Frigidaire FAH126J2T1 User manual

PRODUCT NO.
BASE MODEL NO.
VOLTS
BTU-COOLING
FAH126J2T1 FAH126J2T 230 12000
P.O. Box 212378
Augusta, GA 30917
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
©2000 White Consolidated Industries, Inc
ROOM AIR CONDITIONER
Model No.
FAH126J2T1
WIRING DIAGRAM # - 309107701
OWNERS GUIDE # - 309000823
Publication No.
000307
-EN/SERVICE /REP
345
5995338505

FAH126J2T1
CABINET FRONT AND WRAPPER
5/00 1

FAH126J2T1
1 309627504 WRAPPER-U BEND 18.5 BLD
2 309636101 SCREEN-SAFETY 18.5 BLD
7 309324004 LINK-VERT LOUVER
8 309628004 LOUVERS-HORIZ
9 309628104 LOUVER-VERT
12 309628204 FILTER-MOLDED AIR
17 309629405 FRONT ASSY 18.5 BLD
20 309307011 KNOB-CONTROL
29 5304410881 SCREW
43 309631805 FNT/CTRL LABEL ASSY
73 309629304 LOUVER ASSY
*5304408740 PANEL-REAR PLASTIC
CABINET FRONT AND WRAPPER
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
5/00 2

FAH126J2T1
CONTROL PARTS
5/00 3

FAH126J2T1
7# 309628501 #BOX-CONTROL
8# 5304408739 SWITCH-7POS GE
9 5304408746 CONTROL-AIR TEMP
12 309329801 #RETAINING CLIP
13# 5303319112 Capacitor,370V, 30+7.5
14 5303285199 Screw,phillips, 8-18,sq. recess
truss head
15 5303303077 Strap-capacitor
17# 309343109 CORD-SRV 230V/18GA TYPE C
18 5303007754 Screw,.138-32
35 3200761 Spacer-control bulb
*309111201 Grommet-wires
CONTROL PARTS
# = Functional Parts
* = Non-illustrated Parts
POS. NO. PART NO. DESCRIPTION
5/00 4

FAH126J2T1
AIR HANDLING PARTS
5/00 5

FAH126J2T1
1# 309629102 BLADE-FAN ASSY
2 3202975 Screw,10-16 x 0.72 sq. drive
3 309628901 SHROUD-CONDENSER
8# 5304409323 MOTOR-FAN 3SP,W/LEADS
10 309627401 BULKHEAD-18.5CHASSIS
11# 309631701 BLOWER WHEEL
12 5303012110 Clamp-blower
13 309628802 TOP-CONDENSER
15 309622801 SCROLL-18.5
20 309622901 SCROLL PLATE
25 309335201 BAFFLE-AIR
30 309629001 PARTITION-SHROUD
35 309335001 BAFFLE-CONDENSATE
AIR HANDLING PARTS
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
5/00 6

FAH126J2T1
COMPRESSOR PARTS
5/00 7

FAH126J2T1
1# 5304408198 COMPR-MATSUSHITA
2 5303283877 Grommet,compressor,(3)
3 5308006948 Nut,compressor,(3)
6 5303002035 Gasket-cover
7 5303211011 Cover-terminal
8# 5304408199 OVERLOAD-MRA 99809-694
9 5303301734 Nut,cover
11# 309632401 EVAP ASSY-2RW/19FPI
12# 309632505 COND ASSY-3RW/15FPI
13 309628703 TRAY-BASE
14 309632003 BASE/STUD ASSY
16# 5308017120 Capillary tube
17 5300265301 Drier-filter
19 5303002664 Washer,compressor
20 5303002036 Spring,overload
21 5303295516 Washer,cover
COMPRESSOR PARTS
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
5/00 8

FAH126J2T1
1 309628603 TRIM FRAME-SIDES
2 309628604 TRIM FRAME-TOP & BOTTOM
3 5304409303 KIT-GROUNDING WIRE
4 5304409304 BLOCK-TAPERED
5 5303301038 SEAL-WRAPPER
6 5304409305 SEAL-COND END BRACKET
7 5304409306 SEAL-COND/REAR PANEL
8 5304409307 SEAL-COND/REAR PNL,SIDES
9 5304409308 SEAL-COND/RR PNL,TOP &BTTM
10 5304409309 SEAL-COND/REAR PNL, SIDES
11 5304409310 BLOCK-CHASSIS/CABINET
12 309335101 DIVIDER-COND IN/OUT
13 5304409311 KIT-GRILLE MOUNTING
15 309636002 KIT-MTG-ALL PARTS ABOVE
# = Functional Parts
* = Non-illustrated Parts
WINDOW MOUNTING PARTS
POS. NO. PART NO. DESCRIPTION
5/00 9

FAH126J2T1
WIRING DIAGRAM
5/00 10
