Intended Use
For internal use only.
The Mobile Hoist is a lifting aid used by trained personnel. The Mobile Hoist makes it possible to transfer/lift mobility
impaired clients with minimal strain or risk to the caregiver, while providing complete safety, dignity and comfort to
the client.
The Mobile Hoist is one of two components that makes this possible. The other component, the sling, is a specially designed
fabric accessory that attaches to the Hoist by means of a carry bar and straps, and holds the client during the lift/transfer.
Please refer to the user guides supplied with the sling and reference them while reviewing this manual.
The functions of raising and lowering the boom, and opening and closing of the legs on the Hoist, are accomplished by pressing
buttons on the hand control. The hand control is attached to the Mobile Hoist.
1.1 Warning Notes
Your Freeway M205 Mobile Hoist has been manufactured and tested to exceed BS EN 10535:2006. This does not
mean that it can be used without care. ALL OPERATORS should have read the operating instructions and appreciate
this warning section.
1. ALL Mobile Hoists are less stable on sloping surfaces. A 5-degree slope is the maximum permitted and then only with
great care.
2. ALL Mobile Hoists are dangerous to the person being transferred when used recklessly or pushed at speed.
1.2 Operating Environment
The M205 Mobile Hoist is intended for use within the professional healthcare facility environment as well as the home health
care environment. The Hoist is not suitable for any other environment or special environments.
The Mobile Hoist is not intended to be used in environments where there are rapid changes in the environmental temperature
and humidity during intended use.

993069 –Revision A P a g e | 4 of 12
Slings
The Freeway M205 is designed to be used in combination with a Sling to perform its intended use. The sections below include
the correct and safe manor of attaching/detaching the Slings as well as a list of approved slings for use.
2.1 Sling Attachment/Detachment
Sling loops should be attached as follows:
1. Put the required sling loop onto your finger and thumb and then using the same finger or thumb, pull back the spring
locking mechanism on the correct hook on the correct side of the carry bar (Figure 1 and 2).
2. Slide the sling loop from your finger and thumb over the edge of the hook (Figure 3).
3. After positioning the loop below the locking mechanism (Figure 3) release the spring locking mechanism to secure the
sling loop (Figure 4).
To remove the sling, simply reverse the process –pull back on the spring locking mechanism, lift the loop out of the hook and
release the locking mechanism.
The same process of attaching and detaching the Sling is relevant for the QRS (Quick Release System) Carry Bar.
2.1 Compatible Slings
Below is a list of slings that are recommended and have been approved by Prism Medical UK for use in combination with the
product.
We recommend the use of the Mackworth Healthcare or Care-Ability manufactured sling range (type ‘B’ applied part) to be
utilised with the Freeway M205 Mobile Hoist. It is at the user’s discretion to use alternative supplied product. In utilising another
manufacturer’s sling, checks must first be made to ensure the sling is safe to use and meets the requirements of BS EN ISO
10535 before its use.
The slings with a safe working load of 205kg that can be used with the Freeway M205 Mobile Hoist are shown in the table
below, for full details on the various Sling sizes and material options. See the User Manual for the specific Sling Model.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7

993069 –Revision A P a g e | 5 of 12
Mackworth Sling Range - Product Material and Code
Mackworth Oak
Mackworth Oak with head support
Mackworth Yew
Mackworth Yew with head support
Mackworth Hazel
Mackworth Hazel with head support
Mackworth Willow
Mackworth Willow with head support
Mackworth Beech
Mackworth Beech with head support
Mackworth Pine
Mackworth Pine with head support
Care-Ability Sling Range - Product Material and Code
CA300 Universal
CA400 Universal Deluxe
CA500 Toilet Access
CA501 Toilet Access with crossover straps
CA502 Toilet Access with head support
CA503 Toilet Access with high back
CA503E Toilet Access with high back extensor
CA600 Hammock
CA700 Classic Hammock
CA701 Deluxe Hammock
CA701 Deluxe Hammock with head support
CA702 Comfort In Chair Hammock
CA702 Comfort In Chair Hammock with head support
CA703 Split Leg In Chair Hammock
Do not use a clip fit sling on a Carry Bar designed specifically for loop fitting slings.
Table 1
Table 2

