Friedrich CP Line CP05 User manual

ENGLISH
Room Air Conditioner
Installation and Operation
Manual
Registering Your Room Air Conditioner
Model information can be found on the name plate located on the
side of the unit near the control panel. Please complete and mail
the owner registration card furnished with this product or register
on-line at www.friedrich.com (USA only). For your future
convenience, record the model information here.
MODEL NUMBER SERIAL NUMBER PURCHASE DATE
920-152-00 (12/04)
CP05
115 Volts CP Line
FRANÇAIS ESPAÑOL

Congratulations! Thank you for choosing
Friedrich.
Your Friedrich unit is designed for
maximum comfort and quietness.
Table of Contents
Introduction ..................................................................................3
Safety Precautions.......................................................................4
How to operate your Friedrich ...................................................6
Features and Installation.............................................................8
Installation Instructions...............................................................9
Troubleshooting Tips.................................................................13
Warranty......................................................................................14

3
ENGLISH
Before Operating Your Unit
Make sure the wiring is adequate for your unit.
If you have fuses, they should be of the time delay type. Before you install or relocate this unit, be sure that
the amperage rating of the circuit breaker or time delay fuse does not exceed the amp rating listed in figure 1.
DO NOT use an extension cord.
The cord provided will carry the proper amount of electrical power to the unit; an extension cord will not.
Make sure that the receptacle is compatible with the wall plug provided.
This insures proper grounding. If you have a two-prong receptacle you will need to have the circuit replaced
by a certified electrician with a grounded circuit that meets all national and local codes and ordinances. You
must use the three-prong plug furnished with the air conditioner.
Figure 1
For the Best Cooling Performance and Energy Efficiency
Keep the filter clean
Make sure that your air conditioner is always in top performing condition by cleaning the filter regularly.
Instructions for removing and cleaning the filter can be found on page 6.
Provide good airflow
Make sure that the airflow into and out of the unit is unobstructed. (both indoors and outdoors)
Maximum airflow is critical for peak performance. Your air conditioner blows air out of the top of the unit
and takes in air at the bottom of the unit.
Unit Placement
If your air conditioner can be placed in a window or a wall that is shaded by a tree or another building, the
unit will operate even more efficiently. Using drapes or blinds on the sunny side of the dwelling will also
add to your unit's efficiency.
Insulation
Good insulation will be a big help in maintaining desirable comfort levels. Doors should have weather
stripping. Be sure to caulk around doors and windows.
Introduction
MODEL
CP05
.
AMP VOLT NEMA NO.
15 125 5-15P
CIRCUIT
RATING OR
TIME DELAY
FUSE PLUG FACE

4
WARNING
Safety Precautions
To prevent injury and property damage, follow these instructions.
■Incorrect operation due to ignoring instructions can cause harm or damage. The seriousness is classified
by the following indications.
WARNING This symbol indicates the possibility of death or serious injury.
CAUTION This symbol indicates the possibility of injury or damage to
properties only.
■Meanings of symbols used in this manual are as shown below.
Never Do This
Always Do This
Plug in the power plug
properly.
• Otherwise, it will cause electric
shock or fire due to heat
generation.
Do not operate or stop the
unit by inserting or pulling
out the power plug.
• It will cause electric shock or fire
due to heat generation.
Do not damage or use an
unspecified power cord.
• It will cause electric shock or fire.
• If the power cord is damaged, it must
be replaced by the manufacturer or a
Friedrich-certified service agent.
Do not modify power cord
length.
• It will cause electric shock or fire
due to heat generation.
Do not operate with wet
hands or in damp
environment.
• It will cause electric shock.
Do not direct air flow directly
at room occupants.
• This could lead to health problems .

