1 Overview
The M5211DEMO is a low-cost development system for
the Freescale MCF5211 ColdFire®microcontroller.
Application development is quick and easy with the
included DB9 serial cable and integrated BDM. The
integrated BDM is compatible with popular hosting
software and allows easy application development and
debugging. An optional BDM port compatible with
standard ColdFire BDM / JTAG interface cables and
hosting software is provided but not installed.
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Software Development . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6 Development Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 Low-Power Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10 Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11 Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
12 User Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
13 I/O Port Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Demonstration Board for
Freescale MCF5211

Demonstration Board for Freescale MCF5211, Rev. 1
Overview
Freescale Semiconductor2
Figure 1. M5211DEMO Board
1.1 Features
• MCF5211 CPU, 64 pins
— 128 byte flash
— 16K byte RAM
— 2K byte cache RAM
— DMA controller with timers
— Interrupt controller
— Eight channel 12 bit A/D
— QSPI, IIC, and CAN serial ports
— 1 x UART Serial Ports with DMA capability
— Edge / interrupt port
— Eight PWM timers
— Four GPT timers
— BDM / JTAG port
— 3.3 V operation
— 66 MHz bus
• 40 pin I/O port
• Integrated USB BDM port
• BDM / JTAG port, 26 pins, development port (not installed)

Overview
Demonstration Board for Freescale MCF5211, Rev. 1
Freescale Semiconductor 3
• RS-232 serial port with DB9-S connector
• Timing options
— Internal oscillator, 8 MHz
— External XTAL option (not installed)
— External clock options (not installed)
• RESET switch with indicator
• ON/OFF Power Switch w/ LED indicator
• Power input selection jumper
— Power input from USB BDM
— Power input from on-board, +3.3 V, regulator
— Power input from terminal block
— Power from connector J1
— Optional power output through connector J1
• User features
— Four user LEDs with enable jumper
— Two user push switches
—5kΩPOT with enable jumper
• Option jumpers
— Power input select
— Optional power output Enable
— BDM_EN
— XTAL_EN
— POT_EN
— COM_EN
— LED_EN
• Connectors
— DB9 serial connector
— Type B USB connector
— 2.0 mm barrel power input
— 2 pos, screw type, terminal block
• Supplied with DB9 serial cable, USB cable, utility / support CD
• Manuals and wall adapter power supply.
1.2 Specifications
• Board size: 3.5" x 5.5"
• Power input: +5 to +20 VDC, 9 VDC typical
• Current consumption: 100 mA typical at 9 VDC input

Demonstration Board for Freescale MCF5211, Rev. 1
Overview
Freescale Semiconductor4
1.3 Reference Documents
Table 1 shows a list of reference documents that are provided on the support CD in Adobe Portable
Document Format (PDF).
1.4 Cautionary Notes
Electrostatic discharge (ESD) prevention measures must be used when handling this product. ESD
damage is not a warranty repair item.
The manufacturer of this board, Axiom Manufacturing, does not assume any liability arising out of the
application or use of any product or circuit described herein; neither does it convey any license under
patent rights or the rights of others.
1.4.1 EMC Information on the M5211DEMO board
This product is shipped from the factory with associated power supplies and cables, and has been verified
to meet with requirements FCC as a CLASS A product.
This product is designed and intended for use as a development platform for hardware or software in an
educational or professional laboratory.
In a domestic environment, this product may cause radio interference in which case you may be required
to take adequate prevention measures.
Attaching additional wiring to this product or modifying the product operation from the factory default as
shipped may effect its performance and cause interference with other apparatus in the immediate vicinity.
If such interference is detected, suitable mitigating measures must be taken.
1.5 Terminology
This development board uses option selection jumpers. A jumper is a plastic shunt that connects
two terminals electrically. Terminology for application of the option jumpers is as follows:
• Jumper on, in, or installed—jumper is installed such that two pins are connected.
• Jumper off, out, or idle— jumper is installed on one pin only. It is recommended that jumpers be
idled by installing on 1 pin so they will not be lost.
Table 1. Reference Documents
File name Document Description
M5211DEEMO_UG.pdf M5211DEMO User Guide (this document)
M5211DEMO_SCH_E.pdf M5211DEMO Schematic, Rev E
M5211DEMO_QSG.pdf M5211DEMO Quick Start Guide
M5211DEMO_example1.zip CodeWarrior Demo Application
M5211DEMO_example2.zip CodeWarrior Demo Application
MCF5213RM.pdf MCF5213 Reference Manual
MCF5213DE.pdf MCF5213 Device Errata