993069 –Revision A P a g e | 6 of 12
Detachable Parts
Detachable parts that are included with the product consist of the Battery and the QRS (Quick Release System) Carry Bar. This is
an optional accessory that is not included with the standard product.
Below are the instructions for attaching and detaching the QRS Carry Bar and the Battery.
3.1 Attaching/detaching QRS (Quick Release System) Carry Bar
If you have chosen to have QRS carry bar please follow the following section to attach and detach the carry bar from hoist.
Attach the carry bar (type ‘BF applied part) into the QRS Hook, located at the end of the boom, in the following way:
Attach
1. On the hook, move the locking mechanism into the hook by pressing down on the tab (Figure 8 and 9).
2. With the carry bar positioned sideways along the length of the bar, move the pin at the top of the carry bar into the
hook (Figure 10).
3. Alternatively, with the carry bar positioned sideways, the pin at the top of the carry bar can gently push the locking
mechanism out of the way as the pin is carefully moved into the hook.
4. Once the pin is in the hook, rotate the carry bar 90° down so the carry bar is hanging below the hook on the pin in the
hook. Move the locking mechanism into place by pushing up on the tab, securing the carry bar on the hook and lifting
tape. (Figure 11 and 12)
Detach
1. Press down on the locking mechanism as described in step 1 (Attach).
2. Rotate the Carry Bar to a sideways position and remove from the hook.
Figure 8
Figure 9
Figure 10
Figure 11
Figure 12

993069 –Revision A P a g e | 7 of 12
3.2 Attaching/detaching the Battery
The attachment and detachment of the Battery can be completed safely by following the following procedure:
Attach
1. Grab Hold of the Battery from the top position as shown in figure 13 and place your fingers onto the latch.
2. Press the latch to release the Battery and lift the Battery from its fixing. (Figure 14)
Detach
1. Place the Battery into the fixing location and push it forward into placement, the Battery will “click” into place.
Figure 13
Figure 14
Figure 15

993069 –Revision A P a g e | 8 of 12
Technical Specification
4.1 Freeway M205 Mobile Hoist Dimensions
All dimensions below are shown in millimetres.
Figure 16
Figure 17

993069 –Revision A P a g e | 9 of 12
4.2 Specifications
Dimensions
Turning Circle
1010mm
Overall Height
2010mm
Overall Width
625mm
Ground Clearance
15mm
Front and Rear Castors Size
75mm and 100mm
Operational Forces
Moving Force (with 205 kg)
83 N
Moving Force (with 0 kg)
16 N
Operation of the Brake
35 N
Handset
4.5 N
E-Stop Button
12 N
Carry Bar Rotation (205 kg)
18 N
Carry Bar Rotation (0 kg)
< 0.5 N
4.3 Electrical Specifications
Battery type: 2 x 12-volt Rechargeable sealed lead acid.
Battery capacity: 24 V DC, 1 x 2.9 Ah
Charger rated input: 230VAC 50/60Hz
Charger rated output: 27.4/29.0 VDC @ 0.8A
Electric Shock Protection
Charger: Class II *Lift ‐ internal power source
Degree of shock protection: Type B *Lift ‐ internal power source
Duty cycle: 10% Use –90% Rest (90 seconds use - 810 seconds rest)
IP rating, control box: IPX4
IP rating, battery: IPX5
IP rating, handset: IPX4
Weights:
Safe Working Load (SWL)
205 kg
Full Product
40 kg
Base Assembly
18.5 kg
Mast & Boom Assembly
21.5 kg
Sound Levels
Loaded dB(a)
Unloaded dB(a)
Lifting
41.7
38.5
Lowering
40.9
30.5
Table 3
Table 4
Table 5
Table 6

