Fridababy 61-067 User manual
This appliance conforms to the following standards:
ASTM E1112
ISO 80601-2-56 - Part 2-56
IEC 60601-1-11 - Part 1-11
IEC 60601-1-2(EMC)
AAMI/ANSI ES60601-I (Safety Standards)
ISO 13485 Certified Manufacturing Facility
3-in-1 True Temp
Thermometer
10 second predictive quick
read + 30 second final
temperature read
USER MANUAL
Read instructions thoroughly before using digital thermometer.
Choking Hazard: Thermometer battery door and battery may be fatal if swallowed. Do not allow children to
use this device without parental supervision.
Do not use thermometer in ear. Designed use is for rectal, oral and armpit (axillary) readings only.
Do not place thermometer battery near extreme heat as it may explode.
Remove battery from the device for long-term storage.
The use of temperature readings for self-diagnosis is dangerous. Consult your doctor for the interpretation
of results.
Do not attempt measurements when the thermometer is wet as inaccurate readings may result.
Do not bite the thermometer.
Do not attempt to disassemble or repair the thermometer.
After each use, disinfect the thermometer.
Do not force the thermometer into the rectum.
Do not use thermometer orally after being used rectally, without proper sanitation.
For children who are two years old or younger, do not use the device orally.
This product is not intended to diagnose or treat any health problem or disease and should not be used as a
substitute for the consultation and advice of a physician or other medical professional.
Thermometers should only be used under the supervision of an adult.
Before use, it is recommended that the patient avoid eating, drinking, smoking or exercising for at least twenty
minutes prior to taking a measurement. Never walk, run or talk during a measurement.
1 Thermometer, 1 3V Battery (CR2032), 1 Storage Case, 1 Owner's Manual, 1 Quick Start Guide
Portable and mobile RF communications can affect the device. The device needs special pre-cautions regarding
EMC according to the EMC information provided in the accompany documents.
Type: Digital Thermometer
Measure Range: 89.6˚F - 111.0˚F (32.0˚C - 43.9˚C)
(˚C / ˚F chosen by user)
Accuracy: ±0.2˚F (0.1 C) during 95.9˚F ~ 107.6 ˚F
(35.5˚C ~ 42.0˚C) at 64.4˚F ~ 82.4˚F (18˚C ~ 28˚C )
ambient operating range + 0 .4˚F (0.2˚C) for other
measuring and ambient operating range. Procedures for
determining the accuracy of the thermometer are
available upon request.
*Accuracy: +/- .2F in laboratory testing as stated
Operating mode: Predictive Mode
Display: Liquid crystal display, 3 1/2 digits
Memory: For storing the last 10 values
Battery: One 3.0 V DC CR2032 battery
Battery life: Approx 200 hours
Dimension: 160mm (open) x 32mm x 26mm. (LxWxD)
Weight: Approx. 1.35oz including battery
Ambient operating range:
Temperature: 41˚F - 104 F (5˚C ~ 40˚C)
Relative humidity: 15% ~ 95%RH
Storage and transportation condition:
Temperature: -4˚F ~ 131˚F (-20˚C ~ 55˚C)
Relative humidity: 15% ~ 95%RH
Ingress Protection Rating: IP 22
Classification: Type BF
Model: 61-067
Gift Box: 92-61003 11/19 Instruction Manual: 93-1471 03/20
Please read and save these instructions
FCC Statement
Specifications
Contents
Product illustration
Warning:
High temps are no joke. Is your munchkin just a bit flushed or is this a full-blown fever fest? You need
answers RIGHT. NOW. And we’re here in the trenches with you. That’s where our 3-in-1 True Temp
Thermometer comes in, with rectal, oral and armpit reading functions. It gives you both a 10-second quick
read and a 30-second final read with a single insertion.
Taking a temp rectally is the only way to go with babies up to one year and is recommended by the AAP as
the best method until age three. Middle of the night fever fears? No problem. The built-in LED light lets you
see where you’re going and what you’re doing. (Important for rectal readings…) Worried about going too
deep? The insertion stopper’s got you covered. Can’t remember what your little one’s temp was an hour
ago? Memory Mode to the rescue!
We’ve thought of it all so that you don’t have to.
FEVER OR FINE IN A FLASH
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference; and (2) this device must accept any interference received, including interference
that may cause undesirable operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This end for
mouth or armpit
Probe button
Flexible tip
Insertion stopper
LED light
BPA-free and latex-free Water-resistant
Digital screen
(˚F or ˚C)
Power Button
This end
for rectal
Manufactured for
Fridababy LLC, Miami, FL 33137
Love it? Leave a review fridababy.com
Troubleshooting / Error codes
10-Second read: Quick check
Memory mode: To enter, press and hold the button for 3 seconds when the device is off.
Once in memory mode, press the button once to scroll to the next memory reading.
Press and hold the button for three seconds to turn off.
5. When you are in the right mode and unit settings, you’re ready to go.
Taking baby’s temperature with a 10 or 30-Second reading:
7. Press the Power Button to turn off. This can be done at any point during a reading.
6. Wait a minimum of one minute before attempting a new measurement.
8. Remember to sanitize the thermometer before and after all readings, especially if you are using it both rectally and orally.
Insert the thermometer into the appropriate body
part based on the mode setting (“rct,” “orl,” “udr”).
Screen will show a loading “wheel” while registering
the temperature.
30-Second read: Final temperature check
Keep the thermometer inserted. The screen will
continue to flash for another 20 seconds.
Once 30 seconds have passed, the reading is
complete. The thermometer will beep and display
the final temperature reading.
The thermometer will beep and flash a temperature
reading after 10 seconds.