Getting Started
Demonstration Board for Freescale MCF5211, Rev. 1
Freescale Semiconductor 5
2 Getting Started
To get started, please refer to the M5211 Quick Start Guide included with this development kit.
The M5211DEMO single board computer is a fully assembled, fully functional development board for the
Freescale MCF5211 microcontroller. An included serial cable, USB cable, and support software allows
you to get started quickly.
The purpose of this development board is to assist you in quickly developing an application in a known
working environment, to provide an evaluation platform, or as a control module for an embedded system.
You should be familiar with memory mapping, memory types, and embedded software design for
successful application development.
You should be familiar with the hardware and software operation of the target MCF5211 device before
beginning. If necessary, refer to the MCF5213 Integrated Microcontroller Reference Manual, included on
the support CD, for details on the operation of the MCF5211.
3 Software Development
Software development requires the use of a ColdFire assembler or compiler and a host PC running a
ColdFire BDM interface. CodeWarrior 6.1 Special Edition, which is supplied with this board, allows you
to develop and debug application code and to program the flash memory.
To ensure successful application development, load and execute the application from RAM. After the
application has been completely debugged fully functional, it can be ported to flash memory. When
programmed into flash memory, the application will execute from power-on or RESET.
4 Operating Modes
TheM5211DEMOboardoperatesintwobasicmodesRUNmode, or DEBUG mode. RUN mode executes
user application code from power-on or reset. DEBUG mode supports the development and debug of
applications via the integrated USB BDM. An optional BDM_PORT is provided but not installed. See
the related sections below for quickly starting the board in the desired mode of operation.
The board has been preloaded with a demonstration program that operates in the RUN mode (see the
M5211DEMO Quick Start Guide for additional information). The VDD LED is lit when power is applied
to the board and the PWR_SEL option header is set correctly. The OFF/ON switch must also be set to the
ON position.
4.1 RUN Mode
RUN mode allows your application to execute out of flash memory when power is applied to the board or
the RESET button is pressed. Use these settings to configure the M5211DEMO board for RUN mode
using the USB bus to power the board. See tSection 7, “Power,” for details on configuring the board for
alternate power input.
1. Connect a serial cable between the board and a host PC if needed.
2. Connect auxiliary equipment to board if needed.
3. Configure the board option jumpers as shown in Table 2.

Demonstration Board for Freescale MCF5211, Rev. 1
Memory Map
Freescale Semiconductor6
Connect the USB cable to an open USB port on the host PC and attach to the USB port on the target board.
LED's 1–4 located adjacent to the DB-9 connector, andthe VDD LED will light and the loaded application
will begin to execute.
4.2 DEBUG Mode
DEBUG mode supports application development and debug using the ColdFire background debug mode
(BDM). Background mode is accessible using either the integrated USB-BDM or an external ColdFire
BDM cable. Use of the integrated BDM requires a host PC with an available USB port and an A/B USB
cable and appropriate hosting software. The USB cable used must be USB 2.0 compliant. A 26-pin
BDM_PORT header supports the use of an external BDM cable. This header is not installed in default
configurations. The steps describe using the integrated USB-BDM. See Section 7, “Power,” for details
on configuring the board for alternate power input.
1. Connect a serial cable between the board and a host PC if needed.
2. Connect auxiliary equipment to board if needed.
3. Install and launch CodeWarrior™6.1 Special Edition, or other software capable of communicating
with the ColdFire MCU.
4. Configure the board option jumpers as shown in Table 3.
Connect the supplied USB cable between an available USB port on the host PC and the USB connector on
the board.
Hosting development software will establish background communication.
5 Memory Map
Refer to the MCF5213 Integrated Microcontroller Reference Manual for details.
Table 2. Run Mode Setup
PWR_SEL Set to VB
BDM_EN OFF
COM_EN ALL ON (if required)
VX_EN ON (if required)
Table 3. Debug Mode Setup
PWR_SEL Set to VB
BDM_EN ON
COM_EN ALL ON (if required)
VX_EN ON (if required)

