GQ5 MGSF1N02LT1G
1
23
D13 LED_ORANGE D13 LED_ORANGE
12
C34
2.2UF
C34
2.2UF
D21
LED WHITE
D21
LED WHITE
21
TPGND10TPGND10
J39
HDR_1X3
J39
HDR_1X3
1
2
3
C50 2.2UFC50 2.2UF
J32
HDR_1X3
J32
HDR_1X3
1 2 3
R30 200KR30 200K
INTINT
J19
HDR 1X2 TH
J19
HDR 1X2 TH
1
2
D2
LED WHITE
D2
LED WHITE
21
J29
HDR 1X2 TH
J29
HDR 1X2 TH
1 2
R32
200
R32
200
J30
HDR_1X3
J30
HDR_1X3
1 2 3
TPGND3TPGND3
SWLEDSWLED
TP1TP1
ADIN7ADIN7
L2 1.5UHL2 1.5UH
1 2
WDIWDI
R26 200KR26 200K
D19
LED WHITE
D19
LED WHITE
21
Q1
2N7002
Q1
2N7002
3
1
2
C1
4.7uF
C1
4.7uF
BATTBATT
R34 10MR34 10M
C3
2.2uF
C3
2.2uF
ADIN5ADIN5
C65 2.2UFC65 2.2UF
C20 4.7uFC20 4.7uF
C18
22UF
C18
22UF
C30 2.2UFC30 2.2UF
J12
HDR_1X3
J12
HDR_1X3
1
2
3
J15
HDR 2X7
J15
HDR 2X7
1 2
3 4
5 6
78
910
11 12
13 14
R29 200KR29 200K
GPO1GPO1
VGEN3VGEN3
C26
0.1UF
C26
0.1UF
GPO4GPO4
R22 0R22 0
C61
18PF
C61
18PF
TPGND6TPGND6
Q4 MGSF1N02LT1GQ4 MGSF1N02LT1G
1
23
R5
1.0M
R5
1.0M
J2
BANANA
J2
BANANA
IN
1
PWRGT_SW3PWRGT_SW3
MOSI/A0MOSI/A0
TP2TP2
VGEN1VGEN1
C58
2.2UF
C58
2.2UF
TPGND9TPGND9
R10
0
R10
0
D23
MBR120LSFT1G
D23
MBR120LSFT1G
2 1
C41
0.1UF
C41
0.1UF
R1
0.02
R1
0.02
C22
0.1UF
C22
0.1UF
R12 0R12 0
R14 0R14 0
L5 2.2uHL5 2.2uH
1 2
R13 20KR13 20K
1 3
2
D5
LED WHITE
D5
LED WHITE
2
1
VCOREDIGVCOREDIG
R27 200KR27 200K
C10
22UF
C10
22UF
C36 2.2UFC36 2.2UF
R35 200KR35 200K
C56 2.2UFC56 2.2UF
C62
18PF
C62
18PF
C31
0.1UF
C31
0.1UF
VSW4VSW4
VDIGVDIG
J22
HDR_1X3
J22
HDR_1X3
1
2
3
J36
HDR_1X3
J36
HDR_1X3
1
2
3
R6 51R6 51
CLK32KCLK32K
Q8
NSS12100UW3
Q8
NSS12100UW3
1
23
C16
10UF
C16
10UF
R4 0R4 0
VVIDEOVVIDEO
CHRGRAWCHRGRAW
C64 2.2UFC64 2.2UF
D6
LED WHITE
D6
LED WHITE
21
J21
HDR 1X2 TH
J21
HDR 1X2 TH
1
2
TPGND11TPGND11
VBUSENVBUSEN
C47
2.2UF
C47
2.2UF
R31
200
R31
200
J31
HDR_1X3
J31
HDR_1X3
1 2 3
J1
BANANA
J1
BANANA
IN
1
VIOHIVIOHI
C28 2.2UFC28 2.2UF
LICELLLICELL
TSX1TSX1
C44 2.2UFC44 2.2UF
TPGND2TPGND2
D22
LED WHITE
D22
LED WHITE
21
J6
BANANA
J6
BANANA
IN 1
BPBP
C43 2.2UFC43 2.2UF
C60
2.2UF
C60
2.2UF
J26
HDR_1X3
J26
HDR_1X3
1
2
3
CSCS
C59
0.1UF
C59
0.1UF
C6
10.0uF
C6
10.0uF
C32
2.2UF
C32
2.2UF
C11
0.1UF
C11
0.1UF
R19 0R19 0
J40
HDR_1X3
J40
HDR_1X3
1
2
3
TPGND4TPGND4
R8
1.0M
R8
1.0M
R28 200KR28 200K
VSW2VSW2
C5
10.0uF
C5
10.0uF
VCAMVCAM
GPO2GPO2
J8
BANANA
J8
BANANA
IN 1
ADIN6ADIN6
R17 0R17 0
TPGND8TPGND8
GPO3GPO3
C40 2.2UFC40 2.2UF
J25
CON_1X8
J25
CON_1X8
1
2
3
4
5
6
7
8
PWRGT_SW1PWRGT_SW1
D10
LED WHITE
D10
