Frico PFSE4 User manual

PF Smart
.... 9
SE .... 19 GB
Original instructions
.... xx
NO .... xx DE .... xx ES
.... xx
FR .... xx IT .... xx NL .... xx PL .... xx RU

PFS
2
Introduktionssidorna består huvudsakligen av bilder. För översättning av de
engelska texter som används, se respektive språksidor.
SE
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the respective language pages.
GB
Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de
engelske tekstene, se de respektive språksidene.
NO
Les pages de présentation contiennent principalement des images. Pour la
traduction des textes en anglais, consultez la page correspondante à la langue
souhaitée.
FR
Die Einleitungsseiten bestehen hauptsächlich aus Bildern. Für die Übersetzung
der verwendetenTexte in englischer Sprache, siehe die entsprechenden
Sprachseiten.
DE
Las páginas introductorias contienen básicamente imágenes. Consulte la
traducción de los textos en inglés que las acompañan en las páginas del
idioma correspondiente.
ES
De inleidende pagina's bevatten hoofdzakelijk afbeeldingen.Voor een vertaling
van de gebruikte Engelse teksten, zie de pagina's van de resp. taal.
NL
Le pagine introduttive contengono prevalentemente immagini. Per le
traduzioni dei testi scritti in inglese, vedere le pagine nelle diverse lingue.
IT
Początkowe strony zawierają głównie rysunki. Tłumaczenie wykorzystanych
tekstów angielskich znajduje się na odpowiednich stronach językowych.
PL
RU Страницы в начале Инструкции состоят в основном из рисунков, схем и
таблиц. Перевод встречающегося там текста приведен в разделе RU.

PFS
3
PFS
450 / 660 / 940
325
10
105
Fig. 1
min 100
min 100
min 100
Fig. 2: Minimum distance

PFS
4
Fig. 3: Mounting wall bracket
Fig. 4: Fastening with lockplate
A B
10 cm
Possibility to use guide holes for easy positioning
A
B
Mounting with wall bracket
C
Align the wall bracket

PFS
5
Fig. 5: Free space to mount the connection box behind the unit
Fig. 6: Bending the wall bracket
Mounting when a connection box is to be placed behind the unit
Fig. 7: Floor stand
Portable use
11 3
PFS4/10/17 - 214/434/712 40 30
1
2
3
AB

PFS
6
Fig. 8: Opening the unit
Fig. 9: Changing the maximum surface temperature from 90 °C to 60 °C by removing the jumper.
Default 90 °C.
Overheat protection
°C
OUTLET
SENSOR
INLET
SENSOR
POWER
BOARD
230/400V
RF In
DISPLAY
BOARD
12VDC
PFSE/D10
PFSE/D17
PFSE/D4
1
0
12VDC
M
Jumper
60/90°C
90°C
60°C
PFSD
PFSE
M M
OL LNON
A B
1
2

PFSS
PFSRF PFSH
PFS
7
Type
PFSS4 PFSE4
PFSS10 PFSE10
PFSS17 PFSE17
PFSRF PFSE, PFSD
PFSH PFSE, PFSD
Accessories
Type Output
[W]
Voltage
[V]
Amperage
[A]
Output
Motor (12V)
[W]
LxHxD
[mm]
Weight
[kg]
PFSE4 400 230V~ 1,8 1,2 450x325x105 4,1
PFSE10 1000 230V~ 4,4 1,8 660x325x105 5,8
PFSE17 1750 230V~ 7, 6 3,0 940x325x105 8,1
Type Output
[W]
Voltage
[V]
Amperage
[A]
Output
Motor (12V)
[W]
LxHxD
[mm]
Weight
[kg]
PFSD4 400 400V2~ 1,0 1,2 450x325x105 4,1
PFSD10 1000 400V2~ 2,5 1,8 660x325x105 5,8
PFSD17 1750 400V2~ 4,4 3,0 940x325x105 8,1
3Electrical heat 400V2~ PFSD
3Electrical heat 230V~ PFSE
Protection class: IP24.
CE compliant.

