Quick Start Guide
i.MX 6SoloLite Evaluation Kit
Downloaded from Elcodis.com electronic components distributor

Quick Start Guide
2
• i.MX6SLsingleARMCortex-A9
coreoperatingupto1GHz
• 1GBLPDDR2(400MHz)
• SPINOR
• SDsocketforexternaldevices
• SDsocketforbootcode
• SDsocketforWi-Fi
®
andaccessories
• eMMCexpansionfootprint
• Audiocodec
• EPDCexpansionport
• Paralleldisplayport
• PortforCSICMOSsensor(camera)
• SIMcardslot
• Buttonmatrix
• Ethernet
• Lithiumbatterycharger
• USBhost,USBOTGandUSBto
UARTports
Aboutthei.MX6SoloLiteEvaluationKit
Thei.MX6SoloLiteevaluationkit(EVK)offersasolidplatformtoevaluatethei.MX
6seriessingle-coreprocessorbuiltonARM
®
Cortex
™
-A9technologyaswellasa
referenceforfuturedesigns.Keyfeaturesofthisplatforminclude:
Downloaded from Elcodis.com electronic components distributor

3
i.MX 6Series
GettingStarted
Thei.MX6SoloLiteEVKincludesthefollowingitems:
•Board:MCIMX6SLEVK
•Cables:MicroUSB-B-2-USB-TypeAmale,V2.0
•Powersupply:100/240Vinput,5V,2.4AoutputW/ACadaptor
•Documentation:Quickstartguide(thisdocument)
•SDcards:ProgrammedAndroid™
Downloaded from Elcodis.com electronic components distributor

Quick Start Guide
4
GettoKnowthei.MX6SoloLiteEVK(top)
Over-Voltage
LED
Main Power
LED
PMIC on LED
Microphone
Parallel
Display
Port
SIM Card
Slot
EPDC Expansion
Port
Port for CSI
CMOS Sensor
(Camera)
Button Matrix
Downloaded from Elcodis.com electronic components distributor

5
i.MX 6Series
GettoKnowthei.MX6SoloLiteEVK(bottom)
5 V Power
Jack
Mini PCIe
(Only USB
connection
is supplied
for Mini PCIe
connector)
USB Host
USB OTG
Li Cell
Connectors
On/Off
Switch
Ethernet
Connector JTAG
Connector
Boot Mode
Selection
Switch USB to UART
Connector
Boot
Selection
Switches
Headphone
Connector
Speaker
Out
eMMC
Expansion
Footprint
SD Socket for Wi-Fi
and SD Accessories
(SD3)
SD Socket for Primary
External Card Slot
(SD1)
SD Socket for
Boot Code
(SD2)
Downloaded from Elcodis.com electronic components distributor

Quick Start Guide
6
SettinguptheBoard
Insert SD
Card
InsertthesuppliedSDcardinto
theSD2cardslot.
Set Up Boot
Switches
Bydefault,bootswitchesare
configuredtobootfromSD2.Ifany
otherbootsourceisdesired,boot
switcheshavetobeconfigured
accordingtoTable1.
Connect USB to
UART Cable
ConnectfromUSBtoUARTport
(J26)usingamicroUSBcableto
PC.OncethePCrecognizesthe
virtualUSBtoUARTdevice,it
canbeseenitinyourPCDevice
Managerlist.
Serialportconfiguration:115.2
Kbaud,8databits,1stopbit,
noparity.
Note:ThePCneedsadriverto
enableavirtualCOMportthrough
thePCUSBport.
Visitftdichip.comtodownload
thecorrectdriver.
Connect EPDC or
Parallel Display
Connectbymeansofthe
IMXEBOOKDC3-Eboard,which
hastobeconnectedtoJ12
andJ13.Formoreinformation
aboutthisboard,pleasevisit
freescale.com.
Connect Power
Supply
Connect5Vpowersupplyinto
powerjackJ6andsetSW14to
theOnposition(seetable2).
2
1
4
3
5
Downloaded from Elcodis.com electronic components distributor

7
i.MX 6Series

Thei.MX6SoloLiteEVKiscompatiblewiththefollowingdaughtercardsthroughthe
LCDextensionslot:
• MCIMX28LCD—LCDdaughtercard*
• MCIMXHDMICAR—HDMIdaughtercard
• IMXEBOOKDC3—EPDdaughtercard
*
EVK does not natively support the resistive touch screen on the LCD cards.
It does support touch on the EPD cards.
J13 J12
Downloaded from Elcodis.com electronic components distributor

Quick Start Guide for TWRPI-MMA845xQQuick Start Guide
8
TheAndroidBSPisprovidedontwodifferentSDcards,dependinguponthedisplay
daughtercardused.
LCD/HDMI SD Card for Booting Android
ThedefaultbootmodeconfiguresthesystemtodisplaytheUIontheMCIMX28LCD
(soldseparately).
TochangethedefaultconfigurationandenabletheMCIMXHDMICARdaughtercard
(soldseparately),hitanykeytostopu-bootfromproceeding.Oncepromptisvisible,
theu-bootcanbeconfiguredasfollows:
ForLCDbootup,typethefollowingcommands(asoneline):
setenv bootargs console=ttymxc0,115200 init=/init
androidboot.console=ttymxc0 panel=lcd
saveenv
reset
ForHDMIbootup,typethefollowingcommands(asoneline):
setenv bootargs console=ttymxc0,115200 init=/init
androidboot.console=ttymxc0 panel=hdmi
saveenv
reset
EPDC SD Card for Booting Android
Thedefaultsettingsshouldbeusedandnochangeisneeded.
Downloaded from Elcodis.com electronic components distributor

