Vassilias R-052T User manual

INSTRUCTIONS MANUAL
MODEL R-052T
Convector Usage Guidance
Please read this guidance carefully before using the electrical appliance, so that you can use it
correctly.
Please keep well with this guidance.
Brief Introduction of the product:
The convector adopts convecting heating technology, and has a high heating efficiency,
centralized heat and adjustable heating range. Also it has available accessories such turbo. The
convector has a reasonable foot structure not easy to be toppled by accident.
Assemble before you use:
Please assemble the feet and the body in the order given in the picture below:
1. Place the convector on the flat desk or carton.
2. Insert the 2 position fins of the feet into the position holes of the body.
3. Tight the fixed screw to connect body .and feet.
Position pin
Position hole
Fixed screw
Technical parameters:
Model Rated Power Rated Voltage Rated Frequency
R-052T 2000W 230V~ 50Hz
Usage:
1. Please check before you use:
A: The heating wire and electric wire can not be broken.
B: Please do not use the socket lower than 10A for fear of any accident.
2. Use the convector on the flat place to avoid being toppled.
3. There are 2 switches for the power setting. “I” is for 800W; “II” is for 1200W. You can get 3
power setting 800W, 1200W, 2000W (800W+1200W).
4. There is a thermostat knob for adjusting heating. You can rotate the knob to get your desired
heating level.
5. For the convector with turbo, there is a independent switch for this function.
6. If you stop using convector, turn off all the power switch, then put off the plug.
7. If you want to move the convector, please turn off the switches, then put off the plug, and hand
on the handle on the back of the convector.

Name of the components:
Feet
Air inlet
Thermostat knob
Power switch
Turbo switch Ho t air o utlet
Handle
Turbo
Electric Drawing:
TIMER
(ONLY FOR THE
MODEL WITH TIMER)
THERMOSTAT
INDICATO R HEATING
ELEMENT
I
N
D
I
C
A
T
O
R
M
M
O
T
O
R
I
N
D
I
C
A
T
O
R
T
U
R
B
O
(
O
N
L
Y
F
O
R
T
H
E
M
O
D
E
L
W
I
T
H
T
U
R
B
O
)
H
E
A
T
I
N
G
P
R
O
T
E
C
T
O
R
FUSE
L
N
K1 K2 K3
TURBO
Notes:
1. The product is for household use only.
2. Strictly prohibit to use the convector near the combustibles such as curtains etc., explosive
objects, things easy to be deformed or deteriorate, and where full of dust.
3. Strictly prohibit to use the convector in where be easy shocked or be toppled.
4. Strictly prohibit to stem the small hole on the convector and insert anything into the machine.
Especially for children for fear of shock.
5. Strictly prohibit to use the convector in the place have rainfall.
6. Strictly prohibit to use the convector when it being covered.
(When the convector working, To avoid hazard prohibit use the convector to humidify room
or dry clothes, towel etc. )
7. Strictly prohibit to plug-in or off the plug instead of turn on or off the power switch.
8. Do not use the convector without Feet fixed.
9. Do not locate the convector immediately below a socket-outlet.
10. Strictly prohibit to use the same plug or socket-outlet with other big power appliance.
11. Please put off the plug when nobody is nearby.
12. If there is something wrong with the convector, please turn off the machine and put off the
plug immediately and send to repair company.
13. The used heating wire treated by a special way, it has a long using life, please do not use any
other heating wire instead of it.
14. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or
a similar qualified person in order to avoid a hazard.
15. Do not use this convector with a programmer, timer or any other device that switch as the
convector on automatically, since a fire risk exists if the convector is covered or positioned
incorrectly.
16. Do not use this convector in the immediate surroundings of a bath, a shower or a swimming

pool.
17. When working, the surface is very hot, strictly prohibit children to touch. Usually keep a
distance at lest 0.5m
18. The heater must in a well-ventilated place. Pay attention combustible materials such as blanket,
clothes, paper etc to jam the air inlet and outlet.
19. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
20. Children should be supervised to ensure that they do no play with the appliance.
21. In order to avoid overheating, do not cover the heater
WARNING: This heater is not equipped with a device to control the room temperature. Do not use
this heater in small rooms when they are occupied by persons not capable of leaving the room on
their own, unless constant supervision is provided.
Maintenance:
Please make sure the plug should be put off before cleaning the convector.
1. Strictly prohibit to use water to wash the convector, it can be cleaned by a piece of soft damp
cloth with a little neutral detergent. Please do not use other solvent like gasoline.
2. The machine must be used or stored after cooled and dried completely.
3. If stop using convector, please put off the plug from the socket, and store it in the dry place with
a rust-proof poly bag, original packing is favored.
Packing List:
NO NAME QUANTITY
1 BODY OF CONVECTOR 1 PCS
2 FEET 1 SET
3 FIXED SCREW 2 PCS
4 INSTRUCTION 1 PCS
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer
providing this service.
Disposing of a household appliance separately avoids possible negative consequences for
the environment and health, deriving form inappropriate disposal and enables the constituent
materials to be recovered to obtain significant savings in energy and resources. As a reminder
of the need to dispose of household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