**Normal body temperature / Fever indicator
Body temperature can vary
from 97°F and 100.0°F and still
be considered normal. The
medically accepted ‘normal’
body temperature is 98.6°F
Body temperature is commonly
lower in the upon waking than
at any point during the rest of
an individual’s waking hours.
Temperature readings will vary
based on the body location point of
the reading. Oral temperature
readings between 97°F (36.1°C) and
100°F (37.7°C) are considered
normal. A rectal temperature reading
is generally 1°F (0.5°C) higher; while
an underarm, or axillary,
temperature will be 1°F (0.5°C) lower.
A fever is defined as a body temperature that
is elevated above the normal for that person.
It is important to determine what is normal for
an individual before determining if a fever is
present. Tracking an individual’s temperature
on a consistent basis, at the same body site
and at the same time every day when the
person is well or healthy will help determine
an individual’s normal temperature.
Do not dispose of used batteries in the trash. Consult your
local recycling center for the proper way to dispose of
batteries in your area. Keep used batteries away from
children, pets and excessive heat.
The measured temperature is
above 109.2°F (42.9°C).
Hi
- - -
Err
Results are above range; wait several minutes and
attempt new measurement.
The measured temperature is
below 89.6°F (32°C).
Results are below range; wait one minute and attempt
new measurement.
The system is not functioning
properly.
Dead battery: Battery icon is
flashing, can’t be measurable.
Attempt new measurement; if error persists contact
Check battery and replace with a new battery if
necessary.
Performance may be degraded should one or more of the following occur:
Error Problem/Cause Solution
3. You’ll see the selected reading mode on the screen
(“rct,” “orl,” “udr”).
4. You’ll see “---” and either F˚ or C˚ on the top right of
the screen. (See below to CHANGE UNIT.)
1. Press the Power Button to turn the thermometer on. 2. Your last temperature reading will show on the LCD
screen.
Call your child's doctor right away if your child has a fever and:
Is younger than 3 months (12 weeks) and has a temperature of 100.4°F (38.0°C) or higher.
If, at any age, the fever rises above 104°F (40°C) repeatedly.
Directions
For Rectal Use:
For Oral or Underarm Use:
We want the best for you and your fam. The American Academy of Pediatrics (AAP) recommends that for at least
the first year of baby’s life (though up to three is best), temp checks should only be done rectally. That’s why our
thermometer defaults to Rectal (“rct”).
Confirm that the thermometer is in the correct mode: Oral (“orl”) or Underarm (“udr”).
(See below to CHANGE MODE.)
Press the white probe button on the side and flip the tip into oral/underarm mode.
Oral (recommended only for ages four and up):Place the thermometer tip under tongue.
Underarm: Place the thermometer probe with tip in armpit and keep arm firmly pressed against side.
Note: To ensure an accurate temperature, always wait for the 30-second reading in underarm mode
(the 10-second reading may not be reliable due to environmental factors, like air temperature).
Confirm that the thermometer is still in Rectal (“rct”) mode. (See below to CHANGE MODE.)
Before inserting the thermometer, lubricate the silver tip. We suggest coconut oil or other natural lubricants.
Press against the small bump on the thermometer probe to turn on the LED light for easy visibility.
Then, lift baby’s legs and gently insert the thermometer tip up to the insertion stopper.
Do not insert past the point where you feel resistance (usually from baby’s lower cheeks).
Battery replacement
1. Replace battery when “ ” appears in the lower right corner of LCD display.
2. Pull Battery door off and open Battery chamber.
3. Discard battery lawfully. Replace with new 3.0V DC button type CR2032, or equivalent.
4. Slide battery chamber back into place and attach battery door.
Operation outside stated temperature and humidity range.
Storage outside stated temperature and humidity range.
Mechanical shock.
Patient temperature is below ambient temperature.
Cleaning and disinfection
Do not use benzene, thinner, gasoline or other strong solvents to clean the thermometer.
Do not attempt to disinfect the sensing section (tip) of the thermometer by immersing in alcohol or in hot water (water
over 122°F / 50°C).
Do not use ultrasonic washing to clean the thermometer.
Wipe the thermometer with a soft clean cloth. For stubborn stains, wipe the thermometer with a cloth that has
been dampened with water or a neutral detergent and wipe thoroughly. Finish by wiping with a soft dry cloth.
For disinfection, 75% Ethanol or Isopropyl alcohol can be used.
Observe the following to prevent damage to the thermometer.
Change mode: The thermometer defaults to rectal (“rct”) mode.
To change from current setting:
1. Turn it on and wait for the screen to light up.
2. Hold the button for 3 seconds when the mode (“rct,” “orl,” “udr”) flashes.
3. Press the button once to scroll to next mode. Once on
preferred mode, wait 3 seconds for the thermometer to
register the selected mode OR press the button for 3
seconds to confirm selection and proceed with the reading.
In order to achieve the most accurate results, always use the thermometer in the mode that corresponds with the
method you will use: Rectal (“rct”), Oral (“orl”), or Underarm (“udr”).
“rct”– Rectal
“orl”– Oral
“udr”– Underarm
Change unit: To change from Fahrenheit (°F) to Celsius
(°C), turn it on, when the last temp reading flashes, hold
the button for 3 seconds. Press button once to scroll to
next mode. Once on preferred mode, press button for 3
seconds to confirm selection.
>
Method
Rectal
Oral
Underarm
**Normal Temperature
97.3°F – 100.4°F
97.0°F – 99.6°F
95.4°F – 98.6°F
**Fever Range
100.4°F +
99.6°F +
98.6°F +
Table of contents