5
ENGLISH
Sharp
edges
When the air filter is to be
removed, do not touch the
metal parts of the unit.
•They are sharp and may cause
an injury.
Do not clean the air
conditioner with water.
•Water may enter the unit and
degrade the insulation. It may
cause an electric shock.
When the unit is to be
cleaned, switch the unit off,
and unplug it.
•Since the fan rotates at high
speed during operation, it may
cause an injury.
Do not operate the unit
without the air filter or when
the front intake grille has
been removed.
•It could cause dust to
accumulate on the heat
exchanger.
Do not put a pet or house
plant where it will be
exposed to direct air flow.
•This could injure the pets
or plants.
Do not use for special
purposes.
•Do not use this air conditioner to
preserve precision devices, food,
pets, plants, and art objects.
It may cause deterioration of
quality, etc.
Do not apply an insecticide
or flammable spray.
•It may cause a fire or
deformation of the cabinet.
SHARP EDGES!
The edges of the cabinet can
be SHARP!
•Use caution when handling the
case. Grip it firmly and do not allow
it to slip while holding it.
• Use heavy gloves to handle
the cabinet if necessary.
• DO NOT
allow the
cabinet to slide
against
your skin!

6
ON/OFF TIMER
OPERATION MODE SELECTOR
POWER
TEMPERATURE SETTING
•These buttons control the temperature
of the room. The temperature can be set within a range of
60°F to 86°F, in increments of 1°F.
FAN SPEED
•Everytime you push this button it will rotate between the
following fan speeds:
High (F3) Low(F1) Medium (F2) High (F3)
MONEY SAVER
1
2
3
4
65
1
2
3
4
5
6
The fan stops when the compressor stops cooling.
•Approximately every 3 minutes the fan will turn on and sample
the room air to determine if more cooling is needed.
ON-If unit is off, use Timer to set number of hours before unit starts.
• Push Timer button to advance setting from 1hr - 2hrs - .....12 hrs
maximum.
OFF - You will usually use shut-off time while you sleep.
• If unit is running, use Timer to set number of hours until shut-off.
• For your sleeping comfort, once Time is set, the temperature
setting will rise 2
° F after 30 min, and once again after another
30min.
• Push Timer button to advance setting from 2 hrs....12 hrs
maximum.
•To turn the unit ON, push the button. To turn the unit OFF, push
the button again.
•This button takes priority over all other buttons.
•When you first turn it on, the unit is on the High Cool mode and
the temperature is set at 72°F.
Power
Temp
Fan Speed
Timer Mode
Money
Saver
5
1
6
34
2
•Everytime you push this button, it will rotate between the COOL,
FAN and DRY modes.
How to operate your Friedrich
The controls will look like the following.
Control and Remote Control Operations
1. Remove the cover from the back of the remote
control.
2. Insert two batteries.
•Be sure that the (+) and (-) directions are correct.
•Be sure that both batteries are new.
3. Re-attach the cover.
•Do not use rechargeable
batteries. Such batteries
differ from standard dry
cells in shape, dimensions,
and performance.
•Remove the batteries from
the remote control if the air
conditioner is not going to
be used for an extended
length of time.
How to Insert Batteries

7
ENGLISH
TURN THE AIR CONDITIONER OFF AND REMOVE THE PLUG FROM THE POWER OUTLET.
• TO CLEAN FILTER
The air filter will become dirty as it removes
dust from the inside air.
It should be washed at least every 2 weeks.
If the air filter remains full of dust, the air
flow will decrease and the cooling capacity
will be reduced, possibly damaging the unit.
1. Pull the inlet grille forward and pull out the
air filter. (Fig. 1)
2. Wash the air filter in warm water.
Be sure to completely dry the filter before
placing it back into the unit.
• CLEANING THE AIR CONDITIONER
The front grille and inlet grille may be wiped with a
cloth dampened in a mild detergent and lukewarm
water solution. (Fig. 2)
The cabinet may be washed with mild soap or
detergent and lukewarm water.
To ensure continued peak efficiency, the outdoor
coil (condensor coil) should be checked
periodically and cleaned if clogged with soot or
dirt from the atmosphere.
Consult a certified Friedrich service agent for more information.
• HOW TO REMOVE THE FRONT GRILLE
1. Pull the inlet grille forward.
2. Remove the screw securing the Front Grille. (Fig. 3)
3. Push the grille up from the bottom and pull the top of the
grille away from the case to lift the top tabs out of their
slots. (Fig. 4)
4. Carefully position the grille, bottom first, and snap back into
place.
5. Reposition the screw that secures the front grille and replace
the knobs.
Do not force open
or open too far
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Control Tabs
Filter
Inlet grill
Additional controls and important information.
Air Direction
• ADJUSTING THE AIR DIRECTION USING THE HORIZONTAL AIR-DEFLECTOR CONTROL
Using the control tabs, the air flow can be directed
to the left, right, straight ahead, or any combination
of these directions.
Care and Maintenance