PFS
8
PFSE / PFSD
Overheat protection
°C
OUTLET
SENSOR
INLET
SENSOR
POWER
BOARD
230/400V
RF In
DISPLAY
BOARD
12VDC
PFSE/D10
PFSE/D17
PFSE/D4
1
0
12VDC
M
Jumper
60/90°C
90°C
60°C
PFSD
PFSE
M M
OL LNON

PFS GB
19
General Instructions
Read these instructions carefully before
installation and use. Keep this manual for
future reference.
The product may only be used as set out in
the assembly and operating instructions. The
guarantee is only valid if the product is used
in the manner intended and in accordance
with the instructions.
Application
With its smart functions and streamlined
design, the PF Smart fan convector is
the perfect choice for fast and efficient
heating. The PF Smart is suitable for most
environments including offices and homes.
It is ideal for installation in premises that
are used rarely, such as weekend cottages
and assembly halls where rapid heating is
desirable. In addition, the PF Smart can be
remotely controlled so that the premises is
warm by the time you arrive.
Protection class: IP24.
Approvals
• When the maximum surface temperature
is set to 60 °C, PFS are suitable for use in
preschools, afterschool recreation centres
and toilet and bathroom facilities.
• The convector is approved for installation
in wet rooms on condition that no control
devices (buttons, switches, etc.) are within
reach of persons in the bath or shower.
Convectors for portable use must not be
used close to pools, bathtubs or showers.
Protection class: IP24.
Mounting
Fan convector PFS is mounted on the wall
with the wall bracket. The unit must not be
positioned immediately below a permanent
socket. For minimum distances with
permanent installation, see Fig. 2. PFSE can
also be used portable, floor stand is available
as an accessory.
Mounting with wall bracket
1. Mount the wall bracket stable on the wall
with screws in the oval holes (at least 2x).
It is important that the wall bracket is
aligned to a straight horizontal position.
Guide holes on the wallbracket can be
used to mark out where the bracket should
be postioned to end up 10 cm above the
floor. Fig. 3.
2. Hang the fan convector on the wall
bracket.
3. Rotate the locking plate (Fig. 4) and fasten
with a screw in the wall, so that the fan
convector is mounted securely.
Mounting when a connection box is to be used
To enable the installation of a surface-
mounted connection box behind the fan
convector, the wall bracket is bent in order
for the unit to be placed further from the wall.
Fig. 5 and 6.
1. Bend the wall bracket acc. to Fig 6. Now
the holes in the bent-down part is used to
fasten the wall bracket to the wall.
2. Follow steps 1-3 in section "Mounting with
wall bracket".
Portable use
PFSE can also be used as a portable unit. The
floor stand is available as an accessory.
Hang the fan convector on the floor stand.
The lock plate is removed and not used.
Screw the stand to the unit with screws
included, in intended holes, PFSE4 1x,
PFSE10/17 2x. Fig.7.
Electrical installation
PFSE is equipped with a 1.4 metre long cord
with plug for connection to an earthed power
socket (230V~).
PFSD is intended for fixed installation and is
connected via cord without plug.
PFSD is intended for permanent installation
and is connected via cable without plug.
The installation, which should be preceded
by an omnipolar switch with a contact
separation of at least 3 mm, should only
be wired by a competent electrician and in
accordance with the latest edition of IEE
wiring regulations.
Fan convector PFS is turned on with the
switch, postioned low on the right plastic end.
See wiring diagrams.
Assembly and operating instructions