LED WHITE
21
R33 200KR33 200K
SWBSTSWBST
R2
0.1
R2
0.1
D14 LED_GREEN D14 LED_GREEN
12
L4 2.2uHL4 2.2uH
1 2
TSY1TSY1
D3
LED WHITE
D3
LED WHITE
21
D18
LED WHITE
D18
LED WHITE
21
J7
HDR 1X2 TH
J7
HDR 1X2 TH
1 2
J5
HDR 1X2 TH
J5
HDR 1X2 TH
1 2
TPGND12TPGND12
SW1
FSMSM
SW1
FSMSM
1 2
J10
HDR_2X3
J10
HDR_2X3
1 2
3 4
65
J4
HDR 1X2 TH
J4
HDR 1X2 TH
1 2
J23
HDR_1X3
J23
HDR_1X3
1
2
3
J20
HDR 1X2 TH
J20
HDR 1X2 TH
1
2
J14
HDR_2X8
J14
HDR_2X8
12
3 4
65
7 8
910
11 12
13 14
15 16
D25
LED_GREEN
D25
LED_GREEN
12
R7 51R7 51
VGEN2VGEN2
TPGND5TPGND5
SW1
1050mA
Buck
SW2
800mA
Buck
SW3
800mA
Buck
SW4
800mA
Buck
SWBST
350mA
Boost
VVIDEO
350mA
VUSB2
50mA
VAUDIO
150mA
VVIOHI
100mA
VPLL
50mA
VDIG
50mA
VCAM
250mA
VSD
250mA
VGEN1
200mA
VGEN2
350mA
VGEN3
50mA
SPI/I2C
interface
Touch
Screen
interface
Battery
Interface &
Protection Charger
Interface
and Control
Backlight
LED Drive Tri-Color
LED Drive
Reference
Generation
VUSB
100mA
U1
MC13892
SW1
1050mA
Buck
SW2
800mA
Buck
SW3
800mA
Buck
SW4
800mA
Buck
SWBST
350mA
Boost
VVIDEO
350mA
VUSB2
50mA
VAUDIO
150mA
VVIOHI
100mA
VPLL
50mA
VDIG
50mA
VCAM
250mA
VSD
250mA
VGEN1
200mA
VGEN2
350mA
VGEN3
50mA
SPI/I2C
interface
Touch
Screen
interface
Battery
Interface &
Protection Charger
Interface
and Control
Backlight
LED Drive Tri-Color
LED Drive
Reference
Generation
VUSB
100mA
U1
MC13892
PWG TDRV1 K4
PWG TDRV2 M7
SW1IN G13
SW1OUT F13
GNDSW1 E13
SW1FB H10
SW2IN H13
SW2OUT J13
GNDSW2 K13
SW2FB J10
SW3IN H1
SW3OUT G1
GNDSW3 F1
SW3FB F4
SW4IN J1
SW4OUT K1
GNDSW4 L1
SW4FB G4
DVS1
D6 DVS2
B3
SWBST IN A4
SWBST OUT B4
SWBST FB D4
GNDSW BST A5
VVIDEODRV K12
VVIDEO L13
VINUSB2 A3
VUSB2_1 A1
VAUDIO N8
VINIOHI N10
VIOHI N9
VPLL E2
VINDIG M9
VDIG M8
VCAMDRV M6
VCAM K6
VSDDRV C2
VSD D2
VGEN1DRV M10
VGEN1 N11
VGEN2DRV N4
VGEN2 M3
VINGEN3DRV N3
VGEN3_1 M1
GNDREG1
J7 GNDREG2
G5
XTAL1
N6
GNDRTC
M5 XTAL2
N5
GNDCTRL
H9
MODE
A8
PUMS1
G9
PWRON1
D13
STANDBY
J5
INT
E12
WDI
G10
RESETBMCU
F11
RESETB
F12
STANDBYSEC
H12
CLK32K
K5
CLK32KMCU
J4
VSRTC
M4
GPO1
B2
GPO2
F10
GPO3
F9
GPO4
G12
GNDSUB1
F6
GNDSUB2
F7
GNDSUB3
F8
GNDSUB4
G6
GNDSUB5
G7
GNDSUB6
G8
GNDSUB7
H6
GNDSUB8
H7
GNDSUB9
H8
GNDADC
J6
ADIN5
K9
ADIN6
K10
ADIN7
M11
TSX1
J9
TSX2
J12
TSY1
M12
TSY2
L12
TSREF_1
M13
ADTRIG
E11
CFP
K7
CFM
K8
SPIVCC
K2
CS
L2
CLK
M2
MOSI
J2
MISO
H2
GNDSPI
H4
VCORE
A9
VCOREDIG
B9
REFCORE
D7
GNDCORE
B8
UID
E6
UVBUS
E1
VBUSEN
F2
VINUSB
G2
VUSB
D1
LICELL