9
i.MX 6Series
Table 1: Boot Options
S1_2 S1_1
BOOT_MODE1 BOOT_MODE0
Bootfromfuses 0 0
Serialdownloader 0 1
Internalboot 1 0
Reserved 1 1
BootOptionsandSwitchConfiguration
Table 2: SW3 Configuration

SW3_8 SW3_7 SW3_6 SW3_5 SW3_4 SW3_3 SW3_2 SW3_1
BT_CFG1_0 BT_CFG1_1 BT_CFG1_2 BT_CFG1_3 BT_CFG1_4 BT_CFG1_5 BT_CFG1_6 BT_CFG1_7
SD1
D
* ** * * * 0 1 0
SD2 * ** * * * 0 1 0
SD3 * ** * * * 0 1 0
SD4 * ** * * * 0 1 0
eMMC X X * * * 1 1 0
SPINOR XXXX1 1 0 0
X Nonespecified
DDefaultconfiguration
* Switchneedstobeconfiguredforhighorlowdependingontheapplicationneeds.Pleasecheckreferencemanualfor
bootconfigurationoptions
** 1=powercycleonpower-upviaSDa_RST_B(SD3_RST).0=nopowercycle
Downloaded from Elcodis.com electronic components distributor

Quick Start Guide
10
Table 3: SW4 Configuration

SW4_8 SW4_7 SW4_6 SW4_5 SW4_4 SW4_3 SW4_2 SW4_1
BT_CFG2_0 BT_CFG2_1 BT_CFG2_2 BT_CFG2_3 BT_CFG2_4 BT_CFG2_5 BT_CFG2_6 BT_CFG2_7
SD1 * X X 0 0 1 * *
SD2
D
*X X 1 0 1 * *
SD3 * X X 0 1 1 * *
SD4 * X X 1 1 1 * *
eMMC * * * 1 0 0 1 1
SPINOR XXXXXXXX
Table 4: SW5 Configuration

SW5_8 SW5_7 SW5_6 SW5_5 SW5_4 SW5_3 SW5_2 SW5_1
BT_CFG4_0 BT_CFG4_1 BT_CFG4_2 BT_CFG4_3 BT_CFG4_4 BT_CFG4_5 BT_CFG4_6 BT_CFG4_7
SD1 XXXXXXXX
SD2
D
XXXXXXXX
SD3 XXXXXXXX
SD4 XXXXXXXX
eMMC XXXXXXXX
SPINOR 0 0 0 1 0 0 X X
BootOptionsandSwitchConfigurationcont’d
X Nonespecified
DDefaultconfiguration
* Switchneedstobeconfiguredforhighorlowdependingontheapplicationneeds.Pleasecheckreferencemanualfor
bootconfigurationoptions
** 1=powercycleonpower-upviaSDa_RST_B(SD3_RST).0=nopowercycle
Downloaded from Elcodis.com electronic components distributor

11
i.MX 6Series
Table 5: Jumper and Solder Short Configuration
Reference Shunt Installation Function
J16
1-2 Usepins1and2toconnectanexternalcharger
2-3 Shunt2–3toexperimentwithUSBcharging
Open
D
 Nocharger
J17 1-2
D
5VrailsuppliedbyPMIC(600mAlimited)
2-3 5Vrailsuppliedfromwalladapter
J18 1-2 Mini-PCIeconnectorJ8supplyvoltageconnected
Open
D
 Mini-PCIeconnectorJ8supplyvoltageunconnected
SH12
1-2
D
MX_USB_HOST_D_PconnectedtoUSBtypeAconnector
2-3 J10-USB_HOST_D_P
MX_USB_HOST_D_PconnectedtoPCIE_USB_HOST_D_P
SH13
1-2
D
MX_USB_HOST_D_NconnectedtoUSBtypeAconnector
2-3 J10-USB_HOST_D_N
MX_USB_HOST_D_NconnectedtoPCIE_USB_HOST_D_N
SW14 1-2 0
2-3
DDefaultconfiguration
JumperandSolderShortConfiguration
Tips and Precautions
Thei.MX6SoloLiteincludesan
over-voltageprotectioncircuitthatwill
disconnectthepowersupplyfromthe
systembyopeningtransistorQ1incase
thesupplyvoltageexceeds5.5V.The
usermusttakeintoaccountthisisthe
maximumvoltagethatcanbeplugged
intoJ6.
Further Documentation
•MX6SLEVKschematics
•MX6SLEVKBOMMX6SL
•EVKgerberfiles
•MX6SLEVKreferencemanual
Completedocumentationisavailableat
freescale.com/6SLEVK.
Downloaded from Elcodis.com electronic components distributor

Quick Start Guide
For more information, visit
freescale.com/iMX6series
Freescale and the Freescale logo are trademarks of Freescale
semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. ARM is a registered
trademark of ARM Limited. ARM Cortex-A9 is a trademark of
ARM Limited. All other product or service names are the property of
their respective owners. © 2012 Freescale Semiconductor, Inc.
Doc Number: IMX6SLEVKQSG REV 0
Agile Number: 926-27452 REV A
Quick Start Guide
Quick Start Guide
GetStarted
Downloadtheinstallationsoftwareand
documentationunder“JumpStartYourDesign”
atfreescale.com/6SLEVK.
Support
Visitthei.MXcommunityatimxcommunity.org.
Warranty
Visitfreescale.com/warrantyforcomplete
warrantyinformation.