PFS
GB
20
Overheat protection
The fan convector is equipped with overheat
protection. The overheat protection resets by
turning off the unit for 10 minutes.
Replacement of fan motor
1. Disconnect the electricity.
2. The front is opened by removing the
screws down on the plastic ends (2x),
angle out the front at the bottom and then
lift it up. (Fig. 8)
3. Loosen the motor cables.
4. Loosen the motor mounting screws and lift
the motor.
5. Install the new motor in reverse.
6. Remount the front.
Safety
• For all installations of electrically heated
products should a residual current circuit
breaker 300 mA for fire protection be used.
• Keep the areas around the air intake
and exhaust grilles free from possible
obstructions!
• The unit may have hot surfaces during
operation and when cooling down!
• The unit must not be fully or partially
covered with clothing, or similar
materials, as overheating can result in a
fire risk! (E)
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.
Changeover surface temperature 60 / 90 °C
On delivery, the surface temperature is
max. 90 °C. To select the lower surface
temperature - max 60 ° C, remove the jumper
on the circuit board, that is placed inside the
convector below the display screen.
1. Disconnect the electricity.
2. The front is opened by removing the
screws down on the plastic ends (2x),
angle out the front at the bottom and then
lift it up. (Fig. 8)
3. Remove the jumper. Fig. 9.
4. Remount the front.
A surface temperature of 60 °C can at some
conditions result in a power reduction, to
keep the temperature low.
Start up (E)
When the unit is used for the first time or
after a long period of disuse, smoke or odour
may result from dust or dirt that has collected
on the element. This is completely normal
and disappears after a short time.
Service, repairs and maintenance
For all service, repair and maintenance first
carry out the following:
1. Disconnect the electricity.
2. The front is opened by removing the
screws down on the plastic ends (2x),
angle out the front at the bottom and then
lift it up. (Fig. 8)
3. Remount the front.
Maintenancel
In all electrical heating appliances, small
clicks can occur due to movement when the
material expands and contracts with changes
in temperature.
Since fan motors and other components are
maintenance free, no maintenance other than
cleaning is necessary. The level of cleaning
can vary depending on local conditions.
Undertake cleaning at least twice a year. Inlet
and exhaust grilles, fans and elements can be
vacuum cleaned or wiped using a damp cloth.
Use a brush when vacuuming to prevent
damaging sensitive parts. Avoid the use of
strong alkaline or acidic cleaning agents.

PFS GB
21
Hold: Quick command
Child/screen lock off/on
Display time and week-
day
Current room tempera-
ture (actual value)
Control
The fan convector has a digital display on
which all settings are made and can also be
remotely controlled via an app (iOS, Android)
or web browser.
A
°C
OK
7
43
2
1
9
8
6
5
Start-up
Home screen and button unit
Button unit
1 Increase / up
2 Decrease / down
3 User menu / browse / proceed
4 Return
5 Confirm / select
Display
6 Desired room temperature (setpoint)
7 Fan mode Auto active
8 Mode Comfort active
9 Heat on
When the screen is inactive, it can be activated by
pressing any button.
PF Smart comes with default settings. The
temperature is easily changed easily
with + or -.
PF Smart can also be precisely adapted to
individual requirements, see the following
pages.
Default settings
Setpoint 21 °C
Fan mode Auto
Temperature mode Comfort
Quick commands
+
+
At the first start-up or after a longer power
failure the clock needs to be set. If the weekly
program is not to be used and the clock not
needs to be set, this can get past by pressing
the OK button repeatedly until the home
screen appears.

PF Smart App
PF Smart can also be remotely controlled
via an app (iOS, Android) or web browser.
Requires an RF module per fan convector,
hub and wireless Internet connection. See
accessories in the first pages and separate
manual.
PFS
GB
22
A
OFF P
°C
Display symbols
Heat on
Surface temperature 60 °C
selected.
Surface temperature 90 °C
selected.
Child/screen lock
Symbol flashes.
Weathering mode active
Weekly program active
Symbol flashing
Timer active
Frost protection mode active
Reduced mode active
Comfort mode active
Fan off. Flashes
when cooling.
Fan Auto mode
Active fan steps
Weekday:
1 = Mon till 7 = Sun
A
OFF
Timeline for the current weekly
program. Black timing marks =
comfort mode
P
Symbol flashes
Sending/reception RF
Fan active