Development Support
Demonstration Board for Freescale MCF5211, Rev. 1
Freescale Semiconductor 7
6 Development Support
Application development and debug for the target MCF5211 is supported through the BDM interface. The
debug interface consists of an integrated USB-BDM debugger and an optional 26-pin header
(BDM_PORT). The BDM_PORT header is not installed in default configuration, but you may install it if
needed.
6.1 Integrated BDM_PORT
The M5211DEMO board featuresan integratedUSB-BDMdebuggerfromP&EMicrocomputerSystems.
The integrated debugger supports application development and debugging via the background debug
mode. A USB, type B, connector provides connectivity between the target board to the host PC.
The integrated debugger provides power and ground to the target, thereby eliminating the need to power
the board externally. When used, power from the USB-BDM circuit is derived from the USB bus and total
current consumption is limited by the USB specification. Total current consumption for the target board,
and all connected circuitry, must not exceed 500 mA. Excessive current drain will violate the USB
specification causing the bus to disconnect. This forces a target POR.
CAUTION
Violating the USB specification will cause the USB bus to disconnect
forcing the target to reset.
Use of the integrated USB BDM requires the use of CodeWarrior 6.1 Special Edition or development tools
from P&E Microcomputer Systems.
6.2 BDM_PORT Header
A ColdFire BDM cable may be attached to the 26-pin BDM_PORT port header. This header is not
installed in default configuration and its use requires you to install a 2x13, 0.1" center, BERG header.
Refer to the BDM documentation in the MCF5213 User's Manual for details on the use of the BDM cable.
The BDM_PORT header pin-out is shown in Figure 2.

Demonstration Board for Freescale MCF5211, Rev. 1
Power
Freescale Semiconductor8
7Power
The M5211DEMO is designed to be powered from the USB_BDM during application development. A
2.0 mm barrel connector and a two-position, screw-type, terminal block (BATT) has been applied to
support stand-alone operation. Additionally, the board may be powered through connector J1. The board
may also be configured to supply power through connector J1 to external circuitry. An OFF/ON switch
allows you to quickly and easily turn the board on and off.
When using the integrated USB-BDM, the board draws power from the USB bus. Excessive current drain
will violate the USB specification causing the USB bus to disconnect forcing a POR. Total current
consumption of the board and connected circuitry, therefore, must be limited to less than 500 mA.
CAUTION
Violating the USB specification will cause the USB bus to disconnect. This
will force a hard reset on the target.
The installed barrel connector accepts a center-positive, 2.1 mm barrel plug. The terminal block accepts
wire sizes ranging from 28 ga to 16 ga. Voltage input must be in the range between +5 V and +20 V. At
no time should input voltage exceed +20 V as damage to the board may result. The terminal block input
is connected directly to the upper voltage rail. Input protection is not applied on this voltage input.
Exercise caution when using the terminal block to input power to the board.
Voltage supplied through connector J1 is also connected directly to the board voltage rails. No protection
is applied on this input and you must exercise caution when powering the board from connector J1.
CAUTION
Input protection is not applied to the J1 or BATT power inputs. Excessive
input voltage or current will damage the board.
NC 1 2 BKPT* See the ColdFire BDM chapter in the
MCF5213 User's Manual for complete
BDM_PORT documentation.
GND 3 4 DSCLK
GND 5 6 TCLK (JTAG)
RSTI* 7 8 DSI
VDD 910 DSO
GND 11 12 ALLPST
ALLPST 13 14 ALLPST
ALLPST 15 16 NC
NC 17 18 NC
NC 19 20 GND
NC 21 22 NC
GND 23 24 TCLK (BDM)
VDD 25 26 TA*
Note: This header is not installed in default configuration.
Figure 2. BDM_PORT Header