993069 –Revision A P a g e | 10 of 12
Environmental - Storage and Operating Conditions
The Freeway M205 is intended for internal use within normal environmental conditions.
It is not intended to be used in environments where there are rapid changes in the environmental temperature and
humidity during use.
5.1 Normal Operating Conditions
+5°C to +40°C (41°F to 104°F) at a relative humidity between 15% to 90% RH, non-condensing but not requiring a water vapour
pressure greater than 50hPa and atmospheric pressure between 700hPa to 1060hPa.
5.2 Shipping and storage conditions
-25°C to +5°C (-13ºF to 41ºF) with any humidity level.
+5°C to +35°C (41°F to 95°F) at a relative humidity up to 90%.
+35°C to 70°C (95⁰F to 158⁰F) non-condensing at a water vapour pressure up to 50hPa.
Maintenance
No service is to be carried out on the M205 Mobile Hoist, while transferring a person to reduce the risk of injury.
Service must be completed by a Prism Medical UK authorised Service Engineer.
Do not attempt to service the product yourself, or warranty is void.
To ensure the safety and continued good function of your Hoist, routine service must be performed on your Freeway M205
Mobile Hoist.
Service should be completed by a Prism Medical UK approved service engineer every 6 months to ensure the products required
standard is maintained. The service history of the product should be documented each service in the Service Log at the back of
this User Manual.
When the Mobile Hoist is serviced, the 6 month service checklist must be completed for the Freeway M205.
Service Manual Document Number: 995069.
Spare Parts Manual Document Number 992069
The Service must be completed every 6 months after installation of the Hoist to comply with LOLER Regulations.
The Freeway M205 Mobile Hoist has an expected Service Life of 10 Years.
Contact your local authorised Prism Medical UK dealer if you:
•Need more information.
•Have any questions about the use or service of your Mobile Hoist.
•Notice any change in the performance.
•Want to report an unexpected occurrence.
•Want to arrange a service.
•Need to ascertain necessary information for replacement parts and components.
Contact details of your local Prism Medical UK dealer are shown on the last page of this manual.

993069 –Revision A P a g e | 11 of 12
Cleaning
Please follow the cleaning guidelines below on cleaning and disinfecting the Hoist.
7.1 General cleaning
It is recommended to clean the Freeway M205 and accessories before the use by a different patient, reducing the risk
of cross–contamination.
The exterior of the Freeway M205 can be cleaned using a damp soapy cloth for general cleaning duties. Please ensure the cloth
is damp and not wet. Ensure the exterior of the device is dry after cleaning. Dry using a clean dry cloth.
7.2 Disinfecting (if necessary)
Should the Mobile Hoist require a more thorough clean, the use of the Actichlor™disinfectant product (which is widely available
in tablet form and used throughout the health care industry) is recommended.
Follow the manufacturer’s safety instructions for the use of the cleaning product before use to ensure safe use for the
operator and the patient.
Ensure the cloth is damp before the cleaning process.
Application is through a clean damp cloth applied to wipe the device down. Use in the following dilutions to ensure an effective
clean:
•Actichlor™dissolvable chlorine tablets provide a concentration of 1000 ppm of available chlorine (0.1%) per 1 tablet
•1 tablet (1.7g formed tablet (x1)) will create a virucidal solution, diluted in 1 litre of water to provide effective means to
clean a “dirty” device. This is also ideal for use after an outbreak of the Norovirus/winter vomiting and can be used as a
precaution against C.Diff. It is effective against viruses, bacteria, spores, yeasts and moulds.
•The contact time against the outer components of the device should be for 5 minutes to prevent any virucidal
infections without a degradation to the functionality of the device. 5 minutes is a recommended contact time. The
device can withstand a longer contact period but the 5 minute recommendation as a minimum must be followed to
provide an effective cleaning regime.
•Blood spills should be dealt with by an increased concentration of the solution –please refer to the instructions on the
manufacturers product labelling.

993069 –Revision A P a g e | 12 of 12
Disclaimer
While every effort has been made to ensure the accuracy of
information contained in this user manual, no liability can be
accepted by Prism Medical UK for any errors or omissions.
Prism Medical UK operates a policy of continuous
improvement. Specifications and other data are subject to
change without notice.
Manufacturer contact details:
Prism Medical UK
Address: Unit 1 • Tir Llwyd Industrial Estate • St Asaph Avenue • Kinmel Bay • Conwy • LL18 5JZ
Telephone Number: 01924 840100
Unit 1 • Tir Llwyd Industrial Estate • St Asaph Avenue •
Kinmel Bay • Conwy • LL18 5JZ