PFS GB
23
Temperature modes
It is possible to choose between three modes -
Comfort mode, reduced mode (night mode) or
Frost protection. Values set for mode Comfort
and Reduced is also used in the weekly
program, when it is active.
Default settings
Temperature
mode
Setpoint Fan mode
Comfort 21 °C
Reduced 18 °C
Frost protection 10 °C High (locked)
Comfort
Reduced
Frost protection
See section Fan modes to set the desired
fan mode. For temperature mode Frost
protection, the fan mode is locked to High (for
maximum heat distribution).
Fan modes
The fan speed can be set to suit the needs,
modes Auto, Off, Low or High.
User menu
A
OFF
Set the desired fan mode.
Auto Off
HighLow
Fan mode Function
Auto The fan runs at low speed except:
• when the room temperature
is more than 2 °C below the
set point, then the fan speed
increases to high speed for a
shorter heating time.
• if it is too hot in the the unit
Off The fan is off.
When Off is selected, the fan first
runs during a cooling period for
the right temperature to be achie-
ved before it turns off.
The internal sensor controls,
which may cause power reduc-
tion, to prevent excessive internal
temperature.
Low Low speed
The internal sensor controls,
which may cause power reduc-
tion, to prevent excessive internal
temperature.
High High speed
AP
Select
Confirm.
OK
Confirm.
OK
User menu
Select mode in the user menu:
Set the desired room temperature.
Confirm.
OK
Confirm.
OK

PFS
GB
24
Timer
The set temperature can be changed for a
limited time with the timer (1 hour to 45
days). The fan runs on the set value.
1h - 45d
AP
°C
AP
Meanwhile the timer counts down, the timer
symbol flashes and the display alternately
shows the remaining time and the set
temperature.
When time is up the control returns to
previous settings.
Weekly program
PFS has nine preset weekly program (P1 to
P9) and the possibility to add four own (U1-
U4).
The function ITCS (default) makes the
control to learn when it needs to start to
achieve a certain desired temperature at a
specific time in the environment it is used. It
can be disabled, see Settings.
Preset programs
Program Description Comfort
mode
Reduced
mode
P1 Residence Mon-fri;
05:30 - 08
17 - 22
Sat-sun;
07 - 23
Other time
P2 Residence,
late
Mon-fri;
06:30 - 10
19 - 23:30
Sat-sun;
07:30 - 23:30
Other time
P3 Residence,
short
Mon-fri;
06 - 09
16 - 23
Sat-sun;
07 - 23
Other time
P4 Residence,
only night
Mon-sun;
06 - 22
Other time
P5 Weekend Fri;
17 - 23
Sat-sun;
07 - 23
Other time
P6 Office Mon-fri;
06 - 18
Other time
P7 Office, late Mon-fri;
09 - 21
Other time
P8 Shop, late Mon-fri;
09 - 22
Sat-sun;
09 - 20
Other time
P9 Shop Mon-fri;
09 - 18
Sat-sun;
09 - 14
Other time
User menu
Set the desired time.
AP
Select
Confirm.
OK
Confirm.
OK
Set the desired temperature.
Confirm.
OK
Read more on the following page.

PFS GB
25
Select a preset program P1 - P9
Confirm with ok to start the program.
Switch between days of the week
with the arrow to view times for the
selected program. 1 = Mon to 7 =
sun. The times when Comfort mode
is active can be seen down in the
display at the selected weekday.
Select your own program U1 - U4
P1 or the recently used program is shown.
P
User menu
AP
Select
Confirm.
OK
Setting weekly program
Select P1-P9.
OK
Select U1-P4.
Hold OK 2 s. to confirm.
OK
Select if you want to begin the
setting for Reduced mode or Comfort
mode.
PP
Comfort modeReduced mode
Confirm.
OK
Select the start time for the selected
mode (Reduced/Comfort).
P
Confirm.
OK
Select between Reduced mode or
Comfort mode for following time.
Confirm.
OK
Select the start time for the selected
mode (Reduced/Comfort).
P
Confirm.
OK
These steps can be repeated until a full
program is set. When the program is finished,
proceed to the next day.
Monday
Following days, tue- sun
To access the following day
Select copy (COPY) to copy the
previous day's settings or no (no).
°C °C
No to copyYes to copy
Confirm.
OK
Of no(no) is choosen, settings is made in the
same way as for Monday 1.
When all 7 days are completed, save (SAVE)
can be choosen.
Select yes to save (YE) or no (no).
Confirm with ok to start the
program.
OK

