Frigidaire FAH096M2T1 User manual

PRODUCT NO. BASE MODEL NO. SERIES VOLTS BTU-COOLING
FAH096M2T1 FAH096M2T Frigidaire 230 10000 BTU
MARKET
Domestic
Publication No.
5995383832
030109
-EN/SERVICE /KC
345
ROOM AIR CONDITIONER
Model No.
FAH096M2T1
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309107703
OWNER’S GUIDE - # 309000823
ENERGY GUIDE - # 309369918
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917

01/03 2
Publication No. FAH096M2T1
5995383832
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 01/03
* = Non-Illustrated Parts
FAH096M2T1 Publication No.
5995383832
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309627504 Cabinet,wrapper
1* 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
2 309636101 Screen,safety ,wire mesh ,cabinet rear
2* 5304408740 Panel,plastic mesh ,cabinet rear
6 309629304 Louver Assy,grey ,Includes 7,8,9
* 3202951 Seal,bottom
7 309324004 Link,vertical louver ,with handle
8 309628004 Louver,horizontal
9 309628104 Louver,vertical
12 309628204 Filter,air ,molded plastic ,grey
17 309629405 Front Assy,18.5 bld cool
20 309307013 Knob,control
29 3015312 Screw,8-18AB x 0.500
43 309631805 Frame,cabinet front ,w/control label
* 5304402119 Seal-tube
* 309369918 Energy Guide,FAH096M2T1

01/03 4
Publication No. FAH096M2T1
5995383832
CONTROLS

# = Fast-moving Parts 5 01/03
* = Non-Illustrated Parts
FAH096M2T1 Publication No.
5995383832
CONTROLS
POS. NO PART NO DESCRIPTION
7 # 309628501 Control Box
8 # 5304408739 Switch,selector ,7 posn,3 speed
9 # 5304408746 Control,temperature ,12 amp
12 309329801 Clip,sensor retainer ,3/8 inch
13 # 5303202395 Capacitor,370 V ,6+25 mfd
14 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,grounding
15 5303303077 Strap,capacitor mtg.
17 # 309343109 Cord-electric power,type C ,18 AWG ,230 V
18 5303007754 Screw,6-32 x 0.188
35 3200761 Spacer,control bulb ,rubber

01/03 6
Publication No. FAH096M2T1
5995383832
AIR HANDLING PARTS

# = Fast-moving Parts 7 01/03
* = Non-Illustrated Parts
FAH096M2T1 Publication No.
5995383832
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 309629102 Fan Blade
2 3202975 Screw,10-16AB x 0.72 ,square drive
3 309628901 Shroud,fan
* 3015312 Screw,8-18AB x 0.500
8 # 309647501 Motor,fan ,3 speed
10 309627401 Bulkhead
10* 309111201 Grommet,wire protector
* 5303015427 Screw,truss head ,8-18AB x 0.47 ,with nibs
11 # 309631701 Blower Wheel
12 5303012110 Clamp,blower wheel mt
13 309628802 Cover,fan ,top
15 309622801 Housing,blower scroll
20 309622901 Plate,scroll cover
25 309335201 Baffle,air
30 309629001 Partition,shroud,galv-steel
35 309335001 Baffle,splash/motor

01/03 8
Publication No. FAH096M2T1
5995383832
COMPRESSOR PARTS

# = Fast-moving Parts 9 01/03
* = Non-Illustrated Parts
FAH096M2T1 Publication No.
5995383832
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 309603115 Compressor
2 5303283877 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
6 5303291330 Gasket,terminal cover
7 5304416126 Cover,elec terminal ,compressor
8 # 5304430631 Overload Protector
9 5303294292 Nut,terminal cover
11 # 309632303 Evaporator
12 # 309632503 Condenser
13 309628705 Tray,evap base
14 309632006 Base,compressor mt. ,with studs
16 # 5303018217 Tube,capillary ,40 inch long ,cut to length
17 # 5300265301 Drier-filter,service kit
19 309112501 Washer,metallic
21 5303293809 Washer,terminal cover

01/03 10
Publication No. FAH096M2T1
5995383832
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 01/03
* = Non-Illustrated Parts
FAH096M2T1 Publication No.
5995383832
POS. NO PART NO DESCRIPTION
1 309628603 Trim,frame ,side
2 309628604 Trim,frame ,top & bottom
4 5304409304 Block,tapered
5 5303301038 Seal,stuffer ,wrapper
6 5304409305 Seal,cond. end brkt ,rear panel
7 5304409306 Seal,condenser ,26.5 x 1.5 x1.5 ,rear panel
8 5304409307 Seal,condenser ,14 x 1.5 x 1.5 ,rear panel/side
9 5304409308 Seal,condenser ,26.5 x 1.5 x.38 ,rear panel,top & bottom
10 5304409309 Seal,condenser ,14 x 1.5 x 0.38 ,rear panel/side
11 5304409310 Block,chassis/cabinet
12 309335101 Divider,cond. in/out ,14 x 14.5 x .12 ,cond in/out
* 309636002 Mounting Kit,complete
* 5304409303 Grounding Kit
* 5304409311 Grille Mtg. Kit
WINDOW MOUNTING PARTS

01/03 12
Publication No. FAH096M2T1
5995383832 WIRING DIAGRAM