8
1
8
5
3
2
9
4
10
76
Learning the key components will help you properly install the unit.
Features
1. CABINET
2. HORIZONTAL AIR DEFLECTOR
3. COOL AIR DISCHARGE
4. FRONT GRILLE
5. INLET GRILLE
6. AIR FILTER
7. CONTROL BOARD
8. AIR INTAKE
9. UPPER GUIDE
10. REMOTE CONTROL
Features and Installation

9
ENGLISH
OUTDOORSINDOORS
INNER
SILL
OUTER
SILL
INNER
SILL
WOOD STRIP MOUNTED
ON TOP OF INNER SILL
WOOD STRIP
FOR
L BRACKET
LBRACKET
3/4"
CLEARANCE
1" MAX.
STORM
WINDOW
FRAME
OUTDOORSINDOORS
OUTER
SILL
TYPE B: 5EA
(WOOD SCREW)
HARDWARE
TYPE A: 11EA
(SHORT SCREW) TYPE C: 3EA ( L BRACKET)
TYPE E: 1EA
(SASH SEAL)
(Not adhesive backed)
TYPE D: 1EA
(SEAL STRIP)
(Adhesive backed)
TYPE F: 2EA
(GUIDE PANEL) TYPE G: 1EA (SUPPORT BRACKET)
10mm
16mm
NOTE: All supporting parts should be firmly secured to wood, or metal.
1. This unit is designed for installation in standard double hung windows with actual opening widths of
22" to 36". The upper and lower sash must open sufficiently to allow a clear vertical opening of 14"
from the bottom of the sash to the window sill.
2.If storm window presents interference, fasten a 2" wide wood strip (OUTER SILL) to the inner
window sill across the full width of the sill. The wood strip should be thick enough to raise the height
of the window sill so that the unit can be installed without interference by the storm window frame.
See Fig. 5-2. Top of wood strip should be approximately 3/4" higher than the storm window frame
(STORM WINDOW FRAME) or wood strip (OUTDOORS) to help condensation to drain properly to
the outside.
3. Install a second wood strip (approximately 6" long by 11/2" wide and same thickness as first strip) in
the center of the outer sill flush against the back off the inner sill. This will raise the Lbracket as
shown Fig. 5-2.
4. If the distance between STORM WINDOW FRAME and WOOD STRIP MOUNTED ON TOP OF
INNER SILL is more than 1", two of wood strip are not necessary.
Window Requirements
Installation
Fig. 5-1 Fig. 5-2
Installation Instructions

10
TYPE A
TYPE A
ROOM SIDE
CENTER LINE
OUTSIDE
INSIDE
L BRACKET
OUTER SILL
SHORT SIDE
INNER SILL
TYPE A
8" 8"
INNER SILL
CENTER LINE
SEAL STRIP
(TYPE D)
CENTER LINE
A. BEFORE INSTALLATION
1. Insert the guide panels into the guides of the air
conditioner. Fasten the curtains to the unit with
screws (TYPE A) as shown Fig. 6.
2. Cut the adhesive-backed seal strip (TYPE D) to
match the window width.
Remove the backing from the seal strip and attach
the seal strip to the underside of the bottom
window. (Fig. 7)
B. BEGIN INSTALLATION
1. LOCATING UNIT IN WINDOW
Open the window and mark center line on the
center of the inner sill, as shown in Fig. 8.
2. ATTACH LBRACKET
a. Install the Lbrackets behind the inner window
sill, with the short side of bracket as shown.
Use the 2 screws (TYPE A) provided.
b. The bracket helps to hold unit securely in place.
Be sure to place bracket edge flush against back
of inner sill. See Fig. 9.
3. INSTALL THE AIR CONDITIONER IN THE WINDOW
a. Carefully lift the air conditioner and slide it into
the open window. Make sure the bottom guide of
the air conditioner drops into the notches of the
Lbracket. See Fig. 9.
IMPORTANT :
When the air conditioner drops into the Lbracket, the
air conditioner will be centered in window opening as
shown in Fig. 10.
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
During the following step, hold unit firmly until
window sash is lowered to top channel behind
side panel frames. Personal injury or property
damage may result if unit falls from window.
CAUTION