Power failure
Note! A power loss longer than 12 hours may
require an adjustment of time and date.
The week program is affected if the clock is
not correctly set.
PFS
GB
26
Settings
AP
Menu
options
Operation Default
settings
Description
Time (01) For weekly program.Time and date Must be
set if the
weekly
program
is to be
used
Set the following:
• hour (24 h)
• minute
• weekday: mon=1, sun=7
• day/month
• year
Increase/decrease with +/-.
Confirm every step with OK.
dst (02) For weekly program. Daylight saving/
summer time and winter time
on (on) Switch between on (on) and off
(OFF) with +/-.
Confirm with OK.
Frt (03) For weekly program. No fan (fan off) in
reduced mode.
off (OFF) Switch between off (OFF) and
on (on) with +/-.
Confirm the selected with OK.
In t (04) Read internal temperature. - Press OK to return to the menu..
ItcS (05) For weekly program.The control learns
when it needs to start to achieve a cer-
tain desired temperature at a specific
time in the environment it is used.
on (on) Switch between on (on) and off
(OFF) with +/-.
Confirm the selected with OK.
rF (06) For PF Smart App. Pairing the RF module
with the control.
- See separate manual for PF
Smart App.
oPn (07) Open window mode to save energy. If
the temperature drops more than 3 °C
in one minute, the control enters frost
protection mode for 15 minutes (see
Temperature Modes). Unless the tem-
perature drops further, after 15 minutes,
the control returns to previous settings.
on (on) Switch between on (on) and off
(OFF) with +/-.
Confirm the selected with OK.
clr (08) Factory Reset. Clear all settings. - Switch between no (no) and yes
(YES) with +/-.
To factory reset, choose yes
by retain OK about 4 seconds
(countdown).
uEe (09) Read version number. - Press OK to return to the menu.
User menu
Select
Confirm.
OK
Browse the menu options.
Confirm.
OK

Trouble shooting
PFS GB
27
Symptom Cause Action
The fan symbol is
flashing. No heat
and the fan runs at
maximum speed.
The internal temperature has exceeded
the upper limit, even though the heat is
off.The fans automatically works at the
highest speed and the heat is blocked
until the internal temperature is below
the limit, and then return to the previous
settings.
• Check that the air flow is not
blocked at the intake grille or
outlet grille.
• Clean the inside of the unit.
• Check that the internal sensor (at
the outlet grille) are placed cor-
rectly.
• If the problems continue, please
contact Frico for support.
The text "Heat OFF"
appears. No heat.
The control experience that no heat is
emitted from the heating element. (The
temperature difference between the
room sensors and internal sensors is
less than 5 °C after 90 sec.)
• Check that the air flow is not
blocked at the intake grille or
outlet grille.
• Disconnect the power for at least
10 minutes so that the overheat
protection resets.
• Reconnect power and cancel the
alarm by pressing the OK button
for 3 seconds.
• If the problems continue, please
contact Frico for support.
The text "Sens Out"
flashes in the display
and there is no heat.
The lower sensor is faulty or has beco-
me detached from its fastening.
• Please contact Frico for support.
The text "Sens In"
flashes in the display
and there is no heat.
The upper sensor is faulty or has beco-
me detached from its fastening.
• Please contact Frico for support.
The fan convector emits
heat, but it becomes
progressively more
difficult to achieve
the desired room
temperature, even
though the settings are
unchanged.
The internal temperature reaches its
limit value faster, which limits the heat
emission.
• Check that the air flow is not
blocked at the intake grille or
outlet grille.
• Clean the inside of the unit.
• Check that all motors operats cor-
rectly.
• If the problems continue, please
contact Frico for support.
All the fans are inactive. • The fan speed is set to OFF.
• The function with fans off at reduced
mode (FRT) is active.
• The quick plug for the first motor is
detached.
• Change fan mode to Auto.
• Put FRT function to OFF in Set-
tings.
• Check the fan motor connections.
• If the problems continue, please
contact Frico for support.

Art.no 211237, 20170111, HH
Main office
Frico AB Tel: [phone]
Box 102
SE-433 22 Partille [email protected]
Sweden www.frico.se
For latest updated information and information
about your local contact: www.frico.se