D9
BATT A10
BATTISNS C13
BATTFET D10
BP B10
BPSNS D12
CHRGISNS C12
CHRGCTRL2_1 A12
CHRGCTRL1 B11
CHRGRAW A11
CHRGLED E9
CHRGSE1B D8
GNDCHRG E8
NC A7
LEDMD D5
LEDAD F5
LEDKP B6
GNDSWLED A6
LEDR B7
LEDG E4
LEDB B5
GNDLED E5
VUSB2_2 A2
VUSB2_3 B1
CHRGCTRL2_2 A13 CHRGCTRL2_3 B13
VINPLL C1
PWRON2
E10
PWRON3
J8
PUMS2 E7
GNDREG3
H5
VGEN3_2 N1
VGEN3_3 N2
TSREF_2
N12
TSREF_3
N13
BATTISNSCC
B12
VINAUDIO N7
VPLLVPLL
J38
HDR_1X3
J38
HDR_1X3
1 2 3
C67 2.2UFC67 2.2UF
J33
HDR 1X2 TH
J33
HDR 1X2 TH
1 2
CLK32KMCUCLK32KMCU
Q12
2N7002
Q12
2N7002
3
1
2
C27 2.2UFC27 2.2UF
C23 4.7uFC23 4.7uF
C24
10.0uF
C24
10.0uF
C52
2.2UF
C52
2.2UF
C37
0.1UF
C37
0.1UF
C38 2.2UFC38 2.2UF
R21
560
R21
560
C53
0.1UF
C53
0.1UF
D7 MBR140SFT D7 MBR140SFT
2 1
Y1
32.768KHZ
Y1
32.768KHZ
2 1
C21
10UF
C21
10UF
C54 2.2UFC54 2.2UF
Q9
NSS12100UW3
Q9
NSS12100UW3
1
23
J27
HDR_1X3
J27
HDR_1X3
1 2 3
C49
0.1UF
C49
0.1UF
R3 0R3 0
Q3 MGSF1N02LT1GQ3 MGSF1N02LT1G
1
23
REFCOREREFCORE
PWRGT_SW4PWRGT_SW4
J13
HDR_1X3
J13
HDR_1X3
1
2
3
C12 4.7uFC12 4.7uF
TPGND1TPGND1
J16
HDR 1X2 TH
J16
HDR 1X2 TH
1
2
C39
0.1UF
C39
0.1UF
C4
10.0uF
C4
10.0uF
D15
BLUE
D15
BLUE
12
C15 4.7uFC15 4.7uF
CLKCLK
M3
NTHS2101P
M3
NTHS2101P
8 2
4 1
5 3 6 7
L3 2.2uHL3 2.2uH
1 2
J37
HDR_1X3
J37
HDR_1X3
1
2
3
PWRGT_SW2PWRGT_SW2
C9 4.7uFC9 4.7uF
RSTBMCURSTBMCU
C29
0.1UF
C29
0.1UF
J17
CON PLUG 12
J17
CON PLUG 12
1
2
3
4
5
6
7
8
9
10
12
11
D4
LED WHITE
D4
LED WHITE
21
C35
0.1UF
C35
0.1UF
C2510.0uF C2510.0uF
DVS2DVS2
J18
CON PLUG 12
J18
CON PLUG 12
1
2
3
4
5
6
7
8
9
10
12
11
TSY2TSY2
R11
0
R11
0
R18 0R18 0
C7
10.0uF
C7
10.0uF
Q6
NSS12100UW3
Q6
NSS12100UW3
1
23
M1
FDZ193P
M1
FDZ193P
B2 C2
A1 C1
A2 B1
VUSB2VUSB2
C63 2.2UFC63 2.2UF
C66 2.2UFC66 2.2UF
UIDUID
L6
2.2uH
L6
2.2uH
1 2
J28
HDR_1X3
J28
HDR_1X3
1
2
3
R15 0R15 0
L1 3.3uHL1 3.3uH
1
2
C42
0.1UF
C42
0.1UF
C2
10.0uF
C2
10.0uF
D11
LED WHITE
D11
LED WHITE
21
D12
LED_ORANGE
D12
LED_ORANGE
12
D20
LED WHITE
D20
LED WHITE
21
C33 2.2UFC33 2.2UF
VAUDIOVAUDIO
D1
LED WHITE
D1
LED WHITE
21
J3
HDR 1X2 TH
J3
HDR 1X2 TH
1 2
C55
0.1UF
C55
0.1UF
J34
HDR_1X3
J34
HDR_1X3
1
2
3
J9
HDR 1X2 TH
J9
HDR 1X2 TH
1
2
C57
0.1UF
C57
0.1UF
C14
0.1UF
C14
0.1UF
Q13
2N7002
Q13
2N7002
3
1
2
C46 2.2UFC46 2.2UF
BT1
HU2477N-LF
BT1
HU2477N-LF
21
C17
2.2UF
C17
2.2UF
MC13892 Evaluation Board Supports KIT13892VKEVBEJ and KIT13892VLEVBEJ, Rev. 3.0
Freescale Semiconductor 19
Schematics
6 Schematics