Power
Demonstration Board for Freescale MCF5211, Rev. 1
Freescale Semiconductor 9
7.1 Power Input
7.1.1 Power (PWR) Jack
The PWR power jack, shown in Figure 3, consists of a 2.1 mm, center-positive, barrel connector. Voltage
applied at this connector should range between +5 V and +20 V.
Figure 3. PWR Jack
7.1.2 Terminal (BATT) Block
The BATT terminal block, shown in Figure 4, is a 3.5 mm, screw-type terminal block connected directly
to the VDD voltage rail. Caution must be used when using this input since input protection is not applied.
Use of this input requires a regulated +3.3 V voltage source.
Figure 4. BATT Terminal Block
7.1.3 Connector J1
See the schematic for details on using this connection to supply power to the board or source power from
the board. Use of this input requires a regulated +3.3 V voltage source.
CAUTION
Do not overdrive the J1 or BATT inputs as damage to the board may result.
7.2 VDD LED
The VDD LED indicates the state of power applied to the development board. This LED is on when power
is applied to the board. If no power is applied or the OFF/ON switch is in the OFF position, this LED be
off. The VDD LED is located after the OFF/ON switch and will indicate the state of the switch if the board
is powered from the on-board regulator, the USB circuit, or the BATT terminal block input.
2.0 mm–2.1 mm, center-positive, +V input
Applied voltage: +5 V – +20 V
PWR
Accepts wire size 28 AWG – 16 AWG
Applied voltage must be +3.3 V.
BATT
-
+

Demonstration Board for Freescale MCF5211, Rev. 1
Power
Freescale Semiconductor10
7.3 Power (OFF/ON) Switch
The OFF/ON switch, shown in Figure 5, connects and disconnects all input voltage sources to the board.
In the OFF position, the board is unpowered and no voltage is present on the upper voltage rail. In the ON
position, the input voltage source is connected to the upper voltage rail.
Figure 5. OFF/ON Switch
7.4 Power Select
Configuration of applied input power is controlled using two option headers. The PWR_SEL header
selects between the on-board voltage regulator and the USB voltage input. The VX_EN header connects
J1-1 directly to the upper voltage rail. The illustrations below show the different configuration for each
option header.
7.4.1 PWR_SEL
Figure 6 shows the PWR_SEL header.
Figure 6. PWR_SEL Option Header
Power from the integrated BDM is drawn from the USB bus and is limited to 500 mA. Excessive current
drain will violate the USB specification causing the USB bus to disconnect.
CAUTION
Violating the USB specification will cause the USB bus to disconnect. This
will cause the board to reset.
The on-board voltage regulator (VR1) accepts power input through a 2.1 mm barrel connector (PWR).
Input voltage may range from +5 V to +20 V. VR1 provides a +3.3 V fixed output limited to 800 mA.
Over-temperature and over-current limit built into the voltage regulator provides limited protection from
damage due to excessive stresses.
CONFIGURATION
OFF/ON
OFF/ON
OFF—Input power source disconnected from upper voltage rail
ON—Input power source connected to upper voltage rail
VB
Select power input from USB-BDM
VDD
PWR_SEL
VB VDD
PWR_SEL
Select power input from VR1
